二连盆地优质烃源岩发育特征及成藏贡献

王建; 王权; 钟雪梅; 董雄英; 马学峰; 隋丽敏

doi:10.11781/sysydz201505641

二连盆地优质烃源岩发育特征及成藏贡献

doi: 10.11781/sysydz201505641

1.
中国矿业大学地质学博士后流动站, 北京 100083
2. 中国石油华北油田分公司勘探开发研究院, 河北任丘 062552

基金项目: 中国石油天然气股份有限公司科技项目(2013E-050204)和国土资源部油气资源评价及矿业权管理支撑系统建设专项(1A14YQKYQ0102)资助。

详细信息

作者简介:
王建(1972—),男,博士,高级工程师,从事石油地质综合研究。E-mail:yjy_wangj@petrochina.com.cn。

中图分类号: TE122.1⁺1
计量
- 文章访问数: 1068
- HTML全文浏览量: 101
- PDF下载量: 853
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-20
- 修回日期: 2015-08-24
- 刊出日期: 2015-09-28

Characteristics of high-quality hydrocarbon source rocks and their contributions to reservoirs in the Erlian Basin

1.
China University of Mining & Technology, Beijing 100083, China
2. Exploration and Development Research Institute, PetroChina Huabei Oilfield Company, Renqiu, Hebei 062552, China

摘要

摘要: 二连盆地由众多小凹陷组成,物源多、相变快且热演化程度较低,是否发育优质烃源岩决定了油气藏的勘探方向。通过建立残余有机碳含量与氢指数相关关系,以及不同沉积环境下有机碳含量的变化,发现浅湖与较深湖等稳定沉积区优质烃源岩发育,河流与滨浅湖等不稳定沉积区主要发育中—差烃源岩;利用残余有机碳对不同沉积相带烃源岩级别进行划分,稳定沉积区可划分出优质[w(TOC)>2%]、中等[1%<w(TOC)<2%]与差[w(TOC)<1%]烃源岩,不稳定沉积区可划分为中等[w(TOC)>1%]与差[w(TOC)<1%]烃源岩。同时,依据测井计算残余有机碳的方法划分出了各凹陷不同级别烃源岩的厚度及分布。优质烃源岩与油气藏有较好的亲缘关系,且资源贡献率大,占烃源岩总体积20%以上的优质烃源岩资源贡献率超过了70%,其分布区是寻找规模储量的有利区域。
- 油气成藏 /
- 资源预测 /
- 优质烃源岩 /
- 测井评价 /
- 二连盆地
Abstract: The Erlian Basin consists of many sags characterized by multiple provenances, changeable phases and a low degree of thermal evolution.The identification of high-quality source rocks determines the direction of exploration efforts.By building correlations between TOC and HI, and analyzing the changes of organic carbon contents under various sedimentary circumstances, we have shown that stable sedimentary areas such as shallow lakes and relatively deep lakes commonly develop high-quality source rocks, and unstable sedimentary areas like rivers and shallow shore lakes commonly develop poor- or medium-quality source rocks.We can use TOC to classify source rock levels.The source rocks from stable sedimentary areas are divided into high (TOC > 2%), medium (1% < TOC < 2%) and poor (TOC < 1%) quality source rocks.The source rocks from the unstable sedimentary areas are divided into medium (1% < TOC < 2%) and poor (TOC < 1%) quality source rocks.Furthermore, based on TOC values calculated from well logging data, the thickness and distribution of different levels of source rocks can be ascertained.High-quality source rocks have a close relationship with oil and gas reservoirs, and are the main sources of oil to these reservoirs.The source contribution from high quality source rocks is > 70% even though they constitute only 20% of total source rock volume.Consequently, the distribution zones of high-quality source rocks are commonly favorable areas for large scale reserves.
- hydrocarbon reservoir forming /
- resource prediction /
- high-quality source rock /
- logging evaluation /
- Erlian Basin

HTML全文

参考文献(31)

