准噶尔盆地南缘卡因迪克地区油气成藏模式研究

林小云; 覃军; 聂婉; 倪倩

doi:10.11781/sysydz20140304

准噶尔盆地南缘卡因迪克地区油气成藏模式研究

doi: 10.11781/sysydz20140304

林小云^1,2,
覃军^1,2,
聂婉^1,2,
倪倩^1,2

1.
长江大学油气资源与勘探技术教育部重点实验室, 武汉 430100
2. 长江大学地球科学学院, 武汉 430100

基金项目: 国家油气重大专项（2011ZX05003-005）资助。

详细信息

作者简介:
林小云（1965—）,女,博士,教授,从事油气成藏地质与资源评价的科研和教学工作。E-mail: linxy65@126.com。

中图分类号: TE122.3
计量
- 文章访问数: 885
- HTML全文浏览量: 63
- PDF下载量: 686
- 被引次数: 0
出版历程
- 收稿日期: 2013-11-26
- 修回日期: 2014-04-01
- 刊出日期: 2014-05-28

Hydrocarbon accumulation pattern of Kayindike region in southern Junggar Basin

Lin Xiaoyun^1,2,
Qin Jun^1,2,
Nie Wan^1,2,
Ni Qian^1,2

1.
Key Laboratory of Oil and Gas Resources & Exploration Technologies of Ministry of Education, Yangtze University, Wuhan, Hubei 430100, China
2. College of Geosciences, Yangtze University, Wuhan, Hubei 430100, China

摘要

摘要: 以油气藏形成的静态要素为基础、以各要素的动态演化过程为主线，通过生物标志化合物对比、烃源岩热演化、流体包裹体分析以及典型油气藏解剖，厘清了准噶尔盆地南缘卡因迪克地区油气来源、成藏过程，建立油气成藏模式。卡因迪克地区原油可分为3类，分别源自侏罗系煤系地层、古近系湖相泥岩以及二者混源，以侏罗系油源为主。该地区主要接受了2期油气充注，分别距今10~8 Ma和2 Ma左右，第二期充注包含第一期充注所形成古油藏的调整。卡因迪克地区砂层主要受北部物源控制，与南部连通性差，油气在侧向上主要通过区域性不整合运移，断层是沟通深部油源及古油藏调整的关键因素。在断裂和背斜的双重控制下，油气藏类型以断控—挤压型背斜油气藏为主，成藏主控因素为沟通烃源的断层，成藏模式为混源、垂向运移为主、2期成藏、晚期为主。
- 油源对比 /
- 油气运移 /
- 成藏期次 /
- 成藏模式 /
- 卡因迪克地区 /
- 准噶尔盆地
Abstract: Based on the static elements for reservoir formation, taking the dynamic evolution process of the elements as the main line, the comparison of biomarkers and the analyses of source rock thermal evolutions, fluid inclusions and typical reservoirs were made to study the hydrocarbon source and accumulation process in the Ka-yindike region in the southern Junggar Basin. A hydrocarbon accumulation model was established to guide hydrocarbon exploration. Crude oils in the Kayindike region were classified into 3 types, respectively, from the Jura-ssic coal series, the Paleogene lacustrine mudstones and the two mixed, and the Jurassic coal series were more contributive. There were 2 major charging periods, about 10-8 and 2 Ma, respectively, and the ancient reservoirs charged in the 1st period adjusted during the 2nd period. The permeable sand series in the Kayindike region were controlled by the northern source materials, and were poorly connected with the south. Hydrocarbon migrated mainly along regional unconformities, and faults played important roles in communicating deep source rocks and ancient reservoirs. Controlled by faults and anticlines, the reservoirs were mainly fault-controlled and squeeze anticline type. The main controlling factor for hydrocarbon accumulation was the faults communicating source rocks. The hydrocarbon accumulation model was featured by mixed sources, vertical migration and 2 accumulation periods, among which the 2nd period was the major one.
- oil source correlation /
- hydrocarbon migration /
- accumulation period /
- accumulation model /
- Kayindike region /
- Junggar Basin

HTML全文

参考文献(27)

