复杂构造背景区页岩气富集条件研究——以大巴山前缘地区为例

康建威; 林小兵; 余谦; 田景春; 门玉澎; 闫剑飞; 林家善; 孙媛媛

doi:10.11781/sysydz201704437

复杂构造背景区页岩气富集条件研究——以大巴山前缘地区为例

doi: 10.11781/sysydz201704437

1.
成都理工大学沉积地质研究院, 成都 610059
2. 成都地质调查中心, 成都 610081

基金项目: 中国地质调查局“四川盆地下古生界海相页岩气基础地质调查”（DD20160176）和重庆市国土资源和房屋管理局“重庆富有机质页岩沉积特征与储层评价研究”（渝地调设审字[2013]032号）资助。

详细信息

作者简介:
康建威(1980—),男,在读博士,工程师,从事沉积与油气地质研究。E-mail:best_kang@163.com。

通讯作者:
林小兵(1980—),博士,讲师,从事沉积地质学的教学与科研工作。E-mail:linxiaobing07@cdut.cn。

中图分类号: TE132.2
计量
- 文章访问数: 979
- HTML全文浏览量: 97
- PDF下载量: 495
- 被引次数: 0
出版历程
- 收稿日期: 2017-03-06
- 修回日期: 2017-06-10
- 刊出日期: 2017-07-28

Shale gas enrichment conditions in complex geological structure areas: A case study in the front margin of Daba Mountain

1.
Institute of Sedimentary Geology, Chengdu University of Technology, Chengdu, Sichuan 610059, China
2. Chengdu Center, China Geological Survey, Chengdu, Sichuan 610081, China

摘要

摘要: 通过大巴山前缘地区五峰—龙马溪组富有机质泥岩的野外露头、钻井、岩心等资料的研究，对一系列岩石样品进行了显微薄片、扫描电镜、有机地化、孔渗性、比表面积、含气性解析等多项实验测试分析，对五峰—龙马溪组页岩气的富集条件进行了综合研究。结果表明：大巴山前缘地区富有机质泥岩总体处在浅水—深水陆棚沉积环境下，其沉积厚度在40~70 m左右，平均有机碳含量大于2%；有机质类型为腐泥型Ⅰ型干酪根，有机质成熟度多数为0.82%~3.04%，达到高—过成熟阶段；低渗透—低孔特征，并发育多种微观空隙结构。典型钻井解剖分析认为，页岩气保存条件是该区富集条件中最为关键的因素；未被断裂破坏的箱状背斜是最为有利的构造保存条件。
- 富有机质泥岩 /
- 页岩气富集条件 /
- 构造复杂区 /
- 五峰—龙马溪组 /
- 大巴山前缘
Abstract: A series of investigations on both outcrops and drilling cores from the front edge of Daba Mountain were carried out. Organic-rich mudstones collected from the Wufeng-Longmaxi formations in Fengjie-Kaixian-Baiquan-Manyue areas were sampled and analyzed. Information was obtained from thin sections and Scanning Electron Microscopy (SEM), and some relevant laboratory tests including organic geochemistry, X-ray diffraction, He-porosity and permeability and Specific Surface Area were made to summarize the basic geological conditions of Wufeng-Longmaxi formations in the study area. The results show that the organic-rich mudstones in the front edge of Daba Mountain were probably formed in a shallow to deep shelf during the Late Ordovician-Early Silurian. The thicknesses of these mudstones range 40-70 m, and the average total organic carbon (TOC) content is more than 2%. The kerogen mainly shows characteristics of type Ⅰ. The thermal maturity of mudstones ranges 0.82%-3.04%, indicating a high to over mature stage. Additionally, the features of low permeability and low porosity as well as several types of pore microstructures were observed in these mudstones. The analyses of typical wells indicate that the preservation of shale gas is a key element for hydrocarbon accumulation. The well-preserved box-shaped anticlines are most favorable for shale gas preservation.
- organic-rich mudstone /
- shale gas preservation condition /
- complex geological structure area /
- Wufeng-Longmaxi formations /
- front margin of Daba Mountain

HTML全文

参考文献(23)

