渤海湾盆地沾化凹陷陆相页岩储层岩石力学特征及可压裂性研究

夏遵义; 马海洋; 房堃

doi:10.11781/sysydz201901134

渤海湾盆地沾化凹陷陆相页岩储层岩石力学特征及可压裂性研究

doi: 10.11781/sysydz201901134

1. 北京大学工学院, 北京 100871;
2. 中国石油大学(华东) 石油工程学院, 山东青岛 266580

基金项目:

国家科技重大专项“东部断陷盆地页岩油气赋存方式与富集规律研究”（2016ZX05034-001-007）资助。

详细信息

作者简介:
夏遵义(1974-),女,博士,研究员,从事石油地质、页岩储层、页岩油气赋存与富集等方面的研究。E-mail:xiazy@pku.org.cn。

中图分类号: TE122.2
计量
- 文章访问数: 1222
- HTML全文浏览量: 132
- PDF下载量: 123
- 被引次数: 0
出版历程
- 收稿日期: 2018-09-19
- 修回日期: 2018-12-11
- 刊出日期: 2019-01-28

Rock mechanical properties and fracability of continental shale in Zhanhua Sag, Bohai Bay Basin

1. College of Engineering, Peking University, Beijing 100871, China;
2. School of Petroleum Engineering, China University of Petroleum(East China), Qingdao, Shandong 266580, China

摘要

摘要: 页岩储层的岩石力学性质与可压裂性对页岩油气的开发具有重要影响。目前对于陆相页岩的岩石力学特征和可压裂性方面的研究较少。利用X射线衍射和岩石力学实验等方法，测试沾化凹陷沙河街组陆相页岩全岩矿物组分、在不同成熟度、不同围压条件下的抗压强度、杨氏模量和泊松比等力学参数，并且对页岩储层的可压裂性进行了分析。页岩矿物成分主要为碳酸盐矿物，平均为44.93%，脆性矿物含量稍高于黏土矿物，分别为30.98%和24.09%；单轴压缩时页岩多为劈裂式破裂，易形成缝网；加围压后破坏形式变为剪切式，抗压强度、杨氏模量和泊松比均增大，可压裂性降低；页岩可压裂性与加热温度，即热成熟度呈正相关。综合考虑页岩矿物成分、力学性质、成岩作用和围压等因素，建立可压裂系数数学模型，可对页岩储层的可压裂性进行定量评价，为压裂选层提供依据。
- 岩石力学 /
- 可压裂性 /
- 陆相页岩 /
- 数学模型 /
- 沾化凹陷 /
- 渤海湾盆地
Abstract: The rock mechanical properties and fracability of a shale reservoir play an important role in the development of shale oil and gas. There is limited literature on the rock mechanical properties and fracability of continental shale. The mineral composition, compressive strength, Young's modulus and Poisson's ratio of the continental shale in the Shahejie Formation in the Zhanhua Sag were measured by X-ray diffraction and rock mechanical tests under different maturities and confining pressures. The content of carbonate minerals in the shale is the largest, with an average of 44.93%. The content of brittle mineral is slightly higher than that of clay mineral, Which is 30.98% and 24.09%, respectively. The failure mode of shale is predominantly splitting under uniaxial compression, which easily forms a fracture network. With additional confining pressure, the failure mode changed to shear mode. The compressive strength, Young's modulus and Poisson's ratio all increased with the increase of confining pressure, but the fracability decreased. The fracability of shale is positively correlated with thermal maturity. By considering mineral composition, mechanical properties, diagenesis and confining pressure, a mathematical model of the fracturing coefficient was established to evaluate the fracability of shale reservoir, which can provide a reference for the selection of fracturing layer.
- rock mechanics /
- fracability /
- continental shale /
- mathematical model /
- Zhanhua Sag /
- Bohai Bay Basin

HTML全文

参考文献(29)

