Formation conditions and exploration direction of large and medium oil and gas reservoirs in Xihu Sag, East China Sea
-
摘要: 为了解决东海西湖凹陷保俶斜坡带勘探成效差以及中央背斜带勘探效果南北差异大的问题，通过盆地分析理论体系对西湖凹陷石油地质条件进行了系统研究和重新认识，认为保俶斜坡带和中央背斜带由于构造格局及构造演化的差异形成了不同的油气成藏体系，有利成藏要素的叠合区为大中型油气田的发育区。保俶斜坡带以断陷构造层为主，晚期挤压弱，构造定型早，具有“紧邻富生烃洼陷、发育多期叠置的规模储集体、形成多类型构造—岩性复合圈闭、具有良好的垂向封盖条件以及发育网毯式高效输导体系”的有利成藏条件。近生烃洼陷的断层坡折带及地貌坡折带处形成的大型潮控三角洲砂体上倾尖灭带为大中型油气田发育区。中央背斜带经历了拗陷期强烈挤压，形成了大型反转背斜，具有“先存古构造背景、发育大型构造—岩性复合圈闭、断砂配置条件好以及具备高效储盖组合”四元控藏的特征，成藏条件叠合较好的龙井、古珍珠、湖心亭等地区是大中型气田发育区。Abstract: A low exploration success ratio on the Baochu Slope of Xihu Sag of East China Sea has been inferred, and the ratio in the Central Anticline Belt varies significantly in different sub structures. To solve this issue, the petroleum geologic conditions of the sag were systematically reviewed in light of new basin analysis methodologies, and new understanding have been achieved. Due to the differences in tectonic features and evolution histories, the Baochu Slope and Central Anticline Belt developed different petroleum systems and play types. Only those areas with overlapping favorable fairways of all petroleum system elements promise the formation of large oil and gas fields. The Baochu Slope is featured by tectonic rifting, with weak later compression and early structure formation. Its favorable conditions for hydrocarbon accumulation include: short distance to the main source kitchen; multiple, overlapping, large-scale reservoirs; multiple structural-stratigraphic trap types; good vertical sealing zones; and effective lattice pattern migration pathways. The large to medium structural-stratigraphic fields are concentrated in fairways with a large scale source kitchen and updip pinchout of tide-dominated delta sands controlled by paleo slope break which in turn were induced by either faulting or paleo morphology. The Central Anticline Belt has experienced strong inversion and compression during the late depression stage, and developed inverted compressional slip faults and large scale anticlines. Hydrocarbon accumulation is controlled by four major factors: preexisting structural highs before the compressional event, large scale structural-lithological traps, excellent timing of hydrocarbon charging during deformation, and highly effective reservoir-seal combinations. The areas with good congruence of these contro-lling factors promise the occurrence of large-scale deposits such Longjing, Guzhenzhu, Huxinting fields.
-
图 2 东海西湖凹陷保俶斜坡带构造—岩性复合圈闭发育模式
Figure 2. Development model of structural-lithological traps in Baochu Slope, Xihu Sag, East China Sea
图 3 东海西湖凹陷武云亭构造—岩性复合油气藏成藏模式
Figure 3. Accumulation model of Wuyunting structural-lithological reservoir in Xihu Sag, East China Sea
-
[1] 朱夏. 朱夏论中国含油气盆地构造[M]. 北京: 石油工业出版社, 1986.ZHU Xia. ZHU Xia's discussion on China's petroleum basin[M]. Beijing: Petroleum Industry Press, 1986. [2] 朱夏. 中国东部板块内部盆地形成机制的初步探讨[J]. 石油实验地质, 1979, 1(1): 1-9. doi: 10.11781/sysydz197900001ZHU Xia. A preliminary study on the formation mechanism of basins within the eastern plate of China[J]. Petroleum Geology & Experiment, 1979, 1(1): 1-9. doi: 10.11781/sysydz197900001 [3] 朱夏. 板块构造与中国石油地质[M]. 北京: 石油工业出版社, 1981.ZHU Xia. Plate tectonics and petroleum geology of China[M]. Beijing: Petroleum Industry Press, 1981. [4] 周心怀, 高顺莉, 高伟中, 等. 东海陆架盆地西湖凹陷平北斜坡带海陆过渡型岩性油气藏形成与分布预测[J]. 中国石油勘探, 2019, 24(2): 153-164.ZHOU Xinhuai, GAO Shunli, GAO Weizhong, et al. Formation and distribution of marine-continental transitional lithologic reservoirs in Pingbei Slope Belt, Xihu Sag, East China Sea Shelf Basin[J]. China Petroleum Exploration, 2019, 24(2): 153-164. [5] 郭黔杰. 