塔里木盆地塔中10号构造带志留系柯坪塔格组低渗储层特征及控制因素

彭丽; 王振彪; 阳建平; 陆永潮; 王倩; 张少伟; 王娜; 彭鹏

doi:10.11781/sysydz201903355

塔里木盆地塔中10号构造带志留系柯坪塔格组低渗储层特征及控制因素

doi: 10.11781/sysydz201903355

彭丽^1,2,3,
王振彪¹,
阳建平¹,
陆永潮^2,3,
王倩¹,
张少伟¹,
王娜¹,
彭鹏¹

1. 中国石油塔里木油田分公司勘探开发研究院, 新疆库尔勒 841000;
2. 中国地质大学(武汉) 资源学院, 武汉 430074;
3. 中国地质大学构造与油气资源教育部重点实验室, 武汉 430074

基金项目:

中国石油重大科技攻关专项“塔里木油田勘探开发关键技术研究及应用”（2212IG20112001）资助。

详细信息

作者简介:
彭丽(1986-),女,博士,工程师,从事含油气盆地储层地质学研究。E-mail:474545488@qq.com。

中图分类号: TE122.2
计量
- 文章访问数: 804
- HTML全文浏览量: 178
- PDF下载量: 95
- 被引次数: 0
出版历程
- 收稿日期: 2019-01-04
- 修回日期: 2019-03-28
- 刊出日期: 2019-05-28

Characteristics and controlling factors of low-permeability reservoirs in Silurian Kepingtage Formation, 10th tectonic belt in the Tazhong area, Tarim Basin

1. Research Institute of Petroleum Exploration Development of Tarim Oil Company, PetroChina, Kuerle, Xinjiang 841000, China;
2. Faculty of Earth Resources, China University of Geosciences, Wuhan, Hubei 430074, China;
3. Key Laboratory of Tectonics and Petroleum Resources(China University of Geosciences), Ministry of Education, Wuhan, Hubei 430074, China

摘要

摘要: 综合运用岩心观察、薄片鉴定、扫描电镜、阴极发光以及物性测试等方法，对塔里木盆地塔中10号构造带志留系柯坪塔格组上段低渗储层的基本特征进行研究，并从沉积、成岩和构造作用3方面开展储层控制因素分析。塔中10号构造带柯坪塔格组上段低渗透砂岩储层主要由岩屑砂岩和岩屑石英砂岩组成，属于低孔低渗储层。储集空间主要为残余原生粒间孔、粒间溶孔和构造微裂缝。储层发育主要受控于沉积作用、成岩作用和构造作用，潮道和砂坪微相形成于强水动力环境，原生孔隙发育且后期酸性溶蚀作用明显，储层物性好，是优质储层发育的有利部位；压实和胶结作用使孔隙减少，而溶蚀作用可以改善储层物性；构造作用形成的微裂缝可以提高储层的渗流能力，对改善储层的储集性能起到一定的建设性作用。
- 低渗储层 /
- 控制因素 /
- 柯坪塔格组 /
- 志留系 /
- 塔里木盆地
Abstract: The basic characteristics of low-permeability reservoirs in the upper unit of Silurian Kepingtage Formation, 10th tectonic belt in the Tazhong area were investigated and the controlling factors associated with sedimentology, diagenesis and tectonism were determined based on core observation, thin section, scanning electron microscopy (SEM), cold-cathode luminescence microscopy (CL) coupled with petro-physical property testing. The results indicate that the low-permeability sandstone reservoirs are mainly composed of litharenite and sublitharenite and the studied reservoirs belong to low-porosity and low-permeability reservoirs. The reservoir space mainly includes residual primary pores, intergranular dissolution pores and tectonic microfractures. The reservoir development was controlled by sedimentology, diagenesis and tectonism. The reservoirs in tidal channel and sand-flat microfacies deposited in strong hydrodynamic environments have substantial primary pores and obviously later acidic dissolution. The resulting reservoirs have good petro-physical properties and are targets for high-quality reservoirs. The controlling factors associated with diagenesis are evidenced by porosity reduction due to compaction and cementation, whereas the reservoir petro-physical properties can be enhanced by dissolution. Microfactures induced by tectonism can improve permeability capability and play some positive role in enhancing reservoir petro-physical properties.
- low-permeability reservoirs /
- controlling factors /
- Kepingtage Formation /
- Silurian /
- Tarim Basin

HTML全文

参考文献(29)

