川西新场须四段致密砂岩储层微观孔喉与可动流体变化特征

肖开华; 冯动军; 李秀鹏

doi:10.11781/sysydz201401077

川西新场须四段致密砂岩储层微观孔喉与可动流体变化特征

doi: 10.11781/sysydz201401077

中国石油化工股份有限公司石油勘探开发研究院, 北京 100083

基金项目: 中国石油化工股份有限公司科技项目“新场须四段致密气藏描述（P12109）”资助。

详细信息

作者简介:
肖开华（1963-），男，硕士，高级工程师，从事油气地质综合研究。E-mail：xiaokh.syky@sinopec.com。

中图分类号: TE132.2
计量
- 文章访问数: 916
- HTML全文浏览量: 111
- PDF下载量: 827
- 被引次数: 0
出版历程
- 收稿日期: 2013-09-25
- 修回日期: 2013-11-26
- 刊出日期: 2014-01-28

Micro pore and throat characteristics and moveable fluid variation of tight sandstone in 4th member of Xujiahe Formation, Xinchang Gas Field, western Sichuan Basin

SINOPEC Exploration and Production Research Institute, Beijing 100083, China

摘要

摘要: 为了评价川西新场须四段致密砂岩储层，应用恒速压汞及核磁共振实验方法对储层微观孔喉与可动流体变化特征进行定量分析。结果表明，须四段致密砂岩储层可动流体参数、喉道特征参数及孔隙参数变化幅度大。微裂隙发育的致密砂岩储层孔隙对可动流体参数的影响较喉道要更大一些，在微观上可动流体参数主要受孔隙控制。孔喉半径比较大、分布范围宽是致密砂岩储层可动流体含量低、可动用程度差的主要原因之一。微裂隙发育的致密砂岩储层具有喉道进汞饱和度较孔隙进汞饱和度高的特点，说明新场须四段致密砂岩储层的储集空间类型主要为孔隙—裂缝型。
- 可动流体参数 /
- 孔喉特征 /
- 核磁共振 /
- 恒速压汞 /
- 致密砂岩储层 /
- 川西
Abstract: In order to evaluate the tight sandstone reservoirs in the 4th member of the Xujiahe Formation in the Xinchang area of the western Sichuan Basin, nuclear magnetic resonance and constant-rate mercury intrusion experiments have been carried out to quantitatively analyze micro pore and throat and moveable fluid variation characteristics. Studies have indicated that the moveable fluid parameters, throat parameters and pore parameters of tight sandstones vary largely. In micro-fractured tight sandstones, pores have an advantage over throats affecting the moveable fluid parameters, and the moveable fluid parameters are mainly controlled by pores. Low moveable fluid content and low producing degree of tight sandstones are mainly caused by the relatively long radius and wide distribution of pores and throats. In micro-fractured tight sandstones, the mercury saturation in throats is higher than that in pores, indicating that the dominant type of reservoir space is pore-fracture type in the 4th member of the Xujiahe Formation, the Xinchang Gas Field.
- moveable fluid parameter /
- pore and throat characteristics /
- nuclear magnetic resonance /
- constant-rate mercury intrusion /
- tight sandstone reservoir /
- western Sichuan Basin

HTML全文

参考文献(17)

