三塘湖盆地牛圈湖油田低孔特低渗储集层特征及形成机理

文静; 杨明; 齐韦林; 姚孟多; 侯全政

doi:10.11781/sysydz201802141

三塘湖盆地牛圈湖油田低孔特低渗储集层特征及形成机理

doi: 10.11781/sysydz201802141

1.
成都理工大学沉积地质研究院, 成都 610059
2. 中国石油吐哈油田公司勘探开发研究院, 新疆哈密 839009
3. 中国石油拉美公司, 委内瑞拉
4. 中国石油吐哈油田公司工程技术研究院, 新疆鄯善 838202

基金项目: 国家科技重大专项“吐哈—三塘湖盆地岩性地层油气藏有利区带预测与目标优选”（2017ZX05001003-007）资助。

详细信息

作者简介:
文静(1983-),女,博士研究生,工程师,从事沉积学、储层精细描述工作。E-mail:wenjing1983426@163.com。

中图分类号: TE122.2
计量
- 文章访问数: 1449
- HTML全文浏览量: 148
- PDF下载量: 164
- 被引次数: 0
出版历程
- 收稿日期: 2017-05-18
- 修回日期: 2018-01-10
- 刊出日期: 2018-03-28

Characteristics and formation mechanism of low porosity and extra-low permeability reservoirs in the Niujuanhu oil field, Santanghu Basin

1.
Institute of Sedimentary Geology, Chengdu University of Technology, Chengdu, Sichuan 610059, China
2. Research Institute of Exploration and Development, Tuha Oil Field Company, PetroChina, Hami, Xinjiang 839009, China
3. CNPC America Ltd, Venezuela
4. Research and Development Center, Tuha Oilfield Company, PetroChina, Shanshan, Xinjiang 839009, China

摘要

摘要: 三塘湖盆地牛圈湖油田西山窑组储集层埋深浅（小于2 000 m），储集层类型却属于低孔特低渗型。为揭示其储集层特征及形成机理，通过岩心观察、铸体薄片鉴定、常规高压压汞实验和电镜扫描等技术，结合区域构造资料分析，进行了储集层特征及低孔特低渗形成机理研究。结果表明：西山窑组储集层以长石岩屑砂岩为主，储集空间类型有原生粒间孔、溶蚀孔及裂缝。沉积、成岩和构造三重因素共同作用，造成了储集层低孔特低渗；西山窑组早期因为含煤地层的酸性环境导致碳酸盐胶结弱，颗粒间缺少支撑而发生较强烈的快速压实，同时沉积作用又从粒径大小和填隙物含量上控制着储集层原始物性特征，成岩过程中发生的压实作用致使减孔率达到18%，酸性环境还导致高岭石的大量形成、石英次生加大边的发育及晚期的含铁质碳酸盐胶结的发育，胶结减孔率为5%左右；构造应力形成的裂缝为后期溶蚀作用的发生提供了一定通道，但岩石已在早期压实作用下基本固结致密，且煤层厚度较薄、酸性流体含量不足，难以在小体积粒间大规模流动，溶解强度不大，导致对渗透率贡献很大的粗喉道较少，形成了低孔特低渗储集层。
- 特低渗 /
- 成岩作用 /
- 构造作用 /
- 形成机理 /
- 西山窑组 /
- 三塘湖盆地
Abstract: The Xishanyao reservoir in the Niujuanhu oil field of Santanghu Basin, though shallow (usually less than 2 000 m), is a low porosity and ultra-low permeability reservoir.The reservoir characteristics and the causes for low porosity and ultra-low permeability were studied by using core and cast thin section observations, conventional high pressure mercury injection experiments, SEM, and combined with regional tectonic data. The Xishanyao Formation was mainly composed of feldspar lithic sandstones. The reservoir includes intergranular pores, dissolution pores and fractures. Sedimentation, diagenesis and tectonic effects resulted in low porosity and ultra-low permeability. During the early deposition period of Xishanyao Formation, carbonate cementation was weak due to the acidic environment of coal-bearing formations.A strong and rapid compaction occurred due to the lack of support between particles. At the same time, sedimentation also controlled the original physical properties of the reservoir from the size of particle and the content of capping agent. The compaction effect during diagenesis led to a porosity reduction of 18%, and the acidic environment also led to a large amount of kaolinite formation, quartz secondary growth and the development of late iron-rich carbonate cementation with a cementing porosity rate of about 5%. The cracks formed by tectonic stress provided channels for late stage dissolution. However, rocks have become consolidated due to early compaction. What's more, the coal seam is thin, and the acidic fluid is not enough to flow in large scale through small particles, leading to poor dissolution strength. As a result, coarse throats which have a great contribution to permeability generated little, and a reservoir with low porosity and ultra-low permeability was formed.
- ultra-low permeability /
- diagenesis /
- tectonic effect /
- formation mechanism /
- Xishanyao Formation /
- Santanghu Basin

HTML全文

参考文献(30)

