黔南坳陷下石炭统摆佐组暗色页岩热演化与生烃史研究

宋颖睿; 侯宇光; 刘宇坤; 何生; 范志伟; 梁雅琪

doi:10.11781/sysydz201802226

黔南坳陷下石炭统摆佐组暗色页岩热演化与生烃史研究

doi: 10.11781/sysydz201802226

1.
中国地质大学构造与油气资源教育部重点实验室, 武汉 430074
2. 中国石化勘探分公司, 成都 610041
3. 湖北省地质实验测试中心, 武汉 430034

基金项目: 国家自然科学基金项目（41772143，41302111）、“十三五”国家科技重大专项（2016ZX05034002-003）和政府间国际科技创新合作重点专项“中美石炭—二叠系页岩储层评价技术合作研究”（2017YFE0106300）资助。

详细信息

作者简介:
宋颖睿(1996-),女,从事页岩油气地质评价、石油地质方面的研究。E-mail:1996syr@sina.com。

通讯作者:
侯宇光(1979-),男,副教授,从事油气成藏、非常规油气地质方面的研究和教学工作。E-mail:sporthyg@126.com。

中图分类号: TE122.113
计量
- 文章访问数: 1108
- HTML全文浏览量: 107
- PDF下载量: 153
- 被引次数: 0
出版历程
- 收稿日期: 2017-07-03
- 修回日期: 2018-01-30
- 刊出日期: 2018-03-28

Thermal evolution and hydrocarbon generation histories of black shale in Lower Carboniferous Baizuo Formation, Southern Guizhou Depression

1.
Key Laboratory of Tectonics and Petroleum Resources of Ministry of Education, China University of Geosciences(Wuhan), Wuhan, Hubei 430074, China
2. SINOPEC Petroleum Exploration Branch Company, Chengdu, Sichuan 610041, China
3. Geological Experimental Testing Center of Hubei Province, Wuhan, Hubei 430034, China

摘要

摘要: 为了对黔南坳陷下石炭统摆佐组暗色页岩的生烃能力进行评估，利用油气地质、地球化学资料分析以及含油气系统模拟技术等方法，对其热演化-成熟历史和生烃演化的过程进行了重建。研究表明：摆佐组页岩具有较高的有机质丰度和较低的生烃潜量，有机质类型主要为Ⅱ₂型，已经达到高-过成熟阶段；摆佐组页岩从中石炭世（约312 Ma）开始进入生烃门限，在早三叠世（约238 Ma）进入过成熟阶段，在早侏罗世（约196 Ma）达到最大埋深9 000 m，最高温度约为200℃；摆佐组页岩分别在二叠纪中期（291~270 Ma）和三叠纪后期（262~208 Ma）达到生油和生气高峰；高演化背景下的油裂解气过程，可为摆佐组页岩气的富集提供充足的甲烷气和存储空间，然而196 Ma以来的构造抬升剥蚀对页岩气的保存具有一定的破坏作用。
- 热演化 /
- 生烃能力 /
- 页岩气 /
- 下石炭统 /
- 黔南坳陷
Abstract: The thermal evolution and hydrocarbon generation histories of the Lower Carboniferous Baizuo Formation in the Southern Guizhou Depression were studied with petroleum geology, geochemical data and petroleum system simulation in order to evaluate the hydrocarbon generation potential of black shale. Results showed that the black shale of the Baizuo Formation has relatively high organic matter abundance and low hydrocarbon potential. The organic matter in the black shale is mainly of type Ⅱ₂, and has reached the high-maturity and over-mature stages. The black shale entered the threshold of hydrocarbon generation during the Middle Carboniferous (about 312 Ma) and the mature stage in the early Triassic (about 238 Ma), and reached the maximum burial depth (about 9 000 m) in the early Jurassic (196 Ma), with a maximum temperature of about 200℃. They reached the oil generation peak in the Middle Permian (291-270 Ma) and the gas generation peak in the Late Triassic (262-208 Ma), respectively. The process of oil cracking to gas during the high thermal evolution provided sufficient methane gas and storage space for shale gas enrichment. However, tectonic uplift and erosion since 196 Ma had a certain destructive influence on shale gas enrichment.
- thermal evolution /
- hydrocarbon generation capacity /
- shale gas /
- Lower Carboniferous /
- Southern Guizhou Depression

HTML全文

参考文献(32)

