川东北下寒武统筇竹寺组稀土元素特征及其地质意义——以南江杨坝剖面为例

曹婷婷; 徐思煌; 王约

doi:10.11781/sysydz201805716

川东北下寒武统筇竹寺组稀土元素特征及其地质意义——以南江杨坝剖面为例

doi: 10.11781/sysydz201805716

1. 中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126;
2. 中国石化油气成藏重点实验室, 江苏无锡 214126;
3. 中国地质大学(武汉) 资源学院, 武汉 430074;
4. 贵州大学资源与环境工程学院, 贵阳 550003

基金项目:

中国石油化工股份有限公司海相油气勘探前瞻性研究项目（G0800-06-ZS-319）和地质过程与矿产资源国家重点实验室科技部专项资助。

详细信息

作者简介:
曹婷婷(1986-),女,硕士,工程师,从事地球化学分析研究。E-mail:ctt.syky@sinopec.com。

中图分类号: TE122.2
计量
- 文章访问数: 1192
- HTML全文浏览量: 174
- PDF下载量: 137
- 被引次数: 0
出版历程
- 收稿日期: 2017-10-16
- 修回日期: 2018-05-18
- 刊出日期: 2018-09-28

Characteristics of rare earth elements in Lower Cambrian Qiongzhusi Formation in northeastern Sichuan Basin and its geological implications: a case study of Yangba section, Nanjiang

1. Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China;
2. Key Laboratory of Petroleum Accumulation Mechanisms, SINOPEC, Wuxi, Jiangsu 214126, China;
3. Resource Institute, China University of Geosciences, Wuhan, Hubei 430074, China;
4. College of Resource and Environmental Engineering, Guizhou University, Guiyang, Guizhou 550003, China

摘要

摘要: 筇竹寺组是四川盆地重要的页岩气产层。为了揭示筇竹寺组优质烃源岩层段形成时期的物源区构造背景、物源特征及其沉积环境，选择四川盆地南江杨坝剖面出露较完整的下寒武统筇竹寺组系统采样，并对样品中稀土元素及微量元素进行分析。稀土元素分布模式及参数特征指示：整体上筇竹寺组物质来源较为一致，沉积物源区处于被动大陆边缘构造背景条件下，母岩以沉积岩和花岗岩混合为主，其中底部碳质页岩形成时期陆源碎屑中黏土矿物含量多。δCe与V/Cr参数指示：筇竹寺组底部形成于厌氧的水介质环境，中部—上部地层沉积时期属于贫氧—弱氧化的环境。
- 稀土元素 /
- 筇竹寺组 /
- 下寒武统 /
- 川东北
Abstract: The Qiongzhusi Formation is an important shale gas production layer in the Sichuan Basin. A case study was made in the Yangba section of the northeastern Sichuan Basin. Samples were collected for rare earth and trace element analyses from the Lower Cambrian Qiongzhusi Formation in the study area so as to reveal the tectonic settings, provenance features and sedimentary environment when favorable source rocks were deposited. The distribution pattern and parameter characteristics of rare earth elements indicated that the Qiongzhusi Formation had a relatively consistent material source, mainly a passive continental margin. The parent rocks were mainly composed of sedimentary rocks and granites. When carbonaceous shale was deposited at the bottom of the Qiongzhusi Formation, the content of clay minerals increased in land sourced debris.The δCe and V/Cr parameters indicated that the bottom of the Qiongzhusi Formation was deposited in an anoxic reducing environment, while the middle and upper parts were deposited in a dysoxic-suboxic environment.
- rare earth element /
- Qiongzhusi Formation /
- Lower Cambrian /
- northeastern Sichuan

HTML全文

参考文献(38)

