塔里木盆地顺北地区中下奥陶统缝洞充填方解石地球化学特征及地质意义

王昱翔; 王斌; 顾忆; 傅强; 万旸璐; 李映涛

doi:10.11781/sysydz201904583

塔里木盆地顺北地区中下奥陶统缝洞充填方解石地球化学特征及地质意义

doi: 10.11781/sysydz201904583

王昱翔^1,2,
王斌^2,3,
顾忆²,
傅强¹,
万旸璐²,
李映涛⁴

1. 同济大学海洋与地球科学学院, 上海 200092;
2. 中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126;
3. 中国地质大学(武汉) 资源学院, 武汉 430074;
4. 中国石化西北油田分公司勘探开发研究院, 乌鲁木齐 830011

基金项目:

中国石油化工股份有限公司科技开发部项目（P15115）资助。

详细信息

作者简介:
王昱翔(1986-),男,博士后,从事碳酸盐岩储层地质学研究。E-mail:306109890@qq.com。

中图分类号: TE122.2
计量
- 文章访问数: 1156
- HTML全文浏览量: 263
- PDF下载量: 140
- 被引次数: 0
出版历程
- 收稿日期: 2019-01-28
- 修回日期: 2019-06-25
- 刊出日期: 2019-07-28

Geochemical characteristics and geological significance of calcite filled fractures and caves in Middle-Lower Ordovician, northern Shuntuoguole area, Tarim Basin

1. School of Ocean and Earth Science, Tongji University, Shanghai 200092, China;
2. Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China;
3. Faculty of Earth Resources, China University of Geosciences(Wuhan), Wuhan, Hubei 430074, China;
4. Research Institute of Petroleum Exploration and Production, SINOPEC Northwest Branch Company, Urumqi, Xinjiang 830011, China

摘要

摘要: 利用微区阴极发光和原位元素测试技术，对塔里木盆地顺北地区中下奥陶统中的方解石样品进行了微量元素和稀土元素测试分析。该区稀土元素含量整体不高，为0.735~24.538 μg/g，平均为4.963 μg/g，表现出轻稀土元素明显富集、重稀土元素相对亏损，且两者分异明显、轻微正Ce异常和明显正Eu异常的特征；Sc、Th含量和Fe/Mn值均较低，U/Th和Sr/Ba值高，指示研究区方解石形成时期气候干旱且主要形成于相对还原的成岩环境中。对该区不同产状、不同期次方解石和附近围岩颗粒地球化学对比分析表明，储集体地质流体主要来源于海水性质地层水，局部存在大气水和富硅热液流体的混源叠加改造，证实了原始沉积围岩内稀土元素较为富集，方解石颗粒中稀土元素继承于附近围岩，但受流体改造强度的控制。
- 稀土元素 /
- 微量元素 /
- 元素地球化学 /
- 方解石 /
- 中下奥陶统 /
- 顺北地区 /
- 塔里木盆地
Abstract: Micro-element cathodoluminescence and in situ elemental analysis were used to determine the trace and rare earth elements in calcite samples from the Middle and Lower Ordovician in the northern Shuntuoguole area of the Tarim Basin. The content of rare earth elements in calcite particles was not high, ranging from 0.735 to 24.538 μg/g, with an average of 4.963 μg/g. An obvious enrichment of light rare earth elements and a relative depletion of heavy rare earth elements was observed, with an obvious differentiation between them. There was a slight positive Ce anomaly and an obvious positive Eu anomaly. The Sc, Th contents and the Fe/Mn values were low, while the U/Th and Sr/Ba values were high, indicating that the calcites were deposited in a dry and reducing environment. The comparative geochemical analyses of different occurrences and different periods of calcites and surrounding rock particles were carried out. It is clear that the reservoir geological fluids in the study area mainly came from the formation water of seawater nature, and there were mixed sources of atmospheric water and silicon-rich hydrothermal fluids. It was confirmed that rare earth elements in the original sedimentary wall rocks were relatively rich, and the rare earth elements in calcite grains inherit from the surrounding rocks nearby, but were controlled by the strength of diagenetic fluid transformation.
- rare earth elements /
- trace elements /
- element geochemistry /
- calcite /
- Middle and Lower Ordovician /
- northern Shuntuoguole area /
- Tarim Basin