[1]	MASTALERZ M,SCHIMMELMANN A,DROBNIAK A,et al.Porosity of Devonian and Mississippian New Albany shale across a maturation gradient:Insights from organic petrology,gas adsorption,and mercury intrusion[J].AAPG Bulletin,2013,97(10):1621-1643.
[2]	MILLIKEN K L,RUDNICKI M,AWWILLER D N,et al.Organic matter-hosted pore system,Marcellus Formation (Devonian),Pennsylvania[J].AAPG Bulletin,2012,97(2):177-200.
[3]	吉利明,吴远东,贺聪,等.富有机质泥页岩高压生烃模拟与孔隙演化特征[J].石油学报,2016,37(2):172-181. JI Liming,WU Yuandong,HE Cong,et al.High-pressure hydrocarbon-generation simulation and pore evolution characteristics of organic-rich mudstone and shale[J].Acta Petrolei Sinica,2016,37(2):172-181.
[4]	马中良,郑伦举,徐旭辉,等.富有机质页岩有机孔隙形成与演化的热模拟实验[J].石油学报,2017,38(1):23-30. MA Zhongliang,ZHENG Lunju,XU Xuhui,et al.Thermal simulation experiment on the formation and evolution of organic pores in organic-rich shale[J].Acta Petrolei Sinica,2017,38(1):23-30.
[5]	CHEN J,XIAO X M.Evolution of nanoporosity in organic-rich shales during thermal maturation[J].Fuel,2014,129:173-181.
[6]	张金川,徐波,聂海宽,等.中国页岩气资源勘探潜力[J].天然气工业,2008,28(6):136-140. ZHANG Jinchuan,XU Bo,NIE Haikuan,et al.Exploration potential of shale gas resources in China[J].Natural Gas Industry,2008,28(6):136-140.
[7]	赵文智,李建忠,杨涛,等.中国南方海相页岩气成藏差异性比较与意义[J].石油勘探与开发,2016,43(4):499-510. ZHAO Wenzhi,LI Jianzhong,YANG Tao,et al.Geological diffe-rence and its significance of marine shale gases in South China[J].Petroleum Exploration & Development,2016,43(4):499-510.
[8]	董大忠,王玉满,李新景,等.中国页岩气勘探开发新突破及发展前景思考[J].天然气工业,2016,36(1):19-32. DONG Dazhong,WANG Yuman,LI Xinjing,et al.Breakthrough and prospect of shale gas exploration and development in China[J].Natural Gas Industry,2016,36(1):19-32.
[9]	徐政语,姚根顺,郭庆新,等.黔南坳陷构造变形特征及其成因解析[J].大地构造与成矿学,2010,34(1):20-31. XU Zhengyu,YAO Genshun,GUO Qingxin,et al.Genetic interpretation about geotectonics and structural transfiguration of the Southern Guizhou Depression[J].Geotectonica et Metallogenia,2010,34(1):20-31.
[10]	张江江.黔南坳陷构造演化研究[D].青岛:中国石油大学(华东),2010. ZHANG Jiangjiang.The research of tectonic evolution in Southern Guizhou Depression[D].Qingdao:China University of Petroleum (East China),2010.
[11]	白森舒,彭金宁,刘光祥,等.黔南安顺凹陷油气成藏特征及勘探潜力分析[J].石油实验地质,2013,35(1):24-28. BAI Senshu,PENG Jinning,LIU Guangxiang,et al.Hydrocarbon accumulation features and exploration potentials in Anshun Sag,Southern Guizhou Depression[J].Petroleum Geology & Experiment,2013,35(1):24-28.
[12]	徐思煌,马永生,梅廉夫,等.中国南方典型气(油)藏控藏模式探讨[J].石油实验地质,2007,29(1):19-24. XU Sihuang,MA Yongsheng,MEI Lianfu,et al.Natural gas models controlled by graded multi-factors in marine sequences of South China[J].Petroleum Geology & Experiment,2007,29(1):19-24.
[13]	HOU Y G,LIANG Y Q,HE S,et al.Distribution and thermal maturity of Devonian carbonate reservoir solid bitumen in Desheng area of Guizhong Depression,South China[J].Geofluids,2017,2017:4580416.
[14]	张渠,腾格尔,张志荣,等.凯里-麻江地区油苗与固体沥青的油源分析[J].地质学报,2007,81(8):1118-1124. ZHANG Qu,TENGER,ZHANG Zhirong,et al.Oil source of oil seepage and solid bitumen in the Kaili-Majiang area[J].Acta Geologica Sinica,2007,81(8):1118-1124.
[15]	李梅.黔南桂中坳陷水文地质地球化学与油气保存条件研究[D].杭州:浙江大学,2011. LI Mei.Hydrogeology-geochemistry characteristics and the conditions of hydrocarbon preservation in Qiannan-Guizhong Depression[D].Hangzhou:Zhejiang University,2011.
[16]	王伟锋,周维维,徐政语.黔南坳陷构造变形特征及稳定区块评价[J].中国矿业大学学报,2014,43(2):255-261. WANG Weifeng,ZHOU Weiwei,XU Zhengyu.Deformation characteristics and stability zones evaluation in the Southern Guizhou Depression[J].Journal of China University of Mining & Techno-logy,2014,43(2):255-261.