[1]	马瑶,李文厚,欧阳征健,等.鄂尔多斯盆地南梁西区长6油层组砂岩低孔超低渗储集层特征及主控因素[J].地质通报,2013,32(9):1471-1476. MA Yao,LI Wenhou,OUYANG Zhengjian,et al.Reservoir characteristics and main control factors of Chang 6 oil-bearing formation in western Nanliang area of Ordos Basin[J].Geological Bulletin of China,2013,32(9):1471-1476.
[2]	谢锐杰,漆家福,杨桥.东营凹陷北带构造特征及其对沉积作用的控制[J].石油天然气学报,2004,26(1):17-19. XIE Ruijie,QI Jiafu,YANG Qiao.Structural characteristics and its control to deposition in the north of Dongying Depression[J].Journal of Jianghan Petroleum Institute,2004,26(1):17-19.
[3]	DENNEY D.Evaluating implications of hydraulic fracturing in shale-gas reservoirs[J].Journal of Petroleum Technology,2015,61(8):53-54.
[4]	JIN M D,WEI Z,TAN X C,et al.Characteristics and controlling factors of beach-controlled karst reservoirs in Cambrian Longwangmiao Formation,Moxi-Gaoshiti area,Sichuan Basin,NW China[J].Petroleum Exploration and Development,2014,41(6):712-723.
[5]	TOBIN R C,MCCLAIN T,LIEBER R B,et al.Reservoir quality modeling of tight-gas sands in Wamsutter Field:Integration of diagenesis,petroleum systems,and production[J].AAPG Bulletin,2010,94(8):1229-1266.
[6]	李道品.低渗透砂岩油田开发[M].北京:石油工业出版社,1997:5-8. LI Daopin.The development of the low permeability sandstone oil field[M].Beijing:Petroleum Industry Press,1997:5-8.
[7]	赵泽辉,郭召杰,张臣,等.新疆东部三塘湖盆地构造演化及其石油地质意义[J].北京大学学报,2003,39(2):219-228. ZHAO Zehui,GUO Zhaojie,ZHANG Chen,et al.Tectonic evolution of the Santanghu Basin,east Xinjiang and its implication for the hydrocarbon accumulation[J].Acta Scicentiarum Naturalum Universitis Pekinesis,2003,39(2):219-228.
[8]	朱筱敏,康安,王贵文,等.三塘湖盆地侏罗系辫状河三角洲沉积特征[[J].石油大学学报:自然科学版,1998,22(1):14-17. ZHU Xiaomin,KANG An,WANG Guiwen,et al.Sedimentary characteristics of Jurassic braid delta in Santanghu Basin[J].Journal of the University of Petroleum,China,1998,22(1):14-17.
[9]	李佳鸿,宋新民,王友净,等.安塞油田王窑老区特低渗透油藏储层厚砂体精细解剖[J].地质科技情报,2014,33(1):129-136. LI Jiahong,SONG Xinmin,WANG Youjing,et al.Configuration delineation of thick sandbody within ultra-low permeability reservoir,Wangyaolaoqu,Ansai oilfield[J].Geological Science and Technology Information,2014,33(1):129-136.
[10]	高辉,敬晓锋,张兰.不同孔喉匹配关系下的特低渗透砂岩微观孔喉特征差异[J].石油实验地质,2013,35(4):401-406. GAO Hui,JING Xiaofeng,ZHANG Lan.Difference of micro-pore throat characteristics in extra-low permeability sandstone of dif-ferent pore throat matching relationship[J].Petroleum Geology & Experiment,2013,35(4):401-406.
[11]	国家能源局.SY/T6285-2011油气储层评价方法[S].北京:石油工业出版社,2011. National Energy Agency.SY/T6285-2011 Evaluating methods of oil and gas reservoirs[S].Beijing:Petroleum Industry Press,2011.
[12]	王黎,王果寿,谢锐杰,等.苏北盆地溱潼凹陷俞垛-华庄地区沉积微相类型及特征[J].石油实验地质,2014,36(1):51-55. WANG Li, WANG Guoshou, XIE Ruijie,et al.Sedimentary microfacies types and features in Yuduo-Huazhuang area, Qintong Sag, Northern Jiangsu Basin[J].Petroleum Geology & Experiment,2014,36(1):51-55.
[13]	POURSOLTANI M R,GIBLING M R.Composition,porosity,and reservoir potential of the Middle Jurassic Kashafrud Formation,northeast Iran[J].Marine and Petroleum Geology,2011,28(5):1092-1110.
[14]	ARMSTRONG-ALTRIN J S,MADHAVARAJU J,SIAL A N,et al.Petrography and stable isotope geochemistry of the Cretaceous El Abra Limestones (Actopan),Mexico:Implication on diagenesis[J].Journal of the Geological Society of India,2011,77(4):349-359.
[15]	JONK R,HURST A,DURANTI D,et al.Orgin and timing of sand injection,petroleum migration,and diagenesis of Tertiary reservoirs,South Viking Graben,North Sea[J].AAPG Bulletin,2005,89(3):329-357.