HTML全文

参考文献(41)

[1]	何治亮,魏修成,钱一雄,等.海相碳酸盐岩优质储层形成机理与分布预测[J].石油与天然气地质,2011,32(4):489-498. HE Zhiliang, WEI Xiucheng, QIAN Yixiong, et al. Forming mechanism and distribution prediction of quality marine carbonate reservoirs[J]. Oil & Gas Geology,2011,32(4):489-498.
[2]	刘四兵,黄思静,沈忠民,等.砂岩中碳酸盐胶结物成岩流体演化和水岩作用模式:以川西孝泉-丰谷地区上三叠统须四段致密砂岩为例[J].中国科学(地球科学),2014,44(7):1403-1417. LIU Sibing,HUANG Sijing,SHEN Zhongmin,et al.Diagenetic fluid evolution and water-rock interaction model of carbonate cements in sandstone:an example from the reservoir sandstone of the fourth member of the Xujiahe Formation of the Xiaoquan-Fenggu area, Sichuan Province, China[J].Science China(Earth Sciences),2014,57(5):1077-1092.
[3]	钱一雄,何治亮,李慧莉,等.塔里木盆地北部上震旦统葡萄状白云岩的发现及成因探讨[J].古地理学报,2017,19(2):197-210. QIAN Yixiong, HE Zhiliang, LI Huili, et al. Discovery and discussion on origin of botryoidal dolostone in the Upper Sinian in north Tarim Basin[J]. Journal of Palaeogeography,2017,19(2):197-210.
[4]	刘存革,张钰,吕海涛.塔河油田中-下奥陶统古岩溶洞穴巨晶方解石成因及演化[J].地质科技情报,2008,27(4):33-38. LIU Cunge, ZHANG Yu, LV Haitao.Genesis and evolution of gigantic calcites in Paleokarstic caves of Middle-Lower Ordovician in Tahe Oilfield[J]. Geological Science and Technology Information,2008,27(4):33-38.
[5]	蔡春芳,李开开,李斌,等.塔河地区奥陶系碳酸盐岩缝洞充填物的地球化学特征及其形成流体分析[J].岩石学报,2009,25(10):2399-2404. CAI Chunfang, LI Kaikai, LI Bin, et al. Geochemical characteristics and origins of fracture-and vug-fillings of the Ordovician in Tahe oilfield, Tarim Basin[J]. Acta Petrologica Sinica,2009,25(10):2399-2404.
[6]	金强,康逊,田飞.塔河油田奥陶系古岩溶径流带缝洞化学充填物成因和分布[J].石油学报,2015,36(7):791-798. JIN Qiang, KANG Xun, TIAN Fei.Genesis of chemical fillings in fracture-caves in paleo-karst runoff zone in Ordovician and their distributions in Tahe oilfield, Tarim Basin[J]. Acta Petrolei Sinica,2015,36(7):791-798.
[7]	朱东亚,孟庆强,胡文瑄,等.塔里木盆地塔北和塔中地区流体作用环境差异性分析[J].地球化学,2013,42(1):82-94. ZHU Dongya, MENG Qingqiang, HU Wenxuan, et al. Differences between fluid activities in the central and north Tarim Basin[J]. Geochimica,2013,42(1):82-94.
[8]	林会喜,孟凡超,徐佑德,等.准噶尔盆地西北缘石炭-二叠系火山岩裂缝中方解石脉成因[J].地质科学,2016,51(3):824-834. LIN Huixi, MENG Fanchao, XU Youde, et al. Genesis of calcite veins in Carboniferous Permian volcanic fractures, northwestern Junggar Basin[J]. Chinese Journal of Geology,2016,51(3):824-834.
[9]	雷川,陈红汉,苏奥,等.方解石充填物对于深层古岩溶洞穴保存的独特意义:以塔河地区奥陶系为例[J].沉积学报,2016,34(5):842-852. LEI Chuan, CHEN Honghan, SU Ao, et al. Distinctive significance of calcite fillings for preservation of deep buried karst paleocaves:taking the Ordovician system in Tahe area for example[J]. Acta Sedimentologica Sinica,2016,34(5):842-852.
