Characteristics and exploration potential of porous reservoirs in 4th to 5th members of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
-
摘要: 四川盆地下三叠统嘉陵江组主体为一套克拉通台地相沉积，其西南部地区具有埋深浅、储层薄、含气性较好的特点，早期发现了麻柳场、磨溪、赤水为代表的中小型气藏，近年来中国石化在川西南探区井研JS1井嘉四段测试获气2.32×104 m3/d、威远JH1井嘉五段测试获气5.58×104 m3/d。为了进一步明确川西南嘉陵江组孔隙型储层分布及下步勘探的有利目标区，通过区域地质特征、钻井岩心岩屑、铸体薄片及实验地质分析等研究，对嘉陵江组四段—五段孔隙型储层进行了地质评价。嘉四—五段孔隙型储层主要分布于嘉四1、嘉五1层段，灰岩和白云岩储层均有发育，纵向上表现为（灰）云坪与颗粒滩多期叠置的发育模式；储层主要岩石类型为晶粒白云岩、颗粒白云岩和颗粒灰岩，优质储层孔隙结构表现为大孔中喉、大孔细喉及中孔细喉的特征。有利沉积微相云坪和颗粒滩控制了储层的分布，准同生期溶蚀是形成优质孔隙型储层的关键，印支—燕山中晚期流体充注抵御了后期成岩压实和胶结作用对孔隙的破坏；位于泸州古隆起西缘的川西南井研、荣县—宜宾、威远一带是下步勘探评价的有利目标区。Abstract: The main body of Lower Triassic Jialingjiang Formation in the Sichuan Basin is a set of cratonic platform facies deposits. It is characterized by shallow burial depth, thin reservoir thickness and good gas-bearing property in the southwest. Some small- and medium-scale gas reservoirs such as Maliuchang, Moxi and Chishui were discovered in the early stage. In the southwestern Sichuan exploration zone of SINOPEC, a gas production of 2.32×104 m3/d has been discovered in the 4th member of Jialingjiang Formation in well JS 1 in Jingyan area, and a gas production of 5.58×104 m3/d has been discovered in the 5th member of Jialingjiang Formation in well JH 1 in Weiyuan area in recent years. In order to further clarify the distribution of pore-type reservoirs in the Jialingjiang Formation in the southwestern Sichuan Basin and favorable target areas for further exploration, the pore-type reservoirs of the 4th and 5th members of Jialingjiang Formation were evaluated in this study based on the analyses of regional geological characteristics, drilling core cuttings, casting thin sections and experiments. The pore-type reservoirs are found to be mainly distributed in the 1st section of the 4th/5th member of Jialingjiang Formation. Both limestones and dolomites were developed. Vertically, (grey) dolomitic flat and granular beach superimposed in multiple periods. The main rock types of the reservoirs are crystalline dolomite, granular dolomite and granular limestone. The pore structure of high-quality reservoirs is characterized by large pores with medium throat, large pores with fine throat, and medium pores with fine throat. Favorable sedimentary microfacies such as dolomitic flat and granular beach controlled the distribution of reservoirs. Quasi-contemporaneous dissolution was the key to the formation of high-quality pore-type reservoirs. Fluid charging in the Indosinian and mid-late Yanshanian resisted the destruction of pores caused by later diagenetic compaction and cementation. The areas of Jingyan, Rongxian-Yibin and Weiyuan on the western margin of Luzhou paleo-uplift are favorable targets for future exploration.
