岩性差异变化对断层带结构影响的物理模拟

单亦先; 劳海港; 王永诗; 陈建平

doi:10.11781/sysydz201601108

岩性差异变化对断层带结构影响的物理模拟

doi: 10.11781/sysydz201601108

1.
中国石油大学(华东)信息与控制工程学院, 山东东营 257061
2. 华北理工大学矿业工程学院, 河北唐山 063009
3. 中国石化胜利油田分公司勘探开发研究院, 山东东营 257015
4. 中国石化胜利油田分公司, 山东东营 257015

基金项目: 国家重大科技专项"渤海湾盆地精细勘探关键技术"(2011ZX05006,2016ZX05006)资助。

详细信息

作者简介:
单亦先(1965-),男,硕士,教授,从事油气田生产过程的智能监控技术、石油专用试验设备研制与石油装备检测技术与故障诊断研究。E-mail:18605460902@163.com。

中图分类号: TE122.3⁺4
计量
- 文章访问数: 1318
- HTML全文浏览量: 104
- PDF下载量: 1370
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-27
- 修回日期: 2015-12-18
- 刊出日期: 2016-01-28

Physical simulation of the influence of lithological differences on fault zone structure

1.
College of Information and Control Engineering, China University of Petroleum, Qingdao, Shandong 266580, China
2. College of Mining Engineering, North China University of Science and Technology, Tangshan, Hebei 063009, China
3. Exploration and Development Research Institute, SINOPEC Shengli Oilfield Company, Dongying, Shandong 257015, China
4. SINOPEC Shengli Oilfield Company, Dongying, Shandong 257015, China

摘要

摘要: 采用分解和统计相结合的实验原则,逐步考察了影响断层带结构变化的地层因素。通过对砂、泥岩力学性质及含量进行变换,模拟砂、泥岩地层中可能形成的断层带结构。实验结果表明:泥岩泊松比、泥岩含量是影响断层带结构及其内部单元规模的2个重要因素。单一的砂岩泊松比并不直接影响断层带结构类型,其原因可能是因为实验中的砂岩主要表现为脆性变形的结果;但砂岩含量是影响断层带结构类型的重要因素。在泥岩含量一定的情况下,砂岩泊松比的变化影响断层带的宽度,且两者比值在1~1.33之间时断层带发育二元结构;砂岩泊松比低于0.28、泥岩泊松比低于0.34时,断层带形成疏松的一元型结构;当砂岩泊松比高于0.35、泥岩泊松比高于0.38时,断层带为紧闭的一元型滑动面。
- 泥岩泊松比 /
- 砂岩泊松比 /
- 泥岩含量 /
- 断层带结构 /
- 模拟实验
Abstract: The controlling stratigraphic elements for fault zone structure were studied. Possible fault zone structures in sand and mudstone formations were simulated in view of sand and mudstone mechanical properties and contents. The Poisson's ratio and content of mudstone controlled fault zone structure and its internal unit size. The Poisson's ratio of sand did not directly determine fault zone structure, which might be explained by the brittle deformation of sand in the experiment. On the contrary, sand content was a key element for fault zone structure. When mudstone content was fixed, the Poisson's ratio of sand controlled the width of the fault zone. When the ratio of mud to sandstone Poisson's ratio was 1-1.33, dualistic structure developed in the fault zone. When the Poisson's ratios of sand and mudstones were less than 0.28 and 0.34, respectively, a unitary fault zone with loose structure formed. When the Poisson's ratios of sand and mudstones were more than 0.35 and 0.38, respectively, a closed unitary sliding surface developed.
- Poisson's ratio of mud stone /
- Poisson's ratio of sand stone /
- mud stone content /
- fault zone structure /
- simulation experiment

HTML全文

参考文献(13)

[1]	Fossen H.Structural geology[M].New York:Cambridge University Press,2010,119-185.
[2]	Caine J S,Evans J P,Forster C B.Fault zone architecture and permeability structure[J].Geology,1996,24(11):1025-1028.
[3]	Gibson R G.Physical character and fluid-flow properties of sandstone-derived fault zones[M]//Coward M P,Daltaban T S,Johnson H,eds.Structural geology in reservoir characterization,Geological Society Special Publication 127.London:Geological Society,1998:83-97.
[4]	Ben-Zion Y,Sammis C G.Characterization of fault zones[J].Pure and Applied Geophysics,2003,160(3/4):677-715.
[5]	Wu Zhiping,Chen Wei,Xue Yan,et al.Structural characteristics of faulting zone and its ability in transporting and sealing oil and gas[J].Acta Geological Sinica,2010,84(4):570-578.
[6]	Sibson R H.Fault rocks and fault mechanisms[J].Journal of the Geological Society of London,1977,133:191-213.
[7]	Lindsay N C,Murphy F C.Outcrop studies of shale smear on fault surface[J].International Association of Sedimentologists Special Publication,1993,15:113-123.
[8]	Kim Y S,Peacock D C P,Sanderson D J.Fault damage zones[J].Journal of Structural Geology,2004,26(3):503-517.
[9]	Gray M B,Stamatakos J A,Ferrill D A,et al.Fault-zone deformation in welded tuffs at Yucca Mountain,Nevada,USA[J].Journal of Structural Geology,2005,27(10):1873-1891.
[10]	Micarelli L,Benedicto A,Wibberley C A J.Structural evolution and permeability of normal fault zones in highly porous carbonate rocks[J].Journal of Structural Geology,2006,28(7):1214-1227.
[11]	Clausen J A,Gabrielsen R H.Parameters that control the deve-lopment of clay smear at low stress states:an experimental study using ring-shear apparatus[J].Journal of Structural Geology,2002,24(10):1569-1586.
[12]	Sperrevik S,Færseth R B,Gabrielsen R H.Experiments on clay smear formation along faults[J].Petroleum Geoscience,2000,6(2):113-123.
[13]	王学军,单亦先,劳海港,等.构造变形与烃类充注一体化物理模拟的难点及解决策略[J].石油实验地质,2013,35(4):453-456. Wang Xuejun,Shan Yixian,Lao Haigang,et al.Difficulties and solving strategies for integrated physical simulation of tectonic deformation and hydrocarbon charging[J].Petroleum Geology & Experiment,2013,35(4):453-456.