[1]	陈建平,梁狄刚,张水昌,等.中国古生界海相烃源岩生烃潜力评价标准与方法[J].地质学报,2012,86(7):1132-1142. CHEN Jianping,LIANG Digang,ZHANG Shuichang,et al.Evaluation criterion and methods of the hydrocarbon generation potential for China's Paleozoic marine source rocks[J].Acta Geologica Sinica,2012,86(7):1132-1142.
[2]	邹才能,董大忠,王社教,等.中国页岩气形成机理、地质特征及资源潜力[J].石油勘探与开发,2010,37(6):641-653. ZOU Caineng,DONG Dazhong,WANG Shejiao,et al.Geological characteristics,formation mechanism and resource potential of shale gas in China[J].Petroleum Exploration and Development,2010,37(6):641-653.
[3]	李建忠,董大忠,陈更生,等.中国页岩气资源前景与战略地位[J].天然气工业,2009,29(5):11-16. LI Jianzhong,DONG Dazhong,CHEN Gengsheng,et al.Prospects and strategic position of shale gas resources in China[J].Natural Gas Industry,2009,29(5):11-16.
[4]	任东超,陈义才,孙超亚,等.威远地区筇竹寺组页岩气成藏条件分析[J].石油化工应用,2016,35(8):99-103. REN Dongchao,CHEN Yicai,SUN Chaoya,et al.Shale gas reservoir-forming conditions and predicting favorable exploration area in Qiongzhusi Formation,Vying region[J].Petrochemical Industry Application,2016,35(8):99-103.
[5]	王同,熊亮,徐猛,等.川南地区下寒武统筇竹寺组页岩储层特征[J].石油实验地质,2016,38(2):197-203. WANG Tong,XIONG Liang,XU Meng,et al.Shale reservoir characteristics of the Lower Cambrian Qiongzhusi Formation in the southern Sichuan Basin[J].Petroleum Geology & Experiment,2016,38(2):197-203.
[6]	李琪琪,李斌,刘羿伶,等.川西北古生界烃源岩特征及生烃潜力评价[J].特种油气藏,2018,25(3):44-49. LI Qiqi,LI Bin,LIU Yiling,et al.Paleozoic source-rock properties and hydrocarbon generation potential in Northwest Sichuan[J].Special Oil & Gas Reservoirs,2018,25(3):44-49.
[7]	史洪亮,王同,陈霞,等.川南下古生界高演化页岩成熟度指标[J].断块油气田,2018,25(1):43-47. SHI Hongliang,WANG Tong,CHEN Xia,et al.Research on thermal maturity indicators of Lower Palaeozoic over-mature shale in southern Sichuan area[J].Fault-Block Oil and Gas Field,2018,25(1):43-47.
[8]	黄金亮,邹才能,李建忠,等.川南下寒武统筇竹寺组页岩气形成条件及资源潜力[J].石油勘探与开发,2012,39(1):69-75. HUANG Jinliang,ZOU Caineng,LI Jianzhong,et al.Shale gas gene-ration and potential of the Lower Cambrian Qiongzhusi Formation in southern Sichuan Basin,China[J].Petroleum Exploration and Development,2012,39(1):69-75.
[9]	闫德宇,黄文辉,王婷灏,等.中、下扬子地区下寒武统黑色页岩微量元素富集特征[J].地学前缘,2016,23(3):41-50. YAN Deyu,HUANG Wenhui,WANG Tinghao,et al.Trace element characteristics of the Lower Cambrian black shales in middle and lower Yangtze area,China[J].Earth Science Frontiers,2016,23(3):41-50.
[10]	程克明,王世谦,董大忠,等.上扬子区下寒武统筇竹寺组页岩气成藏条件[J].天然气工业,2009,29(5):40-44. CHENG Keming,WANG Shiqian,DONG Dazhong,et al.Accumulation conditions of shale gas reservoirs in the Lower Cambrian Qiongzhusi Formation,the Upper Yangtze region[J].Natural Gas Industry,2009,29(5):40-44.
[11]	刘本立.地球化学基础[M].北京:北京大学出版社,1994. LIU Benli.Foundation of geochemistry[M].Beijing:Peking University Press,1994.
[12]	HATCH J R,LEVENTHAL J S.Relationship between inferred redox potential of the depositional environment and geochemistry of the Upper Pennsylvanian (Missourian) Stark Shale Member of the Dennis Limestone,Wabaunsee County,Kansas,U.S.A.[J].Chemical Geology,1992,99(1/3):65-82.
[13]	朱志军,陈洪德,林良彪,等.川东南-湘西地区志留系小河坝组砂岩微量元素地球化学特征及意义[J].地质科技情报,2010,29(2):24-30. ZHU Zhijun,CHEN Hongde,LIN Liangbiao,et al.Signification and characteristic of the trace element ratios of the sandstone in Silurian Xiaoheba Formation in southeastern Sichuan Province and western Hunan Province[J].Geological Science and Technology Information,2010,29(2):24-30.