[1]	卢双舫,马延伶,曹瑞成,等.优质烃源岩评价标准及其应用:以海拉尔盆地乌尔逊凹陷为例[J].地球科学——中国地质大学学报,2012,37(3):535-544.Lu Shuangfang,Ma Yanling,Cao Ruicheng,et al.Evaluation criteria of high-quality source rocks and its applications:taking the Wuerxun Sag in Hailaer Basin as an example[J].Earth Science-Journal of China University of Geosciences,2012,37(3):535-544.
[2]	秦建中,申宝剑,陶国亮,等.优质烃源岩成烃生物与生烃能力动态评价[J].石油实验地质,2014,36(4):465-472.Qin Jianzhong,Shen Baojian,Tao Guoliang,et al.Hydrocarbon-for-ming organisms and dynamic evaluation of hydrocarbon generation capacity in excellent source rocks[J].Petroleum Geology & Experiment,2014,36(4):465-472.
[3]	倪春华,周小进,包建平,等.西非里奥穆尼盆地油气成藏条件及勘探方向[J].石油实验地质,2014,36(5):583-588.Ni Chunhua,Zhou Xiaojin,Bao Jianping,et al.Petroleum accumulation conditions and exploration direction of Rio Muni Basin,West Africa[J].Petroleum Geology & Experiment,2014,36(5):583-588.
[4]	侯读杰,张善文,肖建新,等.济阳坳陷优质烃源岩特征与隐蔽油气藏的关系分析[J].地学前缘,2008,15(2):137-146.Hou Dujie,Zhang Shanwen,Xiao Jianxin,et al.The excellent source rocks and accumulation of stratigraphic and lithologic traps in the Jiyang depression,Bohai Bay Basin,China[J].Earth Science Frontiers,2008,15(2):137-146.
[5]	庞雄奇,郭永华,姜福杰,等.渤海海域优质烃源岩及其分布预测[J].石油与天然气地质,2009,30(4):393-398.Pang Xiongqi,Guo Yonghua,Jiang Fujie,et al.High-quality source rocks and their distribution prediction in the Bohai Sea waters[J].Oil & Gas Geology,2009,30(4):393-398.
[6]	王建,马顺平,罗强,等.渤海湾盆地饶阳凹陷烃源岩再认识与资源潜力分析[J].石油学报,2009,30(1):51-56.Wang Jian,Ma Shunping,Luo Qiang,et al.Recognition and resource potential of source rocks in Raoyang sag of Bohai bay basin[J].Acta Petrolei Sinica,2009,30(1):51-56.
[7]	秦建中,申宝剑,腾格尔,等.不同类型优质烃源岩生排油气模式[J].石油实验地质,2013,35(2):179-186.Qin Jianzhong,Shen Baojian,Tenger,et al.Hydrocarbon generation and expulsion pattern of different types of excellent source rocks.Petroleum Geology & Experiment,2013,35(2):179-186.
[8]	李威,文志刚.鄂尔多斯盆地马岭地区延长组长7烃源岩特征与分布[J].断块油气田,2014,21(1):24-27.Li Wei,Wen Zhigang.Characteristics and distribution of Chang 7 source rocks of Yangchang Formation in Maling Area of Ordos Basin[J].Fault-Block Oil & Gas Field,2014,21(1):24-27.
[9]	杨华,张文正,刘显阳,等.优质烃源岩在鄂尔多斯低渗透富油盆地形成中的关键作用[J].地球科学与环境学报,2013,35(4):1-9.Yang Hua,Zhang Wenzheng,Liu Xianyang,et al.Key role of high-quality source rocks on the formation of low-permeability oil-rich reservoirs in Ordos Basin[J].Journal of Earth Sciences and Environment,2013,35(4):1-9.
[10]	张善文.准噶尔盆地哈拉阿拉特山地区风城组烃源岩的发现及石油地质意义[J].石油与天然气地质,2013,34(2):145-152.Zhang Shanwen.Identification and its petroleum geologic significance of the Fengcheng Formation source rocks in Hala'alt area,the northern margin of Junggar Basin[J].Oil & Gas Geology,2013,34(2):145-152.