[1]	邹才能,董大忠,王社教,等.中国页岩气形成机理、地质特征及资源潜力[J].石油勘探与开发,2010,37(6):641-653. ZOU Caineng,DONG Dazhong,WANG Shejiao,et al.Geological characteristics,formation mechanism and resource potential of shale gas in China[J].Petroleum Exploration and Development,2010,37(6):641-653.
[2]	贾承造,郑民,张永峰.中国非常规油气资源与勘探开发前景[J].石油勘探与开发,2012,39(2):129-136. JIA Chengzao,ZHENG Min,ZHANG Yongfeng.Unconventional hydrocarbon resources in China and the prospect of exploration and development[J].Petroleum Exploration and Development,2012,39(2):129-136.
[3]	刘超英.页岩气勘探选区评价方法探讨[J].石油实验地质,2013,35(5):564-569. LIU Chaoying.Discussion on methods of shale gas exploration evaluation[J]. Petroleum Geology & Experiment,2013,35(5):564-569.
[4]	张大权,张家强,王玉芳,等.中国非常规油气勘探开发进展与前景[J].资源科学,2015,37(5):1068-1075. ZHANG Daquan,ZHANG Jiaqiang,WANG Yufang,et al.China's unconventional oil and gas exploration and development:progress and prospects[J].Resources Science,2015,37(5):1068-1075.
[5]	温庆志,翟恒立,罗明良,等.页岩气藏压裂支撑剂沉降及运移规律实验研究[J].油气地质与采收率,2012,19(6):104-107. WEN Qingzhi,ZHAI Hengli,LUO Mingliang,et al.Study on proppant settlement and transport rule in shale gas fracturing[J].Petroleum Geology and Recovery Efficiency,2012,19(6):104-107.
[6]	张东晓,杨婷云.页岩气开发综述[J].石油学报,2013,34(4):792-801. ZHANG Dongxiao,YANG Tingyun.An overview of shale-gas production[J].Acta Petrolei Sinica,2013,34(4):792-801.
[7]	张东晓,杨婷云,吴天昊,等.页岩气开发机理和关键问题[J].科学通报,2016,61(1):62-71. ZHANG Dongxiao,YANG Tingyun,WU Tianhao,et al.Recovery mechanisms and key issues in shale gas development[J].Chinese Science Bulletin,2016,61(1):62-71.
[8]	唐颖,邢云,李乐忠,等.页岩储层可压裂性影响因素及评价方法[J].地学前缘,2012,19(5):356-363. TANG Ying,XiNG Yun,Li Lezhong,et al.influence factors and evaluation methods of the gas shale fracability[J].Earth Science Frontiers,2012,19(5):356-363.
[9]	郝运轻,宋国奇,周广清,等.济阳坳陷古近系泥页岩岩石学特征对可压性的影响[J].石油实验地质,2016,38(4):489-495. HAO Yunqing,SONG Guoqi,ZHOU Guangqing,et al.influence of petrological characteristics on fracability of the Paleogene shale,Jiyang Depression[J].Petroleum Geology & Experiment,2016,38(4):489-495.
[10]	JARVIE D M,HILL R J,RUBLE T E,et al.Unconventional shale-gas systems:the Mississippian Barnett shale of north-central Texas as one model for thermogenic shale-gas assessment[J].AAPG bulletin,2007,91(4):475-499.
[11]	RICKMAN R,MULLEN M J,PETRE J E,et al.A practical use of shale petrophysics for stimulation design optimization:all shale plays are not clones of the Barnett shale[C]//SPE Annual Technical Conference and Exhibition.Denver,Colorado,USA:Society of Petroleum Engineers,2008.
[12]	刁海燕.泥页岩储层岩石力学特性及脆性评价[J].岩石学报,2013,29(9):3300-3306. DIAO Haiyan.Rock mechanical properties and brittleness evaluation of shale reservoir[J].Acta Petrologica Sinica,2013,29(9):3300-3306.
[13]	范宜仁,李格贤,冀昆,等.基于数字岩心技术的页岩储层可压裂性定量评价[J].测井技术,2017,41(6):685-690. FAN Yiren,LI Gexian,JI Kun,et al.Fracability quantitative interpretation of shale reservoir based on digital core technology[J].Well Logging Technology,2017,41(6):685-690.
[14]	赵佩,李贤庆,孙杰,等.川南地区下古生界页岩气储层矿物组成与脆性特征研究[J].现代地质,2014,28(2):396-403. ZHAO Pei,LI Xianqing,SUN Jie,et al.Study on mineral composition and brittleness characteristics of shale gas reservoirs from the Lower Paleozoic in the southern Sichuan Basin[J].Geoscience,2014,28(2):396-403.
[15]	李进步,卢双舫,陈国辉,等.基于矿物学和岩石力学的泥页岩储层可压裂性评价[J].大庆石油地质与开发,2015,34(6):159-164. LI Jinbu,LU Shuangfang,CHEN Guohui,et al.Friability evaluation for the mud shale reservoirs based on the mineralogy and rock mechanics[J].Petroleum Geology and Oilfield Development in Daqing,2015,34(6):159-164.
