东非裂谷系东支油气成藏主控因素及勘探潜力

张燕; 田作基; 温志新; 王兆明; 宋成鹏; 吴义平

doi:10.11781/sysydz201701079

东非裂谷系东支油气成藏主控因素及勘探潜力

doi: 10.11781/sysydz201701079

中国石油勘探开发研究院, 北京 100083

基金项目: 国家油气重大专项（2016ZX05029）和中国石油天然气股份公司重大科技专项（2013E-0501）资助。

详细信息

作者简介:
张燕(1991-),女,硕士研究生,从事含油气盆地分析及石油地质研究。E-mail:zhangyan91@petrochina.com.cn。

中图分类号: TE122.3
计量
- 文章访问数: 1054
- HTML全文浏览量: 110
- PDF下载量: 362
- 被引次数: 0
出版历程
- 收稿日期: 2016-07-20
- 修回日期: 2016-12-07
- 刊出日期: 2017-01-28

Controlling factors for petroleum accumulation and exploration potential of the eastern branch of East African Rift System

Research Institute of Petroleum Exploration & Development, PetroChina, Beijing 100083, China

摘要

摘要: 东非裂谷系东支是新生代形成的陆内裂谷盆地群，南洛基查盆地位于东支裂谷系肯尼亚地区北部，自2012年以来已相继发现8个油田，累计发现2C储量766 MMbbl。通过对南洛基查盆地地震、钻井等地质资料综合研究，厘清了其油气地质特征及成藏规律。作为小型箕状断陷湖盆，盆地具有西断东超构造特征，西侧陡坡带以形成构造—岩性复合圈闭为主，东侧缓坡带以断块构造圈闭为主。盆地沉积充填为河流—（扇）三角洲—湖泊沉积体系，呈现出初始裂陷期—扩张期—萎缩期旋回特征。盆地发育渐新统—下中新统和中—下中新统2套成藏组合。根据对南洛基查盆地已发现油气田的解剖，认为成熟烃源岩、有效储集层及成藏要素间的合理配置是东支裂谷系油气规模成藏的主控因素。结合重力、地震、沉积厚度等资料综合分析，认为凯里奥山谷盆地、图尔卡纳盆地西北陆上和凯里奥盆地同样具有良好勘探潜力，值得重点关注。
- 裂谷 /
- 半地堑 /
- 成藏主控因素 /
- 勘探潜力 /
- 南洛基查盆地 /
- 东非裂谷系东支
Abstract: The eastern branch of the East African Rift System belongs to an intracontinental rift basin group formed during the Cenozoic. The South Lokichar Basin is located in the north of Kenya. Since 2012, 8 oil fields have been discovered here, with 2C resource being 766 million bbl. Through integrated study of seismic, well and other geological data, we investigated the petroleum geological features and developed reservoir-forming rules. The basin has small-scale, mono-faulted structural characteristics, faulting to the west and overlapping to the east. In the western steep-slope zone, there are mainly structural-lithologic combination traps, and in the eastern gentle slope zone is structural traps. Depositional fill is characterized by a river-(fan) delta-lacustrine sedimentary system, presenting a cycle of initial rifting stage-expanding stage-waning stage. There are two sets of plays, one is Oligocene-Lower Miocene combination and the other one is Middle-Lower Miocene combination. Based on the analysis of discovered fields in the South Lokichar Basin, it was determined that mature source rocks, significant reservoirs and reasonable positioning of accumulation elements were the main controlling factors in the eastern branch rifts. The exploration potential of the eastern branch rift system was analyzed through comprehensive interpretation of gravity, seismic and depositional thickness data. The most favorable targets deserving attention are the Kerio Valley Basin to the south of South Lokichar Basin, the northwest onshore of the Turkana Basin and the Kerio Basin.
- rift /
- half graben /
- controlling factor for accumulation /
- exploration potential /
- South Lokichar Basin /
- eastern branch of East African Rift System

HTML全文

参考文献(22)