[14]	万友利,王剑,万方,等.羌塘盆地南部古油藏带布曲组碳酸盐岩稀土元素特征及意义[J].石油实验地质,2017,39(5):655-665. WAN Youli,WANG Jian,WAN Fang,et al.Characteristics and indications of rare earth elements in carbonates in the Buqu Formation, southern Qiangtang Basin[J].Petroleum Geology & Experiment,2017,39(5):655-665.
[15]	郭春涛,李德武,陈树民.塔里木盆地古城地区上寒武统白云岩稀土元素地球化学特征及成因模式[J].石油实验地质,2017,39(5):666-674. GUO Chuntao,LI Dewu,CHEN Shumin.Geochemical characteristics and genetic model of rare earth elements in the Upper Cambrian dolomites in Gucheng area, Tarim Basin[J].Petroleum Geology & Experiment,2017,39(5):666-674.
[16]	梁世友,陈迎宾,赵国伟,等.四川盆地川西坳陷雷口坡组四段稀土元素地球化学特征及意义[J].石油实验地质,2017,39(1):94-98. LIANG Shiyou,CHEN Yingbin,ZHAO Guowei,et al.Geochemical characteristics of rare earth elements and their geological significance in the fourth member of the Middle Triassic Leikoupo Formation in western Sichuan Basin[J].Petroleum Geology & Experiment,2017,39(1):94-98.
[17]	赵立鹏,王冉,钟方军,等.赣东北重点泥页岩层系地球化学特征分析[J].特种油气藏,2017,24(1):64-69. ZHAO Lipeng,WANG Ran,ZHONG Fangjun,et al.Geochemistry features of key mud shale formations in Northeast Jiangxi Province[J].Special Oil & Gas Reservoirs,2017,24(1):64-69.
[18]	何德军,陈洪德,钱利军.新场地区须二段泥岩稀土元素地球化学特征及意义[J].断块油气田,2013,20(2):157-161. HE Dejun,CHEN Hongde,QIAN Lijun.Geochemical characteristics of rare earth elements and its geological signification for mudstones of the second member of Xujiahe Formation in Xinchang area[J].Fault-Block Oil and Gas Field,2013,20(2):157-161.
[19]	龙胜祥,郭彤楼,刘彬,等.通江-南江-巴中构造河坝飞仙关组三段、嘉陵江组二段气藏形成特征研究[J].地质学报,2008,82(3):338-345. LONG Shengxiang,GUO Tonglou,LIU Bin,et al.Gas-pool characteristics of the second section of the Jialingjiang Formation and the third section of the Feixianguan Formation in the Heba area of Tongjiang-Nanjiang-Bazhong Structure Belt,North Sichuan[J].Acta Geologica Sinica,2008,82(3):338-345.
[20]	李伟,余华琪,邓鸿斌.四川盆地中南部寒武系地层划分对比与沉积演化特征[J].石油勘探与开发,2012,39(6):681-690. LI Wei,YU Huaqi,DENG Hongbin.Stratigraphic division and correlation and sedimentary characteristics of the Cambrian in central-southern Sichuan Basin[J].Petroleum Exploration and Development,2012,39(6):681-690.
[21]	李皎,何登发.四川盆地及邻区寒武纪古地理与构造-沉积环境演化[J].古地理学报,2014,16(4):441-460. LI Jiao,HE Dengfa.Palaeogeography and tectonic-depositional environment evolution of the Cambrian in Sichuan Basin and adjacent areas[J].Journal of Palaeogeography,2014,16(4):441-460.
[22]	赵来时,吴元保,胡兆初,等.牙形石微量元素对生物绝灭事件的响应:以二叠-三叠系全球层型剖面第一幕绝灭事件为例[J].地球科学(中国地质大学学报),2009,34(5):725-732. ZHAO Laishi,WU Yuanbao,HU Zhaochu,et al.Trace element compositions in Conodont phosphates responses to biotic extinction event:a case study for main act of global boundary stratotype section and point of the Permian-Triassic[J].Earth Science(Journal of China University of Geosciences),2009,34(5):725-732.
[23]	亨德森.稀土元素地球化学[M].田丰,施烺.译.北京:地质出版社,1989:201-203. HENDERSON P.Rare earth element geochemistry[M].TIAN Feng,SHI Lang,trans.Beijing:Geological Publishing House,1989:201-203.
