江西萍乐坳陷中部赣丰地1井上二叠统乐平组页岩气聚气条件

方朝刚; 徐振宇; 滕龙; 黄正清; 郑红军; 徐菲菲

doi:10.11781/sysydz201901083

江西萍乐坳陷中部赣丰地1井上二叠统乐平组页岩气聚气条件

doi: 10.11781/sysydz201901083

1. 中国地质调查局南京地质调查中心, 南京 210016;
2. 山东科技大学, 山东青岛 266590

基金项目:

国家科技重大专项“下扬子地区寒武系页岩地球化学特征与含气性研究”（2016ZX05034-001-003）和中国地质调查局调查二级项目“下扬子地区古生界页岩气基础地质调查”（DD2016-0180）联合资助。

详细信息

作者简介:
方朝刚(1987-),男,硕士,工程师,从事沉积学与岩相古地理学研究。E-mail:fangchaogang206@163.com。

通讯作者:
徐振宇(1978-),男,高级工程师,从事页岩气基础地质调查与研究。E-mail:xzy_nj@foxmail.com。

中图分类号: TE122.3
计量
- 文章访问数: 982
- HTML全文浏览量: 69
- PDF下载量: 129
- 被引次数: 0
出版历程
- 收稿日期: 2018-09-19
- 修回日期: 2018-12-06
- 刊出日期: 2019-01-28

Shale gas accumulation in the Upper Permian Leping Formation: a case study of well Ganfengdi-1 in the central Pingle Depression, Jiangxi Province

1. Nanjing Center, China Geological Survey, Nanjing, Jiangsu 210016, China;
2. Shandong University of Science and Technology, Qingdao, Shandong 266590, China

摘要

摘要: 江西萍乐坳陷普遍发育上二叠统乐平煤系，是下扬子地区页岩气勘探突破的重点区域。为查明萍乐坳陷中部页岩气聚集条件及勘探潜力，以坳陷首口地质调查井完整钻遇乐平组各套主力页岩的赣丰地1井岩心资料为研究对象，通过不均匀采样，对200余块岩心样品开展了薄片鉴定、有机地球化学分析、全岩及黏土矿物X衍射分析、氩离子抛光扫描电镜观察和页岩现场解析。萍乐坳陷中部乐平组黑色碳质页岩厚度大、有机碳含量高、有机质类型好且处于高成熟生气阶段，有利于页岩气的生成和聚集；另外，其脆性矿物含量高（脆性指数Ⅰ为26%~53.5%，均值为37.3%；脆性指数Ⅱ为23.3%~52.6%，均值为39.0%），指示页岩层段具备良好的可压性；有机孔和黏土矿物粒内孔较为发育，孔隙内部连通性好，有效增大了矿物比表面积，有利于页岩气的赋存；微裂缝主要起到沟通导流作用，改善页岩渗透性。通过分析乐平组4段地层（官山段、老山段、狮子山段和王潘里段）的勘探潜力参数指标，认为王潘里段和老山段页岩在气测显示、厚度、TOC、有机质孔隙和矿物组成等各方面更加有利，可作为萍乐坳陷中部地区乐平煤系下一步页岩气勘探开发的重点层段。
- 页岩 /
- 页岩气 /
- 重点层段 /
- 乐平组 /
- 上二叠统 /
- 萍乐坳陷 /
- 江西
Abstract: The Upper Permian Leping coal measures are widely developed in the Pingle Depression, Jiangxi Pro-vince, which is a key area for shale gas exploration in the Lower Yangtze region. The core data of well Ganfengdi-1, the first geological survey well in the Pingle Depression, which drilled through the main shale of Leping Formation, were studied in order to determine the shale gas accumulation conditions and exploration potential in the central Pingle Depression. More than 200 core samples were analyzed using non-uniform sampling. By means of thin section observations, organic geochemical analysis, X-ray diffraction analysis of whole rock and clay minerals, argon ion polishing scanning electron microscopy and in situ analysis of shale, it was determined that a large thickness of the black carbonaceous shale of the Leping Formation in the central Pingle Depression has a high content of organic carbon. The type of organic matter is good, and the stage of high maturity gas generation is favorable for shale gas generation and accumulation. In addition, the content of brittle minerals is high. The brittle index I is 26%-53.5%, averaging 37.3%, while the brittle index Ⅱ is 23.3%-52.6%, averaging 39.0%, which indicates that the shale formation has a good compressibility. Organic pores and intragranular pores in clay minerals are well-developed. The internal connectivity of the pores is good, and the specific surface area of the minerals is high, which is of great significance for the occurrence of shale gas. The micro-cracks mainly play a role of communication and diversion to improve the permeability of the shale. By analyzing the exploration potential parameter indexes of the 4 sections of the Leping Formation (Guanshan, Laoshan, Shizishan and Wangpanli), it is considered that the Wangpanli and Laoshan shale have more outstanding gas show, thickness, TOC content, organic matter pore and mineral composition, which can be regarded as favorable shale gas exploration targets in the Leping coal-bearing system in the central Pingle Depression.
- shale /
- shale gas /
- key stratum /
- Leping Formation /
- Upper Permian /
- Pingle Depression /
- Jiangxi Province

