新疆北部石炭系高演化烃源岩加氢催化裂解实验

李艳丽; 林会喜

doi:10.11781/sysydz201701120

新疆北部石炭系高演化烃源岩加氢催化裂解实验

doi: 10.11781/sysydz201701120

中国石化胜利油田分公司勘探开发研究院西部分院, 山东东营 257000

基金项目: 国家科技重大专项02课题（2011ZX05002-002）和中石化重大科技攻关课题（P12035）资助。

详细信息

作者简介:
李艳丽(1978-),女,硕士,高级工程师,从事油气地球化学研究。E-mail:24123054@qq.com。

中图分类号: TE112.114
计量
- 文章访问数: 1089
- HTML全文浏览量: 61
- PDF下载量: 216
- 被引次数: 0
出版历程
- 收稿日期: 2016-06-02
- 修回日期: 2016-12-07
- 刊出日期: 2017-01-28

Catalytic hydropyrolysis for highly mature Carboniferous source rocks in the northern Xinjiang

Li Yanli,
Lin Huixi

Western Branch of Exploration and Development Research Institute, SINOPEC Shengli Oilfield, Dongying, Shandong 257000, China

摘要

摘要: 针对新疆北部石炭系高演化烃源岩常规索氏抽提物含量低的特点，开展加氢催化裂解实验，对比分析两者的生物标志化合物特征，提高烃源岩的沉积背景及母源特征研究的可靠度。结果显示应用氢解产物的正构烷烃和甾烷化合物指示母质来源效果更好。浅部泥岩的正构烷烃呈nC₁₈和nC₂₂_-24的双峰型分布，表明远洋水生浮游动物的贡献大，而深部泥岩呈主峰碳为nC₁₈-nC₂₄的单峰型分布，指示以低等菌藻类水生生物贡献为主；抽提物中C₂₇和C₂₉规则甾烷含量相当，指示混合母质来源，而氢解产物中规则甾烷以C₂₉为主，明确指示单一的母质来源。此外，氢解产物中含有更加丰富的βα-莫烷及ββ-升藿烷系列化合物，丰富了烃源岩的母质信息。研究明确石炭系烃源岩发育于较还原的沉积环境，优质烃源岩主要分布在下段，以菌藻类等单一的水生生物为有机母质来源，具备良好的生烃的背景及物质基础。实验也进一步证实氢解实验能够获取更多的生物标志物信息，对常规抽提方法是一种有益的补充。
- 加氢催化裂解 /
- 高演化 /
- 生物标志化合物 /
- 烃源岩 /
- 石炭系 /
- 新疆北部
Abstract: The Carboniferous source rocks in the northern Xinjiang have the characteristics of high thermal evolution, which leads to the low level of biomarkers from conventional extraction. Catalytic hydropyrolysis was carried out in order to study the sedimentary background and organic matter biological sources. The results show that the n-alkanes and steranes from hydrogenolysis are representative of parent materials. The n-alkanes have a bimodal pattern with the main carbon peaks at n-C₁₈ and n-C_22-24 in shallow mudstones, indicating a contribution of pelagic aquatic zooplankton, and have a single-peak pattern with the main carbon peak at n-C₁₈-n-C₂₄ in deep mudstones, indicating a contribution of aquatic bacteria and algae. The contents of C₂₉ and C₂₇ steranes are comparable, which indicates a mixed source. In the pyrolysis products, the content of C₂₉ steranes is much higher, which clearly indicates a single parent material. Moreover, hydropyrolysis products contain more βα-moretanes and ββ-homohopanes. The Carboniferous source rocks were mainly developed in a reducing environment. High-quality marine source rocks of Carboniferous are mainly distributed in the lower segment with aquatic organisms such as bacteria and algae as a single source of organic matter. The experiments also confirmed that the hydrogen hydrolysis reaction could recover more information of biolo-gical markers, which is a useful supplement to conventional extraction methods.
- catalytic hydropyrolysis /
- high evolution /
- biomarker /
- source rock /
- Carboniferous /
- northern Xinjiang

HTML全文

参考文献(27)

