东非裂谷阿尔伯特盆地石油地质特征及成藏模式

崔哿; 金爱民; 邬长武; 丁锋; 史丹妮

doi:10.11781/sysydz201804513

东非裂谷阿尔伯特盆地石油地质特征及成藏模式

doi: 10.11781/sysydz201804513

1. 浙江大学海洋学院, 浙江舟山 316021;
2. 中国石化石油勘探开发研究院, 北京 100083

基金项目:

中国石化“东非重点盆地油气资源潜力与选区评价”（P14037）资助。

详细信息

作者简介:
崔哿(1993-),女,硕士研究生,从事海洋地质和石油地质研究。E-mail:21534052@zju.edu.cn。

通讯作者:
金爱民(1973-),男,副教授,从事油田地下水和油气成藏、保存条件研究。E-mail:aiminjin@163.com。

中图分类号: TE122.3
计量
- 文章访问数: 1950
- HTML全文浏览量: 416
- PDF下载量: 160
- 被引次数: 0
出版历程
- 收稿日期: 2017-09-11
- 修回日期: 2018-05-28
- 刊出日期: 2018-07-28

Petroleum geology and hydrocarbon accumulation pattern in the Lake Albert Basin of East African rift system

1. Ocean College, Zhejiang University, Zhoushan, Zhejiang 316021, China;
2. SINOPEC Petroleum Exploration & Production Research Institute, Beijing 100083, China

摘要

摘要: 基于地质、地震和钻井资料，对东非阿尔伯特盆地（Lake Albert Basin）的形成演化及构造-沉积地层特征进行了研究，深入分析了盆地石油地质特征，总结其成藏模式及油气富集条件。盆地主要受东非裂谷期构造运动的影响，形成两侧以深大断裂为界、狭长（半）地堑的构造格局。沉积地层以新近系碎屑岩为主，岩性多为泥岩、砂岩和砾岩。河流-（扇）三角洲-湖泊沉积体系发育，主要烃源岩为中新统上部富有机质页岩，中新统-上新统河流相、（扇）三角洲相砂岩为主要储层，与细粒湖相泥岩在纵向上形成良好的生储盖匹配。盆地发育大量断块、断背斜等构造圈闭。盆地成藏模式为"凹陷供烃、侧向与垂向复合运移、下生上储"，生储盖匹配良好控制垂向上形成多套成藏组合，优质砂体与垂向断层控制油气有效运移，断层控制的构造圈闭是油气聚集的主要场所。
- 石油地质特征 /
- 油气富集条件 /
- 成藏模式 /
- 阿尔伯特盆地 /
- 东非裂谷系西支
Abstract: The evolution and tectonic-sedimentary stratigraphic features of the Lake Albert Basin in the East Africa were studied using geological, seismic and drilling data. The petroleum geology features and the accumulation pattern and enrichment conditions were summarized. The basin was mainly affected by the tectonic movement of the East Africa rift system, forming a long and narrow (semi-) graben with deep faults on both sides. The sedimentary strata are dominated by Neogene clastic rocks, including mudstone, sandstone and conglomerate. Depositional fill is characterized by a river-(fan) delta-lacustrine sedimentary system. The Upper Miocene organic-rich shale, Miocene-Pliocene fluvial-(fan) delta sandstone and fine lacustrine mudstone formed a favorable source-reservoir-cap assemblage vertically. There are a large number of structural traps. Hydrocarbon generated in depressions, migrated vertically and laterally, and finally accumulated in upper formations, resulting in multiple sets of stacked reservoirs. High-quality sand bodies and vertical faults controlled the effective migration of oil and gas, and structural traps developed by fault control are the main sites for oil and gas accumulation.
- petroleum geological characteristics /
- hydrocarbon enrichment conditions /
- hydrocarbon accumulation pattern /
- Lake Albert Basin /
- western branch of East African rift system

HTML全文

参考文献(20)