[1]	HU Wenrui,WEI Yi,BAO Jingwei.Development of the theory and technology for low permeability reservoirs in China[J].Petroleum Exploration and Development,2018,45(4):685-697.
[2]	GAO Zhiye,YANG Xibing,HU Chenhui,et al.Characterizing the pore structure of low permeability Eocene Liushagang Formation reservoir rocks from Beibuwan Basin in northern South China Sea[J].Marine and Petroleum Geology,2019,99:107-121.
[3]	WANG Dongqi,YIN Daiyin,ZHOU Yazhou.Fine classification of ultra-low permeability reservoirs around the Placanticline of Daqing oilfield (PR of China)[J].Journal of Petroleum Science and Engineering,2019,174:1042-1052.
[4]	文静,杨明,齐韦林,等.三塘湖盆地牛圈湖油田低孔特低渗储集层特征及形成机理[J].石油实验地质,2018,40(2):141-148. WEN Jing,YANG Ming,QI Weilin,et al.Characteristics and formation mechanism of low porosity and extra-low permeability reservoirs in the Niujuanhu oil field,Santanghu Basin[J].Petroleum Geology & Experiment,2018,40(2):141-148.
[5]	李晓骁,任晓娟,罗向荣.低渗透致密砂岩储层孔隙结构对渗吸特征的影响[J].油气地质与采收率,2018,25(4):115-120. LI Xiaoxiao,REN Xiaojuan,LUO Xiangrong.Influence of pore structures on the characteristic of spontaneous imbibition in low-permeability tight sandstone reservoir[J].Petroleum Geology and Recovery Efficiency,2018,25(4):115-120.
[6]	司庆红,司马献章,张超,等.伊川凹陷谭庄组储层特征与致密油成藏条件[J].特种油气藏,2017,24(5):42-47. SI Qinghong,SIMA Xianzhang,ZHANG Chao,et al.Accumulation conditions for Tanzhuang Formation in Yichuan Depression[J].Special Oil & Gas Reservoirs,2017,24(5):42-47.
[7]	吴悠,陈红汉,赵玉涛,等.塔中地区北坡志留系晚期油气充注证据及控制因素[J].石油与天然气地质,2017,38(2):292-301. WU You,CHEN Honghan,ZHAO Yutao,et al.Evidences and controlling factors of hydrocarbon charging in the Late Silurian in the north slope of the Tazhong Uplift,Tarim Basin[J].Oil & Gas Geology,2017,38(2):292-301.
[8]	宋荣彩,肖锦泉,李猛,等.塔中地区志留系柯坪塔格组内不整合的微观证据[J].地质科学,2015,50(1):303-314. SONG Rongcai,XIAO Jinquan,LI Meng,et al.Microscopic evidence of stratigraphic unconformity within the Silurian Kepingtage Formation in Tazhong area[J].Chinese Journal of Geology,2015,50(1):303-314.
[9]	徐寅,徐怀民,牛玉杰,等.塔中地区志留系海相砂岩层序特征及成藏模式[J].中国矿业大学学报,2013,42(3):405-412. XU Yin,XU Huaimin,NIU Yujie,et al.Sequence characteristics and hydrocarbon accumulation model of marine sandstone of Silurian in Tazhong area[J].Journal of China University of Mining & Technology,2013,42(3):405-412.
[10]	段中钰,庞宏,蒲青山,等.塔里木盆地塔中地区志留系油气成藏模式[J].科技导报,2011,29(23):39-44. DUAN Zhongyu,PANG Hong,PU Qingshan,et al.Hydrocarbon accumulation model of Silurian strata of oil-gas reservoir in Tazhong area,Tarim Basin[J].Science & Technology Review,2011,29(23):39-44.
[11]	赵文光,彭仕宓,蔡忠贤,等.塔中地区志留系层序、沉积和油气分布规律[J].西安石油大学学报(自然科学版),2007,22(1):12-16. ZHAO Wenguang,PENG Shimi,CAI Zhongxian,et al.Stratigraphical sequence,sedimentary characteristics and reservoir distribution of the Silurian in central Talimu Basin[J].Journal of Xi'an Shiyou University (Natural Science Edition),2007,22(1):12-16.
[12]	ZENG Qinglu,ZHANG Xianlong,ZHANG Ronghu,et al.Characte-ristics of tidal action sedimentary system and distribution of favorable sand bodies of Silurian in Tazhong area,Tarim Basin,NW China[J].Quaternary International,2018,468:62-71.
[13]	CHEN Jian,LIU Dayong,HOU Xiaolin,et al.Origin and evolution of oilfield waters in the Tazhong oilfield,Tarim Basin,China,and their relationship to multiple hydrocarbon charging events[J].Marine and Petroleum Geology,2018,98:554-568.
[14]	付晨阳,汤良杰,曹自成,等.塔中北坡走滑断裂横向变形差异及其油气地质意义[J].石油实验地质,2017,39(6):783-789. FU Chenyang,TANG Liangjie,CAO Zicheng,et al.Lateral deformation difference of strike-slip faults on the northern slope of Tazhong uplift and its control on petroleum geology[J].Petroleum Geology & Experiment,2017,39(6):783-789.