HTML全文

参考文献(36)

[1]	CURTIS J B.Fractured shale-gas systems[J].AAPG Bulletin,2002,86(11):1921-1938.
[2]	张金川,金之钧,袁明生.页岩气成藏机理和分布[J].天然气工业,2004,24(7):15-18. ZHANG Jinchuan,JIN Zhijun,YUAN Mingsheng.Reservoiring mechanism of shale gas and its distribution[J].Natural Gas Industry,2004,24(7):15-18.
[3]	MONTGOMERY S L,JARVIE D M,BOWKER K A,et al.Mississippian Barnett shale,Fort Worth Basin,north-central Texas:gas-shale play with multi-trillion cubic foot potential[J].AAPG Bulletin,2005,89(2):155-175.
[4]	张金川,李玉喜,聂海宽,等.渝页1井地质背景及钻探效果[J].天然气工业,2010,30(12):114-118. ZHANG Jinchuan,LI Yuxi,NIE Haikuan,et al.Geologic setting and drilling effect of the shale cored well Yuye-1,Penshui County of Chongqing[J].Natural Gas Industry,2010,30(12):114-118.
[5]	聂海宽,包书景,高波,等.四川盆地及其周缘下古生界页岩气保存条件研究[J].地学前缘,2012,19(3):280-294. NIE Haikuan,BAO Shujing,GAO Bo,et al.A study of shale gas preservation conditions for the Lower Paleozoic in Sichuan Basin and its periphery[J].Earth Science Frontiers,2012,19(3):280-294.
[6]	郭彤楼,刘若冰.复杂构造区高演化程度海相页岩气勘探突破的启示:以四川盆地东部盆缘JY1井为例[J].天然气地球科学,2013,24(4):643-651. GUO Tonglou,LIU Ruobing.Implications from marine shale gas exploration breakthrough in complicated structural area at high thermal stage:taking Longmaxi Formation in well JY1 as an example[J].Natural Gas Geoscience,2013,24(4):643-651.
[7]	周德华,焦方正.页岩气"甜点"评价与预测:以四川盆地建南地区侏罗系为例[J].石油实验地质,2012,34(2):109-114. ZHOU Dehua,JIAO Fangzheng.Evaluation and prediction of shale gas sweet spots:a case study in Jurassic of Jiannan area Sichuan Basin[J].Petroleum Geology & Experiment,2012,34(2):109-114.
[8]	周德华,焦方正,郭旭升,等.川东南涪陵地区下侏罗统页岩油气地质特征[J].石油与天然气地质,2013,34(4):450-454. ZHOU Dehua,JIAO Fangzheng,GUO Xusheng,et al.Geological features of the Lower Jurassic shale gas play in Fuling area,the southeastern Sichuan Basin[J].Oil & Gas Geology,2013,34(4):450-454.
[9]	郭彤楼,李宇平,魏志红.四川盆地元坝地区自流井组页岩气成藏条件[J].天然气地球科学,2011,22(1):1-7. GUO Tonglou,LI Yuping,WEI Zhihong.Reservoir-forming conditions of shale gas in Ziliujing Formation of Yuanba area in Sichuan Basin[J].Natural Gas Geoscience,2011,22(1):1-7.
[10]	何发岐,朱彤.陆相页岩气突破和建产的有利目标:以四川盆地下侏罗统为例[J].石油实验地质,2012,34(3):246-251. HE Faqi,ZHU Tong.Favorable targets of breakthrough and built-up of shale gas in continental facies in Lower Jurassic,Sichuan Basin[J].Petroleum Geology & Experiment,2012,34(3):246-251.
[11]	张金川,聂海宽,徐波,等.四川盆地页岩气成藏地质条件[J].天然气工业,2008,28(2):151-156. ZHANG Jinchuan,NIE Haikuan,XU Bo,et al.Geological condition of shale gas accumulation in Sichuan Basin[J].Natural Gas Industry,2008,28(2):151-156.
[12]	李玉喜,聂海宽,龙鹏宇.我国富含有机质泥页岩发育特点与页岩气战略选区[J].天然气工业,2009,29(12):115-118. LI Yuxi,NIE Haikuan,LONG Pengyu.Development characteristics of organic-rich shale and strategic selection of shale gas exploration area in China[J].Natural Gas Industry,2009,29(12):115-118.
