岩石学方法区分页岩中有机质类型

赵建华; 金之钧; 金振奎; 杜伟; 温馨; 耿一凯

doi:10.11781/sysydz201604514

岩石学方法区分页岩中有机质类型

doi: 10.11781/sysydz201604514

1.
中国石油大学(北京) 地球科学学院, 北京 102249
2. 页岩油气富集机理与有效开发国家重点实验室, 北京 100083
3. 中国石化石油勘探开发研究院, 北京 100083

基金项目: 中国博士后科学基金（2016M591350）资助。

详细信息

作者简介:
赵建华(1985—),男,博士,从事沉积学与非常规油气地质研究。E-mail:zhao_jh2013@163.com。

中图分类号: TE132.2
计量
- 文章访问数: 1367
- HTML全文浏览量: 118
- PDF下载量: 1076
- 被引次数: 0
出版历程
- 收稿日期: 2015-11-03
- 修回日期: 2016-05-12
- 刊出日期: 2016-07-28

Petrographic methods to distinguish organic matter type in shale

1.
College of Geosciences, China University of Petroleum, Beijing 102249, China
2. State Key Laboratory of Shale Oil and Gas Enrichment Mechanisms and Effective Development, Beijing 100083, China
3. SINOPEC Petroleum Exploration & Production Research Institute, Beijing 100083, China

摘要

摘要: 有机质孔在富有机质泥/页岩中广泛发育，被认为是含气页岩孔隙系统中重要的组成部分。有机质孔不仅在干酪根中发育，在固体沥青内部同样发现了大量的有机质孔，不同类型的有机质内部有机孔的形态和发育程度有所差异。根据有机质的成因，可将其分为沉积有机质和迁移有机质。沉积有机质为原始的有机质及其蚀变产物，这些有机质未发生过迁移，与陆源矿物紧密结合；迁移有机质存在于矿物孔隙中，由外地迁移过来的沥青或石油，随着热成熟度的增加，可演变成固体沥青或焦沥青，其周缘通常可见自生矿物。自生石英对页岩孔隙的影响具有双重作用，一方面充填了孔隙空间，减少了页岩孔隙；另一方面自生石英起到了支撑孔隙的作用，抑制了页岩的压实，为迁移有机质的充填保留了一部分孔隙空间。沉积有机质和迁移有机质中均发育孔隙，迁移有机质充填三维空间相互连通的矿物孔隙，内部形成的有机质孔隙在三维空间上的连通性要比沉积有机质强。五峰组—龙马溪组页岩由下至上呈网络状分布的迁移有机质逐渐减少，相互连通的有机质孔隙网络也相应减少，页岩储层质量逐渐变差。
- 有机质孔 /
- 干酪根 /
- 沉积有机质 /
- 迁移有机质 /
- 固体沥青 /
- 孔隙网络
Abstract: Pores within organic matter are widely recognized as a significant component of pore systems in gas shale. These pores form not only in kerogen, but also in solid bitumen, with different morphology and development degree. The source of organic matter can be divided into depositional and migrated organic matter. Depositional organic matter is deposited in direct contact with detrital mineral grains and comprises depositional kerogen and its alteration products. Migrated organic matter occurs in mineral pores initiatially as bitumen or oil that filled the cement-lined pores and cement would separate bitumen or oil from mineral grains and may evolve into solid bitumen and pyrobitumen during maturation. Authigenic quartz has a dual role in influencing shale porosity. On one hand, it reduces shale porosity by filling pore space,while on the other hand,it supports pore preservation by inhibiting shale compaction and preserving pore space for migrated organic matter. There are pores both in depositional organic matter and migrated organic matter. Migrated organic matter is present in three-dimensional connected mineral pores, which produces a pore network with higher reservoir quality than a pore network associated with only depositional organic matter. Migrated organic matter decreases from bottom to top in the Wufeng-Longamxi formations, the connected pore network decreases accordingly, and reservoir quality becomes poorer.
- organic matter pore /
- kerogen /
- depositional organic matter /
- migrated organic matter /
- solid bitumen /
- pore network

HTML全文

参考文献(36)