[16]	谢玉洪,张亚,张哨楠,等.莺歌海盆地东方区黄流组低渗储集层特征及影响因素分析[J].石油实验地质,2015,37(5):541-547. XIE Yuhong,ZHANG Ya,ZHANG Shaonan,et al.Structural characteristics of micro-pores and factors controlling low-permeability reservoirs in the Huangliu Formation in the Dongfang area,Yinggehai Basin[J].Petroleum Geology & Experiment,2015,37(5):541-547.
[17]	许建红.低渗透油藏产能主要影响因素分析与评价[J].西南石油大学学报(自然科学版),2012,34(2):144-148. XU Jianhong.Main influence factor analysis and evaluation of the productivity in low permeability oil reservoirs[J].Journal of Southwest Petroleum University (Science and Technology Edition),2012,34(2):144-148.
[18]	EL-KHATRI F,EL-GHALI M A K,MANSURBEG H,et al.Impact of diagenetic alterations and reservoir quality evolution of Lower Cretaceous fluvial sandstones of the Nubian Formation,Sirt Basin,northern Libya[J].Journal of Petroleum Geology,2013,38(2):217-239.
[19]	MORAD S,AL-RAMADAN K,KETZER J M,et al.The impact of diagenesis on the heterogeneity of sandstone reservoirs:A review of the role of depositional facies and sequence stratigraphy[J].AAPG Bulletin,2010,94(8):1267-1309.
[20]	朱筱敏,李亚辉,张义娜,等.苏北盆地东南部泰州组砂岩储层孔隙类型及有利储集层评价[J].地球科学与环境学报,2011,33(3):246-252. ZHU Xiaomin,LI Yahui,ZHANG Yina,et al.Pore types of sandstone reservoir and evaluation of favorable reservoir of Taizhou Formation in eastern Subei Basin[J].Journal of Earth Sciences and Environment,2011,33(3):246-252.
[21]	李莹,马明永.南华北盆地周口坳陷二叠系砂岩储层岩石学特征及成岩作用研究[J].石油实验地质,2013,35(6):640-645. LI Ying,MA Mingyong.Petrography and diagenesis of Permian sandstone reservoirs in Zhoukou Depression, Southern North China Basin[J].Petroleum Geology & Experiment,2013,35(6):640-645.
[22]	DOS ANJOS S M C,DE ROS L F,DE SOUZA R S,et al.Depositional and diagenetic controls on the reservoir quality of Lower Cretaceous Pendencia sandstones,Potiguar rift basin,Brazil[J].AAPG Bulletin,2000,84(11):1719-1742.
[23]	张育民,李红,朱玉双.新疆三塘湖盆地沉积成岩作用研究[J].西北大学学报(自然科学版)2005,35(6):793-798. ZHANG Yumin,LI Hong,ZHU Yushuang.A study on sedimentary diagenesis in Santanghu Basin in Xinjiang[J].Journal of Northwest University (Natural Science Edition),2005,35(6):793-798.
[24]	BEARD D C,WEYL P K.Influence of texture on porosity and permeability of unconsolidated sand[J].AAPG Bulletin,1973,57(2):349-369.
[25]	朱筱敏,米立军,钟大康,等.济阳坳陷古近系成岩作用及其对储层质量的影响[J].古地理学报,2006,8(3):295-305. ZHU Xiaomin,MI Lijun,ZHONG Dakang,et al.Paleogene diagenesis and its control on reservoir quality in Jiyang Depression[J].Journal of Palaeogeography,2006,8(3):295-305.
[26]	王永建,王延斌.大牛地气田上古生界低渗储集层综合评价[J].西南石油大学学报(自然科学版),2013,35(5):57-64. WANG Yongjian,WANG Yanbing.Comprehensive evaluation of lower porosity and permeability reservoir in Upper Paleozoic of Daniudi gas field[J].Journal of Southwest Petroleum University (Science and Technology Edition),2013,35(5):57-64.
[27]	钟大康,张崇军,文应初.砂岩储集层物性影响因素定量分析方法[J].石油与天然气地质,2000,21(2):130-132. ZHONG Dakang,ZHANG Chongjun,WEN Yingchu.Quantitative analysis method of factors affecting physical properties for sandstone reservoirs[J].Oil & Gas Geology,2000,21(2):130-132.
[28]	时建超.牛圈湖油田低渗透储层特征及对产能影响研究[D].西安:西北大学,2014. SHI Jianchao.Research on the characteristics of low-permeability reservoir and its influence on productivity in Niujuanhu oil field[D].Xi'an:Northwest University,2014.
[29]	操应长,远光辉,王艳忠,等.准噶尔盆地北三台地区清水河组低渗透储集层成因机制[J].石油学报,2012,33(5):758-771. CAO Yingchang,YUAN Guanghui,WANG Yanzhong,et al.Genetic mechanisms of low permeability reservoirs of Qingshuihe Formation in Beisantai area,Junggar Basin[J].Acta Petrolei Sinica,2012,33(5):758-771.
[30]	蒋凌志,顾家裕,郭彬程.中国含油气盆地碎屑岩低渗透储集层的特征及形成机理[J].沉积学报,2004,22(1):13-18. JIANG Lingzhi,GU Jiayu,GUO Bincheng.Characteristics and mechanism of low permeability clastic reservoir in Chinese petro-liferous basin[J].Acta Sedimentologica Sinica,2004,22(1):13-18.
