笔石碎屑对页岩气生成和储集特性的影响

宋笛; 胥畅; 姚素平; 腾格尔

doi:10.11781/sysydz201904540

笔石碎屑对页岩气生成和储集特性的影响

doi: 10.11781/sysydz201904540

宋笛¹,
胥畅¹,
姚素平^1, ,,
腾格尔²

1. 南京大学地球科学与工程学院, 南京 210023;
2. 中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126

基金项目:

国家自然科学基金"下古生界生烃母质成因、演化特征及其对页岩含气性的控制作用研究"（41772128）和联合基金"古生界页岩含气性原生有机质控制作用研究"（U1663202）资助。

详细信息

作者简介:
宋笛(1994-),女,硕士研究生,有机地球化学研究方向。E-mail:njusongdi@foxmail.com。

通讯作者:
姚素平(1965-),男,博士,教授,有机地球化学研究方向。E-mail:spyao@nju.edu.cn。

中图分类号: TE132.2
计量
- 文章访问数: 1075
- HTML全文浏览量: 119
- PDF下载量: 162
- 被引次数: 0
出版历程
- 收稿日期: 2018-12-11
- 修回日期: 2019-05-23
- 刊出日期: 2019-07-28

Influence of graptolite debris on shale gas generation and accumulation

1. School of Earth Sciences and Engineering, Nanjing University, Nanjing, Jiangsu 210023, China;
2. Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China

摘要

摘要: 笔石作为奥陶纪和志留纪的标准生物化石之一，在中国南方下古生界上奥陶统五峰组-下志留统龙马溪组中广泛存在。虽然这套地层显示出巨大的页岩气资源勘探开发潜力，但关于笔石碎屑对这套地层页岩气生成和储集的贡献目前仍存在着较大的分歧。通过对四川盆地威远-长宁地区威页1井五峰组-龙马溪组页岩进行酸处理，提取笔石碎屑，开展了显微傅里叶红外光谱、扫描电镜和透射电子显微镜分析，揭示了笔石有机质的成分及孔隙发育特征，探讨了笔石体对页岩气储集能力的贡献。结果表明，笔石体的成分可能主要为胶原蛋白类的有机质所组成，其生气潜力较低；但笔石体内部胎管呈中空状，体腔内发育草莓状黄铁矿，这些空隙结构有利于页岩气的储集；并且笔石体相互叠置形成多层结构，笔石表皮中纵横纹和纳米矿物的隔档可在叠置的笔石表皮间形成空隙，从而提高了页岩气储集和运移的能力。因此认为五峰组-龙马溪组页岩中笔石大量发育是影响该段页岩气富集的重要原因之一。
- 笔石 /
- 生烃潜力 /
- 孔隙特征 /
- 五峰组 /
- 龙马溪组 /
- 四川盆地
Abstract: As one of the standard fossils of the Ordovician and Silurian, graptolites are widely distributed in the Upper Ordovician Wufeng Formation to the Lower Silurian Longmaxi Formation in the Lower Paleozoic of South China. This stratum shows a good potential for shale gas exploration; however, there is a disagreement about the contribution of graptolite debris to the generation and storage of shale gas. Acid treatment was carried out on shale samples from the Wufeng-Longmaxi formations in well Weiye 1 in the Weiyuan and Changning areas of the Sichuan Basin. Graptolite debris was collected and analyzed with Microscopic Fourier Transform Infrared Spectroscopy, Scanning Electron Microscopy and Transmission Electron Microscopy. The composition and pore development characteristics of the organic matter in graptolites were examined, and the contribution of graptolite bodies to shale reservoir capacity was discussed. The graptolite bodies were mainly composed of organic matter of collagen, which shows a poor gas potential. However, the inner fetal tube of the graptolite body is hollow, and strawberry-like pyrite is developed in the body cavity, which is favorable for the storage of shale gas. The graptolite bodies are superposed on each other to form a multi-layer structure, and the vertical and horizontal stripes and the nano-mineral partitions in the graptolite skin form gaps between the stacked graptolite skins, thereby improving shale gas storage. Therefore, it is believed that the large number of graptolites in the Wufeng-Longmaxi formation shale is one of the important reasons that affect the shale gas enrichment in this segment.
- graptolite /
- hydrocarbon generation potential /
- pore characteristics /
- Wufeng Formation /
- Longmaxi Formation /
- Sichuan Basin
