四川盆地及周缘下寒武统页岩气成藏主控因素与勘探方向

燕继红; 李启桂; 朱祥

doi:10.11781/sysydz201604445

四川盆地及周缘下寒武统页岩气成藏主控因素与勘探方向

doi: 10.11781/sysydz201604445

中国石化勘探分公司, 成都 610041

基金项目: 中国石化科技部项目（P13129）和中国石化油田部重大导向项目资助。

详细信息

作者简介:
燕继红(1969—),男,高级工程师,从事页岩气勘探地质研究。E-mail:Yanjh.ktnf@sinopec.com。

中图分类号: TE132.2
计量
- 文章访问数: 1812
- HTML全文浏览量: 119
- PDF下载量: 1394
- 被引次数: 0
出版历程
- 收稿日期: 2016-03-25
- 修回日期: 2016-06-27
- 刊出日期: 2016-07-28

Main factors controlling shale gas accumulation and exploration targets in the Lower Cambrian, Sichuan Basin and its periphery

Exploration Branch of SINOPEC, Chengdu, Sichuan 610041, China

摘要

摘要: 运用最新的页岩气勘探理论及模拟实验结果，对四川盆地及周缘地区下寒武统页岩气成藏基本地质条件及主控因素进行了研究。该区下寒武统暗色泥页岩发育，可划分为"被动陆缘型"和"拉张槽型"2种类型。前者具有品质好、厚度巨大、分布范围广等特点，页岩气成藏物质基础条件优越，但底板条件差，构造变形强烈，页岩气保存条件受到挑战；后者达到了基本烃源岩标准，虽单层厚度薄，但具有纵向发育层段多、顶底板条件良好、构造变形弱等特点。高演化程度影响了暗色泥页岩的含气性，不利于页岩气富集成藏；顶底板条件是页岩气气藏早期形成的前提；构造条件是页岩气藏后期得以保存的关键。勘探有利区为盆内绵阳—乐至—隆昌—长宁地区及周缘城口—巫溪、鄂西宜恩—鹤峰、湘西花垣—张家界、贵州镇远等地区。
- 热成熟度 /
- 保存条件 /
- 主控因素 /
- 页岩气 /
- 下寒武统 /
- 四川盆地及周缘
Abstract: We studied the basic geological conditions and main controlling factors for shale gas accumulations in the Sichuan Basin and its periphery based on the latest theories for shale gas exploration and modeling results. Dark shale deposited in the Lower Cambrian can be defined as passive continental shale and tensional trough shale. The passive continental shale has good quality, great thickness and wide distribution. It has favorable basic conditions for shale accumulation, but the bottom plates are unfavorable and the structural deformation is extensive, thus the preservation conditions for shale gas are unfavorable. Tensional trough shale has reached the standard of basic hydrocarbon rocks, though the thickness of single shale interval is limited. It developed many vertical layers with good top and bottom plates and weak structural deformation. High thermal evolution degree restricted the gas-bearing capacity of dark shale, which was unfavorable for shale gas enrichment. Top and bottom seals are necessary when shale gas reservoirs were formed during the early stage. Tectonic conditions are important for the preservation of shale gas during the late stage. The favorable area for shale gas exploration is Mianyang-Lezhi-Longchang-Changning in the Sichuan Basin, Chengkou-Wuxi in the northeastern Sichuan Basin, Yien-Hefeng in the western Hubei, Huayuan-Zhangjiajie in the western Hunan, and Zhenyuan in Guizhou.
- thermal maturation /
- preserving condition /
- main controlling factor /
- shale gas /
- Lower Cambrian /
- Sichuan Basin and its periphery

HTML全文

参考文献(17)