[13]	聂海宽,何发岐,包书景.中国页岩气地质特殊性及其勘探对策[J].天然气工业,2011,31(11):111-116. NIE Haikuan,HE Faqi,BAO Shujing.Peculiar geological characteristics of shale gas in China and its exploration countermea-sures[J].Natural Gas Industry,2011,31(11):111-116.
[14]	梁兴,叶熙,张介辉,等.滇黔北下古生界海相页岩气藏赋存条件评价[J].海相油气地质,2011,16(4):11-21. LIANG Xing,YE Xi,ZHANG Jiehui,et al.Evaluation of preservation conditions of Lower Paleozoic marine shale gas reservoirs in the northern part of Dianqianbei Depression[J].Marine Origin Petroleum Geology,2011,16(4):11-21.
[15]	李建青.中国南方海相页岩气选区评价体系研究[D].西安:西北大学,2012. LI Jianqing.Study on evaluation system of marine shale gas separation area in South China[D].Xi'an:Northwest University,2012.
[16]	徐元刚.湘中地区海相泥页岩层系沉积相及有利区预测[D].成都:成都理工大学,2012. XU Yuangang.The sedimentary facies and favorable area forecast of the marine shale formations in Xiangzhong area[D].Chengdu:Chengdu University of Technology,2012.
[17]	邓荣敬,徐备,张立勤,等.萍乐坳陷西部上古生界-下三叠统烃源岩评价[J].天然气工业,2005,25(3):23-28. DENG Rongjing,Xu Bei,ZHANG Liqin,et al.Assessment of the hydrocarbon source rocks in upper Paleozoic-lower Triassic in west Pingle Depression[J].Natural Gas Industry,2005,25(3):23-28.
[18]	李会军,张立勤,梁锋,等.江西萍乐坳陷海相含油气系统特征[J].新疆石油地质,2003,24(3):210-213. LI Huijun,ZHANG Liqin,LIANG Feng,et al.The marine petroleum system characteristics of Pingle Depression in Jiangxi Province[J].Xinjiang Petroleum Geology,2003,24(3):210-213.
[19]	黄孝波,李贤庆,王帅,等.江西萍乐坳陷页岩气成藏条件分析[J].中国煤炭地质,2012,24(11):17-21. HUANG Xiaobo,LI Xianqing,WANG Shuai,et al.Shale gas reservoiring condition analysis in Pingxiang-Leping Depression,Jiangxi[J].Coal Geology of China,2012,24(11):17-21.
[20]	许德如,王力,王智琳,等.江西萍乐凹陷构造-沉积演化的基本特征及对找煤预测的启示[J].大地构造与成矿学,2011,35(4):513-524. XU Deru,WANG Li,WANG Zhilin,et al.Tectonic-sedimentary characteristics of the Ping (Pingxiang)-Le(Leping) Depression in Jiangxi Province and its implications on coal mineral resource prospecting[J].Geotectonica et Metallogenia,2011,35(4):513-524.
[21]	王铁冠,包建平,周玉琦,等.苏北黄桥地区东吴运动热事件的有机地球化学证据[J].地质学报,1998,72(4):358-366. WANG Tieguan,BAO Jianping,ZHOU Yuqi,et al.Organic geochemical evidence for the thermal event of the Dongwu Movement in Huangqiao,northern Jiangsu[J].Acta Geologica Sinica,1998,72(4):358-366.
[22]	王行信,韩守华.中国含油气盆地砂泥岩黏土矿物的组合类型[J].石油勘探与开发,2002,29(4):1-3. WANG Xingxin,HAN Shouhua.The combination pattern of clay minerals of sandstone and mud rock in China's petroliferous basins[J].Petroleum Exploration and Development,2002,29(4):1-3.
[23]	JARVIE D M,HILL R J,RUBLE T E,et al.Unconventional shale-gas systems:the Mississippian Barnett shale of north-central Texas as one model for thermogenic shale-gas assessment[J].AAPG Bulletin,2007,91(4):475-499.
