页岩气保存机制探讨

范明; 俞凌杰; 徐二社; 杨振恒; 张文涛; 刘伟新

doi:10.11781/sysydz201801126

页岩气保存机制探讨

doi: 10.11781/sysydz201801126

范明^1,2,
俞凌杰^1,2,
徐二社^1,2,
杨振恒^1,2,
张文涛^1,2,
刘伟新^1,2

1.
中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126
2. 中国石油化工集团公司油气成藏重点实验室, 江苏无锡 214126

基金项目: 国家重点基础研究发展计划（973计划）项目“下古生界油气封盖机理与盖层有效性评价”（2012CB214803）资助。

详细信息

作者简介:
范明(1964-),男,博士,教授级高级工程师,从事实验地质学及页岩气研究工作。E-mail:Fanming.syky@sinopec.com。

中图分类号: TE132.2
计量
- 文章访问数: 1553
- HTML全文浏览量: 135
- PDF下载量: 521
- 被引次数: 0
出版历程
- 收稿日期: 2017-10-11
- 修回日期: 2018-01-02
- 刊出日期: 2018-01-28

Preservation mechanism of Fuling shale gas

1.
Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China
2. SINOPEC Key Laboratory of Petroleum Accumulation Mechanisms, Wuxi, Jiangsu 214126, China

摘要

摘要: 常规天然气与页岩气在储集空间上的本质差别就是孔径或孔隙结构的差异。根据四川盆地涪陵焦石坝地区页岩埋藏史、含气量、生产数据及解吸气同位素分馏这4方面资料，指出页岩气是以单个或多个有机质碎片所形成的连通孔隙网络为单元被保存在页岩中，毛管压力与静水压力是页岩气孔隙压力的保存机制，因此页岩的富气程度不受构造形态或圈闭的控制。构造活动对页岩气保存条件的破坏主要决定于构造升降对静水压力破坏及地质应力对页岩页理面的破坏程度，水平挤压条件下层理面张开所引起的毛管封闭能力下降，导致页岩气散失。而断层往往是应力释放区域，使页理面不会受到进一步的破坏，相反可能对下盘起到保护作用，成为页岩气的有利勘探目标。根据毛管力原理可进一步估算页岩气的可采收率，从而为勘探开发提供指导。
- 含气量 /
- 毛管压力 /
- 超压 /
- 保存条件 /
- 页岩气 /
- 焦石坝地区 /
- 四川盆地
Abstract: The essential difference between conventional gas and shale gas in reservoir space is the difference in pore size or pore structure. The shale burial history, gas content, production data and isotope fractionation of desorbed gas in the Jiaoshiba area of Fuling, Sichuan Province indicate that shale gas was stored in the inter-connected pore units formed by single or multiple organic matter types, and its preservation mechanism was attributed to capillary pressure and static water pressure. Therefore, tectonic structure or trap shape has little impact on shale gas enrichment. The destruction of shale gas preservation conditions by tectonic activity was mainly determined by the decrease of static water pressure caused by tectonic movements, the destruction of lamination caused by geologic stress, and the decrease of capillary sealing ability caused by the opening of lamellae under horizontal compression conditions. Faults releasing tectonic force would not cause further destruction of lamination. On the contrary, they might be helpful for the preservation of a footwall which could be the optimum shale gas target. The recovery ratio of shale gas could be derived from the theory of capillary pressure, which would supply guidance for production.
- gas content /
- capillary pressure /
- overpressure /
- preservation conditions /
- shale gas /
- Jiaoshiba area /
- Sichuan Basin

HTML全文

参考文献(14)

