渤海湾盆地东营凹陷古近系页岩油主要赋存空间探索

包友书

doi:10.11781/sysydz201804479

渤海湾盆地东营凹陷古近系页岩油主要赋存空间探索

doi: 10.11781/sysydz201804479

包友书

中国石化胜利油田分公司勘探开发研究院, 山东东营 257015

基金项目:

国家重点基础研究发展计划（973计划）项目（2014CB239100）、国家科技重大专项（2016ZX05006-001，2017ZX05049-004）和中石化科技公关项目（P15117）共同资助。

详细信息

作者简介:
包友书(1972-),男,高级工程师,从事石油地质及地球化学研究工作。E-mail:baoyoushu@126.com。

中图分类号: TE132.2
计量
- 文章访问数: 2175
- HTML全文浏览量: 171
- PDF下载量: 248
- 被引次数: 0
出版历程
- 收稿日期: 2017-10-18
- 修回日期: 2018-05-25
- 刊出日期: 2018-07-28

Effective reservoir spaces of Paleogene shale oil in the Dongying Depression, Bohai Bay Basin

BAO Youshu

Exploration and Development Research Institute of SINOPEC Shengli Oilfield Company, Dongying, Shandong 257015, China

摘要

摘要: 以GRI孔隙度和含油饱和度测定、高压压汞分析和地球化学测试为基础，建立了页岩油有效赋存空间的研究方法，并探索了东营凹陷古近系泥页岩孔径分布特征、含油孔径下限以及可动油赋存的有利物性条件。孔隙度与孔径分布关系表明，东营凹陷古近系泥页岩的孔隙度与10 nm以下孔隙所占比例负相关，与10 nm以上孔隙所占比例正相关，10 nm以上孔径的孔隙则是较高孔隙度泥页岩孔隙的重要贡献者；含油饱和度与不同孔径孔隙所占比例关系表明，古近系泥页岩中的油主要赋存在10 nm以上孔径的孔隙中；OSI指数与孔隙度关系表明，孔隙度在6.5%以上，且在生油窗范围内的泥页岩，是可动页岩油的有利储层。
- 含油饱和度 /
- 含油孔径下限 /
- 可动油 /
- 高压压汞 /
- 页岩油 /
- 古近系 /
- 东营凹陷 /
- 渤海湾盆地
Abstract: A comprehensive research method to determine effective reservoir spaces of shale oil was formulated based on GRI shale porosity and oil saturation testing, high-pressure mercury injection and geochemical analysis. The pore size distribution, the smallest pore diameter limit for oil occurrence, and the porosity condition for recoverable oil from the Paleogene shale in the Dongying Depression were discussed. The relationship between porosity and pore size distribution showed that shale porosity is negatively correlated to the volume portion of pores smaller than 10 nm (diameter), while positively correlated to the volume of pores with diameter larger than 10 nm, and that the pores wider than 10 nm are the critical contributor to the reservoir space of high-porosity shale. Shale oil mainly exists in pores wider than 10 nm. The statistical relationship between OSI (Oil Saturation Index) and porosity showed that the shale with a porosity above 6.5% is favorable for the occurrence of recoverable oil.
- oil saturation /
- lowest pore size limit for oil occurrence /
- recoverable oil /
- high pressure mercury injection /
- shale oil /
- Paleogene /
- Dongying Depression /
- Bohai Bay Basin

HTML全文

参考文献(22)