[11]	刘玉华,张建丽.松南新区重点断陷九佛堂组烃源岩影响因素研究[J].断块油气田,2014,21(5):555-559.Liu Yuhua,Zhang Jianli.Influencing factor of Jiufuotang Formation hydrocarbon source rock for important fault depression in new exploration area of southern Songliao Basin[J].Fault-Block Oil and Gas Field,2014,21(5):555-559.
[12]	冯冲,邹华耀,郭彤楼,等.川东北及邻区上二叠统吴家坪组烃源岩评价[J].地球科学与环境学报,2013,35(4):18-29.Feng Chong,Zou Huayao,Guo Tonglou,et al.Evaluation of source rocks in Upper Permian Wujiaping Formation of northeast Sichuan and its adjacent Area[J].Journal of Earth Sciences and Environment,2013,35(4):18-29.
[13]	梁钰,侯读杰,张金川,等.海底热液活动与富有机质烃源岩发育的关系:以黔西北地区下寒武统牛蹄塘组为例[J].油气地质与采收率,2014,21(4):28-32.Liang Yu,Hou Dujie,Zhang Jinchuan,et al.Hydrothermal acti-vities on the seafloor and evidence of organic-rich source rock from the lower Cambrian Niutitang formation,northwestern Guizhou[J].Petroleum Geology and Recovery Efficiency,2014,21(4):28-32.
[14]	秦建中,腾格尔,付小东,等.海相优质烃源层评价与形成条件研究[J].石油实验地质,2009,31(4):366-378.Qin Jianzhong,Tenger,Fu Xiaodong,et al.Study of forming condition on marine excellent source rocks and its evaluation[J].Petroleum Geology & Experiment,2009,31(4):366-378.
[15]	郑红菊,董月霞,朱光有,等.南堡凹陷优质烃源岩的新发现[J].石油勘探与开发,2007,34(4):385-342.Zheng Hongju,Dong Yuexia,Zhu Guangyou,et al.High-quality source rocks in Nanpu sag[J].Petroleum Exploration & Deve-lopment,2007,34(4):385-342.
[16]	刘新颖,邓宏文,邸永香,等.海拉尔盆地乌尔逊凹陷南屯组优质烃源岩发育特征[J].石油实验地质,2009,31(1):68-73.Liu Xinying,Deng Hongwen,Di Yongxiang,et al.High quality source rocks of Nantun formation in Wuerxun depression,the Hailaer Basin[J].Petroleum Geology & Experiment,2009,31(1):68-73.
[17]	费宝生,祝玉衡,邹伟宏,等.二连裂谷盆地群油气地质[M].北京:石油工业出版社,2001.Fei Baosheng,Zhu Yuheng,Zou Weihong,et al.Petroleum geology of rift group in Erlian Basin[M].Beijing:Petroleum Industry Press,2001.
[18]	张成林,黄志龙,卢学军,等.二连盆地巴音都兰凹陷油气资源空间分布研究[J].断块油气田,2014,21(5):550-554.Zhang Chenglin,Huang Zhilong,Lu Xuejun,et al.Research on spatial distribution of petroleum resources in Bayindulan Sag of Erlian Basin[J].Fault-Block Oil and Gas Field,2014,21(05):550-554.
[19]	杜金虎.二连盆地隐蔽油藏勘探[M].北京:石油工业出版社,2003.Du Jinhu.Exploration of subtle oil reservoir in Erlian Basin[M].Beijing:Petroleum Industry Press,2003.
[20]	刘庆,张林晔,王茹,等.湖相烃源岩原始有机质恢复与生排烃效率定量研究:以东营凹陷古近系沙河街组四段优质烃源岩为例[J].地质论评,2014,60(4):877-883.Liu Qing,Zhang Linye,Wang Ru,et al.Recovery of original organic matter content and quantitatively study of generation and expulsion efficiency for lacustrine hydrocarbon source rocks:a case study of the excellent source rocks of the palaeocene E_2-3s₄,Dongying Sag[J].Geological Review,2014,60(4):877-883.