[17]	梁秋原,赵泽恒,李小平.贵州黔南坳陷安顺斜坡油气地质特征及勘探潜力[J].新疆地质,2010,28(3):311-315. LIANG Qiuyuan,ZHAO Zeheng,LI Xiaoping.Geological characteristic and exploration potential of the oil gas at Anshun slope of depression in the south of Guizhou Province[J].Xinjiang Geology,2010,28(3):311-315.
[18]	杨振恒,李志明,沈宝剑,等.页岩气成藏条件及我国黔南坳陷页岩气勘探前景浅析[J].中国石油勘探,2009(3):24-28. YANG Zhenheng,LI Zhiming,SHEN Baojian,et al.Shale gas accumulation conditions and exploration prospect in Southern Guizhou Depression[J].China Petroleum Exploration,2009(3):24-28.
[19]	王鹏万,徐政语,陈子炓,等.黔南拗陷构造变形特征与油气保存有利区评价[J].西南石油大学学报(自然科学版),2010,32(5):36-40. WANG Pengwan,XU Zhengyu,CHEN Ziliao,et al.The tectonic deformation features and the evaluation of the favorable region for hydrocarbon conservation[J].Journal of Southwest Petroleum University (Science & Technology Edition),2010,32(5):36-40.
[20]	胡见义,黄第藩.中国陆相石油地质理论基础[M].北京:石油工业出版社,1991. HU Jianyi,HUANG Difan.The bases of nonmarine petroleum geology in China[M].Beijing:Petroleum Industry Press,1991.
[21]	秦建中.中国烃源岩[M].北京:科学出版社,2005. QIN Jianzhong.Source rocks of China[M].Beijing:Science Press,2005.
[22]	SWEENEY J J,BURNHAM A K.Evaluation of a simple model of vitrinite reflectance based on chemical kinetics[J].AAPG Bulletin,1990,74(10):1559-1570.
[23]	BURNHAM A K,SWEENEY J J.A chemical kinetic model of vitrinite maturation and reflectance[J].Geochimica et Cosmochimica Acta,1989,53(10):2649-2657.
[24]	袁玉松,马永生,胡圣标,等.中国南方现今地热特征[J].地球物理学报,2006,49(4):1118-1126. YUAN Yusong,MA Yongsheng,HU Shengbiao,et al.Present-day geothermal characteristics in South China[J].Chinese Journal of Geophysics,2006,49(4):1118-1126.
[25]	汪洋,邓晋福,汪集旸,等.中国大陆热流分布特征及热-构造分区[J].中国科学院研究生院学报,2001,18(1):51-58. WANG Yang,DENG Jinfu,WANG Jiyang,et al.Terrestrial heat flow pattern and thermo-tectonic domains in the continental area of China[J].Journal of the Graduate School of the Chinese Academy of Sciences,2001,18(1):51-58.
[26]	何斌,徐义刚,王雅玫,等.东吴运动性质的厘定及其时空演变规律[J].地球科学(中国地质大学学报),2005,30(1):89-96. HE Bin,XU Yigang,WANG Yamei,et al.Nature of the Dongwu Movement and its temporal and spatial evolution[J].Earth Science(Journal of China University of Geosciences),2005,30(1):89-96.
[27]	朱传庆,徐明,单竞男,等.利用古温标进行剥蚀量恢复的综合方法:以四川盆地为例[J].中国地质,2013,36(6):1268-1275. ZHU Chuanqing,XU Ming,SHAN Jingnan,et al.Quantifying the denudations of major tectonic events in Sichuan Basin:Constrained by the paleothermal records[J].Geology in China,2013,36(6):1268-1275.
[28]	李双建,肖开华,汪新伟,等.南方志留系碎屑矿物热年代学分析及其地质意义[J].地质学报,2008,82(8):1068-1076. LI Shuangjian,XIAO Kaihua,WANG Xinwei,et al.Thermochronology of detrital minerals in the Silurian strata from Southern China and its geological implications[J].Acta Geologica Sinica,2008,82(8):1068-1076.
[29]	郭小文.含油气盆地生烃增压演化研究:以东营凹陷和白云凹陷为例[D].武汉:中国地质大学,2010. GUO Xiaowen.Overpressure evolution caused by hydrocarbon generation in petroliferous basins:Two cases studies from Dongying and Baiyun depressions[D].Wuhan:China University of Geosciences,2010.
[30]	贺训云,蔡春芳,姚根顺,等.黔南坳陷油苗来源:碳、硫同位素及生物标志物证据[J].岩石学报,2013,29(3):1059-1072. HE Xunyun,CAI Chunfang,YAO Genshun,et al.Origins of oil seepages in the Southern Guizhou Depression,SW China:Evidence from carbon isotopes,sulfur isotopes and biomarkers[J].Acta Petrologica Sinica,2013,29(3):1059-1072.
[31]	张本杰,秦琴,刘甲,等.黔西南晴页2井旧司组页岩特征及勘探意义[J].天然气技术与经济,2016,10(4):19-22. ZHANG Benjie,QIN Qin,LIU Jia,et al.Shale characteristics and prospecting significance of Jiusi Formation for Qingye 2 well,SW Guizhou Province[J].Natural Gas Technology and Economy,2016,10(4):19-22.
[32]	HOU Y G,HE S,YI J Z,et al.Effect of pore structure on methane sorption potential of shales[J].Petroleum Exploration and Deve-lopment,2014,41(2):272-281.
