单冷阱热解色谱仪在烃源岩评价中的应用

蒋启贵; 马媛媛; 李欣

doi:10.11781/sysydz201105546

单冷阱热解色谱仪在烃源岩评价中的应用

doi: 10.11781/sysydz201105546

1.
中国石油化工股份有限公司石油勘探开发研究院无锡石油地质研究所, 江苏无锡, 214151
2. 中国石油勘探开发研究院, 北京, 100083

详细信息

作者简介:
蒋启贵(1964- ),男,高级工程师,从事油气地球化学研究.E-mail:qiguij2004@126.com.

中图分类号: TE135.1⁺1
计量
- 文章访问数: 3026
- HTML全文浏览量: 103
- PDF下载量: 894
- 被引次数: 0
出版历程
- 收稿日期: 2011-01-07
- 修回日期: 2011-08-05
- 刊出日期: 2011-10-28

Application of single cold trap pyrolysis chromatography in source rock evaluation

1.
Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214151, China
2. Research Institute of Petroleum Exploration and Development, CNPC, Beijing 100083, China

摘要

摘要: 利用单冷阱热解色谱仪对烃源岩样品进行热解分析,通过电磁切割和冷阱富集的匹配,能实现烃源岩不同演化阶段热解生烃组分色谱分析,气态烃也得到很好分离,从而为烃源岩组分动力学研究提供了技术保障。对不同类型烃源岩的热解分析表明,烃源岩从Ⅰ型到Ⅲ型有机质,甲烷产率快速增加,而轻质油和重质油则逐渐减少,湿气与有机质类型关系不明确,产率变化不大;烃源岩热解产物正烷烃与正烯烃的比值受到热解速率、烃源岩演化阶段及类型的综合影响,不能简单地以烃源岩热解正烷烃与正烯烃的比值来确定有机质类型。建立的烃源岩热解生烃组分动力学分析技术能提供包括C₁(干气)、C₂—C₄(湿气)、C₅—C₁4(轻质油)和C₁₅₊(重质油)的动力学数据,从而为烃源岩定量评价、确定其主成油期、主成气期、油气比和资源量计算提供了重要技术参数。
- 单冷阱 /
- 热解色谱 /
- 烃源岩 /
- 组分动力学
Abstract: By means of single cold trap pyrolysis chromatography,the pyrolysis analyses of source rock samples have been carried out.Combining electromagnetic cutting with cold trap enrichment,the hydrocarbon components of source rock during different mature stages have been analyzed with pyrolysis chromatography,and gaseous hydrocarbon has been separated well,providing technical supports for dynamic studies of source rock components.As to different types of source rock,from type Ⅰto Ⅲ of organic matter,the yielding rate of methane increases rapidly while the yielding rates of light and black oils decrease gradually,and the yielding rate of wet gas does not change obviously no matter which organic types it belongs to.The n-alkanes/n-alkenes ratios of pyrolysis product of source rock are controlled by pyrolysis rate,source rock evolution stage and type,hence the ratio can not be used to judge organic matter type.The dynamic analyses of hydrocarbon pyrolysis component in source rock provide data including C₁(dry gas),C₂-C₄(wet gas),C₅-C₁4(light oil) and C₁₅₊(black oil),offering important parameters for source rock quantitative evaluation,oil and gas major generation stage determination as well as the calculation of oil/gas ratio and total resource.
- single cold trap /
- pyrolysis chromatography /
- source rock /
- component dynamics

HTML全文

参考文献(18)

[1]	Tissot B P,Pelet R,Ungerer P.Thermal history of sedimentary basins,maturation indices,and kinetics of oil and gas generation[J].AAPG Bulletin,1987,71(12):1445-1466.
[2]	Braum R.Oil and gas evolution kinetics for oil shale and petroleum source rock determined from pyrolysis-TQMS data at two heating rates[J].Energy Fuel,1992(6):468-474.
[3]	Pepper A S,Corvit P J.Simple kinetic models of petroleum formation,Part 1:Oil and gas generation from kerogen[J].Marine Petroleum Geology,1995,12(3):291-319.
[4]	Ritter L K,Mvhr M B,Vinge T,et al.Experimental heating and kinetic models of source rocks:Comparison of different methods[J].Organic Geochemistry,1995,23(1):1-9.
[5]	杨国华,吴肇亮,刘庆豪,等.不同类型干酪根热解生烃动力学研究(一)[J].石油大学学报,1990,14(1):72-79.
[6]	沈忠民,陈义才.源岩平均活化能影响因素浅析[J].成都理工学院学报,2002,29(6):600-604.
[7]	卢双舫,刘晓艳,付晓泰,等.未熟—低熟油生成机理的化学动力学研究及其初步应用[J].沉积学报.2001,19(1):130-135.
[8]	蒋启贵,王延斌,秦建中,等.中国南方海相烃源岩生烃动力学研究[J].石油实验地质,2008,30(6):606-610.
[9]	Tang Y,Stauffer M.Multiple cold trap pyrolysis gas chromatography:A new technique for modeling hydroocarbon generation[J].Organic Geochemistry,1994,22(3-5):863-872.
[10]	刘金钟,唐永春.多冷阱热解气相色谱仪对生烃动力学的研究[J].科学通报,1996,41(10):1021-1024.
[11]	高喜龙,肖贤明,刘中云,等.用开放体系的热解方法对烃源岩生烃动力学的研究:以东营凹陷某生油岩为例[J].地球化学,2003,32(5):487-490.
[12]	韩方,李荣,韩敏欣,等.生油岩热解气相色谱分析方法及其地质应用[J].录井技术,1999,10(3):13-21.
[13]	贾蓉芬,邵敏,刘德汉.在线py-gc分析技术在气源岩评价中的应用[J].地球化学,2001,30(6):592-598.
[14]	Ungger P,Pelet R.Extrapolation of the kinetics of oil and gas formation from laboratory experiments to sedimentary basins[J].Nature,1987,327:52-54.
[15]	Ungerer P.State of the art of research in kinetic modeling of oil formation and expulsion[J].Organic Geochemistry,1990,16(1-3):1-25.
[16]	Tang Y,Perry J K,Jenden P D,et al.Mathematical modeling of stable carbon isotope ratios in natural gases[J].Geochem Cosmochim Acta,2000,64(15):2673-2687.
[17]	李术元,郭绍辉,徐红喜,等.烃源岩热解生烃动力学及其应用[J].沉积学报,1997,15(2):138-141.
[18]	王建龙,王振平,颜红霞.用化学动力学法研究滨北地区中浅层源岩生烃规律[J].河北工业大学学报,2004,33(4):107-112.
