致密砂岩气藏油气轻烃特征及其地质意义——以四川盆地西北部须家河组气藏为例

王玮; 沈忠民; 裴森奇; 戴鸿鸣; 黄东

doi:10.11781/sysydz201806818

致密砂岩气藏油气轻烃特征及其地质意义——以四川盆地西北部须家河组气藏为例

doi: 10.11781/sysydz201806818

1. 油气藏地质及开发工程国家重点实验室(成都理工大学), 成都 610059;
2. 西南石油大学地球科学与技术学院, 成都 610500;
3. 中国石油西南油气田公司川西北气矿, 四川江油 621700;
4. 中国石油西南油气田分公司勘探开发研究院, 成都 610056

基金项目:

国家科技重大专项（2016ZX05047-002-05）和中国石油西南油气田公司科技重大专项（2013ZD01）资助。

详细信息

作者简介:
王玮(1985-),男,博士研究生,从事油气地球化学研究。E-mail:13881819221@163.com。

中图分类号: TE122.11
计量
- 文章访问数: 1198
- HTML全文浏览量: 97
- PDF下载量: 120
- 被引次数: 0
出版历程
- 收稿日期: 2018-04-08
- 修回日期: 2018-10-17
- 刊出日期: 2018-11-28

Light hydrocarbon characteristics of petroleum in a tight sandstone gas reservoir and its geological significance: a case study of the Upper Triassic Xujiahe Formation gas reservoir in the northwestern Sichuan Basin

1. State Key Laboratory of Oil-Gas Reservoir Geology & Exploitation, Chengdu University of Technology, Chengdu, Sichuan 610059, China;
2. School of Geoscience and Technology, Southwest Petroleum University, Chengdu, Sichuan 610500, China;
3. Northwest Sichuan Gas Field, PetroChina Southwest Oil and Gas Field Company, Jiangyou, Sichuan 621700, China;
4. Exploration and Development Research Institute, PetroChina Southwest Oil & Gas Field Company, Chengdu, Sichuan 610056, China

摘要

摘要: 四川盆地西北部上三叠统须家河组天然气、凝析油样品的C₇及C₅-C₇轻烃分布显示出油气主要来源于富含腐殖型干酪根的煤系泥岩与煤岩，该区油气样品的K₁值平均为1.04，整体相关性较好；K₂值差异较大，相关系数也较低，母体-子体比值梓潼凹陷须家河组呈现出较强的离散型。利用庚烷值、异庚烷值及MANGO稳态催化动力学等方法计算表明，天然气处于成熟-高成熟演化阶段，明显低于该区烃源岩实测成熟度及天然气δ¹³C₁值计算的成熟度。梓潼凹陷须家河组凝析油及天然气轻烃星状指纹图分析显示，同一构造不同层位、同一层位不同构造油气可对比性较差，表明该区油气藏内部砂体之间的连通性较差，油气成藏以近源短距离运聚为主。由于该区储层早期已达致密演化阶段，从而导致在封闭-半封闭的地质环境中，天然气受不同热演化阶段天然气的累积效应影响，而凝析油受到同源不同期的天然气多次气侵而产生“蒸发分馏”效应影响，导致部分轻烃参数在应用过程中出现偏差。
- 轻烃 /
- 庚烷值 /
- 异庚烷值 /
- MANGO稳态催化轻烃参数 /
- “蒸发分馏”作用 /
- 致密砂岩气藏 /
- 四川盆地西北部
Abstract: Light hydrocarbons (C₇ and C₅-C₇) of the natural gas and condensate from the Upper Triassic Xujiahe Formation in the northwestern Sichuan Basin indicated that the petroleum was sourced primarily from coaly mudstones and coal rocks that were rich in humic kerogen. K₁ values from the study area average 1.04 and are relatively well correlated, while the K₂ values vary greatly and are relatively poorly correlated. The parent-daughter ratio of the Xujiahe Formation is of the discrete type in the Zitong Sag. The heptane value, isoheptane value and MANGO steady-state catalytic kinetic method indicates that the natural gas is currently in the mature to highly mature stage, with a maturity clearly lower than the measured maturity of the source rocks in the study area and the δ¹³C₁-calculated maturity. The star-plot diagram of light hydrocarbons of natural gas and condensate from the Xujiahe Formation in the Zitong Sag revealed the poor correlation with oil trapped in the same structure but different layers or in the same layer but different structures. This suggested that sand bodies in the reservoirs within the study area were poorly connected and the reservoirs were formed mainly as the result of near-source and short-distance migration and accumulation. Since the early reservoirs in this area have entered the tight evolution stage, natural gas is at different thermal evolution stages, and condensate oil is influenced by the effect of "evaporation and fractionation" of natural gas at different stages of the homologous period, resulting in the discrepancy of the interpretation of some light hydrocarbon parameters.
- low molecular weight hydrocarbon /
- heptane values /
- isoheptane values /
- Mango steady-state catalytic light hydrocarbon parameter /
- “evaporation fractionation” /
- tight sandstone gas reservoir /
- northwestern Sichuan Basin