[10]	韩长城,林承焰,鲁新便,等.塔河油田奥陶系碳酸盐岩岩溶斜坡断控岩溶储层特征及形成机制[J].石油与天然气地质,2016,37(5):644-652. HAN Changcheng, LIN Chengyan, LU Xinbian, et al. Characterization and genesis of fault-controlled karst reservoirs in Ordovician carbonate karst slope of Tahe oilfield, Tarim Basin[J]. Oil & Gas Geology,2016,37(5):644-652.
[11]	鲁新便,胡文革,汪彦,等.塔河地区碳酸盐岩断溶体油藏特征与开发实践[J].石油与天然气地质,2015,36(3):347-355. LU Xinbian, HU Wenge, WANG Yan, et al. Characteristics and development practice of fault-karst carbonate reservoirs in Tahe area, Tarim Basin[J]. Oil & Gas Geology,2015,36(3):347-355.
[12]	焦方正.塔里木盆地顺北特深碳酸盐岩断溶体油气藏发现意义与前景[J].石油与天然气地质,2018,39(2):207-216. JIAO Fangzheng.Significance and prospect of ultra-deep carbonate fault-karst reservoirs in Shunbei area, Tarim Basin[J]. Oil & Gas Geology,2018,39(2):207-216.
[13]	焦方正.塔里木盆地顺托果勒地区北东向走滑断裂带的油气勘探意义[J].石油与天然气地质,2017,38(5):831-839. JIAO Fangzheng.Significance of oil and gas exploration in NE strike-slip fault belts in Shuntuoguole area of Tarim Basin[J]. Oil & Gas Geology,2017,38(5):831-839.
[14]	付晨阳,汤良杰,曹自成,等.塔中北坡走滑断裂横向变形差异及其油气地质意义[J].石油实验地质,2017,39(39):789. FU Chenyang, TANG Liangjie, CAO Zicheng, et al. Lateral deformation difference of strike-slip faults on the northern slope of Tazhong uplift and its control on petroleum geology[J]. Petroleum Geology & Experiment,2017,39(6):783-789.
[15]	邓尚,李慧莉,张仲培,等.塔里木盆地顺北及邻区主干走滑断裂带差异活动特征及其与油气富集的关系[J].石油与天然气地质,2018,39(5):878-888. DENG Shang, LI Huili, ZHANG Zhongpei, et al. Characteristics of differential activities in major strike-slip fault zones and their control on hydrocarbon enrichment in Shunbei area and its surroundings, Tarim Basin[J]. Oil & Gas Geology,2018,39(5):878-888.
[16]	黄太柱.塔里木盆地塔中北坡构造解析与油气勘探方向[J].石油实验地质,2014,36(3):257-267. HUANG Taizhu.Structural interpretation and petroleum exploration targets in northern slope of middle Tarim Basin[J]. Petroleum Geology and Experiment,2014,36(3):257-267.
[17]	宁飞,金之钧,张仲培,等.塔中北坡走滑断裂成因机理与油气成藏[J].石油与天然气地质,2018,39(1):98-106. NING Fei, JIN Zhijun, ZHANG Zhongpei, et al. Mechanism of strike-slip faulting and hydrocarbon accumulation in northern slope of Tazhong area[J]. Oil & Gas Geology,2018,39(1):98-106.
[18]	韩晓影,汤良杰,曹自成,等.塔中北坡"复合花状"构造发育特征及成因机制[J].地球科学,2018,43(2):525-537. HAN Xiaoying, TANG Liangjie, CAO Zicheng, et al. Characteristics and formation mechanism of composite flower structures in northern slope of Tazhong Uplift, Tarim Basin[J]. Earth Science,2018,43(2):525-537.
[19]	胡文瑄,陈琪,王小林,等.白云岩储层形成演化过程中不同流体作用的稀土元素判别模式[J].石油与天然气地质,2010,31(6):810-818. HU Wenxuan, CHEN Qi, WANG Xiaolin, et al.REE models for the discrimination of fluids in the formation and evolution of dolomite reservoirs[J]. Oil & Gas Geology,2010,31(6):810-818.