[1]	Rullk tter J,Mackenzie A S,Welte D H,et al.Quantitative gas chromatography-mass spectrometry analysis of geological samples[J].Organic Geochemistry,1984,6:817-827.
[2]	Dzou L I P,Noble R A,Senftle J T.Maturation effects on absolute biomarker concentration in a suite of coals and associated vitrinite concentrates[J].Organic Geochemistry,1995,23(7):681-697.
[3]	Love G D,Snape C E,Carr A D,et al.Release of covalently-bound alkane biomarkers in high yields from kerogen via catalytic hydro-pyrolysis[J].Organic Geochemistry,1995,23(10):981-986.
[4]	孙永革,Meredith W,Snape C E,等.加氢催化裂解技术用于高演化源岩有机质表征研究[J].石油与天然气地质,2008,29(2):276-282. Sun Yongge,Meredith W,Snape C E,et al.Study on the application of hydropyrolysis technique to the description of organic matter in highly mature source rocks[J].Oil & Gas Geology,2008,29(2):276-282.
[5]	王庆涛,江林香,刘奇宝,等.柯坪剖面中上奥陶统烃源岩的催化加氢裂解产物特征及其地质意义[J].地球化学,2012,41(5):415-424. Wang Qingtao,Jiang Linxiang,Liu Qibao,et al.Catalytic hydropyrolysis for kerogens of middle and upper Ordovician source rocks in Keping Section,Tarim Basin,Northwestern China[J].Geochimica,2012,41(5):415-424.
[6]	吴亮亮,廖玉宏,方允鑫,等.不同成熟度烃源岩的催化加氢热解与索氏抽提在生物标志物特征上的对比[J].科学通报,2012,57(32):3067-3077. Wu Liangliang,Liao Yuhong,Fang Yunxin,et al.The comparison of biomarkers released by hydropyrolysis and Soxhlet extraction from source rocks of different maturities[J].Chinese Science Bulletin,2013,58(3):373-383.
[7]	岳长涛,李术元,凌瑞枫.川东北地区过成熟烃源岩催化加氢热解研究[J].石油实验地质,2011,33(5):540-545. Yue Changtao,Li Shuyuan,Ling Ruifeng.Catalytic hydropyrolysis of over-mature source rock in northeast Sichuan Basin[J].Petroleum Geology & Experiment,2011,33(5):540-545.
[8]	秦黎明,张枝焕,刘洪军,等.准噶尔盆地东北部恰库尔特草原北下石炭统南明水组烃源岩有机地球化学特征及其地质意义[J].天然气地球科学,2008,19(6):761-769. Qin Liming,Zhang Zhihuan,Liu Hongjun,et al.Geochemical characteristics of lower Carboniferous Nanmingshui formation source rock and their geologic implications,Qiakuerte Prairie,Northeastern Jun-ggar Basin[J].Natural Gas Geoscience,2008,19(6):761-769.
[9]	张奎华,李艳丽,张关龙,等.乌伦古拗陷石炭系烃源岩再认识[J].西南石油大学学报(自然科学版),2013,35(5):1-6. Zhang Kuihua,Li Yanli,Zhang Guanlong,et al.The further understanding of carboniferous source rocks in Wulungu depression[J].Journal of Southwest Petroleum University (Science & Techno-logy Edition),2013,35(5):1-6.
[10]	国建英,李志明.准噶尔盆地石炭系烃源岩特征及气源分析[J].石油实验地质,2009,31(3):275-281. Guo Jianying,Li Zhiming.Study of gas source and characteristics of carboniferous hydrocarbon source rock in the Junggar Basin[J].Petroleum Geology & Experiment,2009,31(3):275-281.
[11]	余腾孝,曹自成,徐勤琪,等.准噶尔盆地北部古生代构造演化与石炭系烃源岩[J].石油与天然气地质,2010,31(1):91-97. Yu Tengxiao,Cao Zicheng,Xu Qinqi,et al.The Paleozoic tectonic evolution and the Carboniferous source rocks in the nor-thern Juggar Basin[J].Oil & Gas Geology,2010,31(1):91-97.
[12]	曲彦胜,王圣柱,李艳丽,等.乌伦古地区石炭系烃源岩生烃潜力评价[J].特种油气藏,2016,23(2):31-35. Qu Yansheng,Wang Shengzhu,Li Yanli,et al.Hydrocarbon potential evaluation of Carboniferous source-rocks in Wulungu[J].Special Oil & Gas Reservoirs,2016,23(2):31-35.
