致密砂岩油可动量及其主控因素———以鄂尔多斯盆地三叠系延长组长7为例

崔景伟; 朱如凯; 李士祥; 杨智; 张忠义

doi:10.11781/sysydz201604536

致密砂岩油可动量及其主控因素———以鄂尔多斯盆地三叠系延长组长7为例

doi: 10.11781/sysydz201604536

1.
中国石油勘探开发研究院, 北京 100083
2. 中国石油长庆油田公司勘探开发研究院, 西安 710018

基金项目: 国家重点基础研究发展计划（973计划）项目"中国陆相致密油（页岩油）形成机理与富集规律"（2014CB239000）、国家油气重大专项"岩性地层油气藏成藏规律、关键技术及目标评价项目"（2011ZX05001）资助。

详细信息

作者简介:
崔景伟(1980—),男,工程师,从事成藏地球化学和非常规油气地质研究。E-mail:cuijingwei@petrohcina.com.cn。

中图分类号: TE122
计量
- 文章访问数: 1147
- HTML全文浏览量: 78
- PDF下载量: 720
- 被引次数: 0
出版历程
- 收稿日期: 2015-12-14
- 修回日期: 2016-05-06
- 刊出日期: 2016-07-28

Movable oil and its controlling factors in tight sandstones: A Case study of the Triassic Chang7 reservoir, Yanchang Formation, Ordos Basin

1.
Research Institute of Petroleum Exploration and Development, CNPC, Beijing100083, China
2.Research Institute of Petroleum Exploration and Development, Changqing Oilfield, CNPC, Xi'an, Shaanxi 710018, China

摘要

摘要: 中国致密油地质储量超过100×10⁸ t，但确定可采资源量难度较大。通过改进耗散型石英微天平分析仪（QCM-D）实现地层条件下岩心的单位原油吸附量、利用高压压汞和N₂吸附手段对含油孔隙下限和有效比表面积测试，最后结合密闭取心含油量测试结果，对鄂尔多斯盆地三叠系延长组长7油层组可动油开展评价。结果显示长7致密砂岩表面吸附油厚度15.6 nm，吸附质量13 mg/m²；含油孔径下限为18 nm左右，比表面积平均为1 m²/g；孔隙度6%~10%，游离态原油比例为14.3%~48.6%，结论与核磁共振实验测定结果具有可比性。控制致密砂岩原油可动量的地质因素包括原油密度、黏度、有效孔隙表面积、有效孔隙体积以及储层矿物组成，针对特定区域和层系，可动量主要受孔比表面积控制。
- 吸附态 /
- 游离态 /
- 致密油 /
- 延长组 /
- 鄂尔多斯盆地
Abstract: Tight oil in place in China has been estimated over 10 billion tons, but it is difficult to define [JP]the availably producible reserves. Several efficient ways, including perfecting Quartz Crystal Microbalance with Dissipation (QCM-D) to evaluate adsorption ratio per unit in subsurface cores, applying mercury injection capillary pressure(MICP) and nitrogen adsorption to define the lower oily limit and the effective specific surface area, and combining oil testing results in confined cores, were utilized to evaluate the movable oil in the Triassic Chang7 reservoir, Yanchang Formation, Ordos Basin. The results indicated that the thickness of oil adsorbed on tight sandstone surfaces was 15.6 nm with an intensity around 13 mg/m², the lowest oily limit was around 18 nm, the effective specific surface area was around 1m²/g, the porosity was around 6%-10%, and the ratio of free oil was around 14.3%-48.6%. All these results were comparable with the NMR experiments. Several factors controlled the movable oil amounts in tight sandstones, including crude oil density and viscosity, effective specific surface area, effective porosity volume and mineral constituents. For specific region or layer, the amounts of movable oil is parametrically controlled by pore surface area/effective porosity volume.
- adsorbed state /
- free state /
- tight oil /
- controlling factor /
- Ordos Basin