[24]	李钜源.东营凹陷泥页岩矿物组成及脆度分析[J].沉积学报,2013,31(4):616-620. LI Juyuan.Analysis on mineral components and frangibility of shales in Dongying Depression[J].Acta Sedimentologica Sinica,2013,31(4):616-620.
[25]	赵杏媛,何东博.黏土矿物与页岩气[J].新疆石油地质,2012,33(6):643-647. ZHAO Xingyuan,HE Dongbo.Clay minerals and shale gas[J].Xinjiang Petroleum Geology,2012,33(6):643-647.
[26]	吉利明,马向贤,夏燕青,等.黏土矿物甲烷吸附性能与微孔隙体积关系[J].天然气地球科学,2014,25(2):141-152. JI Liming,MA Xiangxian,XIA Yanqing,et al.Relationship between methane adsorption capacity of clay minerals and micropore volume[J].Natural Gas Groscience,2014,25(2):141-152.
[27]	ARINGHIERI R.Nanoporosity characteristics of some natural clay minerals and soils[J].Clays and Clay Minerals,2004,52(6):700-704.
[28]	BOWKER K A.Barnett shale gas production,Fort Worth Basin:issues and discussion[J].AAPG Bulletin,2007,91(4):523-533.
[29]	GALE J F W,REED R M,HOLDER J.Natural fractures in the Barnett shale and their importance for hydraulic fracture treatments[J].AAPG Bulletin,2007,91(4):603-622.
[30]	严继民,张启元.吸附与凝聚-固体的表面与孔[M].北京:科学出版社,1979. YAN Jimin,ZHANG Qiyuan.Adsorption and condensation:the surface and pore of solid[M].Beijing:Science Press,1979.
[31]	LOUCKS R G,REED R M,RUPPEL S C,et al.Morphology,genesis,and distribution of nanometer-scale pores in siliceous mudstones of the Mississippian Barnett shale[J].Journal of Sedi-mentary Research,2009,79(12):848-861.
[32]	钟太贤.中国南方海相页岩孔隙结构特征[J].天然气工业,2012,32(9):1-4. ZHONG Taixian.Characteristics of pore structure of marine shales in South China[J].Natural Gas Industry,2012,32(9):1-4.
[33]	于炳松.页岩气储层孔隙分类与表征[J].地学前缘,2013,20(4):211-220. YU Bingsong.Classification and characterization of gas shale pore system[J].Earth Science Frontiers,2013,20(4):211-220.
[34]	郭旭升,李宇平,刘若冰,等.四川盆地焦石坝地区龙马溪组页岩微观孔隙结构特征及其控制因素[J].天然气工业,2014,34(6):9-16. GUO Xusheng,LI Yuping,LIU Ruobing,et al.Characteristics and controlling factors of micro-pore structures of Longmaxi Shale Play in the Jiaoshiba area,Sichuan Basin[J].Natural Gas Industry,2014,34(6):9-16.
[35]	张吉振,李贤庆,王刚,等.四川盆地南部上二叠统龙潭组页岩气储集层矿物组成特征及意义[J].矿物岩石地球化学通报,2016,35(5):957-965. ZHANG Jizhen,LI Xianqing,WANG Gang,et al.Mineral compositions of Upper Permian Longtan Formation shale in southern Sichuan Basin and its significance for gas reservoir[J].Bulletin of Mineralogy,Petrology and Geochemistry,2016,35(5):957-965.
[36]	彭建龙,张金川,尉鹏飞,等.四川盆地上三叠统须五段页岩微观孔隙结构及其控制因素[J].现代地质,2016,30(4):896-904. PENG Jianlong,ZHANG Jinchuan,WEI Pengfei,et al.Characteristics and controlling factors of micro-pore structures of the 5th shale member of the Xujiahe Formation of Upper Triassic in Sichuan Basin[J].Geoscience,2016,30(4):896-904.
