页岩油可动性分子地球化学评价方法——以济阳坳陷页岩油为例

蒋启贵; 黎茂稳; 马媛媛; 曹婷婷; 刘鹏; 钱门辉; 李志明; 陶国亮

doi:10.11781/sysydz201806849

页岩油可动性分子地球化学评价方法——以济阳坳陷页岩油为例

doi: 10.11781/sysydz201806849

蒋启贵^1,2,3,4,
黎茂稳^1,2,3,4,
马媛媛^1,2,3,4,
曹婷婷^1,2,3,4,
刘鹏^1,2,3,4,
钱门辉^1,2,3,4,
李志明^1,2,3,4,
陶国亮^1,2,3,4

1. 中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126;
2. 页岩油气富集机理与有效开发国家重点实验室, 江苏无锡 214126;
3. 国家能源页岩油研发中心, 江苏无锡 214126;
4. 中国石化油气成藏重点实验室, 江苏无锡 214126

基金项目:

国家科技重大专项“大型油气田及煤层气开发：中国典型盆地陆相页岩油勘探开发选区与目标评价”（2017ZX05049001）资助。

详细信息

作者简介:
蒋启贵(1963-),男,博士,研究员,从事有机地球化学实验与应用研究。E-mail:qiguij2004@126.com。

中图分类号: TE135
计量
- 文章访问数: 1240
- HTML全文浏览量: 91
- PDF下载量: 230
- 被引次数: 0
出版历程
- 收稿日期: 2018-08-09
- 修回日期: 2018-10-17
- 刊出日期: 2018-11-28

Molecular geochemical evaluation of shale oil mobility: a case study of shale oil in Jiyang Depression

JIANG Qigui^1,2,3,4,
LI Maowen^1,2,3,4,
MA Yuanyuan^1,2,3,4,
CAO Tingting^1,2,3,4,
LIU Peng^1,2,3,4,
QIAN Menhui^1,2,3,4,
LI Zhiming^1,2,3,4,
TAO Guoliang^1,2,3,4

1. Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China;
2. State Key Laboratory of Shale Oil and Gas Enrichment Mechanisms and Effective Development, Wuxi, Jiangsu 214126, China;
3. State Energy Center for Shale Oil Research and Development, Wuxi, Jiangsu 214126, China;
4. SINOPEC Key Laboratory of Petroleum Accumulation Mechanisms, Wuxi, Jiangsu 214126, China

摘要

摘要: 目前，对于页岩油的可动性评价还没有规范的方法和标准，常使用热解S₁、S₁/w（TOC）及中值孔喉半径等多参数的组合并结合勘探开发实际来进行综合表征，相关地质解释理论依据相对缺乏。通过对济阳坳陷页岩油岩心样品的实验分析及研究，利用页岩油分子组成与页岩含油性及页岩油赋存空间的耦合关系，建立了表征页岩油可动性的分子地球化学评价参数模型。研究表明，当∑nC_20^-/∑nC_21⁺比值小于1时，页岩孔喉中值半径一般大于20 nm，此时，热解S₁一般大于3 mg/g，S₁/w（TOC）>100 mg/g，且随S₁、S₁/w（TOC）及页岩孔喉中值半径的增大，∑nC_20^-/∑nC_21⁺比值基本不变，反映了页岩孔喉半径达到一定级别后，喉道中大、小烃类分子扩散运动不受扩散能垒的影响，孔喉道中页岩油分子组成相对均质，页岩油可动性强；当∑nC_20^-/∑nC_21⁺比值大于1时，页岩孔喉中值半径一般小于20 nm，此时热解S₁一般小于3 mg/g，S₁/w（TOC）<100 mg/g，且随S₁、S₁/w（TOC）及页岩孔喉中值半径的减少，∑nC_20^-/∑nC_21⁺比值快速升高，反映了页岩孔喉半径小于一定级别后，大分子烃类组分在喉道中扩散运动受到扩散能垒的抑制，页岩油可动性差，易流动的主要是低分子量烃，此时页岩游离油含量也较低。济阳坳陷页岩油流动孔喉下限半径在20 nm左右。
- 分子组成 /
- 孔喉半径 /
- 扩散能垒 /
- 分子地球化学 /
- 页岩油 /
- 济阳坳陷
Abstract: Shale hydrocarbon potential, shale oil mobility and shale compressibility are three important factors of geological evaluation for shale oil exploration and development. Among them, shale oil mobility is constrained by the pressure system, shale hydrocarbon potential, shale oil composition and occurrence space. Since there were no standardized methods or criteria for shale oil movability evaluation, a combination of multiple parameters (pyrolysis parameter S₁, S₁/w(TOC) and median pore-throat radius) together with exploration and development practice have been used for comprehensive characterization. Based on the experimental analysis of a large number of core samples for shale oil exploration in the Jiyang Depression, a coupling relationship among shale oil molecular composition, shale hydrocarbon potential and shale oil occurrence space was found, and a molecular geochemical evaluation model for shale oil mobility was established. The study revealed that when the ratio of ∑nC_20^-/∑nC_21⁺ was<1, shale pore throat radius was generally>20 nm. Under this condition, pyrolysis S₁ was usually>3 mg/g and S₁/w(TOC) was>100. The ratio of ∑nC_20^-/∑nC_21⁺ basically remained constant with the increase of S₁, the ratio S₁/w(TOC) and shale pore throat radius. This indicated that when shale pore throat radius is large, hydrocarbon molecular diffusion is not affected by diffusion energy barriers, and shale oil molecule occurrence in pore throats is relatively homogeneous, so shale oil has a good fluid mobility. When the ratio of ∑nC_20^-/∑nC_21⁺ was>1, shale pore throat radius was usually<20 nm, pyrolysis S₁ was commonly<3 mg/g, and the ratio of S₁/w(TOC) was<100. The ratio of ∑nC_20^-/∑nC_21⁺ was increasing quickly with the decrease of S₁, S₁/w(TOC) and shale pore throat radius. It indicated that when the shale pore throat radius becomes small, diffusion energy barriers limited the diffusion of macromolecular hydrocarbon components in pore throats, thus shale oil has a poor fluid mobility and low molecular weight hydrocarbon is the main constituent to flow easily. In such a condition, shale has a poor content of free oil. The lowest limit of pore-throat radius for shale oil flow in the Jiyang Depression is approximately 20 nm.
- molecular composition /
- pore-throat radius /
- diffusion energy barrier /
- molecular geochemistry /
- shale oil /
- Jiyang Depression