[13]	董臣强.车排子地区火成岩油气成藏条件及勘探关键技术[J].油气地质与采收率,2015,22(2):45-50. Dong Chenqiang.Hydrocarbon accumulation conditions and key exploration technologies of igneous rock in the Chepaizi area[J].Petroleum Geology and Recovery Efficiency,2015,22(2):45-50.
[14]	柳波,贾梦成,黄志龙,等.三塘湖盆地马朗凹陷石炭系火山岩系烃源岩识别与预测[J].石油实验地质,2015,37(4):452-459. Liu Bo,Jia Mengcheng,Huang Zhilong,et al.Identification and prediction of source rocks in Carboniferous volcanic systems in Malang Sag, Santanghu Basin[J].Petroleum Geology & Experiment,2015,37(4):452-459.
[15]	靳军,张朝军,刘洛夫,等.准噶尔盆地石炭系构造沉积环境与生烃潜力[J].新疆石油地质,2009,30(2):211-214. Jin Jun,Zhang Chaojun,Liu Luofu,et al.Structural/sedimentary environment and hydrocarbon-generating potentials of carboni-ferous in Junggar basin[J].Xinjiang Petroleum Geology,2009,30(2):211-214.
[16]	Gouch M A,Rhead M M,Rowland S J.Biodegradation studies of unresolved complex mixtures of hydrocarbons:model UCM hydrocarbons and the aliphatic UCM[J].Organic Geochemistry,1992,18(1):17-22.
[17]	菲尔普.化石燃料生物标志物:应用与谱图[M].傅家谟,盛国英,译.北京:科学出版社,1987. Philp R P.Fossil fuel biomarkers-applications and spectra[M]. Fu Jiamo,Sheng Guoying,trans.Beijing:Science Press,1987.
[18]	Ficken K J,Li B,Swain D L,et al.An n-alkane proxy for the sedimentary input of submerged/floating freshwater aquatic macrophytes[J].Organic Geochemistry,2000,31(7/8):745-749.
[19]	Ourisson G,Albrecht P,Rohmer M,et al.The microbial origin of fossil fuels[J].Scientific American,1984,251(2):44-51.
[20]	屈定创,史继扬,向明菊.一类新的藿烯化合物的发现及其在地质藿类成因上的意义[J].中国科学(B辑),1995,25(6):665-672. Qu Dingchuang,Shi Jiyang,Xiang Mingju.The discovery of a new hopene compounds and its significance of geological theory of hopan origin[J].Science China (B),1995,25(6):665-672.
[21]	Murray I P,Love G D,Snape C E,et al.Comparison of covalently-bound aliphatic biomarkers released via hydropyrolysis with their solvent-extractable counterparts for a suite of Kimmeridge clays[J].Organic Geochemistry,1998,29(5/7):1487-1505.
[22]	周友平,史继扬,屈定创.沉积有机质中ββ藿烷成因研究:碳稳定同位素证据[J].华南师范大学学报(自然科学版),1999(3):53-58. Zhou Youping,Shi Jiyang,Qu Dingchuang.Study on the origin of ββ hopenes from different depositional environment-stable carbon isotopic evidences[J].Journal of South China Normal University (Natural Science),1999(3):53-58.
[23]	de Leeuw J W,Cox H C,van Graas G,et al.Limited double bond isomerisation and selective hydrogenation of sterenes during early diagenesis[J].Geochimica et Cosmochimica Acta,1989,53(4):903-909.
[24]	朱扬明,张春明,张敏,等.沉积环境的氧化还原性对重排甾烷形成的作用[J].沉积学报,1997,15(4):104-108. Zhu Yangming,Zhang Chunming,Zhang Min,et al.The effect of oxidation reduction nature of depositional environments on the formation of diasteranes[J].Acta Sedimentologica Sinica,1997,15(4):104-108.
[25]	Moldowan J M,Fago F J.Structure and Significance of a novel rearranged monoaromatic steroid hydrocarbon in petroleum[J].Geochimica et Cosmochimica Acta,1986,50(3):343-351.
[26]	Richnow H H,Jenisch A,Michaelis W.Structural investigations of sulphur-rich macromolecular oil fractions and a kerogen by sequential chemical degradation[J].Organic Geochemistry,1992,19(4/6):351-370.
[27]	Bishop A N,Love G D,McAulay A D,et al.Release of kerogen-bound hopanoids by hydropyrolysis[J].Organic Geochemistry,1998,29(4):989-1001.
