弯管含砂流流场与磨损模拟

Simulation of velocity field and erosion of sand-bearing oil flowing in bend pipe

1.
No.3 Tahe Production Plant,SINOPEC Northwest Company,Luntai,Xinjiang 841604,China
2. Engineering Supervision Center,SINOPEC Northwest Company,Luntai,Xinjiang 841604,China
3. Well Completion Test Management Center,SINOPEC Northwest Company,Luntai,Xinjiang 841604,China
4. No.1 Tahe Production Plant,SINOPEC Northwest Company,Luntai,Xinjiang 841604,China

摘要: 含砂流在石油工业中较为常见,是引起设备失效和材料破坏的重要原因之一。引起的这些故障可能导致不可预测的停工和风险,严重影响油井的正常生产。利用FLUENT软件对较易产生磨损的90曘弯管含砂油流流动情形进行了模拟,得到了不同流速下含砂油流在管内的压力场、速度场分布规律,以及管壁处磨损量的分布规律,得出不同速度与冲蚀角对磨损量的影响,此结果可为油品安全输运、流动参数控制及管线磨损防护提供一定的参考依据。
- 含砂油流 /
- 流场 /
- 磨损 /
- 离散相模型 /
- 模拟
Abstract: Sand-bearing oil flow is very common in petroleum industry.It is one of the main reasons forequipment failure and material damage,which may cause unpredictable shutdown and risk,seriously embarrasing normal production.The FLUENT software was used t0 SImUlate Sand-beaYlng O11 flow In900 bend pipes which are more likely to be wore.Characteristics of pressure and velocity fields of sand-bearing oil flows with different velocities as well as abrasion volume at pipe wall were put forward.Therelationship between abrasion volume and velocity,erosion angle was found out,providing referencesfOY Safe tYanSpOYt Of O11,control of flow parameter and prevent of pipe.
- sand-bearing oil flow /
- velocity field /
- abrasion /
- discrete phase model /
- simulation

[1]	Wood R J K,Jones T F,Ganeshalingam J,etal.Compari-son of predicted and experimental erosion estimates in slurry ducts[J].Wear,2004,256(9-10):937-947.
[2]	Forder A,Thew M,Harrision D.A numerical investigationof solid particle erosion experienced within oilfield control valves[J].Wear,1998,216(2):184-193.
[3]	赵学增,刘长运,陈芳.恒流堵塞器冲刷磨损特性的数值模拟[J].哈尔滨工业大学学报,2008,40(5):727-730.
[4]	张涛,陈次昌,李丹.低固相含量液流中磨蚀翼型空化特性研究[J].西南石油大学学报(自然科学版),2009,31(6):152-155.
[5]	陆军平,刘建新,齐宏伟,等.预提升管内部流动的数值计算及磨损分析[J].炼油技术与工程,2009,39(6):29-32.
[6]	孟庆武,韩文静,王宪明,等.油管材料在砂油水液条件下的冲蚀磨损性能[J].石油矿场机械,2008,32(2):52-54.
[7]	陈作炳,李硕,李丽君.用DPM 模型模拟预热器内两相流场研究[J].机械工程与自动化,2007,32(2):51-55.
[8]	付林.油煤浆输送管道弯头部位冲击磨损预测与壁厚监测[D].唐山:河北工业大学,2009.