HTML全文

参考文献(39)

[1]	戴金星.利用轻烃鉴别煤成气和油型气[J].石油勘探与开发,1993,20(5):26-32. DAI Jinxing.Identification of coal formed gas and oil type gas by light hydrocarbons[J].Petroleum Exploration and Development,1993,20(5):26-32.
[2]	蒋启贵,张彩明,张美珍,等.岩石C₆-C₁₅轻烃定量分析方法研究[J].石油实验地质,2007,29(5):512-515. JIANG Qigui,ZHANG Caiming,ZHANG Meizhen,et al.Research on the quantitative analysis method of C₆-C₁₅ light hydrocarbon in source rock samples[J].Petroleum Geology & Experiment,2007,29(5):512-515.
[3]	程克明,金伟明,何忠华,等.陆相原油及凝析油的轻烃单体组成特征及地质意义[J].石油勘探与开发,1987,14(1):34-43. CHENG Keming,JIN Weiming,HE Zhonghua,et al.Composition characteristics of light hydrocarbons in continental oil and condensate and their geological significance[J].Petroleum Exploration and Development,1987,14(1):34-43.
[4]	ODDEN W.A study of natural and artificially generated light hydrocarbons (C₄-C₁₃) in source rocks and petroleum fluids from offshore Mid-Norway and the southernmost Norwegian and Danish sectors[J].Marine and Petroleum Geology,1999,16(8):747-770.
[5]	胡国艺,李剑,李谨,等.判识天然气成因的轻烃指标探讨[J].中国科学(D辑地球科学),2007,37(S2):111-117. HU Guoyi,LI Jian,LI Jin,et al.Preliminary study on the origin identification of natural gas by the parameters of light hydrocarbon[J].Science in China (Series D Earth Sciences),2008,51(S1):131-139.
[6]	HUNT J M.Origin of gasoline range alkanes in the deep sea[J].Nature,1975,254(5499):411-413.
[7]	侯读杰,王培荣,林壬子,等.茂名油页岩裂解气轻烃组成和热演化特征[J].江汉石油学院学报,1989,11(4):7-11. HOU Dujie,WANG Peirong,LIN Renzi,et al.Light hydrocarbons in pyrolysis gas of Maoming oil shale and its thermal evolution significance[J].Journal of Jianghan Petroleum Institute,1989,11(4):7-11.
[8]	TEN HAVEN H L.Applications and limitations of Mango's light hydrocarbon parameters in petroleum correlation studies[J].Organic Geochemistry,1996,24(10/11):957-976.
[9]	AKINLUA A,AJAYI T R,ADELEKE B B.Niger Delta oil geochemistry:insight from light hydrocarbons[J].Journal of Petroleum Science and Engineering,2006,50(3/4):308-314.
[10]	李广之,胡斌.中国油气化探分析技术新进展与发展方向[J].天然气地球科学,2013,24(6):1171-1185. LI Guangzhi,HU Bin.The latest progress of the analytical techniques of the petroleum geochemical exploration in China:problems and development direction[J].Natural Gas Geoscience,2013,24(6):1171-1185.
[11]	唐艳.天然气藏地球化学描述方法及其应用[J].石油与天然气地质,2003,24(1):91-96. TANG Yan.Gas reservoir geochemical description:method and application[J].Oil & Gas Geology,2003,24(1):91-96.
[12]	王顺玉,王廷栋.四川盆地凝析油的地球化学特征[J].石油与天然气地质,1990,11(4):454-461. WANG Shunyu,WANG Tingdong.Geochemical characters of condensates in Sichuan Basin[J].Oil & Gas Geology,1990,11(4):454-461.
[13]	蔡开平,廖仕孟.川西地区上三叠统轻烃的生成特征[J].石油学报,2002,23(1):35-39. CAI Kaiping,LIAO Shimeng.Genetic characteristics of light hydrocarbons in Upper Triassic,West Sichuan Basin[J].Acta Petrolei Sinica,2002,23(1):35-39.