[1]	惠荣耀.对天然气、石油形成特征的一些认识[J].石油勘探与开发,1990(5):8-14. Hui Rongyao.Some characteristics in petroleum and natural gas generation[J].Petroleum Exploration and Development,1990(5):8-14.
[2]	宋岩,戴金星,戴春森,等.我国大中型气田主要成藏模式及其分布规律[J].中国科学:D辑:地球科学,1996,26(6):499-503. Song Yan,Dai Jinxing,Dai Chunsen,et al.Main hydrocarbon accumulation and distribution of large and medium sized gas fields in China[J].Science in China:Series D:Earth sciences,1996,26(6):499-503.
[3]	王屿涛,徐长胜,王静.准噶尔盆地石南油气田成藏史分析[J].石油勘探与开发,1999,26(1):28-31. Wang Yutao,Xu Changsheng,Wang Jing.History of pool formation of Shinan oil-gas field,Junggar basin [J].Petroleum Exploration and Development,1999,26(1):28-31.
[4]	李军生,林春明.反转背斜构造自生自储油藏成藏模式[J].石油学报,2006,27(2):34-37. Li Junsheng,Lin Chunming.Forming pattern of self generating and self preserving reservoirs in reversal anticline structure[J].Acta Petrolei Sinica,2006,27(2):34-37.
[5]	张永刚,马宗晋,王国力,等.中国南方海相油气成藏模式分析[J].地质学报,2007,81(2):236-243. Zhang Yonggang,Ma Zongjin,Wang Guoli,et al.Hydrocarbon reservoir mode of marine sedimentary rock in South China[J].Acta Geologica Sinica,2007,81(2):236-243.
[6]	汤济广,李祺.中国中西部前陆冲断带构造变形与油气成藏模式[J].油气地质与采收率,2008,15(3):1-5. Tang Jiguang,Li Qi.Tectonic deformation and hydrocarbon accumulation model of foreland thrust belts in central and western China[J].Petroleum Geology and Recovery Efficiency,2008,15(3):1-5.
[7]	赵靖舟,李军,曹青,等. 论致密大油气田成藏模式[J].石油与天然气地质,2013,34(5):573-583. Zhao Jingzhou,Li Jun,Cao Qing,et al. Hydrocarbon accumulation patterns of large tight oil and gas fields[J].Oil & Gas Geology,2013,34(5):573-583.
[8]	康德江,姜丽娜,张金友.中国西部叠合盆地油气多期成藏模式及勘探有效性[J].沉积学报,2012,30(1):166-178. Kang Dejiang,Jiang Lina,Zhang Jinyou.The model of the muli-stage of oil-gas formation and exploration effectiveness in superimposed basins in Western China[J].Acta Sedimentologica Sinica,2012,30(1):166-178.
[9]	高渐珍,徐田武,薛国刚,等.东濮凹陷沙一段自生油气藏成藏条件及成藏模式[J].断块油气田,2013,20(4):417-421. Gao Jianzhen, Xu Tianwu,Xue Guogang,et al.Accumulation condition and mode of autogeny hydrocarbon reservoir for the first member of Shahejie Formation in Dongpu Depression[J]. Fault-Block Oil & Gas Field,2013,20(4):417-421.
[10]	赵文智,邹才能,谷志东,等.砂岩透镜体油气成藏机理初探[J].石油勘探与开发,2007,34(3):273-284. Zhao Wenzhi,Zou Caineng,Gu Zhidong,et al.Preliminary discussion on accumulation mechanism of sand lens reservoirs[J].Petroleum Exploration and Development,2007,34(3):273-284.
[11]	李相博,刘显阳,周世新,等.鄂尔多斯盆地延长组下组合油气来源及成藏模式[J].石油勘探与开发,2012,39(2):172-180. Li Xiangbo,Liu Xianyang,Zhou Shixin,et al.Hydrocarbon origin and reservoir forming model of the Lower Yanchang Formation,Ordos basin[J].Petroleum Exploration and Development,2012,39(2):172-180.
[12]	吴冲龙,林忠民,毛小平,等."油气成藏模式"的概念、研究现状和发展趋势[J].石油与天然气地质,2009,30(6):673-683. Wu Chonglong,Lin Zhongmin,Mao Xiaoping,et al.Concept,research status and trend of "hrdrocarbon pooling patterns"[J].Oil & Gas Geology,2009,30(6):673-683.
[13]	陈书平,漆家福,于福生,等.准噶尔盆地南缘构造变形特征及其主控因素[J].地质学报,2007,81(2):151-157. Chen Shuping,Qi Jiafu,Yu Fusheng,et al.Deformation characteristics in the southern margin of the Junggar basin and their controlling factors[J].Acta Geologica Sinica,2007,81(2):151-157.
[14]	况军,齐雪峰.准噶尔前陆盆地构造特征与油气勘探方向[J].新疆石油地质,2006,27(1):5-9. Kuang Jun,Qi Xuefeng.The structural characteristics and oil-gas explorative direction in Junggar foreland basin[J].Xinjiang Petroleum Geology,2006,27(1):5-9.