[1]	Loucks R G,Reed R M,Ruppel S C,et al.Morphology,genesis,and distribution of nanometer scale pores in siliceous mudstones of the Mississippian Barnett shale[J].Journal of Sedimentary Research,2009,79(12):848-861.
[2]	Milliken K L,Esch W L,Reed R M,et al.Grain assemblages and strong diagenetic overprinting in siliceous mudrocks,Barnett shale (Mississippian),Fort Worth Basin,Texas[J].AAPG Bulletin,2012,96(8):1553-1578.
[3]	Curtis M E,Ambrose R J,Sondergeld C H,et al.Transmission and scanning electron microscopy investigation of pore connectivity of gas shales on the nanoscale//Society of Petroleum Engineers North American Unconventional Gas Conference and Exhibition.The Woodlands,Texas:SPE,2011:14-16.
[4]	Slatt R M,O'Brien N R.Pore types in the Barnett and Woodford gas shales:Contribution to understanding gas storage and migration pathways in fine-grained rocks[J].AAPG Bulletin,2011,95(12):2017-2030.
[5]	Ambrose R J,Hartman R C,Diaz-Campos M,et al.New pore-scale considerations for shale gas in place calculations//Society of Petroleum Engineers Unconventional Gas Conference.Pittsburgh,Pennyslvania:SPE,2010:23-25.
[6]	Curtis M E,Sondergeld C H,Ambrose R J,et al.Microstructural investigation of gas shales in two and three dimensions using nanometer-scale resolution imaging[J].AAPG Bulletin,2012,96(4):665-677.
[7]	Loucks R G,Reed R M,Ruppel S C,et al.Preliminary classification of matrix pores in mudrocks[J].GCAGS Transactions, 2010, 60:435-441.
[8]	Nelson P H.Pore-throat sizes in sandstones,tight sandstones,andshales[J].AAPG Bulletin 2009,93(3):329-340.
[9]	Loucks R G,Reed R M,Ruppel S C,et al.Spectrum of pore types and networks in mudrocks and a descriptive classification for matrix-related mudrock pores[J].AAPG Bulletin,2012,96(6):1071-1098.
[10]	Bernard B,Wirth R,Schreiber A,et al.Formation of nanoporous pyrobitumen residues during maturation of the Barnett shale (Fort Worth Basin)[J].International Journal of Coal Geology,2012,103:3-11.
[11]	Loucks R G,Reed R M.Scanning-electron-microscope petrographic evidence for distinguishing organic-matter pores associated with depositional organic matter versus migrated organic matter in mudrocks[J].GCAGS Transactions,2014,64:713.
[12]	Hunt J M.Petroleum geochemistry and geology[M].2nd ed.NewYork:W.H.Freeman and Company,1995:743.
[13]	Abraham H.Asphalts and allied substances[M].6th ed.NewYork:VanNostrand Company,Inc.,1960.
[14]	Jacob H.Nomenclature,classification,characterization,and genesis of natural solid bitumen (migrabitumen)[M]//Parnell J,Kucha H,Landais P.Bitumens in ore deposits.Berlin Heidelberg:Springer-Verlag,1993:11-27.
[15]	Curiale J A.Origin of solid bitumens,with emphasis on biological marker results[J].Organic Geochemistry,1986,10(1/3):559-580.
[16]	Landis C R,Castaño J R.Maturation and bulk chemical properties of a suite of solid hydrocarbons[J].Organic Geochemistry,1995,22(1):137-149.
[17]	Taylor G H,Teichmüller M,Davis A,et al.Organic petrology[M].Berlin,Stuttgart:Gebrüder Borntraeger,1998:704.
[18]	Tissot B P,Welte D H.Petroleum formation and occurrence[M].2nd ed.Berlin Heidelberg:Springer Verlag,1984:699.
[19]	Bernard S,Horsfield B,Schulz H M,et al.Geochemical evolution of organic-rich shales with increasing maturity:ASTXM and TEM study of the Posidonia shale (Lower Toarcian,northern Germany)[J].Marine and Petroleum Geology,2012,31(1):70-89.
[20]	Lewan M D.Effects of thermal maturation on stable organic carbon isotopes as determined by hydrous pyrolysis of Woodford shale[J].Geochimica et Cosmochimica Acta,1983,47(8):1471-1479.