[1]	IHS.International energy oil & gas industry solutions[DB/OL].(2017-07-01).http://www.ihs.com/industry/oil-gas/interna-tional.aspx.
[2]	ROGERS N,MACDONALD R,FITTON J G,et al.Two mantle plumes beneath the East African rift system:Sr,Nd and Pb isotope evidence from Kenya Rift basalts[J].Earth and Planetary Science Letters,2000,176(3/4):387-400.
[3]	PIK R,MARTY B,HILTON D R.How many mantle plumes in Africa? The geochemical point of view[J].Chemical Geology,2006,226(3/4):100-114.
[4]	CHOROWICZ J.The East African rift system[J].Nature,1967,215(5101):578-581.
[5]	MACGREGOR D.History of the development of the East African Rift System:a series of interpreted maps through time[J].Journal of African Earth Sciences,2015,101:232-252.
[6]	DELVAUX D,KERVYN F,MACHEYEKI A S,et al.Geodynamic significance of the TRM segment in the East African Rift (W-Tanzania):Active tectonics and paleostress in the Ufipa Plateau and Rukwa Basin[J].Journal of Structural Geology,2012,37:161-180.
[7]	ROBERTS E M,O'CONNOR P M,STEVENS N J,et al.Sedi-mentology and depositional environments of the Red Sandstone Group,Rukwa Rift Basin,southwestern Tanzania:new insight into Cretaceous and Paleogene terrestrial ecosystems and tecto-nics in sub-equatorial Africa[J].Journal of African Earth Sciences,2010,57(3):179-212.
[8]	张燕,田作基,温志新,等.东非裂谷系东支油气成藏主控因素及勘探潜力[J].石油实验地质,2017,39(1):79-85. ZHANG Yan,TIAN Zuoji,WEN Zhixin,et al.Controlling factors for petroleum accumulation and exploration potential of the eastern branch of East Africa Rift System[J].Petroleum Geology & Experiment,2017,39(1):79-85.
[9]	程顶胜,窦立荣,王建君,等.乌干达Albertine地堑含沥青砂岩的发现及其地球化学意义[J].地球化学,2002,31(6):532-538. CHENG Dingsheng,DOU Lirong,WANG Jianjun,et al.Geoche-mical characteristics of shales and oil seepages in the Albertine Graben,Uganda[J].Geochemica,2002;31(6):532-538.
[10]	SIMON B,GUILLOCHEAU F,ROBIN C,et al.Deformation and sedimentary evolution of the Lake Albert Rift (Uganda,East African Rift System)[J].Marine & Petroleum Geology,2017,86:17-37.
[11]	蔡文杰,韩文明,许志刚,等.东非Lake Albert盆地构造调节带特征及其对油气成藏的控制作用[J].地质科技情报,2015,34(4):119-123. CAI Wenjie,HAN Wenming,XU Zhigang,et al.Geological character of accommodation zone and its important in controlling accumulation of oil and gas in Lake Albert Basin[J].Geological Science and Technology Information,2015,34(4):119-123.
[12]	董朔朋,祝彦庆.乌干达Albert地堑中新-上新统沉积特征及控制因素[J].海洋地质前沿,2016(2):29-37. DONG Shuopeng,ZHU Yanqing.Depositional features and controlling factors of Pliocene-Miocene deposits in Albert Graben,Uganda[J].Marine Geology Frontiers,2016(2):29-37.
[13]	温志新,童晓光,张光亚,等.东非裂谷系盆地群石油地质特征及勘探潜力[J].中国石油勘探,2012(4):60-65. WEN Zhixin,TONG Xiaoguang,ZHANG Guangya,et al.Petroleum geology features and exploration potential of basin group in East African Rift System[J].China Petroleum Exploration,2012(4):60-65.
[14]	孙和风,彭文绪,姜雪.断砂耦合对阿尔伯特凹陷北部转换带油气富集的控制作用[J].中国海上油气,2016,28(5):30-37. SUN Hefeng,PENG Wenxu,JIANG Xue.Fault-sand coupling controlling effect on hydrocarbon enrichment in the northern transfer zone of Albert sag[J].China Offshore Oil and Gas,2016,28(5):30-37.
[15]	谢文胜.阿尔伯特凹陷KF油田原油地球化学特征及来源[J].科学技术与工程,2017,17(5):15-19. XIE Wensheng.Characteristics and Formation Mechanism of High Wax Crude in KF Oilfield[J].Science Technology and Engineering,2017,17(5):15-19.
[16]	杨小丽,胡光义,庞玉茂,等.Albert湖盆北区退积型浅水三角洲沉积及储层特征[J].中国海上油气,2015,27(5):55-61. YANG Xiaoli,HU Guangyi,PANG Yumao,et al.Retrogradation shallow water delta sedimentary model and reservoir characteristics in north area of Albert lacustrine basin[J].China Offshore Oil and Gas,2015,27(5):55-61.
[17]	窦立荣.陆内裂谷盆地的油气成藏风格[J].石油勘探与开发,2004,31(2):29-31. DOU Lirong.Formation style of oil accumulations in interior basins[J].Petroleum Exploration and Development,2004,31(2):29-31.
[18]	童晓光,关增淼.世界石油勘探开发图集(非洲地区分册)[M].北京:石油工业出版社,2002:1-437. TONG Xiaoguang,GAUN Zengmiao.World atlas of petroleum exploration and development[M].Beijing:Petroleum Industry Press,2002:1-437.
[19]	于水,韩文明,赵伟,等.裂谷盆地陡断带三角洲沉积特征与成因模式:以东非裂谷Albertine地堑为例[J].中国海上油气,2013,25(6):31-35. YU Shui,HAN Wenming,ZHAO Wei,et al.Delta sedimentation and origin model within steep faulted zones in rift basins:a case of Albertine graben in East African Rift Valley[J].China Offshore Oil and Gas,2013,25(6):31-35.
[20]	赵伟,韩文明,胡滨,等.东非裂谷Albertine地堑石油地质条件和成藏规律[J].四川地质学报,2016,36(2):275-279. ZHAO Wei,HAN Wenming,HU Bin,,et al.Petroleum geology and hydrocarbon accumulation in the Albertine Graben,East Africa Rift[J].Acta Geologica Sichuan,2016,36(2):275-279.