[21]	秦建中,金聚畅,刘宝泉.海相不同类型烃源岩有机质丰度热演化规律[J].石油与天然气地质,2005,26(2):177-184.Qin Jianzhong,Jin Juchang,Liu Baoquan.Thermal evolution pattern of organic matter abundance in various marine source rocks[J].Oil & Gas Geology,2005,26(2):177-184.
[22]	陈学国.准噶尔盆地石炭系高—过成熟烃源岩有机质丰度恢复研究新进展[J].新疆地质,2013,31(4):324-327.Chen Xueguo.Restoration of organic abundance for high-over mature source rocks of carboniferous in Junggar Basin[J].Xinjiang Geology,2013,31(4):324-327.
[23]	姜福杰,庞雄奇,姜振学,等.海拉尔盆地乌尔逊及贝尔凹陷烃源岩有机质丰度的恢复[J].石油实验地质,2008,30(1):82-93.Jiang Fujie,Pang Xiongqi,Jiang Zhenxue,et al.Restitution of organic abundance of the hydrocarbon source rocks in the Wuerxun and the Beier Sags,the Hailaer Basin[J].Petroleum Geology & Experiment,2008,30(1):82-93.
[24]	Carroll A R,Bohacs K M.Lake-type controls on petroleum source rock potential in nonmarine basins[J].AAPG Bulletin,2001,85(6):1033-1053.
[25]	Derenne S,Largeau C,Brukner-Wein A,et al.Origin of variations in organic matter abundance and composition in a litholo-gically homogeneous maar-type oil shale deposit[J].Organic Geochemistry,2000,31(9):787-798.
[26]	朱光有,金强.烃源岩的非均质性及其研究:以东营凹陷牛38井为例[J].石油学报,2002,23(5):34-39.Zhu Guangyou,Jin Qiang.Study on source rock heterogeneity:a case of Niu-38 Well in Dongying depression[J].Acta Petrolei Sinica,2002,23(5):34-39.
[27]	Passey Q R,Creaney S,Kulla J B,et al.A practical model for organic richness from porosity and resistivity logs[J].AAPG Bulletin,1990,74(12):1777-1794.
[28]	金涛,高日胜,高彩霞,等.从烃源岩测井评价结果看冀中坳陷饶阳凹陷勘探前景[J].天然气地球科学,2010,21(3):406-412.Jin Tao,Gao Risheng,Gao Caixia,et al.Suggestion of exploration prospect in Raoyang sag of Jizhong Depression from the logging evaluation results of source rock[J].Natural Gas Geoscience,2010,21(3):406-412.
[29]	周建林.近海陆架盆地优质烃源岩的测井评价展望[J].海相油气地质,2009,14(2):52-59.Zhou Jianlin.Prospect of logging evaluation of excellent hydrocarbon source rocks in Offshore Shelf Basins in China[J].Marine Origin Petroleum Geology,2009,14(2):52-59.
[30]	朱光有,金强,张林晔.用测井信息获取烃源岩的地球化学参数研究[J].测井技术,2003,27(2):104-109.Zhu Guangyou,Jin Qiang,Zhang Linye.Using log information to analyse the geochemical characteristics of source rocks in Jiyang Depression[J].Well Logging Technology,2003,27(2):104-109.
[31]	张志伟,张龙海.测井评价烃源岩的方法及其应用效果[J].石油勘探与开发,2000,27(3):84-87.Zhang Zhiwei,Zhang Longhai.A method of source rock evaluation by well-logging and its application result[J].Petroleum Exploration & Development,2000,27(3):84-87.
