有机质反射率的数字图像实现方法

仰云峰; 申宝剑; 腾格尔; 徐二社

doi:10.11781/sysydz201704562

有机质反射率的数字图像实现方法

doi: 10.11781/sysydz201704562

中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126

基金项目: 国家科技重大专项“重点层系页岩气生成与储集机理研究”下属专题“泥页岩成烃生物与烃源品质研究”（2017ZX05036002-003）资助。

详细信息

作者简介:
仰云峰(1982—),男,工程师,从事生烃母质与有机质热演化程度评价、页岩微观孔隙与渗透性及气体在页岩中流动机理研究。E-mail:yangyf.syky@sinopec.com。

中图分类号: TE135
计量
- 文章访问数: 1068
- HTML全文浏览量: 99
- PDF下载量: 293
- 被引次数: 0
出版历程
- 收稿日期: 2016-10-16
- 修回日期: 2017-05-09
- 刊出日期: 2017-07-28

Determination of reflectance of organic matter by digital image processing

Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China

摘要

摘要: 有机质反射率参数是烃源岩评价和盆地热演化史研究的基础数据。目前有机质反射率的测量工作主要依靠人工手动方法，人为主观因素对测量结果影响较大。从图像传感技术出发，探寻镜质体反射率与灰度图像之间的相互关系，尝试建立利用镜质体灰度图像表征反射率值的方法。分别对标准物质和地质样品开展了镜质体反射率和灰度级的对应测量工作，发现两者具有极好的重合特征，表明利用灰度级定量镜质体反射率的方法具有可行性。但对于高过成熟阶段，两者的关系尚有待深化研究。
- 数字图像 /
- 灰度级 /
- 镜质体反射率 /
- 烃源岩评价
Abstract: The reflectance of organic matter is a basic parameter for source rock assessment and thermal evolution history study in a basin. At present, the main technique for reflectance measurement is manual despite heavy operator influence on the results. This paper discussed the relationship between vitrinite reflectance and grey level determination by digital image processing, and tried to determine the vitrinite reflectance by grey level. Simultaneous measurements of vitrinite reflectance values and grey levels were implemented on standard materials and geological samples. The trends of vitrinite reflectance values and grey levels coincide with each other, which demonstrate that it is feasible to quantify the vitrinite reflectance using grey level. For high-over maturity, however, more research is needed.
- digital image /
- grey level /
- vitrinite reflectance /
- source rock evaluation

HTML全文

参考文献(19)

[1]	Tissot B P,Welte D H.Petroleum formation and occurrence:A new approach to oil and gas exploration[M].Berlin Heidelberg:Springer-Verlag,1978.
[2]	ICCP.The new vitrinite classification (ICCP System 1994)[J].Fuel,1998,77(5):349-358.
[3]	Hoffman E,Jenkner A.Die Inkohlung und ihre Erkennung im Mikrobildung[J].Gluckauf,1932,68:81.
[4]	Taylor G H,Teichmuller M,Davis A,et al.Organic petrology[M].Berlin:Gebruder Borntraeger,1998:704.
[5]	Corcoran D V,Doré A G.A review of techniques for the estimation of magnitude and timing exhumation in offshore basins[J].Earth Science Review,2005,72(3/4):129-168.
[6]	Dembicki Jr H.Three common source rock evaluation errors made by geologists during prospect or play appraisals[J].AAPG Bulletin,2009,93(3):341-356.
[7]	Suárez-Ruiz I,Flores D,Mendonça Filho J G,et al.Review and update of the applications of organic petrology:Part 1,geological applications[J].International Journal of Coal Geology,2012,99:54-112.
[8]	傅家谟,贾蓉芬.碳酸岩分散有机质的基本存在形式、演化特征与碳酸岩地层油气评价[J].地球化学,1984(1):1-9. Fu Jiamo,Jia Rongfen.Main forms of disseminated organic matter in carbonate rocks,their evolutionary characteristics and significance in oil-gas evaluation[J].Geochimica,1984(1):1-9.
[9]	国家能源局.沉积岩中镜质体反射率测定方法：SY/T 5124-2012[S].北京:石油工业出版社,2012. National Energy Board.Method of determining microscopically the reflectance of vitrinite in sedimentary:SY/T 5124-2012[S].Beijing:Petroleum Industry Press,2012.
[10]	Hackley P C,Araujo C V,Borrego A G,et al.Standardization of reflectance measurements in dispersed organic matter:Results of an exercise to improve interlaboratory agreement[J].Marine and Petroleum Geology,2015,59:22-34.
[11]	Staplin F L.Sedimentary organic matter,organic metamorphism,and oil and gas occurrence[J].Bulletin of Canadian Petroleum Geology,1969,17(1):47-66.
[12]	Epstein A G,Epstein J B,Harris L D.Conodont color alteration:An index to organic metamorphism[R].U.S.Geological Survey,1977:1-27.
[13]	David P,Fermont W J J.Application of colour image analysis in coal petrology[J].Organic Geochemistry,1993,20(6):747-758.
[14]	Helson S,David P,Fermont W J J.Calibration of conodont color alteration using color image analysis[J].The Journal of Geo-logy,1995,103(3):257-267.
[15]	Yule B,Roberts S,Marshall J E A,et al.Quantitative spore color measurement using colour image analysis[J].Organic Geoche-mistry,1998,28(3/4):139-149.
[16]	金奎励,夏俭.煤组分组定量与镜质组反射率测定的自动化测试[J].煤炭分析及利用,1986(2):12-18. Jin Kuili,Xia Jian.Automated testing of maceral quantification and vitrinite reflectance measurement in coal[J].Coal Analysis and Utilization,1986(2): 12-18.
[17]	孟志强,何虎军,秦鹏,等.VB下识别有机煤岩显微镜图片[J].微计算机信息,2006,22(14):303-304. Meng Zhiqiang,He Hujun,Qin Peng,et al.Identified micrograph of organic anthracology in VB[J].Microcomputer Information,2006,22(14):303-304.
[18]	丁华,张宇宏,白向飞.煤中有机显微组分自动识别初步研究[J].煤质技术,2009(1):1-5. Ding Hua,Zhang Yuhong,Bai Xiangfei.Preliminary research on automatic recognition of organic maceral in coal[J].Coal Quality Technology,2009(1):1-5.
[19]	Gonzalez R C,Woods R E.Digital image processing[M].2nd ed.New Jersey:Prentice Hall,2002:49-57.
