海底沉积物中热解成因天然气水合物的形成与分布

林晓英; 曾溅辉

doi:10.11781/sysydz201202178

海底沉积物中热解成因天然气水合物的形成与分布

doi: 10.11781/sysydz201202178

林晓英^1,2,
曾溅辉¹

1.
中国石油大学(北京)地球科学学院, 北京 102249
2. 河南理工大学能源科学与工程学院, 河南焦作 454000

基金项目: 国家863项目(2006AA09A209)资助

详细信息

作者简介:
林晓英(1980- ),女,博士研究生,讲师,从事油气地质学方面的研究工作.E-mail:lxy2002199@126.com.

中图分类号: TE132.2
计量
- 文章访问数: 3170
- HTML全文浏览量: 85
- PDF下载量: 1614
- 被引次数: 0
出版历程
- 收稿日期: 2011-06-03
- 修回日期: 2012-01-17
- 刊出日期: 2012-03-28

Generation and distribution of thermogenic natural gas hydrates in submarine sediments

Lin Xiaoying^1,2,
Zeng Jianhui¹

1.
College of Geosciences, China University of Petroleum, Beijing 102249, China
2. School of Energy Science and Engineering, Henan Polytechnic University, Jiaozuo, Henan 454000, China

摘要

摘要: 利用中国石油大学自制的一维天然气水合物成藏模拟装置,采用常规热解成因气为气源,海底沉积物为多孔介质,进行了水合物形成模拟实验,并采用电阻率法对沉积物中水合物形成与分布进行观测分析.结果表明,沉积物不同部位电阻率的变化不同,沉积物中下部电阻率先增加后趋于稳定,中上部电阻率呈降低-增加(或稳定)-降低-增加-稳定的变化趋势,这种电阻率的变化反映了不同部位的水合物的生成和分布.在中上部水合物诱导成核时,中下部已进入水合物生长阶段,由于温度梯度的影响,水合物生长缓慢,分散状分布;在气体供应充足的条件下,中上部水合物能大量生成,呈块状分布.在上述分析的基础上建立了沉积物中水合物生长与分布模式.
- 天然气水合物 /
- 热解气 /
- 电阻率 /
- 水合物形成 /
- 海底沉积物
Abstract: With an one-dimensional equipment designed by China University of Petroleum,the simulation of natural gas hydrate generation was carried out using conventional thermogenic natural gas as source and submarine sediment as porous medium.Resistivity method was applied to analyze the generation and distribution of natural gas hydrate in sediment.The results showed that resistivity varied between different positions of sediment.In the middle and lower position,resistivity first increased and then became stable.While in the middle and upper position,resistivity changed like zigzag,that was,decreasing,increasing (or stable),decreasing,increasing and stable.The changes of resistivity indicated the generation and distribution of natural gas hydrate in different positions.The natural gas hydrates in the middle and lower positions had come into being while those in the middle and upper positions were still during the induction and nucleation stages.Influenced by temperature gradient,natural gas hydrates generated slowly and scattered.If gas supplied sufficiently,natural gas hydrates might generate massively in the middle and upper positions.Finally,a hydrate generation and distribution model was established based on the above-mentioned analyses.
- natural gas hydrate /
- thermogenic gas /
- resistivity /
- hydrate generation /
- submarine sediment

HTML全文

参考文献(22)

[1]	王力锋,赵克斌,黄欣.南海北部陆坡热流与天然气水合物赋藏研究[J].石油实验地质,2009,31(1):58-62.
[2]	金庆焕,张光宇,杨木桩,等.天然气水合物资源概论[M].北京:科学出版社,2006:32-35.
[3]	Booth J S,Winters W J,Dillon W P.Apparatus Investigates Geological Aspects of Gas Hydrates[J].Oil and Gas Journal,1999,97(40):63-68.
[4]	顾轶东,林维正,张剑,等.沉积物中天然气水合物超声检测技术[J].海洋技术,2005,24(3):49-52.
[5]	孙始财,樊栓狮,梁德青.气体水合物超声结晶实验[J].制冷学报,2004,25(4):10-14.
[6]	Wright J F,Nixon F M,Dallimore S R.A Method for Direct Measurement of Gas Hydrate Amounts Based the Bull Dielectric Properties of Laboratory Test Media//Proceedings of the Fourth International Conference on Gas Hydrates,Yokohama,2002:19-20.
[7]	业渝光,张剑,胡高伟,等.天然气水合物超声和时域反射联合探测技术[J].海洋地质与第四纪地质,2008,28(5):101-107.
[8]	吴青柏,蒲毅彬,蒋观利,等.甲烷水合物生成和分解的X射线断层扫描试验研究[J].冰川冻土,2006,28(1):122-125.
[9]	蒋观利,吴青柏,蒲毅彬,等.利用CT扫描对粗砂土中甲烷水合物形成过程中水分迁移特征的分析[J].冰川冻土,2009,31(1):96-100.
[10]	Gupta A,Sloan E D,Timothy J Jr,et al.Modeling methane hydrate dissociation X-ray CT data using a heat transfer model[C]//Proceedings of 5th International Conference on Gas Hydrate(ICGH),Trondheim,Norway,2005.
[11]	Kawasaki T,Tsuchiya Y,Nakamizu M,et al.Observation of methane hydrate dissociation behavior in methane hydrate bearing sediments by X-ray CT scanner[C]//Proceedings of International Conference on Gas Hydrate,ICGH V.Trondheim,Norway:2005.
[12]	陈建阳,张志杰,于兴河.AVO 技术在水合物研究中的应用及应注意的问题[J].天然气地球科学,2005,16(1):123-126.
[13]	宋永臣,杨明军,刘瑜.天然气水合物生成与分解实验检测技术进展[J].天然气工业,2008,28(8):111-113.
[14]	Lu Hailong,Matsumoto R.Preliminary experimental results of the stable P-T conditions of methane hydrate in a nannofossil-rich claystone column[J].Geochemical Journal,2002,36(1):21-30.
[15]	Wright J F,Dallimore S R,Nixon F M.Influences of grain size and salinity on pressure-temperature thresholds for methane hydrate stability in JAPEX/JNOC/GSC Mallik 2L-38 gas hydrate research-well sediments[J].GSC Bulletin,1999,544:229-240.
[16]	Buffett B A,Zatsepina O Y.Formation of Gas Hydrate from Dissolved Gas in Natural Porous Media[J].Marine Geology,2000,164(1-2):69-77.
[17]	Zatsepina O Y,Buffett B A.Nucleation of CO₂-Hydrate in a Porous Medium [J].Fluid Phase Equilibira,2002,200(2):263-275.
[18]	刘昌岭,业渝光,张剑,等.海洋天然气水合物的模拟实验研究现状[J].岩矿测试,2004,23(3):201-206.
[19]	陈强,刘昌岭,业渝光,等.多孔介质中气体水合物的成核研究[J].石油学报(石油加工),2008,24(3):345-349.
[20]	赵宏伟,刁少波,业渝光,等.多孔介质中水合物阻抗探测技术[J].海洋地质与第四纪地质,2005,25(1):137-142.
[21]	Li Shuxia,Xia Xiran,Xuan Jian,et al.Resistivity in formation an decomposition of natural gas hydrate in porous medium[J].Chinese Journal of Chemical Engineering,2010,18(1):39-42.
[22]	Eric S.Modeling of influence of gas hydrate content on the electrical properties of porous sediments[J].Journal of Geophysical Research,2001,106(B4):6535-6548.