[15]	尚凯.塔中北坡超深层灰岩储集空间类型及储层分类[J].特种油气藏,2018,25(5):65-70. SHANG Kai.Reservoir space characterization and classification of the ultra-deep limestone reservoirs in the northern slope of central Tarim Basin[J].Special Oil & Gas Reservoirs,2018,25(5):65-70.
[16]	巩伟,尚凯,陈松,等.塔中志留系柯坪塔格组下沥青砂岩段储层特征及其含油气性研究[J].重庆科技学院学报(自然科学版),2015,17(2):11-14. GONG Wei,SHANG Kai,CHEN Song,et al.Research on reservoir and its hydrocarbon-bearing characteristics in the lower bitumen-bearing sandstone member of Kepingtage Formation in Tazhong area[J].Journal of Chongqing University of Science and Technology (Natural Sciences Edition),2015,17(2):11-14.
[17]	谢佳彤,李斌,彭军,等.塔中地区柯坪塔格组储层致密化成因[J].特种油气藏,2016,23(2):59-62. XIE Jiatong,LI Bin,PENG Jun,et al.The origin of tight reservoirs in Kepingtage Formation,Tazhong area[J].Special Oil and Gas Reservoirs,2016,23(2):59-62.
[18]	孙崇浩,杨海军,潘文庆,等.塔中地区奥陶系鹰山组精细划分[J].新疆石油地质,2012,33(1):46-48. SUN Chonghao,YANG Haijun,PAN Wenqing,et al.Fine division of Yingshan Formation of Ordovician in Tazhong area,Tarim Basin[J].Xinjiang Petroleum Geology,2012,33(1):46-48.
[19]	吴立群,焦养泉,荣辉.塔里木盆地西部四十厂剖面志留系柯坪塔格组沥青砂岩沉积特征[J].现代地质,2011,25(1):48-54. WU Liqun,JIAO Yangquan,RONG Hui.Sedimentary characte-ristics of Silurian Kepingtage Formation bituminous sandstone at Sishichang section,western Tarim Basin[J].Geoscience,2011,25(1):48-54.
[20]	王勇,李宇平.塔中地区志留系柯坪塔格组储层物性的主控因素[J].天然气技术,2009,3(4):7-11. WANG Yong,LI Yuping.Main controlling factors of reservoir physical property in Silurian Kepingtage Formation,central Tarim Basin[J].Natural Gas Technology,2009,3(4):7-11.
[21]	刘金库,孙永亮,焦旭,等.碎屑岩储层低渗成因及优质储层发育机理:以歧口凹陷歧北斜坡沙二段储层为例[J].天然气地球科学,2016,27(5):799-808. LIU Jinku,SUN Yongliang,JIAO Xu,et al.The genesis of low permeability of high-quality reservoirs in deep-buried clastic rock reservoirs and its development mechanism:a case study of Es₂ Formation in the slope area of Qikou Sag[J].Natural Gas Geoscience,2016,27(5):799-808.
[22]	杨晓萍,赵文智,邹才能,等.低渗透储层成因机理及优质储层形成与分布[J].石油学报,2007,28(4):57-61. YANG Xiaoping,ZHAO Wenzhi,ZOU Caineng,et al.Origin of low-permeability reservoir and distribution of favorable reservoir[J].Acta Petrolei Sinica,2007,28(4):57-61.
[23]	岳绍飞,黄传炎,严德天,等.洛伊地区三叠系上统致密砂岩储层孔隙特征及物性影响因素[J].中南大学学报(自然科学版),2015,46(1):208-216. YUE Shaofei,HUANG Chuanyan,YAN Detian,et al.Characteristics of pore evolution and its influencing factors of petrophysical properties of tight sandstone reservoir in Upper Triassic,Luoyi District[J].Journal of Central South University (Science and Technology),2015,46(1):208-216.
[24]	DOS ANJOS S M C, DE ROS L F,DE SOUZA R S,et al.Depositional and diagenetic controls on the reservoir quality of Lower Cretaceous Pendencia sandstones,Potiguar rift basin,Brazil[J].AAPG Bulletin,2000,84(11):1719-1742.
[25]	AJDUKIEWICZ J M,LANDER R H.Sandstone reservoir quality prediction:the state of the art[J].AAPG Bulletin,2010,94(8):1083-1091.
[26]	BJØRLYKKE K.Relationships between depositional environments,burial history and rock properties:some principal aspects of diagenetic process in sedimentary basins[J].Sedimentary Geology,2014,301:1-14.
[27]	MORAD S,AL-RAMADAN K,KETZER J M,et al.The impact of diagenesis on the heterogeneity of sandstone reservoirs:a review of the role of depositional facies and sequence stratigraphy[J].AAPG Bulletin,2010,94(8):1267-1309.
[28]	MANSURBEG H,MORAD S,SALEM A,et al.Diagenesis and reservoir quality evolution of Palaeocene deep-water,marine sandstones,the Shetland-Faroes Basin,British continental shelf[J].Marine and Petroleum Geology,2008,25(6):514-543.
[29]	胡鹏,鲍志东,于兴河,等.长岭凹陷乾北地区青三段低渗透储集层特征与主控因素[J].矿物岩石地球化学通报,2017,36(2):308-318. HU Peng,BAO Zhidong,YU Xinghe,et al.Characteristics and main controlling factors of low permeability sandstone reservoir of the 3rd member of the Qingshankou Formation in the Qianbei area,Changling Sag[J].Bulletin of Mineralogy,Petrology and Geochemistry,2017,36(2):308-318.