[1]	高长林,刘光祥,张玉箴,等.东秦岭—大巴山逆冲推覆构造与油气远景[J].石油实验地质,2003,25(S):523-531. Gao Changlin,Liu Guangxiang,Zhang Yuzhen,et al.Thrusting nappe structure and oil-gas potential in eastern Qinling and Daba mountain[J].Petroleum Geology & Experiment,2003,25(S):523-531.
[2]	张晓斌,范增辉,欧阳诚,等.董大巴山—米苍山前缘地区油气主控因素及勘探有利区分析[J].复杂油气藏,2014,7(1):21-24. Zhang Xiaobin,Fan Zenghui,Ouyang Cheng,et al.Main factors controlling hydrocarbon accumulation and favorable exploration targets in the front of Daba-Micang Mountain[J].Complex Hydrocarbon Reservoirs,2014,7(1):21-24.
[3]	肖开华,沃玉进,周雁,等.中国南方海相层系油气成藏特点与勘探方向[J].石油与天然气地质,2006,27(3):316-325. Xiao Kaihua,Wo Yujin,Zhou Yan,et al.Petroleum reservoiring characteristics and exploration direction in marine strata in southern China[J].Oil & Gas Geology,2006,27(3):316-325.
[4]	贾锦生,宋华颖,伊海生,等.米仓山—大巴山前缘古生界重点剖面烃源岩特征研究[J].天然气地质科学,2001,22(6):1046-1053. Jia Jinsheng,Song Huaying,Yi Haisheng,et al.Characteristic of Paleozoic hydrocarbon source rocks from key sections of frontal Micangshan-Daba[J].Natural gas geoscience,2001,22(6):1046-1053.
[5]	燕继红,李启桂,朱祥.四川盆地及周缘下寒武统页岩气成藏主控因素与勘探方向[J].石油实验地质,2016,38(4):445-452. Yan Jihong,Li Qigui,Zhu Xiang.Main factors controlling shale gas accumulation and exploration targets in the Lower Cambrian,Sichuan Basin and its periphery[J].Petroleum Geology & Experi-ment,2016,38(4):445-452.
[6]	余谦,牟传龙,张海全,等.上扬子北缘震旦纪—早古生代沉积演化与储层分布特征[J].岩石学报,2011,27(3):672-680. Yu Qian,Mu Chuanlong,Zhang Haiquan,et al.Sedimentary evolution and reservoir distribution of northern Upper Yangtze Plate in Sinian-Early Paleozoic[J].Acta Petrologica Sinica,2011,27(3):672-680.
[7]	梁榜,何生,陈学辉,等.鄂西渝东地区东岳庙段页岩气勘探潜力研究[J].断块油气田,2015,22(1):36-41. Liang Bang,He Sheng,Chen Xuehui,et al.Exploration potential of Dongyuemiao Member shale gas in western Hubei-eastern Chongqing area[J].Fault-Block Oil and Gas Field,2015,22(1):36-41.
[8]	余江浩,周世卿,王亿,等. 中扬子长阳地区寒武系牛蹄塘组页岩气成藏地质条件[J].油气地质与采收率,2016,23(5):9-15. Yu Jianghao,Zhou Shiqing,Wang Yi,et al. Geological conditions of shale gas reservoiring in the Cambrian Niutitang Formation,the Middle Yangtze region of Changyang area[J].Petroleum Geology and Recovery Efficiency,2016,23(5)：9-15.
[9]	刘伟,余谦,闫剑飞,等.上扬子地区志留系龙马溪组富有机质泥岩储层特征[J].石油与天然气地质,2012,33(3):346-352. Liu Wei,Yu Qian,Yan Jianfei,et al.Characteristics of organic-rich mudstone reservoirs in the Silurian Longmaxi Formation in Upper Yangtze region[J].Oil & Gas Geology,2012,33(3):346-352.
[10]	梁峰,拜文华,邹才能,等.渝东北地区巫溪2井页岩气富集模式及勘探意义[J].石油勘探开发,2016,43(3):350-358. Liang Feng,Bai Wenhua,Zou Caineng,et al.Shale gas enrichment pattern and exploration significance of well Wuxi-2 in northeast Chongqing,NE Sichuan Basin[J].Petroleum Exploration and Development,2016,43(3):350-358.
[11]	要继超,王兴志,罗兰,等.渝东地区龙马溪组页岩气成藏地质条件研究[J].特种油气藏,2016,23(4):77-80. Yao Jichao,Wang Xingzhi,Luo Lan,et al.Geology of Longmaxi shale gas accumulation in Eastern Chongqing[J].Special Oil & Gas Reservoirs,2016,23(4)：77-80.
