四川自贡地区五峰组—龙马溪组下段古地貌刻画及其油气意义

王同; 张克银; 熊亮; 史洪亮; 董晓霞; 魏力民; 温真桃; 欧阳嘉穗; 李斌; 王浩宇

doi:10.11781/sysydz201806764

四川自贡地区五峰组—龙马溪组下段古地貌刻画及其油气意义

doi: 10.11781/sysydz201806764

1. 中国石化西南油气分公司, 成都 610016;
2. 中国石化西南油气分公司博士后工作站, 成都 610016;
3. 西南石油大学地球科学与技术学院, 成都 610500

基金项目:

中国石油化工股份有限公司非常规科技项目“川西南下古生界海相页岩气高产富集条件与有利区评价”（P15100）和四川省教育厅重点科研项目“深层页岩储集物性研究”（15ZA0047）联合资助。

详细信息

作者简介:
王同(1987-),男,博士,助理研究员,从事非常规油气地质研究。E-mail:mrmenzu@aliyun.com。

通讯作者:
魏力民(1970-),男,高级工程师,从事非常规油气地质研究。E-mail:478853590@qq.com。

中图分类号: TE121.3
计量
- 文章访问数: 1300
- HTML全文浏览量: 102
- PDF下载量: 249
- 被引次数: 0
出版历程
- 收稿日期: 2018-07-10
- 修回日期: 2018-09-03
- 刊出日期: 2018-11-28

Paleogeomorphology restoration of Wufeng Formation-Lower Member of Longmaxi Formation in Zigong area of Sichuan Province and its oil and gas significance

1. SINOPEC Southwest Oil & Gas Company, Chengdu, Sichuan 610016, China;
2. Post-doctoral Research Station, SINOPEC Southwest Oil & Gas Company, Chengdu, Sichuan 610016, China;
3. School of Geoscience and Technology, Southwest Petroleum University, Chengdu, Sichuan 610500, China

摘要

摘要: 四川盆地威远-自贡地区是页岩气重点产区之一。上奥陶统观音桥段的展布情况对于页岩气勘探具有重要指导意义。通过构造-沉积背景分析，结合自贡地区岩心、薄片、古生物、测井及沉积速率、碳氧同位素等资料，认为观音桥段为构造稳定期大幅海退背景下的介壳灰岩沉积。A205、A1井观音桥段的缺失反映古地貌高点暴露出海平面，未沉积观音桥段介壳灰岩，并剥蚀下伏五峰组页岩。据此，运用残余厚度法对五峰组观音桥段古地貌进行刻画，观音桥段及五峰组厚度在自贡地区由北西向南东均表现出厚-薄-厚的变化特征，认为自贡地区存在以A1井-A205井为核部的北东-南西向展布的自贡低隆。建立了五峰组-龙马溪组下段沉积期自贡低隆沉积演化模式，并揭示了对于龙马溪组高伽马段黑色页岩的沉积厚度的影响。五峰组-龙马溪组高伽马段厚度存在以自贡低隆区A1井-A205井为中心向四周增厚的趋势，自贡低隆区两侧的低洼区域为有利勘探区。
- 页岩 /
- 古地貌 /
- 沉积演化 /
- 自贡低隆 /
- 四川盆地
Abstract: The Weiyuan-Zigong area is a main shale gas production area in the Sichuan Basin. The distribution of the Upper Ordovician Guanyinqiao Member provides significant guidance for shale gas exploration. Tectonic-sedimentary background analysis combined with core, thin section, paleontology, logging, deposition rate and carbon-oxygen isotope data were used to interpret the micro-paleogeomorphology of the Zigong area in the Hirnantian-Rhuddanian period. The Guanyinqiao Member comprises shell limestone deposited under the background of regression in the tectonic stabilization period. The Guanyinqiao Member was missing and the Wufeng Formation was thin in wells A205 and A1. The NE-SW-directed Zigong low uplift identified in wells A1 and A205. A sedimentary evolution model of the Zigong area during the Hirnantian-Rhuddanian period was established, and its influence on black shale thickness was clarified. The Wufeng Formation and the high gamma ray value section of Longmaxi Formation thickened around wells A1 and A205. Both sides of the Zigong low uplift are favorable for exploration.
- shale /
- paleogeomorphology /
- sedimentary evolution /
- Zigong low uplift /
- Sichuan Basin

HTML全文

参考文献(26)

