鄂尔多斯盆地中元古界烃源岩热演化史模拟

田刚; 宋立军

doi:10.11781/sysydz201704520

鄂尔多斯盆地中元古界烃源岩热演化史模拟

doi: 10.11781/sysydz201704520

田刚,
宋立军^,

西安石油大学地球科学与工程学院, 西安 710065

基金项目: 构造地质与油气资源教育部重点实验室基金项目（TRR-2012-20）资助。

详细信息

作者简介:
田刚(1991—),男,硕士,从事含油气盆地分析研究。E-mail:691561570@qq.com。

通讯作者:
宋立军(1977—),男,副教授,从事盆地分析及构造地质教学与研究。E-mail:8210954@qq.com。

中图分类号: TE122.1
计量
- 文章访问数: 1081
- HTML全文浏览量: 110
- PDF下载量: 288
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-23
- 修回日期: 2017-05-03
- 刊出日期: 2017-07-28

Thermal evolution modeling of Mesoproterozoic source rocks in the Ordos Basin

Tian Gang,
Song Lijun^,

Geosciences and Engineering Faculty, Xi'an Shiyou University, Xi'an, Shaanxi 710065, China

摘要

摘要: 鄂尔多斯盆地中元古界是中国石油长庆油田天然气增储上产的潜在层系，然而长期以来对其内烃源岩热演化史一直缺乏深入研究。以PetroMod盆地模拟软件为工具，在对区内各构造单元岩性、剥蚀厚度、古大地热流值等模拟参数分析的基础上，以实测镜质体反射率（R_o）作为约束，对区内各构造单元中元古界进行热史模拟，分析不同构造单元烃源岩热演化的差异性，并结合含油气系统分析，对有利的勘探区进行了预测。结果表明:（1）盆地中元古代拗拉槽及周缘中元古界烃源岩进入生烃门限时间明显较早；除西缘冲断带中北部之外，其他拗拉槽及周缘处烃源岩各阶段成熟时间也早于其他地区，现今处于生干气阶段；除伊盟隆起地区长城系烃源岩成熟期次都较晚、现今仍处于生湿气阶段外，其他地区基本上于晚二叠世晚期进入生烃门限，现今处于生干气阶段；蓟县系烃源岩于晚二叠世晚期—中三叠世早期先后进入生烃门限，随后受盆地沉积中心不断向西迁移和天环向斜北部、渭北隆起西部早白垩世岩浆岩的侵入影响，烃源岩成熟加快，早白垩世先后进入生干气阶段。（2）渭北隆起中部、天环向斜南部、伊陕斜坡西北部、伊盟隆起中部为有利勘探区，是下一步开展研究的重点区域。
- 热史模拟 /
- 镜质体反射率 /
- 生烃门限 /
- 有利勘探区 /
- 中元古界 /
- 鄂尔多斯盆地
Abstract: The Mesoproterozoic is a potential stratum of gas accumulation and production of the Changqing oil field in the Ordos Basin. However, few recent studies have been made on the thermal evolution history of source rocks.Applying the PetroMod basin modeling software, the thermal evolution histories of the Proterozoic source rocks in each tectonic unit of the study area were simulated taking measured R_o values as calibration and based on the analyses of lithology, erosion thickness restoration and ancient heat flow. The differences of thermal evolution of source rocks in different tectonic units were discussed. Some favorable exploration areas were predicted combining with oil and gas system analyses. The results show that: (1)The hydrocarbon generation threshold of Mesoproterozoic aulacogens and peripheral source rocks is much earlier than others. The maturation stage of other aulacogens and peripheral source rocks is also earlier than others except for the mid-northern part of the western margin thrust belt, and it is in a stage of dry gas generation at present. The source rocks in the Changcheng System reached the hydrocarbon generation threshold at the end of the Late Permian and are generating dry gas now, except for those in the Yimeng uplift, which became mature late and are still generating wet gas. The source rocks in the Jixian System reached the hydrocarbon generation threshold from the end of the Late Permian to the beginning of the Middle Triassic, became mature as the basin depositional center migrated continuously to the west and influenced by intrusions in the northern Tianhuan syncline and western Weibei uplift, and finally entered the dry gas stage in the early Cretaceous. (2)The central area of the Weibei uplift, southern Tianhuan syncline, northwestern Yishan slope,and the central part of the Yimeng uplift in the Ordos Basin are favorable exploration areas.
- thermal history simulation /
- vitrinite reflectance /
- hydrocarbon generation threshold /
- favorable exploration zone /
- Mesoproterozoic /
- Ordos Basin