HTML全文

参考文献(34)

[1]	EIA US.Annual energy outlook 2013[M].Washington:US Energy Information Administration,2013:60-62.
[2]	贾承造,邹才能,李建忠,等.中国致密油评价标准、主要类型、基本特征及资源前景[J].石油学报,2012,33(3):343-350. Jia Chengzao,Zou Caineng,Li Jianzhong,et al.Assessment criteria,main types,basic features and resource prospects of the tight oil in China[J].Acta Petrolei Sinica,2012,33(3):343-350.
[3]	贾承造,郑民,张永峰.中国非常规油气资源与勘探开发前景[J].石油勘探与开发,2012,39(2):129-136. Jia Chengzao,Zheng Min,Zhang Yongfeng.Unconventional hydrocarbon resources in China and the prospect of exploration and development[J].Petroleum Exploration and Development,2012,39(2):129-136.
[4]	康玉柱.中国非常规致密岩油气藏特征[J].天然气工业,2012,32(5):1-4. Kang Yuzhu.Characteristics of tight hydrocarbon reservoirs in China[J].Natural Gas Industry,2012,32(5):1-4.
[5]	马洪,李建忠,杨涛,等.中国陆相湖盆致密油成藏主控因素综述[J].石油实验地质,2014,36(6):668-677. Ma Hong,Li Jianzhong,Yang Tao,et al.Main controlling factors for tight oil accumulation in continental lacustrine basins in China[J].Petroleum Geology & Experiment,2014,36(6):668-677.
[6]	杨华,李士祥,刘显阳.鄂尔多斯盆地致密油、页岩油特征及资源潜力[J].石油学报,2013,34(1):1-11. Yang Hua,Li Shixiang,Liu Xianyang.Characteristics and resource prospects of tight oil and shale oil in Ordos Basin[J].Acta Petrolei Sinica,2013,34(1):1-11.
[7]	姚泾利,邓秀芹,赵彦德,等.鄂尔多斯盆地延长组致密油特征[J].石油勘探与开发,2013,40(2):150-158. Yao Jingli,Deng Xiuqin,Zhao Yande,et al.Charateristics of tight oil in Triassic Yanchang Formation,Ordos Basin[J].Petroleum Exploration and Development,2013,40(2):150-158.
[8]	匡立春,唐勇,雷德文,等.准噶尔盆地二叠系咸化湖相云质岩致密油形成条件与勘探潜力[J].石油勘探与开发,2012,39(6):657-667. Kuang Lichun,Tang Yong,Lei Dewen,et al.Formation conditions and exploration potential of tight oil in the Permian saline lacustrine dolomite rock,Junggar basin,NW China[J].Petroleum Exploration and Development,2012,39(6):657-667.
[9]	汪少勇,李建忠,李登华,等.川中地区公山庙油田侏罗系大安寨段致密油资源潜力分析[J].中国地质,2013,40(2):477-486. Wang Shaoyong,Li Jianzhong,Li Denghua,et al.The potential of tight oil resource in Jurassic Da'anzhai Formation of the Gong-shanmiao oil field,Central Sichuan Basin[J].Geology in China,2013,40(2):477-486.
[10]	付锁堂,张道伟,薛建勤,等.柴达木盆地致密油形成的地质条件及勘探潜力分析[J].沉积学报,2013,31(4):672-682. Fu Suotang,Zhang Daowei,Xue Jianqin,et al.Exploration potential and geological conditions of tight oil in the Qaidam basin[J].Acta Sedimentologica Sinica,2013,31(4):672-682.
[11]	黄薇,梁江平,赵波,等.松辽盆地北部白垩系泉头组扶余油层致密油成藏主控因素[J].古地理学报,2013,15(5):635-644. Huang Wei,Liang Jiangping,Zhao Bo,et al.Main controlling factors of tight oil accumulation in the Fuyu Layer of Cretaceous Quantou Formation in Songliao basin[J].Journal of Palaeogeogaraphy,2013,15(5):635-644.