[1]	朱永贤, 孙卫, 于锋.应用常规压汞和恒速压汞实验方法研究储层微观孔隙结构:以三塘湖油田牛圈湖区头屯河组为例[J].天然气地球科学, 2008, 19(4):553-556. Zhu Yongxian, Sun Wei, Yu Feng.Application of high pressure Hg injection and rate-controlled Hg penetration experimental technique to studying reservoir microscopic pore structure:taking Toutunhe formation in Niuquanhu area of Santanghu oilfield as an example[J].Natural Gas Geoscience, 2008, 19(4):553-556.
[2]	王金勋, 杨普华, 刘庆杰, 等.应用恒速压汞实验数据计算相对渗透率曲线[J].石油大学学报:自然科学版, 2003, 27(4):66-69. Wang Jinxun, Yang Puhua, Liu Qingjie, et al.Determination of relative permeability curves using data measured with rate-controlled mercury penetration[J].Journal of the University of Petroleum, China, 2003, 27(4):66-69.
[3]	王为民, 赵刚, 谷长春, 等.核磁共振岩屑分析技术的实验及应用研究[J].石油勘探与开发, 2005, 32(1):56-59. Wang Weimin, Zhao Gang, Gu Changchun, et al.Experiment and application of NMR technology on cuttings[J].Petroleum Exploration and Development, 2005, 32(1):56-59.
[4]	李太伟, 郭和坤, 李海波, 等.应用核磁共振技术研究页岩气储层可动流体[J].特种油气藏, 2012, 19(1):107-109. Li Taiwei1, Guo Hekun, Li Haibo, et al. Research on movable fluids in shale gas reservoirs with NMR technology[J].Special Oil & Gas Reservoirs, 2012, 19(1):107-109.
[5]	时宇, 齐亚东, 杨正明, 等.基于恒速压汞法的低渗透储层分形研究[J].油气地质与采收率, 2009, 16(2):88-90. Shi Yu, Qi Yadong, Yang Zhengming, et al.Fractal study of low permeability reservoir based on constant-rate mercury injection[J].Petroleum Geology and Recovery Efficiency, 2009, 16(2):88-90.
[6]	刘德新, 岳湘安, 侯吉瑞.孔隙介质中边界流体动态特性实验研究[J].大庆石油地质与开发, 2008, 27(5):58-61. Liu Dexin, Yue Xiang'an, Hou Jirui.Experimental studies on dynamic characteristics of boundary fluids in porous media[J].Petroleum Geology & Oilfield Development in Daqing, 2008, 27(5):58-61.
[7]	王为民, 郭和坤, 叶朝辉.利用核磁共振可动流体评价低渗透油田开发潜力[J].石油学报, 2001, 22(6):40-44. Wang Weimin, Guo Hekun, Ye Chaohui.The evaluation of development potential in low permeability oilfield by the aid of NMR movable fluid detecting technology[J].Acta Petrolei Sinica, 2001, 22(6):40-44.
[8]	郝明强, 刘先贵, 胡永乐, 等.微裂缝性特低渗透油藏储层特征研究[J].石油学报, 2007, 28(5):93-98. Hao Mingqiang, Liu Xiangui, Hu Yongle, et al.Reservoir characteristics of micro-fractured ultra-low permeability reservoirs[J].Acta Petrolei Sinica, 2007, 28(5):93-98.
[9]	王瑞飞, 陈明强.特低渗透砂岩储层可动流体赋存特征及影响因素[J].石油学报, 2008, 29(4):558-561. Wang Ruifei, Chen Mingqiang.Characteristics and influencing factors of movable fluid in ultra-low permeability sandstone reservoir[J].Acta Petrolei Sinica, 2008, 29(4):558-561.
[10]	李珊, 孙卫, 王力, 等.恒速压汞技术在储层孔隙结构研究中的应用[J].断块油气田, 2013, 20(4):485-487. Li Shan, Sun Wei, Wang Li, et al.Application of constant-rate mercury injection technology in reservoir pore structure study[J].Fault-Block Oil & Gas Field, 2013, 20(4):485-487.
[11]	高永利, 张志国.恒速压汞技术定量评价低渗透砂岩孔喉结构差异性[J].地质科技情报, 2011, 30(4):73-76. Gao Yongli, Zhang Zhiguo.Valuation on Difference of pore throat structure of low permeability sandstone by Constsp mercury penetration technique[J].Geological Science and Technology Information, 2011, 30(4):73-76.
[12]	李卫成, 张艳梅, 王芳, 等.应用恒速压汞技术研究致密油储层微观孔喉特征:以鄂尔多斯盆地上三叠统延长组为例[J].岩性油气藏, 2012, 24(6):60-65. Li Weicheng, Zhang Yanmei, Wang Fang, et al.Application of constant-rate mercury penetration technique to study of pore throat characteristics of tight reservoir:A case study from the Upper Triassic Yanchang Formation in Ordos Basin[J].Lithologic Reservoirs, 2012, 24(6):60-65.
[13]	高辉, 敬晓锋, 张兰.不同孔喉匹配关系下的特低渗透砂岩微观孔喉特征差异[J].石油实验地质, 2013, 35(4):401-406. Gao Hui, Jing Xiaofeng, Zhang Lan.Difference of micro-pore throat characteristics in extra-low permeability sandstone of different pore throat matching relationship.Petroleum Geology & Experiment, 2013, 35(4):401-406.
[14]	高辉, 孙卫, 高静乐, 等.特低渗透砂岩储层微观孔喉与可动流体变化特征[J].大庆石油地质与开发, 2011, 30(2):89-93. Gao Hui, Sun Wei, Gao Jingle, et al.Characteristic of micro-pore throat and movable fluid in Super-Low Permeability Sandstone Reservoir[J].Petroleum Geology & Oilfield Development in Daqing, 2011, 30(2):89-93.
[15]	王瑞飞, 沈平平, 宋子齐, 等.特低渗透砂岩油藏储层微观孔喉特征[J].石油学报, 2009, 30(4):560-563, 569. Wang Ruifei, Shen Pingping, Song Ziqi, et al.Characteristics of micro-pore throat in ultra-low permeability sandstone reservoir[J].Acta Petrolei Sinica, 2009, 30(4):560-563, 569.
[16]	麦发海, 孟万斌, 李敏, 等.孝泉—新场地区须四段砂岩储层微观孔隙结构特征[J].中国西部科技, 2011, 10(33):28-30. Mai Fahai, Meng Wanbin, Li Min, et al.Characteristic of Micro-Pore Structure in sandstone reservoir of fourth member of Xujiahe Formation in Xiaoquan-Xinchang area[J].Science and Technology of West China, 2011, 10(33):28-30.
[17]	王志文, 葛祥, 张筠.新场气田须四下亚段岩屑砂岩储层评价[J].西部探矿工程, 2011, 23(5):59-61. Wang Zhiwen, Ge Xiang, Zhang Jun.Evaluation of rock-fracturement sandstone reservoir in lower sub section of Xujiahe Formation in Xinchang area[J].West-China Exploration Engineering, 2011, 23(5):59-61.
