烃源岩有机碳含量的测井响应特征与定量预测模型——以珠江口盆地文昌组烃源岩为例

徐思煌; 朱义清

doi:10.11781/sysydz201003290

烃源岩有机碳含量的测井响应特征与定量预测模型——以珠江口盆地文昌组烃源岩为例

doi: 10.11781/sysydz201003290

徐思煌¹,
朱义清²

1.
中国地质大学, 构造与油气资源教育部重点实验室, 武汉, 430074
2. 中国地质大学研究生院, 武汉, 430074

基金项目: 国家油气重大专项课题(2008ZX05023-01)

详细信息

作者简介:
徐思煌(1964- ),男,博士,教授,从事石油及天然气地质学研究与教学.E-mail:xusih@cug.edu.cn.

中图分类号: TE122.113
计量
- 文章访问数: 1843
- HTML全文浏览量: 121
- PDF下载量: 1387
- 被引次数: 0
出版历程
- 收稿日期: 2010-02-09
- 修回日期: 2010-04-28
- 刊出日期: 2010-06-28

WELL LOGS RESPONSE AND PREDICTION MODEL OF ORGANIC CARBON CONTENT IN SOURCE ROCKS-A CASE STUDY FROM THE SOURCE ROCK OF WENCHANG FORMATION IN THE PEARL MOUTH BASIN

Xu Sihuang¹,
Zhu Yiqing²

1.
Key Laboratory of Tectonics and Petroleum Resources of Ministry of Education, China University of Geosciences, Wuhan, Hubei 430074, China
2. Graduate School, China University of Geosciences, Wuhan, Hubei 430074, China

摘要

摘要: 利用测井资料评价烃源岩,能够弥补烃源岩取心少、实测样品分布不连续的不足。富含有机质的烃源岩在测井上具有电阻率高、中子孔隙度高、声波时差高、伽马高、密度低等基本特征。测井资料不仅可用来定性识别烃源岩,而且还能定量预测有机碳含量。近半世纪不断探索出的预测模型,可概括为定性识别模型、单参数等效体积模型、双参数交汇图半定量模型、多元回归模型、测井曲线叠合模型(即ΔlogR技术)、模糊数学模型6种类型。珠江口盆地惠州凹陷及番禺4洼文昌组烃源岩实测有机碳含量与同井段电阻率、中子、声波、伽马和密度等测井参数之间的相关程度比较均衡,因此由这5种测井参数构成的五元回归方程代表着最佳定量预测模型。对番禺4洼一口井文昌组进行了全井段有机碳含量预测,经岩性描述、实测有机碳含量检验,认为预测效果良好。
- 烃源岩 /
- 有机碳含量 /
- 测井响应 /
- 预测模型 /
- 惠州凹陷 /
- 珠江口盆地
Abstract: The evaluation of source rocks from well loggings can make up for the insufficiency of source rock core and discontinuity of samples examined.Organic-rich source rocks show relative increase in response to resistivity,neutron,sonic transit time and gamma loggings and decrease in response to density logs.Based on this response relationship,well logging data not only can be used to identify qualitatively source rocks from non-source rocks,but also predict quantificationally organic carbon content in source rocks.The predicting models proposed during past fifty years can be summed up as qualitative identification model,volume model,cross plot model,regression equation model,ΔlogR technique,and fuzzy model.The TOC of Wenchang Formation source rock in Huizhou Depression and Panyu 4 Sag in the Pearl River Mouth Basin shows similar degree of correlation respectively to resistivity,neutron,sonic transit time,gamma and density.So,the five variate regression equation should be the best prediction model for this study area.The organic carbon content of whole Wenchang Formation of one well in Panyu 4 sag predicted by this numerical model,and it shows good results verified by the lithological description and the TOC test of core samples in this well.
- source rocks /
- organic carbon content /
- well logs response /
- predication model /
- Huizhou Depression /
- Pearl River Mouth Basin

HTML全文

参考文献(28)