HTML全文

参考文献(24)

[1]	盛湘,陈祥,章新文,等.中国陆相页岩油开发前景与挑战[J].石油实验地质,2015,37(3):267-271. SHENG Xiang,CHEN Xiang,ZHANG Xinwen,et al.Prospects and challenges of continental shale oil development in China[J].Petroleum Geology & Experiment,2015,37(3):267-271.
[2]	蒋启贵,黎茂稳,钱门辉,等.不同赋存状态页岩油定量表征技术与应用研究[J].石油实验地质,2016,38(6):842-849. JIANG Qigui,LI Maowen,QIAN Menhui,et al.Quantitative characterization of shale oil in different occurrence states and its application[J].Petroleum Geology & Experiment,2016,38(6):842-849.
[3]	钱门辉,蒋启贵,黎茂稳,等.湖相页岩不同赋存状态的可溶有机质定量表征[J].石油实验地质,2017,39(2):278-286. QIAN Menhui,JIANG Qigui,LI Maowen,et al.Quantitative characterization of extractable organic matter in lacustrine shale with different occurrences[J].Petroleum Geology & Experiment,2017,39(2):278-286.
[4]	薛海涛,田善思,卢双舫,等.页岩油资源定量评价中关键参数的选取与校正:以松辽盆地北部青山口组为例[J].矿物岩石地球化学通报,2015,34(1):70-78. XUE Haitao,TIAN Shansi,LU Shuangfang,et al.Selection and verification of key parameters in the quantitative evaluation of shale oil:a case study at the Qingshankou Formation,northern Songliao Basin[J].Bulletin of Mineralogy,Petrology and Geochemistry,2015,34(1):70-78.
[5]	LOUCKS R G,REED R M,RUPPEL S C,et al.Spectrum of pore types and networks in mudrocks and a descriptive classification for matrix-related mudrock pores[J].AAPG Bulletin,2012,96(6):1071-1098.
[6]	CURTIS M E,AMBROSER J,SONDERGELD C H,et al.Transmission and scanning electron microscopy investigation of pore connectivity of gas shales on the nanoscale//North American Unconventional Gas Conference and Exhibition.The Woodlands,Texas,USA:SPE,2011.
[7]	CURTIS M E,CARDOTT B J,SONDERGELD C H,et al.Development of organic porosity in the Woodford Shale with increasing thermal maturity[J].International Journal of Coal Geology,2012,103:26-31.
[8]	杨峰,宁正福,胡昌蓬,等.页岩储层微观孔隙结构特征[J].石油学报,2013,34(2):301-311. YANG Feng,NING Zhengfu,HU Changpeng,et al.Characterization of microscopic pore structures in shale reservoirs[J].Acta Petrolei Sinica,2013,34(2):301-311.
[9]	田华,张水昌,柳少波,等.压汞法和气体吸附法研究富有机质页岩孔隙特征[J].石油学报,2012,33(3):419-427. TIAN Hua,ZHANG Shuichang,LIU Shaobo,et al.Determination of organic-rich shale pore features by mercury injection and gas adsorption methods[J].Acta Petrolei Sinica,2012,33(3):419-427.
[10]	刘毅,陆正元,戚明辉,等.渤海湾盆地沾化凹陷沙河街组页岩油微观储集特征[J].石油实验地质,2017,39(2):180-185. LIU Yi,LU Zhengyuan,QI Minghui,et al.Microscopic characteristics of shale oil reservoirs in Shahejie Formation in Zhanhua Sag,Bohai Bay Basin[J].Petroleum Geology & Experiment,2017,39(2):180-185.
[11]	JARVIE D M.Shale resource systems for oil and gas:part 2-shale-oil resource systems//BREYER J A.Shale reservoirs:giant resources for the 21st century:AAPG Memoir 97.Texas:AAPG,2012:89-119.
[12]	LOPATIN N V,ZUBAIRAEV S L,KOS I M,et al.Unconventional oil accumulations in the Upper Jurassic Bazhenov black shale formation,West Siberian Basin:a self-sourced reservoir system[J].Journal of Petroleum Geology,2003,26(2):225-244.