[14]	梁艳,李延钧,付晓文,等.川中-川南过渡带上三叠统须家河组油气全烃地球化学特征与成因[J].天然气地球科学,2006,17(4):593-596. LIANG Yan,LI Yanjun,FU Xiaowen,et al.Origin and whole-hydrocarbon geochemical characteristics of oil and gas from Xujiahe Group of Chuanzhong-Chuannan transitional belt[J].Natural Gas Geoscience,2006,17(4):593-596.
[15]	沈忠民,王鹏,刘四兵,等.川西拗陷中段天然气轻烃地球化学特征[J].成都理工大学学报(自然科学版),2011,38(5):500-506. SHEN Zhongmin,WANG Peng,LIU Sibing,et al.Geochemical characteristics of light hydrocarbon in natural gas in the middle member of the West Sichuan Depression,China[J].Journal of Chengdu University of Technology (Science & Technology Edition),2011,38(5):500-506.
[16]	谢增业,杨威,胡国艺,等.四川盆地天然气轻烃组成特征及其应用[J].天然气地球科学,2007,18(5):720-725. XIE Zengye,YANG Wei,HU Guoyi,et al.Light hydrocarbon compositions of natural gases and their application in Sichuan Basin[J].Natural Gas Geoscience,2007,18(5):720-725.
[17]	胡国艺,汪为胜,廖凤蓉.煤成气轻烃地球化学特征及其影响因素:以四川盆地须家河组为例[J].岩石学报,2012,28(3):905-916. HU Guoyi,WANG Weisheng,LIAO Fengrong.Geochemical characteristics and its influencing factors of light hydrocarbon in coal-derived gas:a case study of Sichuan Basin[J].Acta Petrologica Sinica,2012,28(3):905-916.
[18]	李伟,秦胜飞.致密砂岩气区气田水液态轻烃的类型特征及其地质意义:以四川盆地上三叠统须家河组气藏为例[J].天然气工业,2014,34(10):9-17. LI Wei,QIN Shengfei.Liquid hydrocarbon types in formation water of tight sand gas fields and their geological significance:a case study from the Upper Triassic Xujiahe Fm in the Sichuan Basin[J].Natural Gas Industry,2014,34(10):9-17.
[19]	罗启后,王世谦.四川盆地中西部三叠系重点含气层系天然气富集条件研究[J].天然气工业,1996,16(S1):40-54. LUO Qihou,WANG Shiqian.Research on natural gas enrichment conditions of the main coal-bearing strate of Triassic in the centre-west part of Sichuan Basin[J].Natural Gas Industry,1996,16(S1):40-54.
[20]	刘金华,张世奇,孙耀庭,等.川西前陆盆地上三叠统须家河组地层的划分对比及沉积演化[J].地层学杂志,2007,31(2):190-196. LIU Jinhua,ZHANG Shiqi,SUN Yaoting,et al.Correlation and evolution of the Upper Triassic Xujiahe Formation in the West Sichuan Foreland Basin[J].Journal of Stratigraphy,2007,31(2):190-196.
[21]	胡惕麟,戈葆雄,张义纲,等.源岩吸附烃和天然气轻烃指纹参数的开发和应用[J].石油实验地质,1990,12(4):375-394. HU Tilin,GE Baoxiong,ZHANG Yigang,et al.The development and application of fingerprint parameters for hydrocarbons absorbed by source rocks and light hydrocarbons in natural gas[J].Experimental Petroleum Geology,1990,12(4):375-394.
[22]	MANGO F D.The origin of light cycloalkanes in petroleum[J].Geochimica et Cosmochimica Acta,1990,54(1):23-27.
[23]	戴金星.各类烷烃气的鉴别[J].中国科学(B辑),1992(2):185-193. DAI Jinxing.Identification of alkanes gas[J].Science in China(Series B),1992(2):185-193.
[24]	LEYTHAEUSER D,SCHAEFER R G,WEINER B.Generation of low molecular weight hydrocarbons from organic matter in source beds as a function of temperature and facies[J].Chemical Geology,1979,25(1/2):95-108.
[25]	SNOWDON L R,POWELL T G.Immature oil and condensate:modification of hydrocarbon generation model for terrestrial organic matter[J].AAPG Bulletin,1982,66(6):775-788.