[20]	NOTHDURFT L D, WEBB G E, KAMBER B S. Rare earth element geochemistry of Late Devonian reefal carbonates, Canning Basin, Western Australia:confirmation of a seawater REE proxy in ancient limestones[J]. Geochemical et Cosmochimica Acta,2004,68(2):263-283.
[21]	张沛,郑建平,张瑞生,等.塔里木盆地塔北隆起奥陶系-侏罗系泥岩稀土元素地球化学特征[J].沉积学报,2005,23(4):740-746. ZHANG Pei, ZHENG Jianping, ZHANG Ruisheng, et al. Rare earth elemental characteristics of Ordovician-Jurassic mudstone in Tabei Uplift, Tarim Basin[J]. Acta Sedimentologica Sinica,2005,23(4):740-746.
[22]	SVERJENSKY D A. Europium redox equilibria in aqueous solution[J]. Earth and Planetary Science Letters,1984,67(1):70-78.
[23]	KLINKHAMMER G P, ELDERFIELD H, EDMOND J M, et al. Geochemical implications of rare earth element patterns in hydrothermal fluids from mid-ocean ridges[J]. Geochimica et Cosmochimica Acta,1994,58(23):5105-5113.
[24]	高键,何生,何治亮,等.中扬子京山地区方解石脉成因及其对油气保存的指示意义[J].石油与天然气地质,2014,35(1):33-41. GAO Jian, HE Sheng, HE Zhiliang, et al. Genesis of calcite vein and its implication to petroleum preservation in Jingshan region, Mid-Yangtze[J]. Oil & Gas Geology,2014,35(1):33-41.
[25]	KAWABE I, TORIUMI T, OHTA A, et al. Monoisotopic REE abundances in seawater and the origin of seawater tetrad effect[J]. Geochemical Journal,1998,32(4):213-229s.
[26]	MASLOV A V,RONKIN Y L,KRUPENIN M T,et al.Systematics of rare earth elements,Th,Hf,Sc,Co,Cr,and Ni in the vendian pelitic rocks of the Serebryanka and Sylvitsa groups from the western slope of the Central Urals:a tool for monitoring provenance composition[J].Geochemistry International,2006,44(6):559-580.
[27]	林治家,陈多福,刘芊. 海相沉积氧化还原环境的地球化学识别指标[J].矿物岩石地球化学通报,2008,27(1):72-80. LIN Zhijia, CHEN Duofu, LIU Qian. Geochemical indices for redox conditions of marine sediments[J]. Bulletin of Minera-logy, Petrology and Geochemistry,2008,27(1):72-80.
[28]	WANG Shufang, DONG Dazhong, WANG Yuman, et al. Sedimentary geochemical proxies for paleoenvironment interpretation of organic-rich shale:a case study of the Lower Silurian Longmaxi Formation, southern Sichuan Basin, China[J]. Journal of Natural Gas Science and Engineering,2016,28:691-699.
[29]	ALGEO T J, MAYNARD J B. Trace-element behavior and redox facies in core shales of Upper Pennsylvanian Kansas-type cyclothems[J]. Chemical Geology,2004,206(3/4):289-318.
[30]	JONES B, MANNING D A C. Comparison of geochemical indices used for the interpretation of palaeoredox conditions in ancient mudstones[J]. Chemical Geology,1994,111(1/4):111-129.
[31]	胡明毅.塔北柯坪奥陶系碳酸盐岩地球化学特征及环境意义[J].石油与天然气地质,1994,15(2):158-163. HU Mingyi.Geochemical characters and environmental significance of Ordovician carbonate rocks in Keping area, Tarim Basin[J]. Oil & Gas Geology,1994,15(2):158-163.