[1]	王玉满,李新景,董大忠,等.上扬子地区五峰组-龙马溪组优质页岩沉积主控因素[J].天然气工业,2017,37(4):9-20. WANG Yuman,LI Xinjing,DONG Dazhong,et al.Main factors controlling the sedimentation of high-quality shale in Wufeng-Longmaxi Fm,Upper Yangtze region[J].Natural Gas Industry,2017,37(4):9-20.
[2]	魏祥峰,李宇平,魏志红,等.保存条件对四川盆地及周缘海相页岩气富集高产的影响机制[J].石油实验地质,2017,39(2):147-153. WEI Xiangfeng,LI Yuping,WEI Zhihong,et al.Effects of pre-servation conditions on enrichment and high yield of shale gas in Sichuan Basin and its periphery[J].Petroleum Geology & Experiment,2017,39(2):147-153.
[3]	张晓明,石万忠,徐清海,等.四川盆地焦石坝地区页岩气储层特征及控制因素[J].石油学报,2015,36(8):926-939. ZHANG Xiaoming,SHI Wanzhong,XU Qinghai,et al.Reservoir characteristics and controlling factors of shale gas in Jiaoshiba area,Sichuan Basin[J].Acta Petrolei Sinica,2015,36(8):926-939.
[4]	贾承造,郑民,张永峰.非常规油气地质学重要理论问题[J].石油学报,2014,35(1):1-10. JIA Chengzao,ZHENG Min,ZHANG Yongfeng.Four important theoretical issues of unconventional petroleum geology[J].Acta Petrolei Sinica,2014,35(1):1-10.
[5]	孙健,包汉勇.页岩气储层综合表征技术研究进展:以涪陵页岩气田为例[J].石油实验地质,2018,40(1):1-12. SUN Jian,BAO Hanyong.Comprehensive characterization of shale gas reservoirs:a case study from Fuling Shale Gas Field[J].Petroleum Geology & Experiment,2018,40(1):1-12.
[6]	HARPER D A T,HAMMARLUND E U,RASMUSSEN C M ø.End Ordovician extinctions:a coincidence of causes[J].Gondwana Research,2014,25(4):1294-1307.
[7]	郭正吾,邓康龄,韩永辉.四川盆地形成与演化[M].北京:地质出版社,1996. GUO Zhengwu,DENG Kangling,HAN Yonghui.The formation and development of Sichuan Basin[M].Beijing:Geological Publishing House,1996.
[8]	何登发,李德生,张国伟,等.四川多旋回叠合盆地的形成与演化[J].地质科学,2011,46(3):589-606. HE Dengfa,LI Desheng,ZHANG Guowei,et al.Formation and evolution of multi-cycle superposed Sichuan Basin,China[J].Chinese Journal of Geology,2011,46(3):589-606.
[9]	聂海宽,金之钧,马鑫,等.四川盆地及邻区上奥陶统五峰组-下志留统龙马溪组底部笔石带及沉积特征[J].石油学报,2017,38(2):160-174. NIE Haikuan,JIN Zhijun,MA Xin,et al.Graptolites zone and sedimentary characteristics of Upper Ordovician Wufeng Formation-Lower Silurian Longmaxi Formation in Sichuan Basin and its adjacent areas[J].Acta Petrolei Sinica,2017,38(2):160-174.
[10]	朱彤,王烽,俞凌杰,等.四川盆地页岩气富集控制因素及类型[J].石油与天然气地质,2016,37(2):399-407. ZHU Tong,WANG Feng,YU Lingjie,et al.Controlling factors and types of shale gas enrichment in the Sichuan Basin[J].Oil & Gas Geology,2016,37(2):399-407.
[11]	FINNEGAN S,BERGMANN K,EILER J M,et al.The magnitude and duration of Late Ordovician-Early Silurian glaciation[J].Science,2011,331(6019):903-906.
[12]	HAQ B U,SCHUTTER S R.A chronology of Paleozoic sea-level changes[J].Science,2008,322(5898):64-68.
[13]	CHEN Xu,RONG Jiayu,MITCHELL C E,et al.Late Ordovician to earliest Silurian graptolite and brachiopod biozonation from the Yangtze region,South China,with a global correlation[J].Geological Magazine,2000,137(6):623-650.
[14]	王运海.四川盆地平桥地区五峰-龙马溪组页岩微观孔隙特征研究[J].石油实验地质,2018,40(3):337-344. WANG Yunhai.Micro-pore characteristics of shale from Wufeng-Longmaxi formations in Pingqiao area,Sichuan Basin[J].Petroleum Geology & Experiment,2018,40(3):337-344.
[15]	张梦吟,李争,王进,等.四川盆地涪陵页岩气田五峰-龙马溪组岩矿纵向差异性研究:以JYA井为例[J].石油实验地质,2018,40(1):64-70. ZHANG Mengyin,LI Zheng,WANG Jin,et al.Vertical variation of rocks and minerals in Wufeng-Longmaxi formations in Fuling shale gas field,Sichuan Basin:a case study of well JYA[J].Petroleum Geology & Experiment,2018,40(1):64-70.