[1]	PASSEY Q R,CREANEY S.A practical model for organic richness from porosity and resistivity logs[J].AAPG Bulletin,1990,74(12):1777-1794.
[2]	闫建平.蔡进功,赵铭海,等.运用测井信息研究烃源岩进展及其资源评价意义[J].地球物理学进展,2009,24(1):270-279.
[3]	BEERS R F.Radioactivity and organic content of some Paleozoic shales[J].AAPG Bulletin,1945,29(1):1-22.
[4]	SWANSON V E.Oil yield and uranium content of blank shales[M]//USGS Professional Paper 356-A.Reston,Virginia:USGS,1960:1-44.
[5]	FERTL W H,RIEKE H H.Gamma ray spectral evaluation techniques identify fractured shale reservoirs and source rock characteristics[J].Journal of Petroleum Technology,1980,31(11):2053-2062.
[6]	SCHMOKER J W.Determination of organic matter content of Appalachian Devonian shale from Gamma ray logs[J].AAPG Bulletin,1981,65(7):1285-1298.
[7]	谭廷栋.测井识别生油岩方法[J].测井技术,1988,12(6):1-12.
[8]	SCHMOKER J W.Determination of organic content of Appalachian Devonian shales from formation-density logs[J].AAPG Bulletin.1979,63(9):1504-1537.
[9]	SCHMOKER J W,HESTER T C.Organic carbon in Bakken formation,United States Portion of Williston Basin[J].AAPG Bulletin,1983,67(12):2165-2174.
[10]	DELLENBACH J,ESPITALIE J,LEBRETON F F.Source rock logging[C]//Transactions of 8th European SPWLA Symposium.London:[s.n.],1983:paper D.
[11]	AUTRIC A.Resistivity,radioactivity,and sonic transit time logs to evaluate the organic content of low permeability rocks[J].The Log Analyst,1985,26(3):36-45.
[12]	赵彦超.生油岩测井评价的理论和实践:以南阳、泌阳凹陷为例[J].地球科学:中国地质大学学报,1990,15(1):65-74.
[13]	MEYER B L,NEDERLOF M H.Identification of source rocks on wireline logs by density/resistivity and sonic transit time/resistivity crossplots[J].AAPG Bulletin,1984,68(2):121-129.
[14]	HERRON S L.A total organic log for source rock evaluation[J].The Log Analyst,1981,28(6):520-527.
[15]	PATTERSON C D,QUARLES C A,BREYER J A.Possible new well-logging tool using positron Doppler broadening to detect total organic carbon(TOC)in hydrocarbon source rocks[J].Radiation Physics and Chemistry,2003,68:523-526.
[16]	MURRAY G H.Quantitative fracture study:Sanish pool,McKenzie County,North Dakota[J].AAPG Bulletin,1968,52(1):57-65.
[17]	MEISSNER F F.Petroleum geology of the Bakken formation Williston basin,North Dakota and Montana[C]//REHRIG D,ed.The economic geology of the Williston basin:Proceedings of the Montana Geological Society,24th Annual Conference,1978:207-227.
[18]	FERTL W H,CHILINGAR G V.Total organic carbon content determined from wall logs[J].SPE,1988:407-419.
[19]	刘新颖,邓宏文,邸永香,等.海拉尔盆地乌尔逊凹陷南屯组优质烃源岩发育特征[J].石油实验地质,2009,31(1):68-73.
[20]	KAMALI M R,MIRSHADY A A.Total organic carbon content determined from well logs using AlogR and neuro fuzzy techniques[J].Journal of Petroleum Science and Engineering,2004,(45):141-148.
[21]	朱振宇,刘洪,李幼铭.ΔlogR技术在烃源岩识别中的应用与分析[J].地球物理学进展,2003,18(4):647-649.
[22]	HUANG Z,WILLIAMSON M A.Artificial neural network modelling as an aid to source rock characterization[J].Marine and Petroleum Geology,1996,13(2):277-290.
[23]	朱振宇,王贵文,朱广宇.人工神经网络法在烃源岩测井评价中的应用[J].地球物理学进展,2002,17(1):137-140.
[24]	ANDREAS P,AGTERBERG F P.Wavelet analysis of welllogging data from oil source rock,Egret Member,offshore eastern Canada[J].AAPG Bulletin,2000,84(10):1617-1632.
[25]	于水明,施和生,梅廉夫,等.过渡动力学背景下的张扭性断陷:以珠江口盆地惠州凹陷古近纪断陷为例[J].石油实验地质,2009,31(5):485-489.
[26]	施和生,朱俊章,姜正龙,等.珠江口盆地珠-坳陷油气资源再评价[J].中国海上油气,2009,21(1):9-14.
[27]	姜华,王华,李俊良.等.珠江口盆地珠三坳陷断层特征及其对油气成藏的控制作用[J].石油实验地质,2008,30(5):460-466.
[28]	朱俊章,施和生,舒誉,等.珠江口盆地烃源岩有机显微组分特征与生烃潜力分析[J].石油实验地质,2007,29(3):301-306.