[24]	刘锐娥,卫孝峰,王亚丽,等.泥质岩稀土元素地球化学特征在物源分析中的意义:以鄂尔多斯盆地上古生界为例[J].天然气地球科学,2005,16(6):788-791. LIU Ruie,WEI Xiaofeng,WANG Yali.The geochemical characteristics of rare earth elements of the shale rock in the geologic signification of the analysis of the sedimentary provenance:an example in the Upper Palaeozoic in the Ordos Basin[J].Nature Gas Geoscience,2005,16(6):788-791.
[25]	BOYNTON W V.Cosmochemistry of the rare earth elements:meteorite studies[M]//HENDERSON P.Rare earth element geochemistry.Amsterdam:Elsevier,1984:63-114.
[26]	SHIELDS G,STILLE P.Diagenetic constraints on the use of cerium anomalies as palaeoseawater redox proxies:an isotopic and REE study of Cambrian phosphorites[J].Chemical Geology,2001,175(1/2):29-48.
[27]	何德军,陈洪德,钱利军.新场地区须二段泥岩稀土元素地球化学特征及意义[J].断块油气田,2013,20(2):157-161. HE Dejun,CHEN Hongde,QIAN Lijun.Geochemical characteristics of rare earth elements and its geological signification for mudstones of the second member of Xujiahe Formation in Xinchang area[J].Fault-Block Oil and Gas Field,2013,20(2):157-161.
[28]	MURRAY R W,BUCHHOLTZ TEN BRINK M R,JONES D L,et al.Rare earth elements as indicators of different marine depositional environments in chert and shale[J].Geology,1990,18(3):268-271.
[29]	王克兵,孟庆涛,刘招君,等.柴北缘鱼卡地区中侏罗统石门沟组页岩段稀土元素地球化学特征与地质意义[J].世界地质,2017,36(3):862-870. WANG Kebing,MENG Qingtao,LIU Zhaojun,et al.Rare earth element geochemical characteristics and geological significance of shale member in Middle Jurassic Shimengou Formation in Yuqia area of northern margin of Qaidam Basin[J].Global Geology,2017,36(3):862-870.
[30]	TAYLOR S R,MCLENNAN S M.The continental crust,its composition and evolution:an examination of the geochemical record preserved in sedimentary rocks[M].Oxford,London:Blackwell Scientific Publication,1985.
[31]	GIRTY G H,HANSON A G,KNAACK C,et al.Provenance determined by REE,Th,and Sc analyses of metasedimentary rocks,Boyden cave roof pendant,Central Sierra Nevada,California[J].Journal of Sedimentary Research,1994,64(1):68-73.
[32]	BHATIA M R.Rare earth element geochemistry of Australian Paleozoic graywackes and mudrocks:provenance and tectonic control[J].Sedimentary Geology,1985,45(1/2):97-113.
[33]	赵振华.铕地球化学特征的控制因素[J].南京大学学报(地球科学版),1993,5(3):271-280. ZHAO Zhenhua.The controlling factor of Eu geochemical characteristics[J].Journal of Nanjing University (Natural Sciences),1993,5(3):271-280.
[34]	ELDERFIELD H,GREAVES M J.The rare earth elements in seawater[J].Nature,1982,296(5854):214-219.
[35]	赵振华.微量元素地球化学原理[M].北京:科学出版社,1997. ZHAO Zhenhua.The geochemical principle of trace element[M].Beijing:Science Press,1997.
[36]	陈兰.湘黔地区早寒武世黑色岩系沉积学及地球化学研究[D].贵阳:中国科学院研究生院(地球化学研究所),2006:2-89. CHEN Lan.The Hunan Guizhou area,the Early Cambrian black rock series in sedimentology and geochemistry[D].Guiyang:Institute of Geochemistry,Chinese Academy of Sciences,2006:2-89.
[37]	JONES B,MANNING D A C.Comparison of geochemical indices used for the interpretation of palaeoredox conditions in ancient mudstones[J].Chemical Geology,1994,111(1/4):111-129.
[38]	张满郎,谢增业,李熙喆,等.四川盆地寒武纪岩相古地理特征[J].沉积学报,2010,28(1):128-139. ZHANG Manlang,XIE Zengye,LI Xizhe,et al.Characteristics of lithofacies paleogeography of Cambrian in Sichuan Basin[J].Acta Sedimentologica Sinica,2010,28(1):128-139.