[16]	孟志勇.四川盆地涪陵地区五峰组-龙马溪组含气页岩段纵向非均质性及其发育主控因素[J].石油与天然气地质,2016,37(6):838-846. MENG Zhiyong.Vertical heterogeneity and its controlling factors of the gas shale in the Wufeng-Longmaxi Fms in Fuling area,the Sichuan Basin[J].Oil & Gas Geology,2016,37(6):838-846.
[17]	王超,张柏桥,舒志国,等.四川盆地涪陵地区五峰组-龙马溪组海相页岩岩相类型及储层特征[J].石油与天然气地质,2018,39(3):485-497. WANG Chao,ZHANG Boqiao,SHU Zhiguo,et al.Lithofacies types and reservoir characteristics of marine shales of the Wufeng Formation-Longmaxi Formation in Fuling area,the Sichuan Basin[J].Oil & Gas Geology,2018,39(3):485-497.
[18]	伍岳,樊太亮,蒋恕,等.四川盆地南缘上奥陶统五峰组-下志留统龙马溪组页岩矿物组成与脆性特征[J].油气地质与采收率,2015,22(4):59-63. WU Yue, FAN Tailiang, JIANG Shu, et al.Mineralogy and brittleness features of the shale in the upper Ordovician Wufeng Formation and the lower Silurian Longmaxi Formation in southern Sichuan Basin[J].Petroleum Geology and Recovery Efficiency,2015,22(4):59-63.
[19]	申宝剑,仰云峰,腾格尔,等.四川盆地焦石坝构造区页岩有机质特征及其成烃能力探讨:以焦页1井五峰-龙马溪组为例[J].石油实验地质,2016,38(4):480-488. SHEN Baojian,YANG Yunfeng,TENGER,et al.Characteristics and hydrocarbon significance of organic matter in shale from the Jiaoshiba structure,Sichuan Basin:a case study of the Wufeng-Longmaxi formations in well Jiaoye1[J].Petroleum Geology & Experiment,2016,38(4):480-488.
[20]	樊隽轩,MELCHIN M J,陈旭,等.华南奥陶-志留系龙马溪组黑色笔石页岩的生物地层学[J].中国科学:地球科学,2012,42(1):130-139. FAN Junxuan,MELCHIN M J,CHEN Xu,et al.Biostratigraphy and geography of the Ordovician-Silurian Lungmachi black shales in South China[J].Science China:Earth Sciences,2011,54(12):1854-1863.
[21]	王玉满,董大忠,黄金亮,等.四川盆地及周边上奥陶统五峰组观音桥段岩相特征及对页岩气选区意义[J].石油勘探与开发,2016,43(1):42-50. WANG Yuman,DONG Dazhong,HUANG Jinliang,et al.Guanyinqiao Member lithofacies of the Upper Ordovician Wufeng Formation around the Sichuan Basin and the significance to shale gas plays,SW China[J].Petroleum Exploration and Development,2016,43(1):42-50.
[22]	梁峰,王红岩,拜文华,等.川南地区五峰组-龙马溪组页岩笔石带对比及沉积特征[J].天然气工业,2017,37(7):20-26. LIANG Feng,WANG Hongyan,BAI Wenhua,et al.Graptolite correlation and sedimentary characteristics of Wufeng-Longmaxi shale in southern Sichuan Basin[J].Natural Gas Industry,2017,37(7):20-26.
[23]	陈旭,樊隽轩,张元动,等.五峰组及龙马溪组黑色页岩在扬子覆盖区内的划分与圈定[J].地层学杂志,2015,39(4):351-358. CHEN Xu,FAN Junxuan,ZHANG Yuandong,et al.Subdivision and delineation of the Wufeng and Lungmachi black shales in the subsurface areas of the Yangtze platform[J].Journal of Stratigraphy,2015,39(4):351-358.
[24]	NICHOLS G.Sedimentology and stratigraphy[M].2nd ed.Chichester,West Sussex Hoboken,NJ:Wiley-Blackwell,2009:258-262.
[25]	MELCHIN M J,MITCHELL C E,HOLMDEN C,et al.Environmental changes in the Late Ordovician-Early Silurian:review and new insights from black shales and nitrogen isotopes[J].GSA Bulletin,2013,125(11/12):1635-1670.
[26]	周业鑫,丁俊,余谦,等.渝东北地区观音桥段沉积与有机碳同位素特征及其区域对比[J].地质学报,2017,91(5):1097-1107. ZHOU Yexin,DING Jun,YU Qian,et al.Sedimentary and organic carbon isotopic characteristics of the Kuanyinchiao Member in northeastern Chongqing and its regional correlation[J].Acta Geologica Sinica,2017,91(5):1097-1107.