[15]	郭春清,沈忠民,张林晔,等.准噶尔盆地南缘烃源岩生源特征及原油分类[J].成都理工大学学报:自然科学版,2005,32(3):257-262. Guo Chunqing,Shen Zhongmin,Zhang Linye,et al.Biogenic origin characteristics of hydrocarbon source rocks and classification of oils in the south part of Juggar basin,China[J].Journal of Chengdu University of Technology:Science & Technology Edition,2005,32(3):257-262.
[16]	张卫海,查明,曲江秀.油气输导体系的类型及配置关系[J].新疆石油地质,2003,24(2):118-120. Zhang Weihai,Zha Ming,Qu Jiangxiu.The type and configuration of petroleum transportation system[J].Xinjiang Petroleum Geology,2003,24(2):118-120.
[17]	何登发.不整合面的结构与油气聚集[J].石油勘探与开发,2007,34(2):142-201. He Dengfa.Structure of unconformity and its control on hydrocarbon accumulation[J].Petroleum Exploration and Development,2007,34(2):142-201.
[18]	刘玉祥,张金功,王永诗,等.断层输导封闭性能及其油气运移机理研究现状[J].兰州大学学报:自然科学版,2008,44(S1):54-57. Liu Yuxiang,Zhang Jingong,Wang Yongshi,et al.Analysis hydrocarbon migration mechanism and the status of the fault conduit and fault close[J].Journal of Lanzhou University:Natural Sciences,2008,44( S1):54-57.
[19]	李明义,岳湘安,江青春,等.海拉尔—塔木察格盆地中部断陷输导体系类型及其控藏作用[J].石油与天然气地质,2012,33(3):407-416. Li Mingyi,Yue Xiang'an,Jiang Qingchun,et al. Migration system types and their control on hydrocarbon accumulation in central fault depressions of Hailar-Tamtsag Basin[J].Oil & Gas Geology,2012,33(3):407-416.
[20]	李秀鹏,于洁,许晶.准噶尔盆地乌夏断裂带输导体系对油气运聚的控制[J].断块油气田,2012,19(5):559-563. Li Xiupeng,Yu Jie,Xu Jing.Control of pathway systems on hydrocarbon migration and accumulation in Wuerhe-Xiazijie fault belt, Junggar Basin[J].Fault-Block Oil and Gas Field,2012,19(5):559-563.
[21]	任战利,刘丽,崔军平,等.盆地构造热演化史在油气成藏期次研究中的应用[J].石油与天然气地质,2008,29(4):502-506. Ren Zhanli,Liu Li,Cui Junping,et al.Application of tectonic-thermal evolution history to hydrocarbon accumulation timing in sedimentary basins[J].Oil & Gas Geology,2008,29(4):502-506.
[22]	曾治平,王敏芳,倪建华.油气成藏期次研究中有机包裹体方法存在问题的探讨[J].天然气地球科学,2002,13(3/4):55-59. Zeng Zhiping,Wang Minfang,Ni Jianhua.Investigate the presence of organic inclusions problem method study of the hydrocarbon accumulation[J].Natural Gas Geoscience,2002,13(3/4):55-59.
[23]	高勇,牟智全, 王永凯, 等.流体包裹体在油气成藏研究中的应用[J].特种油气藏,2012,19(4):37-41. Gao Yong,Mu Zhiquan,Wang Yongkai,et al.Application of fluid inclusion in hydrocarbon accumulation study[J].Special Oil & Gas Reservoirs,2012,19(4):37-41.
[24]	李建青,夏在连,史海英,等.下扬子黄桥地区龙潭组流体包裹体特征与油气成藏期次[J].石油实验地质,2013,35(2):195-198. Li Jianqing,Xia Zailian,Shi Haiying,et al.Characteristics of fluid inclusions and timing of hydrocarbon accumulation in Longtan reservoirs in Huangqiao region,Lower Yangtze basin[J].Petroleum Geology & Experiment,2013,35(2):195-198.
[25]	时保宏,张艳,张雷,等.鄂尔多斯盆地延长组长7致密储层流体包裹体特征与成藏期次[J].石油实验地质,2012,34(6):599-603. Shi Baohong,Zhang Yan,Zhang Lei,et al.Hydrocarbon accumulation dating by fluid inclusion characteristics in Chang7 tight sandstone reservoirs of Yanchang formation in Ordos basin[J].Petroleum Geology & Experiment,2012,34(6):599-603.
[26]	谭绍泉.准中地区油气成藏关键期的厘定及其石油地质意义[J].断块油气田,2013,20(5):551-555. Tan Shaoquan.Definition of hydrocarbon accumulation key period in central area of Junggar Basin and its petroleum geology significance[J].Fault-Block Oil & Gas Field,2013,20(5):551-555.
[27]	林小云,覃军,陈哲,等.准南四棵树凹陷烃源岩评价及分布研究[J].石油天然气学报,2013,35(11):1-5. Lin Xiaoyun,Qin Jun,Chen Zhe,et al.Research on evaluation and distribution of source rocks in Sikeshu sag of the Southern Junggar basin[J].Journal of Oil and Gas Technology,2013,35(11):1-5.