[26]	王廷栋,王海清,李绍基,等.以凝析油轻烃和天然气碳同位素特征判断气源[J].西南石油学院学报,1989,11(3):1-15. WANG Tingdong,WANG Haiqing,LI Shaoji,et al.Identification of sources of natural gases based on components of C₄-C₇ light hydrocarbons in oils (condensates) and carbon-isotopic characters of natural gases[J].Journal of Southwest Petroleum Institute,1989,11(3):1-15.
[27]	MANGO F D.An invariance in the isoheptanes of petroleum[J].Science,1987,237(4814):514-517.
[28]	MANGO F D.The origin of light hydrocarbons in petroleum:a kinetic test of the steady-state catalytic hypothesis[J].Geochi-mica et Cosmochi-mica Acta,1990,54(1):1315-1323.
[29]	朱俊章,包建平,王培荣,等.塔里木盆地原油的轻烃分类及成因研究[J].海相油气地质,2001,6(1):36-39. ZHU Junzhang,BAO Jianping,WANG Peirong.Classification of light hydrocarbon and origin of oils in Tarim Basin[J].Marine Origin Petroleum Geology,2001,6(1):36-39.
[30]	朱扬明,张春明.Mango轻烃参数在塔里木原油分类中的应用[J].地球化学,1999,28(1):26-33. ZHU Yangming,ZHANG Chunming.Application of Mango's light hydrocarbon parameters in classification of oils from Tarim Basin[J].Geochimica,1999,28(1):26-33.
[31]	张春明.石油中轻烃的成因及其应用[J].石油天然气学报(江汉石油学院学报),2005,27(2):146-148. ZHANG Chunming.Origin and application of light hydrocarbons in petroleum[J].Journal of Oil and Gas Technology (Journal of Jianghan Petroleum Institute),2005,27(2):146-148.
[32]	THOMPSON K F M.Light hydrocarbons in subsurface sediments[J].Geochimica et Cosmochimica Acta,1979,43(5):657-672.
[33]	THOMPSON K F M.Classification and thermal history of petroleum based on light hydrocarbons[J].Geochimica et Cosmochimica Acta,1983,47(2):303-316.
[34]	BEMENT W O,LEVEY R A,MANGO F D.The temperature of oil generation as defined with C₇ chemistry maturity parameter(2,4-DMP/2,3-DMP ratio)[C]//GRIMALT J O,DORRONSORO C.Organic geochemistry:development and application to energy,climate,environment and human history.Donostia-san Sebastian,Spain:AIGOA,1995:505-507.
[35]	何文祥,王培荣,潘贤庄,等.莺-琼盆地原油的蒸发分馏作用[J].石油勘探与开发,2004,31(4):52-54. HE Wenxiang,WANG Peirong,PAN Xianzhuang,et al.Evaporative fractionation of crude oils in the Ying-Qiong Basin[J].Petroleum Exploration and Development,2004,31(4):52-54.
[36]	傅宁,李友川,陈桂华,等.东海西湖凹陷油气"蒸发分馏"成藏机制[J].石油勘探与开发,2003,30(2):39-42. FU Ning,LI Youchuan,CHEN Guihua,et al.Pooling mechanisms of "evaporating fractionation" of oil and gas in the Xihu Depression,East China Sea[J].Petroleum Exploration and Development,2003,30(2):39-42.
[37]	朱扬明,苏爱国,梁狄刚,等.柴达木盆地北缘南八仙油气藏的蒸发分馏作用[J].石油学报,2003,24(4):31-35. ZHU Yangming,SU Aiguo,LIANG Digang,et al.Evaporative fractionation of oil and gas reservoir in Nanbaxian area of northern Qaidam Basin[J].Acta Petrolei Sinica,2003,24(4):31-35.
[38]	陈建平,邓春萍,王绪龙,等.准噶尔盆地南缘凝析油、蜡质油与稠油的形成机理[J].中国科学(地球科学),2017,47(5):567-585. CHEN Jianping,DENG Chunping,WANG Xulong,et al.Formation mechanism of condensates,waxy and heavy oils in the southern margin of Junggar Basin,NW China[J].Science China (Earth Sciences),2017,60(5):972-991.
[39]	THOMPSON K F M.Fractionated aromatic petroleums and the generation of gas-condensates[J].Organic Geochemistry,1987,11(6):573-590.