[12]	邹才能,朱如凯,吴松涛,等.常规与非常规油气聚集类型、特征、机理及展望:以中国致密油和致密气为例[J].石油学报,2012,33(2):173-187. Zou Caineng,Zhu Rukai,Wu Songtao,et al.Types,characteristics,genesis and prospects of conventional and unconventional hydrocarbon accumulations:Taking tight oil and tight gas in China as an instance[J].Acta Petrolei Sinica,2012,33(2):173-187.
[13]	林潼,冉启贵,魏红兴,等.库车坳陷迪北地区致密砂岩孔喉形态特征及其对储层的影响[J].石油实验地质,2015,37(6):696-703. Lin Tong,Ran Qigui,Wei Hongxing,et al.Pore-throat characte-ristics of tight sandstones and its influence on reservoirs in Dibei area of the Kuqa Depression[J].Petroleum Geology & Experiment,2015,37(6):696-703.
[14]	肖开华,冯动军,李秀鹏.川西新场须四段致密砂岩储层微观孔喉与可动流体变化特征[J].石油实验地质,2014,36(1):77-82. Xiao Kaihua,Feng Dongjun,Li Xiupeng.Micro pore and throat characteristics and moveable fluid variation of tight sandstone in 4th member of Xujiahe Formation,Xinchang Gas Field,western Sichuan Basin[J].Petroleum Geology & Experiment,2014,36(1):77-82.
[15]	邹才能,张国生,杨智,等.非常规油气概念、特征、潜力及技术:兼论非常规油气地质学[J].石油勘探与开发,2013,40(4):385-399. Zou Caineng,Zhang Guosheng,Yang Zhi,et al.Geological concept,characteristics,resource potential and key techniques of unconventional hydrocarbon:On unconventional petroleum geology[J].Petroleum Exploration and Development,2013,40(4):385-399.
[16]	Clarkson C R,Pedersen P K.Tight oil production analysis:Adaptation of existing rate-transient analysis techniques//Canadian Unconventional Resources and International Petroleum Conference.Calgary,Alberta,Canada:Society of Petroleum Engineers,2010.
[17]	Kabir S,Rasdi F,Igboalisi B.Analyzing production data from tight oil wells[J].Journal of Canadian Petroleum Technology,2011,50(5):48-58.
[18]	Yu Shaoyong,Miocevic D J.An improved method to obtain reliable production and EUR prediction for wells with short production history in tight/shale reservoirs//Unconventional Resources Technology Conference.Denver,Colorado,USA:Society of Petroleum Engineers,2013.
[19]	崔景伟,朱如凯,崔京钢.页岩孔隙演化及其与残留烃量的关系:来自地质过程约束下模拟实验的证据[J].地质学报,2013,87(5):730-736. Cui Jingwei,Zhu Rukai,Cui Jinggang.Relationship of porous evolution and residual hydrocarbon:Evidence from modeling experiment with geological constrains[J].Acta Geologica Sinica,2013,87(5):730-736.
[20]	崔景伟,朱如凯,吴松涛,等.致密砂岩层内非均质性及含油下限:以鄂尔多斯盆地三叠系延长组长7段为例[J].石油学报,2013,34(5):877-882. Cui Jingwei,Zhu Rukai,Wu Songtao,et al.Heterogeneity and lower oily limits for tight sandstones:A case study on Chang-7 oil layers of the Yanchang Formation,Ordos Basin[J].Acta Petrolei Sinica,2013,34(5):877-882.
[21]	杨华,窦伟坦,刘显阳,等.鄂尔多斯盆地三叠系延长组长7沉积相分析[J].沉积学报,2010,28(2):254-263. Yang Hua,Dou Weitan,Liu Xianyang,et al.Analysis on sedimentary facies of member 7 in Yanchang Formation of Triassic in Ordos Basin[J].Acta Sedmentologica Sinica,2010,28(2):254-263.
