湖相页岩不同赋存状态的可溶有机质定量表征

钱门辉; 蒋启贵; 黎茂稳; 李志明; 刘鹏; 马媛媛; 曹婷婷

doi:10.11781/sysydz201702278

湖相页岩不同赋存状态的可溶有机质定量表征

doi: 10.11781/sysydz201702278

钱门辉^1,2,3,4,
蒋启贵^1,2,3,4,
黎茂稳^1,2,3,4,
李志明^1,2,3,4,
刘鹏^1,2,3,4,
马媛媛^1,2,3,4,
曹婷婷^1,2,3,4

1.
中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126
2. 页岩油气富集机理与有效开发国家重点实验室, 江苏无锡 214126
3. 国家能源页岩油研发中心, 江苏无锡 214126
4. 中国石化油气成藏重点实验室, 江苏无锡 214126

基金项目: 国家重点基础研究发展计划（973计划）项目"中国东部古近系陆相页岩油富集机理与分布规律"（2014CB239101）；页岩油气富集机理与有效开发国家重点实验室自主研发基金"陆相页岩油组成与页岩有效孔喉耦合关系研究"；中国石化科技部项目"陆相断陷盆地页岩油-致密油体系成藏过程示踪"（P15096）联合资助。

详细信息

作者简介:
钱门辉(1985-),男,硕士研究生,工程师,从事实验地质及非常规页岩油气研究.E-mail:qianmh.syky@sinopec.com。

中图分类号: TE122.1
计量
- 文章访问数: 1385
- HTML全文浏览量: 224
- PDF下载量: 336
- 被引次数: 0
出版历程
- 收稿日期: 2016-07-04
- 修回日期: 2017-01-05
- 刊出日期: 2017-03-28

Quantitative characterization of extractable organic matter in lacustrine shale with different occurrences

Qian Menhui^1,2,3,4,
Jiang Qigui^1,2,3,4,
Li Maowen^1,2,3,4,
Li Zhiming^1,2,3,4,
Liu Peng^1,2,3,4,
Ma Yuanyan^1,2,3,4,
Cao Tingting^1,2,3,4

1.
Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China
2. State Key Laboratory of Shale Oil and Gas Enrichment Mechanisms and Effective Development, Wuxi, Jiangsu 214126, China
3. State Energy Center for Shale Oil Research and Development, Wuxi, Jiangsu 214126, China
4. SINOPEC Key Laboratory of Hydrocarbon Accumulation, Wuxi, Jiangsu 214126, China

摘要

摘要: 湖相页岩中可溶有机质可分为游离态、吸附态以及互溶态。不同赋存状态可溶有机质定量研究对油气资源评价、页岩油可动性、烃源岩生烃机理及油气赋存机理研究等具有重要意义。通过不同极性溶剂的组合，对中国东部2种不同岩相的湖相页岩进行了逐次分级抽提，获取了游离态、干酪根吸附-互溶态以及矿物表面吸附态等3种不同赋存状态的可溶有机质含量，并对不同赋存状态的可溶有机质进行地球化学组分分析。分析结果显示，湖相页岩中干酪根吸附-互溶态可溶有机质占有较大比例，其次为游离态有机质。游离态可溶有机质主要以轻质组分为主，压裂有利于轻质组分的析出。干酪根吸附-互溶态可溶有机质主要以中-重质组分为主，同时含有部分轻质组分。岩石矿物表面吸附的可溶有机质主要以含氧杂原子化合物为主。相比纹层不发育的块状页岩，纹层状页岩中游离态可溶有机质占有比例更高，更有利于页岩油的开发。
- 吸附烃 /
- 赋存状态 /
- 逐次抽提 /
- 页岩油 /
- 济阳坳陷
Abstract: The extractable organic matter (OM) in lacustrine shale can be classified into free, adsorbed or miscible states. The quantitative study of OM of these different occurrences has significance for oil/gas resource evaluation, shale oil mobility, hydrocarbon generation mechanism and oil/gas occurrence. Two lacustrine shale samples of different lithofacies from East China were successively extracted by solvents with different polarities. Three different occurrence states of soluble OM were obtained, including free, kerogen adsorptive-miscible and mineral surface adsorptive states, which were characterized using FT-IR spectra and GC-FID analyses. The kerogen adsorptive-miscible state accounts for a large proportion of the soluble OM, followed by the free OM. The free soluble OM was dominated by light compounds, and fracturing was conducive to the precipitation of light components. The kerogen adsorptive-miscible state OM mainly had heavier components, and also contained a lower portion of light fractions. The mineral surface adsorbed OM was mainly comprised of oxygen-containing compounds. Compared to the massive shale samples, the laminated shale samples had a higher proportion of soluble OM, and the hydrocarbon molecules were smaller.
- absorbed hydrocarbon /
- occurrence state /
- successive extraction /
- shale oil /
- Jiyang Depression

HTML全文