[1]	聂海宽,包书景,高波,等.四川盆地及其周缘下古生界页岩气保存条件研究[J].地学前缘,2012,19(3):280-294. NIE Haikuan,BAO Shujing,GAO Bo,et al.A study of shale gas preservation conditions for the Lower Paleozoic in Sichuan Basin and its periphery[J].Earth Science Frontiers,2012,19(3):280-294.
[2]	张涛,尹宏伟,贾东,等.下扬子区构造变形特征与页岩气保存条件[J].煤炭学报,2013,38(5):883-889. ZHANG Tao,YIN Hongwei,JIA Dong,et al.Structural deformation characteristics and shale gas preservation of Lower Yangtze region[J].Journal of China Coal Society,2013,38(5):883-889.
[3]	李海,白云山,王保忠,等.湘鄂西地区下古生界页岩气保存条件[J].油气地质与采收率,2014,21(6):22-25. LI Hai,BAI Yunshan,WANG Baozhong,et al.Preservation conditions research on shale gas in the Lower Paleozoic of western Hunan and Hubei area[J].Petroleum Geology and Recovery Efficiency,2014,21(6):22-25.
[4]	胡东风,张汉荣,倪楷,等.四川盆地东南缘海相页岩气保存条件及其主控因素[J].天然气工业,2014,34(6):17-23. HU Dongfen,ZHANG Hanrong,NI Kai,et al.Main controlling factors for gas preservation conditions of marine shales in southeastern margins of the Sichuan Basin[J].Natural Gas Industry,2014,34(6):17-23.
[5]	潘仁芳,唐小玲,孟江辉,等.桂中坳陷上古生界页岩气保存条件[J].石油与天然气地质,2014,35(4):534-541. PAN Renfang,TANG Xiaoling,MENG Jianghui,et al.Shale gas preservation conditions for the Upper Paleozoic in Guizhong Depression[J].Oil & Gas Geology,2014,35(4):534-541.
[6]	徐政语,姚根顺,梁兴,等.扬子陆块下古生界页岩气保存条件分析[J].石油实验地质,2015,37(4):407-417. XU Zhengyu,YAO Genshun,LIANG Xing,et al.Shale gas pre-servation conditions in the Lower Paleozoic,Yangtze block[J].Petroleum Geology & Experiment,2015,37(4):407-417.
[7]	张健,刘树根,冉波,等.异常高压与页岩气保存[J].成都理工大学学报(自然科学版),2016,43(2):177-187. ZHANG Jian,LIU Shugen,RAN Bo,et al.Abnormal overpre-ssure and shale gas preservation[J].Journal of Chengdu University of Technology (Science & Technology Edition),2016,43(2):177-187.
[8]	邹才能,陶士振,袁选俊,等."连续型"油气藏及其在全球的重要性:成藏、分布与评价[J].石油勘探与开发,2009,36(6):669-682. ZOU Caineng,TAO Shizhen,YUAN Xuanjun,et al.Global importance of "continuous" petroleum reservoirs:Accumulation, distribution and evaluation[J].Petroleum Exploration and Development,2009,36(6):669-682.
[9]	宋岩,姜林,马行陟.非常规油气藏的形成及其分布特征[J].古地理学报,2013,15(5):605-614. SONG Yan,JIANG Lin,MA Xingzhi.Formation and distribution characteristics of unconventional oil and gas reservoirs[J].Journal of Palaeogeography,2013,15(5):605-614.
[10]	余川,聂海宽,曾春林,等.四川盆地东部下古生界页岩储集空间特征及其对含气性的影响[J].地质学报,2014,88(7):1311-1320. YU Chuan,NIE Haikuan,ZENG Chunlin,et al.Shale reservoir space characteristics and the effect on gas content in Lower Palaeozoic Erathem of the Eastern Sichuan Basin[J].Acta Geologica Sinica,2014,88(7):1311-1320.
[11]	马勇,钟宁宁,程礼军,等.渝东南两套富有机质页岩的孔隙结构特征:来自FIB-SEM的新启示[J].石油实验地质,2015,37(1):109-116. MA Yong,ZHONG Ningning,CHENG Lijun,et al.Pore structure of two organic-rich shales in southeastern Chongqing area:Insight from Focused ion beam scanning electron microscope (FIB-SEM)[J].Petroleum Geology & Experiment,2015,37(1):109-116.
[12]	吴艳艳,曹海虹,丁安徐,等.页岩气储层孔隙特征差异及其对含气量影响[J].石油实验地质,2015,37(2):231-236. WU Yanyan,CAO Haihong,DING Anxu,et al.Pore characteristics of a shale gas reservoir and its effect on gas content[J].Petroleum Geology & Experiment,2015,37(2):231-236.
[13]	魏志红.四川盆地及其周缘五峰组-龙马溪组页岩气的晚期逸散[J].石油与天然气地质,2015,36(4):659-665. WEI Zhihong.Late fugitive emission of shale gas from Wufeng-Longmaxi formation in Sichuan Basin and its periphery[J].Oil & Gas Geology,2015,36(4):659-665.
[14]	刘玉婷.中外页岩气评价标准之比较研究[D].荆州:长江大学,2012. LIU Yuting.The trade-off study on evaluation criterion of domestic and external shale gas[D].Jingzhou:Yangtze University,2012.