[32]	黄思静,石和,毛晓冬,等.早古生代海相碳酸盐的成岩蚀变性及其对海水信息的保存性[J].成都理工大学学报(自然科学版),2003,30(1):9-18. HUANG Sijing, SHI He, MAO Xiaodong, et al. Diagenetic alteration of earlier Palaeozoic marine carbonate and preservation for the information of sea water[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2003,30(1):9-18.
[33]	史忠生,陈开远,史军,等.运用锶钡比判定沉积环境的可行性分析[J].断块油气田,2003,10(2):12-16. SHI Zhongsheng, CHEN Kaiyuan, HI Jun, et al. Feasibility analysis of the application of the ratio of strontium to barium on the identifying sedimentary environment[J]. Fault-Block Oil & Gas Field,2003,10(2):12-16.
[34]	倪善芹,侯泉林,王安建,等.碳酸盐岩中锶元素地球化学特征及其指示意义:以北京下古生界碳酸盐岩为例[J].地质学报,2010,84(10):1510-1516. NI Shanqin, HOU Quanlin, WANG Anjian, et al. Geochemical characteristics of carbonate rocks and its geological implications:taking the Lower Palaeozoic carbonate rock of Beijing area as an example[J]. Acta Geologica Sinica,2010,84(10):1510-1516.
[35]	熊小辉,肖加飞.沉积环境的地球化学示踪[J].地球与环境,2011,39(3):405-414. XIONG Xiaohui, XIAO Jiafei.Geochemical indicators of sedimentary environments:a summary[J]. Earth and Environment,2011,39(3):405-414.
[36]	万友利,王剑,万方,等.羌塘盆地南部古油藏带布曲组碳酸盐岩稀土元素特征及意义[J].石油实验地质,2017,39(5):655-665. WAN Youli, WANG Jian, WAN Fang, et al. Characteristics and indications of rare earth elements in carbonates in the Buqu Formation, southern Qiangtang Basin[J]. Petroleum Geology and Experiment,2017,39(5):655-665.
[37]	杜洋,樊太亮,高志前.塔里木盆地中下奥陶统碳酸盐岩地球化学特征及其对成岩环境的指示:以巴楚大板塔格剖面和阿克苏蓬莱坝剖面为例[J].天然气地球科学,2016,27(8):1509-1523. DU Yang, FAN Tailiang, GAO Zhiqian.Geochemical characte-ristics and their implications to diagenetic environment of Lower-Middle Ordovician carbonate rocks, Tarim Basin, China:a case study of Bachu Dabantage outcrop and Aksu Penglaiba outcrop[J]. Natural Gas Geoscience,2016,27(8):1509-1523.
[38]	KAMBER B S, WEBB G E. The geochemistry of late Archaean microbial carbonate:implications for ocean chemistry and continental erosion history[J]. Geochemical et Cosmochimica Acta,2001,65(15):2509-2525.
[39]	AUBERT D, STILLE P, PROBST A, et al. Characterization and migration of atmospheric REE in soils and surface waters[J]. Geochimica et Cosmochimica Acta,2002,66(19):3339-3350.
[40]	黄思静,卿海若,胡作维,等.川东三叠系飞仙关组碳酸盐岩的阴极发光特征与成岩作用[J].地球科学(中国地质大学学报),2008,33(1):26-34. HUANG Sijing, QING Hairuo, HU Zuowei, et al. Cathodoluminescence and diagenesis of the carbonate rocks in Feixianguan Formation of Triassic, eastern Sichuan Basin of China[J]. Earth Science(Journal of China University of Geosciences),2008,33(1):26-34.
[41]	陈永权,蒋少涌,周新源,等.塔里木盆地寒武系层状硅质岩与硅化岩的元素、δ³⁰Si、δ¹⁸O地球化学研究[J].地球化学,2010,39(2):159-170. CHEN Yongquan,JIANG Shaoyong,ZHOU Xinyuan,et al.δ³⁰Si,δ¹⁸O and elements geochemistry on the bedded siliceous rocks and cherts in dolostones from Cambrian strata,Tarim Basin[J].Geochimica,2010,39(2):159-170.