[22]	杨华,张文正.论鄂尔多斯盆地长7段优质油源岩在低渗透油气成藏富集中的主导作用:地质地球化学特征[J].地球化学,2005,34(2):147-154. Yang Hua,Zhang Wenzheng.Leading effect of the seventh mumber high-quality source rock of Yanchang Formation in Ordos Basin during the enrichment of low-penetrating oil-gas accumulation:Geology and geochemistry[J].Geochimica,2005,34(2):147-154.
[23]	牛小兵,冯胜斌,刘飞,等.低渗透致密砂岩储层中石油微观赋存状态与油源关系:以鄂尔多斯盆地三叠系延长组为例[J].石油与天然气地质,2013,34(3):288-293. Niu Xiaobing,Feng Shengbin,Liu Fei,et al.Microscopic occurrence of oil in tight sandstones and its relation with oil sources:A case study from the Upper Triassic Yanchang Formation,Ordos Basin[J].Oil & Gas Geology,2013,34(3):288-293.
[24]	冯胜斌,牛小兵,刘飞,等.鄂尔多斯盆地长7致密油储层储集空间特征及其意义[J].中南大学学报(自然科学版),2013,44(11):4574-4580. Feng Shengbin,Niu Xiaobing,Liu Fei,et al.Characteristics of Chang7 tight oil reservoir space in Ordos Basin and its significance[J].Journal of Central South University:Science and Technology,2013,44(11):4574-4580.
[25]	李士祥,施泽进,刘显阳,等.鄂尔多斯盆地中生界异常低压成因定量分析[J].石油勘探与开发,2013,40(5):528-533. Li Shixiang,Shi Zejin,Liu Xianyang,et al.Quantitative analysis of the Mesozoic abnormal low pressure in Ordos Basin[J].Petroleum Exploration and Development,2013,40(5):528-533.
[26]	Sauerbrey G Z.Use of quartz vibration for weighing thin films on a microbalance[J].Zeitschriftfür Physik,1959,155(2):206-222.
[27]	Ekholm P,Blomberg E,Claesson P,et al.A quartz crystal microba-lance study of the adsorption of asphaltenes and resins onto a hydrophilic surface[J].Journal of Colloid and Interface Science,2002,247(2):342-350.
[28]	LarterS R,Senftle J T.Improvedkerogen typing for petroleum source rock analysis[J].Nature,1985,318(6043):277-280.
[29]	Cui Jingwei,Wang Tieguan,Li Meijun,et al.Oil filling history of the Bashituo Oilfield in the Markit Slope,SW Tarim Basin,China[J].Petroleum Science,2013,10(1):58-64.
[30]	Alboudwarej H,Pole D,Svrcek W Y,et al.Adsorption of asphaltenes on metals[J].Industrial & Engineering Chemistry Research,2005,44(15):5585-5592.
[31]	Balabin R M,Syunyaev R Z.Petroleum resins adsorption onto quartz sand:Near infrared(NIR) spectroscopy study[J].Journal of Colloid and Interface Science,2008,318(2):167-174.
[32]	崔景伟,朱如凯,杨智,等.国外页岩层系石油勘探开发进展及启示[J].非常规油气,2015,2(4):68-82. Cui Jingwei,Zhu Rukai,Yang zhi,et al.Progresses and enlightenment of overseas shale oil exploration and development[J].Unconventional Oil & Gas,2015,2(4):68-82.
[33]	Chilingar G V,Main R,Sinnokrot A.Relationship between porosity,permeability,and surface areas of sediments[J].Journal of Sedimentary Research,1963,33(3):759-765.
[34]	Kuuskraa V,Stevens S H,Moodhe K D.Technically recoverable shale oil and shale gas resources:Anassessment of 137 shale formations in 41 countries outside the United States[M].Washington:US Energy Information Administration,2013.