[21]	Mastalerz M,Schimmelmann A,Drobniak A,et al.Porosity of Devonian and Mississippian New Albany shale across a maturation gradient:Insights from organic petrology,gas adsorption,and mercury intrusion[J].AAPG Bulletin,2013,97(10):1621-1643.
[22]	Milliken K L,Rudnicki M,Awwiller D N,et al.Organic matter-hosted pore system,Marcellus Formation (Devonian),Pennsylvania[J].AAPG Bulletin,2013,97(2):177-200.
[23]	Schieber J.SEM observations on ion-milled samples of Devonian Black shales from Indiana and New York:Thepetrographic context of multiple pore types//Camp W K,Diaz E,Wawak B.Electron microscopy of shale hydrocarbon reservoirs.:American Association of Petroleum Geologists,2013:153-171.
[24]	刘树根,马文辛,Luba J,等.四川盆地东部地区下志留统龙马溪组页岩储层特征[J].岩石学报,2011,27(8):2239-2252. Liu Shugen,Ma Wenxin,Luba J,et al.Characteristics of the shale gas reservoir rocks in the Lower Silurian Longmaxi Formation,East Sichuan Basin,China[J].Acta Petrologica Sinica,2011,27(8):2239-2252.
[25]	郭旭升,李宇平,刘若冰,等.四川盆地焦石坝地区龙马溪组页岩微观孔隙结构特征及其控制因素[J].天然气工业,2014,34(6):9-16. Guo Xusheng,Li Yuping,Liu Ruobing,et al.Characteristics and controlling factors of micro-pore structures of Longmaxi shale play in the Jiaoshiba area,Sichuan Basin[J].Natural Gas Industry,2014,34(6):9-16.
[26]	郭彤楼,张汉荣.四川盆地焦石坝页岩气田形成与富集高产模式[J].石油勘探与开发,2014,41(1):28-36. Guo Tonglou,Zhang Hanrong.Formation and enrichment mode of Jiaoshiba shale gas field,Sichuan Basin[J].Petroleum Exploration and Development,2014,41(1):28-36.
[27]	刘若冰.超压对川东南地区五峰组—龙马溪组页岩储层的影响分析[J].沉积学报,2015,33(4):817-827. Liu Ruobing.Analyses of influences on shale reservoirs of Wufeng-Longmaxi Formation by overpressure in the south-eastern part of Sichuan Basin[J].Acta Sedimentologica Sinica,2015,33(4):817-827.
[28]	Thyberg B,Jahren J,Winje T,et al.Quartz cementation in Late Cretaceous mudstones,northern North Sea:Changes in rock properties due to dissolution of smectite and precipitation of micro-quartz crystals[J].Marine and Petroleum Geology,2010,27(8):1752-1764.
[29]	Müller A.Cathodoluminescence and characterization of defect structures in quartz with applications to the study of granitic rocks.Göttingen:Georg-August-Universität Göttingen,2000:1-22.
[30]	Götze J,Plötze M,Habermann D.Origin,spectral characteristics and practical applications of the cathodoluminescence (CL) of quartz:A review[J].Mineralogy and Petrology,2001,71(3/4):225-250.
[31]	Wilkin R T,Barnes H L,Brantley S L.The size distribution of framboidal pyrite in modern sediments:An indicator of redox conditions[J].Geochimica et Cosmochimica Acta,1996,60(20):3897-3912.
[32]	Hawkins S,Rimmer S M.Pyriteframboid size and size distribution in marine black shales:A case study from the Devonian-Mississippian of central Kentucky//North-Central Section (36th) and Southeastern Section (51st),Geological Society of America Joint Annual Meeting.Lexington,Kentucky:Geological Society of America,2002.
[33]	Bond S,Wignall P B,Racki G.Extent and duration of marine anoxia during the Frasnian-Famennian (Late Devonian) mass extinction in Poland,Germany,Austria and France[J].Geolo-gical Magazine,2004,141(2):173-193.
[34]	Goldhaber M B,Kaplan I R.The sulfur cycle//Goldberg E D,ed.The sea.New York:John Wiley & Son,1974:569-655.
[35]	Raiswell R.Pyritetexture,isotopic composition and the availability of iron[J].American Journal of Science,1982,282(8):1244-1263.
[36]	Rickard D.Kinetics of pyrite formation by the H₂S oxidation of iron (Ⅱ) monosulfide in aqueous solutions between 25 and 125 ℃:The rate equation[J].Geochimica et Cosmochimica Acta,1997,61(1):115-134.
