不同热模拟方式下烃源岩干酪根演化特征红外光谱分析

余晓露; 马中良; 郑伦举; 赵中熙

doi:10.11781/sysydz201701134

不同热模拟方式下烃源岩干酪根演化特征红外光谱分析

doi: 10.11781/sysydz201701134

余晓露^1,2,
马中良^1,2,
郑伦举^1,2,
赵中熙^1,2

1.
中国石油化工集团公司油气成藏重点实验室, 江苏无锡 214126
2. 中国石油化工股份有限公司石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126

基金项目: 中国石油化工股份有限公司科技攻关项目“烃源岩有限空间生排烃机理研究与应用”（P11060）和“烃源岩油气形成新机制与评价体系研究”（P14040）资助。

详细信息

作者简介:
余晓露(1983-),女,硕士,工程师,从事石油地质和油气地球化学研究。E-mail:yuxl.syky@sinopec.com。

中图分类号: TE135
计量
- 文章访问数: 1041
- HTML全文浏览量: 162
- PDF下载量: 281
- 被引次数: 0
出版历程
- 收稿日期: 2016-06-27
- 修回日期: 2016-11-09
- 刊出日期: 2017-01-28

FTIR analyses of source rock kerogen from different hydrous pyrolysis experiments

1.
SINOPEC Key Laboratory of Petroleum Accumulation Mechanisms, Wuxi, Jiangsu 214126, China
2. Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China

摘要

摘要: 烃源岩的生烃过程是在地层孔隙空间内有机质受温度、上覆岩层静岩压力和高地层流体压力（PVT-L共控）等多种作用下的一种复杂的物理化学反应过程。然而目前常用的生烃模拟实验（高压釜加水生烃模拟）大多是在一个低流体压力、无静岩压力、相对较大的生烃空间下进行的，与实际地质情况差异较大。选用南襄盆地泌阳凹陷核三段未熟泥岩分别开展了PVT-L共控和常规高压釜方式加水模拟实验，不同演化阶段干酪根的傅里叶变换红外光谱对比分析表明：（1）伴随着脂族结构裂解、含氧基团脱落及芳香结构缩合，干酪根演化明显呈现出缓慢生油、快速生油和结束生油3个阶段；（2）脂肪度参数I_AL、饱芳比参数I_L/R和含氧度参数I_O表明，同等温度条件下常规高压釜加水模拟脂肪链和含氧基团的热裂解反应更为剧烈，PVT-L共控模拟则相对平缓，380℃时仍伴随有较强的生烃能力；（3）PVT-L共控模拟条件下饱和烃的芳构化程度更低，可能与其限定空间内较高的流体压力有关；（4）含氧度在成熟中期间歇的轻微增大，暗示水对干酪根生烃过程也许有重要的作用。2种不同模拟方式下干酪根红外光谱特征上的差别，暗示其在生烃反应机理上存在较大差异，在热模拟实验研究中要根据研究目的合理选择模拟方式，设置实验条件。
- 生排烃模拟 /
- PVT-L共控 /
- 红外光谱 /
- 烃源岩
Abstract: The generation of hydrocarbons occurred through a complex physical and chemical reaction process in finite pore space under lithostatic pressure and fluid pressure (PVT-L jointly controlled condition). Most of the hydrous pyrolysis experiments have been carried out with low-pressure and relatively large reaction space due to experimental device limitations. PVT-L jointly controlled experiments and conventional autoclave hydrous pyrolysis experiments have been carried out with immature shale from the Biyang Sag, Nanxiang Basin, and kerogens from the experiments were characterized by FTIR, which expressed four trends: (1) Accompanying aliphatic group cracking, oxygen-containing group shedding and aromatic group condensation, the evolution of kerogen experienced three periods including slow oil generation, fast oil generation and finishing oil generation. (2)FTIR parameters show more extensive aliphatic group cracking for conventional autoclave hydrous pyrolysis experiments, while there is still relatively strong hydrocarbon generation in the PVT-L jointly controlled experiment. (3)The lower aromatization of saturated hydrocarbons in PVT-L jointly controlled experiment may be relevant to higher fluid pressure in a finite space. (4)The slight increase of oxygen level implies the role of water in the hydrocarbon generation process. Different evolutionary characters of kerogen reflected the differences of reaction mechanism, which implied that it is important to choose an appropriate experimental mode in practical research.
- simulation experiment of hydrocarbon generation and expulsion /
- PVT-L jointly controlled condition /
- FTIR /
- source rock

HTML全文

参考文献(22)