煤作为源岩研究时对显微组分的重新认识[J]. 石油勘探与开发, 1993, 20(2): 37-40. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK199302006.htmGUO Qianjie. Macerals reconsideration in the studies of "oil from coal"[J]. Petroleum Expoloration and Development, 1993, 20(2): 37-40. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK199302006.htm [6] 杨鹏程, 李浩, 刘峰, 等. 西湖凹陷X构造凝析油与蜡质油的形成机制[J]. 海洋地质与第四纪地质, 2019, 39(6): 177-187. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201906016.htmYANG Pengcheng, LI Hao, LIU Feng, et al. Formation mechanism of condensate oil and waxy oil in Structure X of Xihu Depression[J]. Marine Geology & Quaternary Geology, 2019, 39(6): 177-187. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201906016.htm [7] 曹倩, 宋在超, 周小进, 等. 东海盆地西湖凹陷原油地化特征及来源分析[J]. 石油实验地质, 2019, 41(2): 251-259. doi: 10.11781/sysydz201902251CAO Qian, SONG Zaichao, ZHOU Xiaojin, et al. Geochemical characteristics and source of crude oil in Xihu Sag, East China Sea Shelf Basin[J]. Petroleum Geology & Experiment, 2019, 41(2): 251-259. doi: 10.11781/sysydz201902251 [8] 傅宁. 东海盆地西湖凹陷煤系烃源岩及凝析油中的二萜化合物[J]. 中国海上油气(地质), 1994, 8(1): 21-28. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD199401003.htmFU Ning. Diterpenoid compounds in coal measures and condensates in Xihu Sag of East China Sea Basin[J]. China Offshore Oil and Gas(Geology), 1994, 8(1): 21-28. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD199401003.htm [9] 李磊, 王小刚, 陈玲玲, 等. 东海西湖凹陷始新统复合潮汐水道三维地震表征[J]. 天然气地球科学, 2015, 26(2): 352-359. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201502021.htmLI Lei, WANG Xiaogang, CHEN Lingling, et al. 3-D seismic characterization of the Eocene complex tidal channels in Xihu Sag, East China Sea[J]. Natural Gas Geoscience, 2015, 26(2): 352-359. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201502021.htm [10] 李昆, 周兴海, 丁峰, 等. 西湖凹陷保俶斜坡带平北地区平湖组"多元控砂"机制分析[J]. 海洋地质与第四纪地质, 2019, 39(6): 115-123. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201906010.htmLI Kun, ZHOU Xinghai, DING Feng, et al. "Multi-factor control of sandboies distribution" in the Pinghu Formation, Pingbei region of Baochu Slop, the Xihu Sag[J]. Marine Geology & Quaternary Geology, 2019, 39(6): 115-123. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201906010.htm [11] 贾承造, 池英柳. 中国岩性地层油气藏资源潜力与勘探技术: 隐蔽油气藏形成机理与勘探实践[M]. 北京: 石油工业出版社, 2004: 15-25.JIA Chengzao, CHI Yingliu. Resource potential and exploration techniques of stratigraphic and subtle reservoirs in China: formation mechanism and exploration practice of subtle pool[M]. Beijing: Petroleum Industry Press, 2004: 15-25. [12] 赵贤正, 金凤鸣, 刘震, 等. 二连盆地地层岩性油藏"多元控砂四元成藏主元富集"与勘探实践(Ⅰ)"多元控砂"机理[J]. 岩性油气藏, 2007, 6(2): 9-15.ZHAO Xianzheng, JIN Fengming, LIU Zhen, et al. "Multi-factor controlling, four-factor entrapping and key-factor enrichment" of stratigraphic-lithologic reservoirs and exploration practice in Erlian Basin (Ⅰ)"multi-factor controlling" mechanism[J]. Lithologic Reservoirs, 2007, 6(2): 9-15. [13] 吴嘉鹏, 万丽芬, 张兰, 等. 西湖凹陷平湖组岩相类型及沉积相分析[J]. 岩性油气藏, 2017, 29(1): 27-34. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX201701004.htmWU Jiapeng, WAN Lifen, ZHANG Lan, et al. Lithofacies types and sedimentary facies of Pinghu Formation in Xihu Depression[J]. Lithologic Reservoirs, 2017, 29(1): 27-34. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX201701004.htm [14] 杨彩虹, 孙鹏, 田超, 等. 东海盆地西湖凹陷平湖组异常高压分布及形成机制探讨[J]. 