[16]	高辉,何梦卿,赵鹏云,等.鄂尔多斯盆地长7页岩油与北美地区典型页岩油地质特征对比[J].石油实验地质,2018,40(2):133-140. GAO Hui,HE Mengqing,ZHAO Pengyun,et al.Comparison of geological characteristics of Chang 7 shale oil in Ordos Basin and typical shale oil in North America[J].Petroleum Geology & Experiment,2018,40(2):133-140.
[17]	王濡岳,胡宗全,聂海宽,等.川东南五峰组-龙马溪组与黔东南牛蹄塘组页岩储层特征对比分析与差异性探讨[J].石油实验地质,2018,40(5):639-649. WANG Ruyue,HU Zongquan,NIE Haikuan,et al.Comparative analysis and discussion of shale reservoir characteristics in the Wufeng-Longmaxi and Niutitang formations:a case study of the well JY1 in SE Sichuan Basin and well TX1 in SE Guizhou area[J].Petroleum Geology & Experiment,2018,40(5):639-649.
[18]	周雪晴,张占松,张超谟,等.基于矿物组分和成岩作用的致密砂岩储层脆性评价方法:以鄂尔多斯盆地东北部某区块为例[J].油气地质与采收率,2017,24(5):10-16. ZHOU Xueqing,ZHANG Zhansong,ZHANG Chaomo,et al.A new brittleness evaluation method for tight sandstone reservoir based on mineral compositions and diagenesis:a case study of a certain block in the northeastern Ordos Basin[J].Petroleum Geology and Recovery Efficiency,2017,24(5):10-16.
[19]	SONDERGELD C H,NEWSHAM K E,COMISKY J T,et al.Petrophysical considerations in evaluating and producing shale gas resources[C]//SPE Unconventional Gas Conference.Pittsburgh,Pennsylvania,USA:Society of Petroleum Engineers,2010.
[20]	杨建,付永强,陈鸿飞,等.页岩储层的岩石力学特性[J].天然气工业,2012,32(7):12-14. YANG Jian,FU Yongqiang,CHEN Hongfei,et al.Rock mecha-nical characteristics of shale reservoirs[J].Natural Gas industry,2012,32(7):12-14.
[21]	郭海萱,郭天魁.胜利油田罗家地区页岩储层可压性实验评价[J].石油实验地质,2013,35(3):339-346. GUO Haixuan,GUO Tiankui.Experimental evaluation of crushability of shale reservoirs in Luojia area,Shengli Oilfield[J].Petroleum Geology & Experiment,2013,35(3):339-346.
[22]	胡德高,刘超.四川盆地涪陵页岩气田单井可压性地质因素研究[J].石油实验地质,2018,40(1):20-24. HU Degao,LIU Chao.Geological factors of well fracability in Fuling shale gas field,Sichuan Basin[J].Petroleum Geology & Experiment,2018,40(1):20-24.
[23]	肖佳林,李远照,候振坤,等.一种页岩储层脆性评价方法[J].断块油气田,2017,24(4):486-489. XIAO Jialin,LI Yuanzhao,HOU Zhenkun,et al.Evaluation method for shale reservoir brittleness[J].Fault-Block Oil and Gas Field,2017,24(4):486-489.
[24]	赖富强,罗涵,覃栋优,等.基于层次分析法的页岩气储层可压裂性评价研究[J].特种油气藏,2018,25(3):154-159. LAI Fuqiang,LUO Han,QIN Dongyou,et al.Crushability evaluation of shale gas reservoir based on analytic hierarchy process[J].Special Oil & Gas Reservoirs,2018,25(3):154-159.
[25]	艾池,仇德智,张军,等.页岩力学参数测试及脆性各向异性研究[J].断块油气田,2017,24(5):647-651. AI Chi,QIU Dezhi,ZHANG Jun,et al.Measurements of mechanical parameters and brittleness anisotropy of shale[J].Fault-Block Oil and Gas Field,2017,24(5):647-651.
[26]	吴晶晶,张绍和,曹函,等.湘西北下寒武统牛蹄塘组页岩气储层可压裂性评价[J].中南大学学报(自然科学版),2018,49(5):1160-1168. WU Jingjing,ZHANG Shaohe,CAO Han,et al.Fracability evaluation of shale gas reservoir in Lower Cambrian Niutitang Formation,northwestern Hunan[J].Journal of Central South University(Science and Technology),2018,49(5):1160-1168.
[27]	陈江湛,曹函,孙平贺.湘西北牛蹄塘组页岩可压裂性评价[J].地学前缘,2017,24(6):390-398. CHEN Jiangzhan,CAO Han,SUN Pinghe.Fracability evaluation of shale in the Niutitang Formation in northwestern Hunan[J].Earth Science Frontiers,2017,24(6):390-398.
[28]	SAATY T L.层次分析法:在资源分配、管理和冲突分析中的应用[M].北京:煤炭工业出版社,1988. SAATY T L.The analytic hierarchy process:application in resource allocation,management and conflict analysis[M].Beijing:Coal industry Press,1988.
[29]	张玲,魏绍蕾,黄学斌,等.基于综合权重法的页岩气储量评价方法探讨[J].石油实验地质,2017,39(5):694-699. ZHANG Ling,WEI Shaolei,HUANG Xuebin,et al.Shale gas reserve quality evaluation based on a comprehensive weighting method[J].Petroleum Geology & Experiment,2017,39(5):694-699.