[1]	Landais P,Michels R,Elie M.Are time and temperature the only constraints to the simulation of organic matter maturation?[J].Organic Geochemistry,1994,22(3/5):617-630.
[2]	邹艳荣,帅燕华,孔枫,等.油气生成过程实验研究的思考与展望[J].石油实验地质,2004,26(4):375-382. Zou Yanrong,Shuai Yanhua,Kong Feng,et al.Experiments on petroleum generation:Considerations and outlook[J].Petroleum Geology & Experiment,2004,26(4):375-382.
[3]	郑伦举,马中良,王强,等.烃源岩有限空间热解生油气潜力定量评价研究[J].石油实验地质,2011,33(5):452-459. Zheng Lunju,Ma Zhongliang,Wang Qiang,et al.Quantitative evaluation of hydrocarbon yielding potential of source rock:Application of pyrolysis in finite space[J].Petroleum Geology & Experiment,2011,33(5):452-459.
[4]	郑伦举,秦建中,何生,等.地层孔隙热压生排烃模拟实验初步研究[J].石油实验地质,2009,31(3):296-302. Zheng Lunju,Qin Jianzhong,He Sheng,et al.Preliminary study of formation porosity thermocompression simulation experiment of hydrocarbon generation and expulsion[J].Petroleum Geology & Experiment,2009,31(3):296-302.
[5]	马中良,郑伦举,李志明.烃源岩有限空间温压共控生排烃模拟实验研究[J].沉积学报,2012,30(5):955-963. Ma Zhongliang,Zheng Lunju,Li Zhiming,et al.The thermocompression simulation experiment of source rock hydrocarbon generation and expulsion in formation porosity[J].Acta Sedimentologica Sinica,2012,30(5):955-963.
[6]	冉敬,杜谷,潘忠习.衰减全反射-傅里叶红外光谱法快速测试干酪根样品[J].岩矿测试,2010,29(2):113-117. Ran Jing,Du Gu,Pan Zhongxi.Rapid analysis for kerogen by attenuated total reflection-Fourier transform infrared spectroscopy[J].Rock and Mineral Analysis,2010,29(2):113-117.
[7]	Ganz H,Kalkreuth W.Application of infrared spectroscopy to the classification of kerogen types and the evaluation of source rock and oil shale potentials[J].Fuel,1987,66(5):708-711.
[8]	Lis G P, Mastalerz M,Schimmelmann A,et al.FTIR absorption indices for thermal maturity in comparison with vitrinite reflectance R_o in type-Ⅱ kerogens from Devonian black shales[J].Organic Geochemistry,2005,36(11):1533-1552.
[9]	杨志琼,章聆.利用红外光谱剖析干酪根三类主要原子团的演化[J].石油与天然气地质,1989,10(1):53-58. Yang Zhiqiong,Zhang Ling.Dissecting the evolution of three main atomic groups of kerogen by FTIR[J].Oil & Gas Geology,1989,10(1):53-58.
[10]	郭隽红,邹艳荣,颜永何,等.干酪根分子结构在低熟阶段的演化特征:基于红外光谱分析[J].地球化学,2014,43(5):529-537. Guo Juanhong,Zou Yanrong,Yan Yonghe,et al.Evolutional characteristics of the kerogen molecular structure during the low-mature stage:An infrared spectra analysis[J].Geochimica,2014,43(5):529-537.
[11]	廖泽文,耿安松.沥青质傅里叶变换红外光谱(FT-IR)分析及其在有机地球化学研究中的应用[J].地球化学,2001,30(5):433-438. Liao Zewen,Geng Ansong.Characterization of FT-IR analysis of asphaltenes and its geochemical implications[J].Geochimica,2001,30(5):433-438.
[12]	Painter P C,Snyder R W,Starsinic M,et al.Concerning the application of FT-IR to the study of coal:A critical assessment of band assignments and the application of spectral analysis programs[J].Applied Spectroscopy,1981,35(5):475-485.
[13]	Wang S H,Griffiths P R.Resolution enhancement of diffuse reflectance I.R. spectra of coals by Fourier self-deconvolution:1.C-H stretching and bending modes[J].Fuel,1985,64(2):229-236.
[14]	Sobkowiak M,Painter P.Determination of the aliphatic and aromatic CH contents of coals by FT-I.R.:Studies of coal extracts[J].Fuel,1992,71(10):1105-1125.
[15]	Ibarra J V,Moliner R,Bonet A J.FT-I.R. investigation on char formation during the early stages of coal pyrolysis[J].Fuel,1994,73(6):918-924.
[16]	王擎,许祥成,迟铭书,等.干酪根组成结构及其热解生油特性的红外光谱研究[J].燃料化学学报,2015,43(10):1158-1166. Wang Qing,Xu Xiangcheng,Chi Mingshu,et al.FT-IR study on composition of oil shale kerogen and its pyrolysis oil generation characteristics[J].Journal of Fuel Chemistry and Technology,2015,43(10):1158-1166.
[17]	Tissot B P,Welte D H.Petroleum formation and occurrence:A new approach to oil and gas exploration[M]. Berlin:Springer-Verlag,1978.
[18]	Stalker L,Farrimond P,Larter S R.Water as an oxygen source for the production of oxygenated compounds (including CO₂ precursors) during kerogen maturation[J].Organic Geochemi-stry,1994,22(3/5):477-486.
[19]	Leif R N,Simoneit B R T.The role of alkenes produced during hydrous pyrolysis of a shale[J].Organic Geochemistry,2000,31(11):1189-1208.
[20]	Seewald J S.Aqueous geochemistry of low molecular weight hydrocarbons at elevated temperatures and pressures:Constraints from mineral buffered laboratory experiments[J].Geochimica et Cosmochimica Acta,2001,65(10):1641-1664.
[21]	Seewald J S.Organic-inorganic interactions in petroleum-producing sedimentary basins[J].Nature,2003,426(6964):327-333.
[22]	Lewan M D.Water as a source of hydrogen and oxygen in petroleum formation by hydrous pyrolysis[J].American Chemical Society,Division of Fuel Chemistry Preprints,1992,37(4):1643-1649.