海洋石油, 2013, 33(3): 8-12. https://www.cnki.com.cn/Article/CJFDTOTAL-HYSY201303003.htmYANG Caihong, SUN Peng, TIAN Chao, et al. Distribution and formation mechanism of overpressure in Pinghu Formation, Xihu Sag, East China Sea[J]. Offshore Oil, 2013, 33(3): 8-12. https://www.cnki.com.cn/Article/CJFDTOTAL-HYSY201303003.htm [15] 苏奥, 陈红汉, 雷川, 等. 流体包裹体PVTx模拟研究油气充注期次和古压力恢复: 以西湖凹陷平湖构造带为例[J]. 地质科技情报, 2014, 33(6): 137-142.SU Ao, CHEN Honghan, LEI Chuan, et al. Application of PVTx simulation of fluid inclusions to estimate petroleum charge stages and restore pressure: using Pinghu Structural Belt in Xihu Depression as an example[J]. Geological Science and Technology Information, 2014, 33(6): 137-142. [16] 郑求根, 周祖翼, 蔡立国, 等. 东海陆架盆地中新生代构造背景及演化[J]. 石油与天然气地质, 2005, 26(2): 197-201.ZHENG Qiugen, ZHOU Zuyi, CAI Liguo, et al. Meso-Cenozoic tectonic setting and evolution of East China Sea Shelf Basin[J]. Oil & Gas Geology, 2005, 26(2): 197-201. [17] 朱立新, 宋在超. 东海西湖凹陷原型盆地构造格架与演化分析[J]. 海洋石油, 2016, 36(1): 1-6.ZHU Lixin, SONG Zaichao. Analysis of tectonic framework and evolution of prototype basin in Xihu Sag of the East China Sea[J]. Offshore Oil, 2016, 36(1): 1-6. [18] 董春梅, 赵仲祥, 张宪国, 等. 西湖凹陷中北部花港组物源及沉积相分析[J]. 东北石油大学学报, 2018, 42(5): 25-34. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201805004.htmDONG Chunmei, ZHAO Zhongxiang, ZHANG Xianguo, et al. Analysis of provenance and sedimentary facies of Huagang Formation in the North Central of Xihu Sag[J]. Journal of Northeast Petroleum University, 2018, 42(5): 25-34. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSY201805004.htm [19] 刘金水, 陆永潮, 秦兰芝. 源汇系统分析方法在大型储集体研究中的应用以西湖凹陷中央反转带花港组为例[J]. 石油实验地质, 2019, 41(3): 303-310. doi: 10.11781/sysydz201903303LIU Jinshui, LU Yongchao, QIN Lanzhi. Application of source to sink system analysis in large reservoir research: a case study of Huagang Formation, Central Inversion Belt, Xihu Depression[J]. Petroleum Geology & Experiment, 2019, 41(3): 303-310. doi: 10.11781/sysydz201903303 [20] 蔡佳, 祁鹏, 宋双. 东海盆地西湖凹陷花港组下段沉积相分析[J]. 海洋地质与第四纪地质, 2017, 37(2): 56-65. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201702006.htmCAI Jia, QI Peng, SONG Shuang. Sedimentary facies of the lower Huagang Formation in Xihu Depression of Donghai Basin[J]. Marine Geology & Quaternary Geology, 2017, 37(2): 56-65. https://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201702006.htm [21] 张忠民, 周瑾, 邬兴威. 东海盆地西湖凹陷中央背斜带油气运移期次及成藏[J]. 石油实验地质, 2006, 28(1): 30-33. doi: 10.11781/sysydz200601030ZHANG Zhongmin, ZHOU Jin, WU Xingwei. Oil and gas migration periods and accumulation process in central anticlinal zone in the Xihu Sag, the East China Sea Basin[J]. Petroleum Geology & Experiment, 2006, 28(1): 30-33. doi: 10.11781/sysydz200601030 [22] 徐昉昊, 徐国盛, 刘勇, 等. 东海西湖凹陷中央反转构造带古近系花港组致密砂岩储集层控制因素[J]. 石油勘探与开发, 2020, 47(1): 98-109.XU Fanghao, XU Guosheng, LIU Yong, et al. Factors controlling the development of tight sandstone reservoirs in the Huagang Formation of the central inverted structural belt in Xihu Sag, East China Sea Basin[J]. Petroleum Exploration and Development, 2020, 47(1): 98-109. [23] 吕延防, 许辰璐, 付广, 等. 南堡凹陷中浅层盖-断组合控油模式及有利含油层位预测[J]. 石油与天然气地质, 2014, 35(1): 86-97. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201401012.htmLV Yanfang, XU Chenlu, FU Guang, et al. Oil-controlling models of caprock-fault combination and prediction of favorable horizons for hydrocarbon accumulation in middle-shallow sequences of Nanpu Sag[J]. Oil & Gas Geology, 2014, 35(1): 86-97. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201401012.htm -
