探地雷达在露头地质研究中的应用——以塔里木盆地奥陶系碳酸盐岩露头为例

张兴阳; 罗平; 顾家裕; 曾校丰; 汪圣国; 林鹏

doi:10.11781/sysydz200402212

探地雷达在露头地质研究中的应用——以塔里木盆地奥陶系碳酸盐岩露头为例

doi: 10.11781/sysydz200402212

1.
中国石油, 勘探开发研究院, 油气储层重点实验室, 北京, 100083
2. 中国地质大学, 北京, 100083

基金项目: 国家"973"项目(G1999043311).

详细信息

作者简介:
张兴阳(1973- ),男(汉族),安徽郎溪人,博士,主要从事沉积储层领域的研究工作.

中图分类号: TE19
计量
- 文章访问数: 691
- HTML全文浏览量: 100
- PDF下载量: 495
- 被引次数: 0
出版历程
- 收稿日期: 2002-08-13
- 修回日期: 2004-01-12
- 刊出日期: 2004-03-25

APPLICATION OF GROUND PENETRATING RADAR IN OUTCROP GEOLOGICAL STUDY——AN EXAMPLE OF THE ORDOVICIAN CARBONATE OUTCROPS IN THE TARIM BASIN

1.
Key Laboratory for Oil and Gas Reservoirs, Research Insititute ploration and Development, CNPC, Beijing 100083, China
2. China University of Geosciences, Beijing 100083, China

摘要

摘要: 探地雷达方法是一种确定浅层地下介质分布的高分辨率电磁探测技术.国外已将该技术应用到露头地质研究的众多领域中,如三维储层建模研究、沉积相研究、高分辨率层序地层学研究、三维裂缝成像、浅层断层识别、岩溶地质研究等.塔里木盆地巴楚达吾孜塔格地区奥陶系碳酸盐岩出露良好,礁滩复合体、火成岩侵入、岩溶地貌等地质现象丰富,使用32～500MHz探地雷达对该区露头进行了试验性研究.结果表明,探地雷达的探测深度最大可达20m,分辨率最大可达到分米级.生物礁、水道充填体、浅层小断层、溶洞等地质现象在探地雷达剖面上均有特征性反映,且与野外露头对比良好.这为碳酸盐岩露头地质研究提供了新的辅助手段.
- 碳酸盐岩 /
- 生物礁 /
- 奥陶系 /
- 塔里木盆地 /
- 露头地质建模 /
- 探地雷达
Abstract: Ground penetrating radar (GPR) is a high-resolution electromagnetic method to inspect the shallow subsurface features.Foreign geologists have used GPR in many fields of outcrop geological studies such as 3D reservoir molding,sedimentary facies analysis,high-resolution sequence stratigraphy,3D fracture imaging,shallow-fault finding,paleokarst study and so on.The Ordovician carbonate outcrops of Bachu Dawuzitage hills in the Tarim Basin are well developed and present abundant geological phenomena including bioherm-beach assemblages,intrusion of igneous rocks,karst features and so on.Ground penetrating radar experimental survey with frequency of 32-500 MHz has been conducted in this area.The results indicated that the penetrating depth can be up to 20 m with the maximum resolution of decimeter.Many geological features,such as reefs,channels in the reef,small-scale faults and karst caves,have typical responses in the high-resolution GPR profiles and can be corresponded well with outcrops.This provides a new associate approach for the outcrop study of carbonate rocks.
- carbonate rock /
- reef /
- Ordovician /
- the Tarim Basin /
- outcrop geological molding /
- ground penetrating radar