[1]	程克明,王世谦,董大忠,等.上扬子区下寒武统筇竹寺组页岩气成藏条件[J].天然气工业,2009,29(5):40-44. Cheng Keming,Wang Shiqian,Dong Dazhong,et al.Accumulation conditions of shale gas reservoirs in the Lower Cambrian Qiongzhusi Formation,the upper Yangtze region[J].Natural Gas Industry,2009,29(5):40-44.
[2]	秦建中,陶国亮,腾格尔,等.南方海相优质页岩的成烃生物研究[J].石油实验地质,2010,32(3):262-269. Qin Jianzhong,Tao Guoliang,Tenger,et al.Hydrocarbon-forming organisms in excellent marine source rocks in South China[J].Petroleum Geology & Experiment,2010,32(3):262-269.
[3]	陈波,兰正凯.上扬子地区下寒武统页岩气资源潜力[J].中国石油勘探,2009,14(3):10-14. Chen Bo,Lan Zhengkai.Lower Cambrian shale gas resource potential in upper Yangtze region[J].China Petroleum Exploration,2009,14(3):10-14.
[4]	张金川,边瑞康,荆铁亚,等.页岩气理论研究的基础意义[J].地质通报,2011,30(2/3):318-323. Zhang Jinchuan,Bian Ruikang,Jing Tieya,et al.Fundamental significance of gas shale theoretical research[J].Geological Bulletin of China,2011,30(2/3):318-323.
[5]	聂海宽,张金川,李玉喜.四川盆地及其周缘下寒武统页岩气聚集条件[J].石油学报,2011,32(6):959-967. Nie Haikuan,Zhang Jinchuan,Li Yuxi.Accumulation conditions of the Lower Cambrian shale gas in the Sichuan Basin and its periphery[J].Acta Petrolei Sinica,2011,32(6):959-967.
[6]	孙玮,刘树根,冉波,等.四川盆地及周缘地区牛蹄塘组页岩气概况及前景评价[J].成都理工大学学报(自然科学版),2012,39(2):170-175. Sun Wei,Liu Shugen,Ran Bo,et al.General situation and prospect evaluation of the shale gas in Niutitang Formation of Sichuan Basin and its surrounding areas[J].Journal of Chengdu University of Technology (Science & Technology Edition),2012,39(2):170-175.
[7]	胡明毅,邓庆杰,胡忠贵.上扬子地区下寒武统牛蹄塘组页岩气成藏条件[J].石油与天然气地质,2014,35(2):272-279. Hu Mingyi,Deng Qingjie,Hu Zhonggui.Shale gas accumulation conditions of the Lower Cambrian Niutitang Formation in Upper Yangtze region[J].Oil & Gas Geology,2014,35(2):272-279.
[8]	徐祖新,郭少斌,乔辉,等.页岩气储层孔隙结构分形特征研究[J].非常规油气,2014,1(2):20-25. Xu Zuxin,Guo Shaobin,Qiao Hui,et al.Researches on fractal characteristics of micro pore structure for shale gas[J].Unconventonal Oil & Gas,2014,1(2):20-25.
[9]	余川,程礼军,曾春林,等.渝东北地区下古生界页岩含气性主控因素分析[J].断块油气田,2014,21(3):296-300. Yu Chuan,Cheng Lijun,Zeng Chunlin,et al.Main controlling factor analysis on gas-bearing property of Lower Paleozoic shalein northeastern Chongqing Region[J].Fault-Block Oil and Gas Field,2014,21(3):296-300.
[10]	马超,宁宁,王红岩,等.湘西—黔东地区牛蹄塘组页岩气勘探前景[J].特种油气藏,2014,21(1):38-41. Ma Chao,Ning Ning,Wang Hongyan,et al.Exploration prospect of the Lower Cambrian Niutitang Formation shale gas in Xiangxi-Qiandong area[J].Special Oil & Gas Reservoirs,2014,21(1):38-41.
[11]	熊亮,周维娜.西南分公司探区页岩气整体评价与目标优选.成都:中国石化西南分公司,2016. Xiong Liang,Zhou Weina.Overall assessment and target optimization of shale gas in the exploration area of SINOPEC Southwest Oil & Gas Company.Chengdu:SINOPEC Southwest Oil & Gas Company,2016.
[12]	王道富,王玉满,董大忠, 等.川南下寒武统筇竹寺组页岩储集空间定量表征[J].天然气工业,2013,33(7):1-10. Wang Daofu,Wang Yuman,Dong Dazhong,et al.Quantitative characterization of reservoir space in Lower Cambriam Qiongzhushi shale,southern Sichuan Basin[J].Natural Gas Industry,2013,33(7):1-10.
[13]	朱杰平,何希鹏.华东分公司探区页岩气整体评价与目标优选南京:中国石化华东分公司,2016. Zhu Jieping,He Xipeng.Overall assessment and target optimization of shale gas in the exploration area of SINOPEC East China Company.Nanjing: SINOPEC East China Company,2016.
[14]	汪泽成,姜华,王铜山,等.四川盆地桐湾期古地貌特征及成藏意义[J].石油勘探与开发,2014,41(3):305-312. Wang Zecheng,Jiang Hua,Wang Tongshan,et al.Paleo-geomorpho-logy formed during Tongwan tectonization in Sichuan Basin and its significance for hydrocarbon accumulation[J].Petroleum Exploration and Development,2014,41(3):305-312.
[15]	李伟,刘静江,邓胜徽,等.四川盆地及邻区震旦纪末—寒武纪早期构造运动性质与作用[J].石油学报,2015,36(5):546-556. Li Wei,Liu Jingjiang,Deng Shenghui,et al.The nature and role of Late Sinian-Early Cambrian tectonic movement in Sichuan Basin and its adjacent areas[J].Acta Petrolei Sinica,2015,36(5):546-556.
[16]	Zeng Ping,Guo Tonglou.Enrichment of shale gas in different strata in Sichuan Basin and its periphery:The examples of Cambrian Qiongzhusi Formation and Silurian Longmaxi Formation[J].Energy Exploration & Exploitation,2015,33(3):277-298.
[17]	郭彤楼,张汉荣.四川盆地焦石坝页岩气田形成与富集高产模式[J].石油勘探与开发,2014,41(1):28-36. Guo Tonglou,Zhang Hanrong.Formation and enrichment mode of Jiaoshiba shale gas field,Sichuan Basin[J].Petroleum Exploration and Development,2014,41(1):28-36.