HTML全文

参考文献(24)

[1]	李荣西,梁积伟,翁凯.鄂尔多斯盆地西南部蓟县系古油藏沥青[J].石油勘探与开发,2011,38(2):168-173. Li Rongxi,Liang Jiwei,Weng Kai.Paleo-reservoir bitumen of middle Proterozoic Jixian system in the southwest margin of the Ordos Basin,China[J].Petroleum Exploration and Development,2011,38(2):168-173.
[2]	郭科.鄂尔多斯地块西缘中晚元古代沉积特征研究[D].西安:西北大学,2015:71-75. Guo Ke.Study of sedimentary characteristics of middle-late Proterozoic in west margin of Ordos block[D].Xi'an:Northwestern University,2015:71-75.
[3]	郭彦如,赵振宇,张月巧,等.鄂尔多斯盆地海相烃源岩系发育特征与勘探新领域[J].石油学报,2016,37(8):939-951. Guo Yanru,Zhao Zhenyu,Zhang Yueqiao,et al.Development characteristics and new exploration areas of marine source rocks in Ordos Basin[J].Acta Petrolei Sinica,2016,37(8):939-951.
[4]	彭胜琴.杭锦旗地区中晚元古界油气地质特征与勘探潜力分析[D].西安:西北大学,2009:55-69. Peng Shengqin.The analyzation of middle-late Proterozoic hydrocarbon geologic feature and exploration potential in Hangjinqi area[D].Xi'an:Northwestern University,2009:55-69.
[5]	Burnham A K,Sweeney J J.A Chemical kinetic model of vitrinite maturation and reflectance[J].Geochimica et Cosmochimica Acta,1989,53(10):2649-2656.
[6]	Sweeney J J,Burnham A K.Evaluation of a simple model of vitrinite reflectance based on chemical kinetics[J].AAPG Bulletin,1990,74(10):1559-1570.
[7]	赵振宇,郭彦如,王艳,等.鄂尔多斯盆地构造演化及古地理特征研究进展[J].特种油气藏,2012,19(5):15-20. Zhao Zhenyu,Guo Yanru,Wang Yan,et al.Study progress in tectonic evolution and paleogeography of Ordos Basin[J].Special Oil & Gas Reservoirs,2012,19(5):15-20.
[8]	李振宏. 鄂尔多斯盆地构造演化与古岩溶储层分布[J].石油与天然气地质, 2010, 31(5): 640-647. Li Zhenhong.Structural evolution and distribution of paleokarst reservoirs in the Ordos Basin[J]. Oil & Gas Geology, 2010, 31(5): 640-647.
[9]	章贵松,孙六一,刘刚,等.鄂尔多斯中—新元古代盆地构造初探[J].低渗透油气田,2015(2):1-4. Zhang Guisong,Sun Liuyi,Liu Gang,et al.An initial survey of the Ordos Basin structure in Mesoproterozoic and Neoproterozoic[J].Low Permeability Oil & Gas Fields,2015(2):1-4.
[10]	郝松立,孙六一,包洪平,等.鄂尔多斯盆地中—新元古界勘探方向及潜力[J].天然气地球科学,2016,27(12):2127-2135. Hao Songli,Sun Liuyi,Bao Hongping,et al.Exploration direction and potential of the Middle-Upper Proterozoic in Ordos Basin[J].Natural Gas Geoscience,2016,27(12):2127-2135.
[11]	宗奕,邹华耀,于开平.辽东湾地区古近系烃源岩热演化模拟[J].天然气工业,2010,30(7):21-24. Zong Yi,Zou Huayao,Yu Kaiping.Thermal evolution simulation of the Paleogene source rocks in the Liaodong Bay area[J].Natural Gas Industry,2010,30(7):21-24.
[12]	任战利,张盛,高胜利,等.鄂尔多斯盆地构造热演化史及其成藏成矿意义[J].中国科学(D辑地球科学),2007,37(S1):23-32. Ren Zhanli,Zhang Sheng,Gao Shengli,et al.Tectonic thermal history and its significance on the formation of oil and gas accumulation and mineral deposit in Ordos Basin[J].Science in China(Series D Earth Sciences),2007,50(S2):27-38.
[13]	任战利,张盛,高胜利,等.鄂尔多斯盆地热演化程度异常分布区及形成时期探讨[J].地质学报,2006,80(5):674-684. Ren Zhanli,Zhang Sheng,Gao Shengli,et al.Research on region of maturation anomaly and formation time in Ordos Basin[J].Acta Geologica Sinica,2006,80(5):674-684.