[12]	武瑾,梁峰,拜文华,等.渝东北地区下志留统龙马溪组页岩气勘探前景[J].特种油气藏,2015,22(6):50-55. Wu Jin,Liang Feng,Bai Wenhua,et al.Exploration prospect of Lower Silurian Longmaxi Formation shale gas in northeastern Chongqing City[J].Special Oil & Gas Reservoirs,2015,22(6):50-55.
[13]	许志琴,卢一伦,汤耀庆,等.东秦岭造山带的变形特征及构造演化[J].地质学报,1986,60(3):237-247. Xu Zhiqin,Lu Yilun,Tang Yaoqing,et al.Deformation characteristics and tectonic evolution of the eastern Qinling orogenic belt[J].Acta Geologica Sinica,1986,60(3):237-247.
[14]	李智武,刘树根,罗玉宏,等.南大巴山前陆冲断带构造样式及变形机制分析[J].大地构造与成矿学,2006,30(3):294-304. Li Zhiwu,Liu Shugen,Luo Yuhong,et al.Structural style and deformational mechanism of southern Dabashan foreland fold-thrust belt in central China[J].Geotectonica et Metallogenia,2006,30(3):294-304.
[15]	张国伟,张本仁,袁学诚,等.秦岭造山带与大陆动力学[M].北京:科学出版社,2001. Zhang Guowei,Zhang Benren,Yuan Xuecheng,et al.Orogenic belt of Qinling Mountains and continental dynamics[M].Beijing:Science Press,2001.
[16]	张岳桥,施炜,李建华,等.大巴山前陆弧形构造带形成机理分析[J].地质学报,2010,84(9):1300-1315. Zhang Yueqiao,Shi Wei,Li Jianhua,et al.Formation mechanism of the Dabashan foreland arc-shaped structural belt [J].Acta Geologica Sinica,2010,84(9):1300-1315.
[17]	肖安成,魏国齐,沈中延,等.扬子地块与南秦岭造山带的盆山系统与构造耦合[J].岩石学报,2011,27(3):601-611. Xiao Ancheng,Wei Guoqi,Shen Zhongyan,et al.Basin-mountain system and tectonic coupling between Yangtze block and South Qinling orogen [J].Acta Petrologica Sinica,2011,27(3):601-611.
[18]	陈旭,徐均涛,成汉钧,等.论汉南古陆及大巴山隆起[J].地层学杂志,1990,14(2):81-116. Chen Xu,Xu Juntao,Cheng Hanjun,et al.On the Hannan old land and Dabashan uplift[J].Journal of Stratigraphy,1990,14(2):81-116.
[19]	涂乙,邹海燕,孟海平,等.页岩气评价标准与储层分类[J].石油与天然气地质,2014,35(1):153-158. Tu Yi,Zou Haiyan,Meng Haiping,et al.Evaluation criteria and classification of shale gas reservoirs [J].Oil & Gas Geology,2014,35(1):153-158.
[20]	张金川,金之钧,袁明生.页岩气成藏机理和分布[J].天然气工业,2004,24(7):15-18. Zhang Jinchuan,Jin Zhijun,Yuan Mingsheng.Reservoiring mechanism of shale gas and its distribution[J].Natural Gas Industry,2004,24(7):15-18.
[21]	张金川,徐波,聂海宽,等.中国页岩气资源潜力[J].天然气工业,2008,28(6):136-140. Zhang Jinchan,Xu Bo,Nie Haikuan,et al.Exploration potential of shale gas resources in China[J].Natural Gas Industry,2008,28(6):136-140.
[22]	王茂桢,柳少波,任拥军,等.页岩气储层粘土矿物孔隙特征及其甲烷吸附作用[J].地质论评,2015,61(1):207-216. Wang Maozhen,Liu Shaobo,Ren Yongjun,et al.Pore characteristics and methane adsorption of clay minerals in shale gas reservoir [J].Geological Review,2015,61(1):207-216.
[23]	杨锐,何生,胡东风,等.焦石坝地区五峰组—龙马溪组页岩孔隙结构特征及其主控因素[J].地质科技情报,2015,34(5):105-113. Yang Rui,He Sheng,Hu Dongfeng,et al.Characteristics and the main controlling factors of micro-pore structure of the shale in Wufeng Formation-Longmaxi Formation in Jiaoshiba area[J].Geological Science and Technology Information 2015,34(5):105-113.