[13]	卢双舫,薛海涛,王民,等.页岩油评价中的若干关键问题及研究趋势[J].石油学报,2016,37(10):1309-1322. LU Shuangfang,XUE Haitao,WANG Min,et al.Several key issues and research trends in evaluation of shale oil[J].Acta Petrolei Sinica,2016,37(10):1309-1322.
[14]	WEBSTER C E,DRAGO R S,ZERNER M C.Molecular dimensions for adsorptives[J].Journal of the American Chemical Society,1998,120(22):5509-5516.
[15]	袁帅,龙军,田辉平,等.烃分子尺寸及其与扩散能垒关系的初步研究[J].石油学报(石油加工),2011,27(3):376-380. YUAN Shuai,LONG Jun,TIAN Huiping,et al.Molecular dimensions of hydrocarbons and a primary study on its relationship to diffusion energy barriers in zeolites[J].Acta Petrolei Sinica (Petroleum Processing Section),2011,27(3):376-380.
[16]	袁帅,龙军,周涵,等.芳烃、环烷烃分子在MFI和FAU分子筛中扩散行为的分子模拟[J].石油学报(石油加工),2011,27(4):508-515. YUAN Shuai,LONG Jun,ZHOU Han,et al.Molecular simulation for the diffusion characteristics of aromatic and naphthenic hydrocarbons in the channel of MFI and FAU zeolites[J].Acta Petrolei Sinica (Petroleum Processing Section),2011,27(4):508-515.
[17]	王勇,刘惠民,宋国奇,等.济阳坳陷页岩油富集要素与富集模式研究[J].高校地质学报,2017,23(2):268-276. WANG Yong,LIU Huimin,SONG Guoqi,et al.Enrichment controls and models of shale oil in the Jiyang Depression,Bohai Bay Basin[J].Geological Journal of China Universities,2017,23(2):268-276.
[18]	孙焕泉.济阳坳陷页岩油勘探实践与认识[J].中国石油勘探,2017,22(4):1-14. SUN Huanquan.Exploration practice and cognitions of shale oil in Jiyang Depression[J].China Petroleum Exploration,2017,22(4):1-14.
[19]	周立宏,于超,滑双君,等.沧东凹陷孔二段页岩油资源评价方法与应用[J].特种油气藏,2017,24(6):1-6. ZHOU Lihong,YU Chao,HUA Shuangjun,et al.Shaleoil resource estimation and application in Kong2 member of Cangdong Sag[J].Special Oil & Gas Reservoirs,2017,24(6):1-6.
[20]	张鹏,张金川,刘鸿,等.东濮凹陷北部沙三中亚段页岩油成藏地质条件与有利区优选[J].山东科技大学学报(自然科学版),2016,35(3):1-7. ZHANG Peng,ZHANG Jinchuan,LIU Hong,et al.Geological conditions for accumulation and favorable area selection of shale oil in mid-submember of Es₃ Formation,Northern Dongpu Depression[J].Journal of Shandong University of Science and Technology(Natural Science),2016, 35(3):1-7.
[21]	张鹏飞,卢双舫,李文浩,等.江汉盆地新沟嘴组页岩油储层物性下限[J].石油与天然气地质,2016,37(1):93-100. ZHANG Pengfei,LU Shuangfang,LI Wenhao,et al.Lower limits of porosity and permeability of shale oil reservoirs in the Xingouzui Formation,Jianghan Basin[J].Oil & Gas Geology,2016,37(1):93-100.
[22]	邹才能,朱如凯,白斌,等.中国油气储层中纳米孔首次发现及其科学价值[J].岩石学报,2011,27(6):1857-1864. ZOU Caineng,ZHU Rukai,BAI Bin,et al.First discovery of nano-pore throat in oil and gas reservoir in China and its scientific value[J].Acta Petrologica Sinica,27(6):1857-1864.
[23]	王森,冯其红,查明,等.页岩有机质孔缝内液态烷烃赋存状态分子动力学模拟[J].石油勘探与开发,2015,42(6):772-778. WANG Sen,FENG Qihong,ZHA Ming,et al.Molecular dyna-mics simulation of liquid alkane occurrence state in pores and fractures of shale organic matter[J].Petroleum Exploration and Development,2015,42(6):772-778.
[24]	潘月秋,高金森,王大喜.重油特征分子尺寸的精确计算方法[J].石油学报(石油加工),2007,23(4):63-67. PAN Yueqiu,GAO Jinsen,WANG Daxi.The accurate calculating method for molecular dimensions of heavy oil character molecules[J].Acta Petrolei Sinica (Petroleum Processing Section),2007,23(4):63-67.