[14]	任战利.鄂尔多斯盆地热演化史与油气关系的研究[J].石油学报,1996,17(1):17-24. Ren Zhanli.Research on the relations between geothermal history and oil-gas accumulation in the Ordos Basin[J].Acta Petrolei Sinica,1996,17(1):17-24.
[15]	孙少华,刘顺生,汪集暘.鄂尔多斯盆地热流场特征[J].大地构造与成矿学,1996,20(1):29-37. Sun Shaohua,Liu Shunsheng,Wang Jiyang.Characteristics of heat flow field in Ordos Basin[J].Geotectonica et Metallogenia,1996,20(1):29-37.
[16]	赵桂萍.鄂尔多斯盆地杭锦旗地区上古生界烃源岩热演化特征模拟研究[J].石油实验地质,2016,38(5):641-646. Zhao Guiping.Thermal evolution modeling of Neopaleozoic source rocks in Hangjinqi region,Ordos Basin[J].Petroleum Geology & Experiment,2016,38(5):641-646.
[17]	陈瑞银,罗晓容,陈占坤,等.鄂尔多斯盆地中生代地层剥蚀量估算及其地质意义[J].地质学报,2006,80(5):685-693. Chen Ruiyin,Luo Xiaorong,Chen Zhankun,et al.Estimation of denudation thickness of Mesozoic stata in the Ordos Basin and its geological significance[J].Acta Geologica Sinica,2006,80(5):685-693.
[18]	陈瑞银,罗晓容,陈占坤,等.鄂尔多斯盆地埋藏演化史恢复[J].石油学报,2006,27(2):43-47. Chen Ruiyin,Luo Xiaorong,Chen Zhankun,et al.Restoration of burial history of four periods in Ordos Basin[J].Acta Petrolei Sinica,2006,27(2):43-47.
[19]	翁望飞,王建强,张蓉蓉,等.利用声波测井技术计算地层剥蚀厚度:以鄂尔多斯盆地为例[J].新疆石油地质,2011,32(2):143-146. Weng Wangfei,Wang Jianqiang,Zhang Rongrong,et al.Denudation thickness estimation of sedimentary formation in Ordos Basin by acoustic logging information[J].Xinjiang Petroleum Geology,2011,32(2):143-146.
[20]	李超,张立强,张立宽,等.鄂尔多斯盆地镇泾地区中生代地层剥蚀厚度估算及古构造恢复[J].岩性油气藏,2016,28(2):72-79. Li Chao,Zhang Liqiang,Zhang Likuan,et al.Estimation of denudation thickness of Mesozoic strata and paleostructure restoration in Zhenjing area,Ordos Basin[J].Lithologic Reservoirs,2016,28(2):72-79.
[21]	朱定伟,丁文龙,游声刚,等.鄂尔多斯盆地东南部古构造恢复及地质意义[J].特种油气藏,2013,20(1)：48-51. Zhu Dingwei,Ding Wenlong,You Shenggang,et al.Paleostructure restoration and its geological significance of southeast of Ordos Basin[J].Special Oil & Gas Reservoirs,2013,20(1)：48-51.
[22]	王斌,赵永强,罗宇,等.塔里木盆地草湖凹陷热演化与生烃史:基于IES软件盆地模拟技术[J].石油实验地质,2010,32(6):605-609. Wang Bin,Zhao Yongqiang,Luo Yu,et al.Thermal evolution and hydrocarbon generation in the Caohu Sag of the Tarim Basin:Based on IES basin simulation technology[J].Petroleum Geology & Experiment,2010,32(6):605-609.
[23]	阙永泉,郑伦举,承秋泉,等.有机质热解模拟实验残留物镜质体反射率校正研究[J].石油实验地质,2015,37(4):506-511. Que Yongquan,Zheng Lunju,Cheng Qiuquan,et al.Vitrinite reflectance correction of residues in organic matter pyrolysis simulation experiments[J].Petroleum Geology & Experiment,2015,37(4):506-511.
[24]	郭泽清,钟建华,刘卫红,等.应用EASY%R_o法模拟柴达木盆地西部烃源岩成熟史[J].沉积学报,2004,22(1):154-160. Guo Zeqing,Zhong Jianhua,Liu Weihong,et al.Application of EASY%R_o method to simulating maturation history of source rocks in the western Qaidam Basin[J].Acta Sedimentologica Sinica,2004,22(1):154-160.