[1]	IHS Energy Portal Version 2.0.EDIN.https://my.ihs.com/Energy/Products.
[2]	Africa Oil Corp.Moving forward to development. [2016].http://www.africaoilcorp.com/i/pdf/Corporate-Presentation-Nov-2016.pdf.
[4]	Macgregor D.History of the development of the East African Rift system:A series of interpreted maps through time[J].Journal of African Earth Sciences,2015,101:232-252.
[5]	Delvaux D.Karoo rifting in western Tanzania:precursor of Gondwana break-up[M]//Weiss R H.Contributions to Geology and Paleonto-logy of Gondwana in Honour of Helmut Wopfner.Cologne:Geological Institute,University of Cologne,2001:111-125.
[6]	温志新,童晓光,张光亚,等.东非裂谷系盆地群石油地质特征及勘探潜力[J].中国石油勘探,2012,17(4):60-65. Wen Zhixin,Tong Xiaoguang,Zhang Guangya,et al.Petroleum geo-logy features and exploration potential of basin group in East African Rift System[J].China Petroleum Exploration,2012,17(4):60-65.
[7]	许志刚.东非裂谷系西支中南段Karoo地层分布特点与勘探前景[J].吉林地质,2014,33(1):14-19. Xu Zhigang.Stratigraphic distribution features and exploration prospect of Karoo in south-central segment of west branch,East African Rift System[J].Jilin Geology,2014,33(1):14-19.
[8]	Mugisha F,Ebinger C J,Strecker M,et al.Two-stage rifting in the Kenya rift:Implications for half-graben models[J].Tectonophy-sics,1997,278(1/2/3/4):63-81.
[9]	Morley C K,Wescott W A,Stone D M,et al.Tectonic evolution of the northern Kenyan Rift[J].Journal of the Geological Society,1992,149(3):333-348.
[10]	Morley C K,Karanja F M,Wescott W A,et al.Geology and geophysics of the western Turkana Basins,Kenya//Morley C K.Geoscience of Rift Systems-Evolution of East Africa:AAPG Study 44.Tulsa:AAPG,1999:19-54.
[11]	Morley C K.Interaction of deep and shallow processes in the evolution of the Kenya rift[J].Tectonophysics,1994,236(1/4):81-91.
[12]	Tullow Oil plc.2016 half year results.(2016-07-27).http://www.tullowoil.com/Media/docs/default-source/3_investors/2016-half-year-results/2016-half-year-results-presentation-Aug-update.pdf?sfvrsn=6.
[13]	Morley C K.Evolution of large normal faults:Evidence from seismic reflection data[J].AAPG Bulletin,2002,86(6):961-978.
[14]	Tiercelin J J,Thuo P,Nalpas T,et al.Hydrocarbon prospectivity in Mesozoic and Early Cenozoic rift basins in central/northern Kenya//AAPG International Conference and Exihibition.Cape Town, South Africa:AAPG,2008:10.
[15]	Neumaier M,Tiercelin J J,Nalpas T,et al.Basin analysis and petroleum systems modeling of the Lokichar Basin (Kenya)//AAPG International Conference and Exhibition:The Spirit Between Continents:Energy Geosciences in a Changing World.Istambul,Turkey:AAPG,2014:1.
[16]	Talbot M R,Morley C K,Tiercelin J J,et al.Hydrocarbon potential of the Meso-Cenozoic Turkana Depression,northern Kenya:Ⅱ Source rocks:quality,maturation,depositional environments and structural control[J].Marine and Petroleum Geology,2004,21(1):63-78.
[17]	Rop B K,Patwardhan A M.Hydrocarbon of source rocks evaluation study of Lokichar Basin,Northwestern Kenya[J].Journal of the Geological Society of India,2013,81(4):575-580.
[18]	Rop B K.Hydrocarbon characteristics of source rocks in Loperot-1 well,NW Kenya//Exploration & Production Geology.Nairobi,Kenya:AAPG,2011.
[19]	Tiercelin J J,Thuo P,Potdevin J L,et al.Hydrocarbon prospectivity in Mesozoic and Early-Middle Cenozoic rift basins of central and northern Kenya,Eastern Africa//Gao Deng-liang.Tectonics and Sedimentation:Implications for Petroleum Systems.Tulsa:AAPG,2012:178-207.
[20]	Tiercelin J J,Potdevin J L,Morley C K,et al.Hydrocarbon potential of the Meso-Cenozoic Turkana Depression,northern Kenya:I Reservoirs:depositional environments,diagenetic characte-ristics,and source rock-reservoir relationships[J].Marine and Petroleum Geology,2004,21(1):41-62.
[21]	付广,杨勉.断陷盆地油气成藏模式及分布特征[J].石油实验地质,2001,23(4):408-411. Fu Guang,Yang Mian.Hydrocarbon accumulation and distribution in fault ba
[22]	董荣鑫,苏美珍.近岸水下冲积扇相特征及实例[J].石油实验地质,1985,7(4):294-302. Dong Rongxin,Su Meizhen.Characteristic of beachy underwater alluvial fan facies:With a practical example[J].Petroleum Geo-logy & Experiment,1985,7(4):294-302.
[23]	Vétel W,Le Gall B,Johnson T C.Recent tectonics in the Turkana Rift (North Kenya):An integrated approach from drainage network,satellite imagery and reflection seismic analyses[J].Basin Research,2004,16(2):165-181.
