STUDY ON CONCEPTUAL MODEL OF OIL AND WATER DISTRIBUTION IN WELL GROUP TK461 OF ORDOVICIAN RESERVOIR IN TAHE OILFIELD, TARIM BASIN, CHINA
-
摘要: 塔河油田奥陶系致密碳酸盐岩缝洞油藏的储集空间主要为天然裂缝和酸压裂缝沟通大型管道状洞穴构成的复杂系统。塔河油田四区TK461,TK435,TK455和TK432等4口相互连通的油井见水开发过程表明存在多个不同的边底水侵入通道;并不遵循由低到高逐渐见水的常规开发见水规律。实践表明在低部位的TK461井探索性注水使高部位TK432井的含水下降,高部位TK435变成不产水,而高部位不产水的TK455井的油产量明显提高。根据开发过程中的油水关系变化,建立了TK461井组的储层油水分布概念模式,指出了低部位注水可以增加高部位油井产量,同时可能实现对高部位高含水井从原水侵相反方向上补充剩余油体能量来减缓水体侵入,起到压制水锥增加产油量的效果。Abstract: The reservoir space of the Ordovician dense carbonate in Tahe Oilfield,the Tarim Basin,is a complex system,mainly composed of one or several large pipeline-shaped cavities which were communicated by natural and acid-fracturing fractures.The development performance shows that there are a number of different invading pathways of edge or/and bottom water bodies in Well Group TK461,which are different from the common water invading process from lower to higher position gradually.After water injection from Well TK461 in the lower-position,water production in Well TK432 decreased and Well TK435 produces no water but pure oil.The conceptual model of oil and water distribution has been established in Well Group TK461 according to the relationship between water and oil during the development.The model reveals that water injection from a well in the lower position may increase the energy of remaining oil in the wells in the upper position wells-from the reverse direction of the original invading pathway,resulting in water containing drop and control water coning in wells in the upper position.
-
[1] 焦方正,窦之林.塔河油田碳酸盐岩缝洞型油藏开发研究与实践[M].北京:石油工业出版社,2008. [2] 任玉林,李江龙,黄孝特.塔河油田碳酸盐岩油藏开发技术政策研究[J].油气地质与采收率,2004,11(5):57-59. [3] 陈志海,刘常红,杨坚,等.缝洞性碳酸盐岩油气藏开发对策:以塔河油田主体开发区奥陶系油气藏为例[J].石油与天然气地质,2005,26(5):623-629. [4] 李江龙,黄孝特,张丽萍.塔河油田4区奥陶系缝洞型油藏特征及开发对策[J].石油与天然气地质,2005,26(5):630-633. [5] 陈强路,钱一雄,马红强,等.塔里木盆地塔河油田奥陶系碳酸盐岩成岩作用与孔隙演化[J].石油实验地质,2003,25(6):729-734. [6] 张希明.新疆塔河油田下奥陶统碳酸盐岩缝洞型油气藏特征[J].石油勘探与开发,2001,28(5):17-22. [7] 吕海涛,张卫彪.塔里木盆地塔河油田奥陶系油气成藏演化过程研究[J].石油实验地质,2008,30(6):547-551,556. [8] 鲁新便.塔里木盆地塔河油田奥陶系碳酸盐岩油藏开发地质研究中的若干问题[J].石油实验地质,2003,25(5):508-512. [9] 陈志海,马旭杰,黄广涛.缝洞型碳酸盐岩油藏缝洞单元划分方法研究:以塔河油田奥陶系油藏主力开发区为例[J].石油与天然气地质,2007,28(6):847-855. [10] 陆正元,陈立官,王洪辉.四川盆地下二叠统气藏储层模式的再认识[J].石油与天然气地质,1999,20(1):11-14. -
