哥伦比亚普图马约次盆晚中生代—新生代古今大地热流值

孟庆强; 宋立军; 袁炳强

doi:10.11781/sysydz202002241

哥伦比亚普图马约次盆晚中生代—新生代古今大地热流值

doi: 10.11781/sysydz202002241

1.
中国石化石油勘探开发研究院, 北京 100083
2.
西安石油大学地球科学与工程学院, 西安 710065

基金项目:

国家自然科学基金项目 41102072

国家自然科学基金项目 41872164

国家自然科学基金项目 41102075

详细信息

作者简介:
孟庆强(1978-), 男, 博士, 高级工程师, 从事油气成藏机理与分布规律研究。E-mail: mengqq.syky@sinopec.com

中图分类号: TE121.1
计量
- 文章访问数: 882
- HTML全文浏览量: 215
- PDF下载量: 99
- 被引次数: 0
出版历程
- 收稿日期: 2019-10-15
- 修回日期: 2020-01-21
- 刊出日期: 2020-03-28

Heat-flow value of Late Mesozoic to Cenozoic in Putumayo Sub-Basin, Republic of Colombia

1.
Petroleum Exploration and Production Research Institute, SINOPEC, Beijing 100083, China
2.
Oil Resources Faculty, Xi'an Shiyou University, Xi'an, Shaanxi 710065, China

摘要

摘要: 普图马约次盆地经历了多期构造演化，其大地热流史也经历了长期、复杂的演化过程。利用地质背景约束、古温标正演约束等多种方法，系统地确定了普图马约次盆自白垩纪以来各时期的大地热流值：白垩纪大地热流值为64 mW/m²；古新世大地热流值为95 mW/m²；渐新世末期大地热流值为38 mW/m²；上新世大地热流值处于120~190.00 mW/m²之间，平均155.00 mW/m²，且具有由东到西大地热流值增加的特征；今大地热流值为55 mW/m²。
- 晚中生代 /
- 新生代 /
- 大地热流 /
- 普图马约次盆 /
- 哥伦比亚
Abstract: The heat-flow history of the Putumayo Sub-Basin has undergone a long-term and complex evolutionary process from the Late Mesozoic to the Cenozoic due to multiphases of tectonic evolution. The regional geologic background and the forward modeling of paleo-temperature were applied to determine the heat-flow value during different stages ever since the Cretaceous. The heat-flow value was 64 mW/m² in the Cretaceous, 95 mW/m² in the Paleocene, 38 mW/m² at the end of Oligocene, 120 to 190 mW/m² (increasing from east to west and averaging 155 mW/m²) in the Pliocene, and 55 mW/m² at present.
- Late Mesozoic /
- Cenozoic /
- heat flow /
- Putumayo Sub-Basin /
- Republic of Colombia

HTML全文

图 1 普图马约次盆构造位置与构造特征

据文献[4, 6]修改。

Figure 1. Tectonic framework and features of the Putumayo Sub-Basin

下载: 全尺寸图片幻灯片

图 2 普图马约次盆今温度—深度实测数据与模拟温度—深度数据曲线图

Figure 2. Simulated and measured temperature and depth curves, Putumayo Sub-Basin

下载: 全尺寸图片幻灯片

图 3 普图马约次盆Losada-1井(a)和Uribe-1井(b)大地热流值数据拟合验证

Figure 3. Heat flow data and simulated curves of wells Losada-1 (a) and Uribe-1 (b), Putumayo Sub-Basin

下载: 全尺寸图片幻灯片

图 4 普图马约次盆Uribe-1井白垩系与古新统T_max数据随深度分布图

Figure 4. Relationship between T_max and depth from Cretaceous and Paleocene in well Uribe-1, Putumayo Sub-Basin

下载: 全尺寸图片幻灯片

图 5 普图马约次盆晚中生代至今大地热流值曲线

Figure 5. Heat-flow value curve in Putumayo Sub-Basin ever since the Mesozoic

下载: 全尺寸图片幻灯片

表 1 普图马约次盆实测今温度与深度数据表

Table 1. Measured temperature and depth data of Putumayo Sub-Basin

序号	深度/m	温度/℃
1	496.04	48.89
2	1 036.59	90.00
3	1 649.39	71.11
4	2 074.39	88.89
5	2 185.67	80.00
6	2 279.57	80.00
7	2 314.63	92.78
8	2 515.55	93.89
9	2 570.73	93.89
10	2 572.56	86.67
11	2 606.71	87.22
12	2 620.73	97.22
13	2 643.60	93.89
14	2 655.79	88.33
15	2 670.73	90.00
16	2 697.56	90.56

下载: 导出CSV