[1]	HILL R J,JARVIE D M,ZUMBERGE J,et al.Oil and gas geochemistry and petroleum systems of the Fort Worth Basin[J].AAPG Bulletin,2007,91(4):445-473.
[2]	MILLER B A,PANEITZ J M,MULLEN M J,et al.The successful application of a compartmental completion technique used to isolate multiple hydraulic-fracture treatments in horizontal Bakken shale wells in North Dakota[C]//SPE Annual Technical Conference and Exhibition.Denver:SPE,2008.
[3]	BAZAN L W,LARKIN S D,LATTIBEAUDIERE M G,et al.Improving production in the Eagle Ford Shale with fracture modeling,increased fracture conductivity,and optimized stage and cluster spacing along the horizontal wellbore[C]//Tight Gas Completions Conference.Texas:SPE,2010.
[4]	张林晔,李政,李钜源,等.东营凹陷古近系泥页岩中存在可供开采的油气资源[J].天然气地球科学,2012,23(1):1-13. ZHANG Linye,LI Zheng,LI Juyuan,et al.Feasibility analysis of existing recoverable oil and gas resource in the Palaeogene shale of Dongying Depression[J].Natural Gas Geoscience,2012,23(1):1-13.
[5]	张善文,王永诗,张林晔,等.济阳坳陷渤南洼陷页岩油气形成条件研究[J].中国工程科学,2012,14(6):49-55. ZHANG Shanwen,WANG Yongshi,ZHANG Linye,et al.Formation conditions of shale oil and gas in Bonan Sub-sag,Jiyang Depression[J].Engineering Sciences,2012,14(6):49-55.
[6]	ZHANG Linye,BAO Youshu,LI Juyuan,et al.Movability of lacustrine shale oil:A case study of Dongying Sag,Jiyang Depression,Bohai Bay Basin[J].Petroleum Exploration and Development,2014,41(6):703-711.
[7]	谢晓永,唐洪明,王春华,等.氮气吸附法和压汞法在测试泥页岩孔径分布中的对比[J].天然气工业,2006,26(12):100-102. XIE Xiaoyong,TANG Hongming,WANG Chunhua,et al.Contrast of nitrogen adsorption method and mercury porosimetry method in analysis of shale's pore size distribution[J].Natural Gas Industry,2006,26(12):100-102.
[8]	JOUINI M S,VEGA S,MOKHTAR E A.Multiscale characterization of pore spaces using multifractals analysis of scanning electronic microscopy images of carbonates[J].Nonlinear Processes in Geophysics,2011,18(6):941-953.
[9]	邹才能,朱如凯,白斌,等.中国油气储层中纳米孔首次发现及其科学价值[J].岩石学报,2011,27(6):1857-1864. ZOU Caineng,ZHU Rukai,BAI Bin,et al.First discovery of nano-pore throat in oil and gas reservoir in China and its scientific value[J].Acta Petrologica Sinca,2011,27(6):1857-1864.
[10]	JOOS J,CARRARO T,WEBER A,et al.Reconstruction of porous electrodes by FIB/SEM for detailed microstructure modeling[J].Journal of Power Sources,2011,196(17):7302-7307.
[11]	崔景伟,邹才能,朱如凯,等.页岩孔隙研究新进展[J].地球科学进展,2012,27(12):1319-1325. CUI Jingwei,ZOU Caineng,ZHU Rukai,et al.New advances in shale porosity research[J].Advances in Earth Science,2012,27(12):1319-1325.
[12]	周闻达,王莹,鲍征宇,等.等温吸附法在页岩孔隙结构测试中的应用[J].科技通报,2015,31(1):12-18. ZHOU Wenda,WANG Ying,BAO Zhengyu,et al.The application of isotherm adsorption in measuring the shale pore structure[J].Bulletin of Science and Technology,2015,31(1):12-18.
[13]	公言杰,柳少波,赵孟军,等.核磁共振与高压压汞实验联合表征致密油储层微观孔喉分布特征[J].石油实验地质,2016,38(3):389-394. GONG Yanjie,LIU Shaobo,ZHAO Mengjun,et al.Characterization of micro pore throat radius distribution in tight oil reservoirs by NMR and high pressure mercury injection[J].Petroleum Geology & Experiment,2016,38(3):389-394.
[14]	宋磊,宁正福,孙一丹,等.联合压汞法表征致密油储层孔隙结构[J].石油实验地质,2017,39(5):700-705. SONG Lei,NING Zhengfu,SUN Yidan,et al.Pore structure characterization of tight oil reservoirs by a combined mercury method[J].Petroleum Geology & Experiment,2017,39(5):700-705.
[15]	张守鹏,方正伟,杨诗棣,等.全直径油气储层岩心三维可视化信息采集方法及应用前景[J].石油实验地质,2017,39(5):706-710. ZHANG Shoupeng,FANG Zhengwei,YANG Shidi,et al.Technique and application of three-dimensional visualized information collection of full diameter oil and gas reservoir cores[J].Petroleum Geology & Experiment,2017,39(5):706-710.
[16]	GUIDRY K,LUFFEL D,CURTIS J.Development of laboratory and petrophysical techniques for evaluating shale reservoirs.Final technical report,October 1986-September 1993[R].Houston:ResTech Houston,Inc.,TX,1996.
[17]	KUILA U.Measurement and interpretation of porosity and pore-size distribution in mudrocks:The hole story of shales[D].Colorado:Colorado Schoolof Mines,2013.
[18]	包友书,张林晔,张守春,等.东营凹陷深部异常高压与岩性油气藏的形成[J].新疆石油地质,2008,29(5):585-587. BAO Youshu,ZHANG Linye,ZHANG Shouchun,et al.The deep abnormal pressure and the formation of lithologic reservoir in Dongying Sag[J].Xinjiang Petroleum Geology,2008,29(5):585-587.
[19]	BAO Youshu,LI Zheng,LI Juyuan,et al.Discussion on movability of shale oils in the Paleogene of Dongying Depression[J].Acta Geologica Sinica (English Edition),2015,89(S1):372-374.
[20]	包友书,张林晔,张守春,等.烃源岩生烃抑制模拟实验及机理[J].石油学报,2017,38(7):753-762. BAO Youshu,ZHANG Linye,ZHANG Shouchun,et al.Simulation experiment and mechanism of hydrocarbon-generation retardation for source rocks[J].Acta Petrolei Sinica,2017,38(7):753-762.
[21]	JARVIE D M.Components and processes affecting producibility and commerciality of shale resource systems[J].Geologica Acta,2014,12(4):307-325.
[22]	JARVIE D M.Shale resource systems for oil and gas:part 2-shale-oil resource systems[R].Humble:Worldwide Geochemistry,2012:89-119.