-
图 1 四川盆地川西南构造位置(a)及下三叠统嘉陵江组岩相综合柱状图(b)
底图引自“十三五”中石化油气资源评价。
Figure 1. Structural zoning map of southwestern Sichuan Basin (a) and comprehensive histogram of Lower Triassic Jialingjiang Formation (b)
图 2 川西南地区下三叠统嘉陵江组嘉四1亚段沉积相
Figure 2. Sedimentary facies of 1st section of 4th member of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 3 川西南地区下三叠统嘉陵江组嘉五1亚段沉积相
Figure 3. Sedimentary facies of 1st section of 5th member of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 4 川西南地区下三叠统嘉陵江组岩石宏观特征
Figure 4. Macroscopic characteristics of rocks from Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 5 川西南地区下三叠统嘉陵江组岩石储集空间
Figure 5. Reservoir space in rocks from Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 6 川西南地区下三叠统嘉陵江组四—五段物性统计
Figure 6. Physical properties of 4th to 5th members of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 7 川西南地区JH1井下三叠统嘉陵江组Ⅰ—Ⅲ类储层典型压汞曲线
Figure 7. Mercury injection curves of reservoirs of types Ⅰ to Ⅲ in Lower Triassic Jialingjiang Formation in well JH 1, southwestern Sichuan Basin
图 8 川西南地区下三叠统嘉四1、嘉五1亚段孔隙型储层发育模式
Figure 8. Development model of pore-type reservoirs in 1st section of 4th/5th member of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 9 川西南地区下三叠统嘉四1储层厚度分布
Figure 9. Reservoir thickness of 1st section of 4th member of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 10 川西南地区下三叠统嘉五1储层厚度分布
Figure 10. Reservoir thickness of 1st section of 5th member of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 11 川西南地区下三叠统嘉陵江组成岩孔隙演化
Figure 11. Pore evolution of Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
图 12 川西南地区下三叠统嘉陵江组储层流体包裹体特征(a)及均一温度分布(b)
Figure 12. Fluid inclusion characteristics (a) and homogenization temperature distribution (b) of reservoirs in Lower Triassic Jialingjiang Formation in southwestern Sichuan Basin
-
[1] 王宓君, 包茨, 肖明德, 等. 中国石油地质志: 卷十四川油气区[M]. 北京: 石油工业出版社, l989: 65-67.WANG Mijun, BAO Ci, XIAO Mingde, et al. Petroleum geology of China: vol. 10 Sichuan petroliferous region[M]. Beijing: Petroleum Industry Press, 1989: 65-67. [2] 陈宗清. 论四川盆地下三叠统嘉陵江组三-四段天然气勘探[J]. 中国石油勘探, 2008, 13(6): 1-11. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY200806002.htmCHEN Zongqing. A discussion on exploration for natural gas in T1j3-4 in Sichuan Basin[J]. China Petroleum Exploration, 2008, 13(6): 1-11. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY200806002.htm [3] 刘华. 四川盆地麻柳场气田嘉陵江组气藏描述[D]. 成都: 西南石油大学, 2006.LIU Hua. Gas reservoir description in Jialingjiang Formation of Maliuchang structure, Sichuan Basin[D]. Chengdu: Southwest Petroleum University, 2006. [4] 孟宪武, 刘勇, 石国山, 等. 四川盆地川西坳陷中段构造演化对中三叠统雷口坡组油气成藏的控制作用[J]. 石油实验地质, 2021, 43(6): 986-995. doi: 10.11781/sysydz202106986MENG Xianwu, LIU Yong, SHI Guoshan, et al. The structural evolution of the middle section of the West Sichuan Depression in the Sichuan Basin controlled the hydrocarbon accumulation in the Middle Triassic Leikoupo Formation[J]. Petroleum Geology & Experiment, 2021, 43(6): 986-995. doi: 10.11781/sysydz202106986 [5] 徐国盛, 孟昱璋, 赵异华, 等. 川中磨溪-龙女寺构造带嘉陵江组天然气成藏机理研究[J]. 石油实验地质, 2009, 31(6): 576-582. doi: 10.11781/sysydz200906576XU Guosheng, MENG Yuzhang, ZHAO Yihua, et al. The study of accumulation mechanism of natural gas in Jialingjiang Formation, Moxi-Longnüsi area in the middle of Sichuan Basin[J]. Petroleum Geology & Experiment, 2009, 31(6): 576-582. doi: 10.11781/sysydz200906576 [6] 成艳, 陆正元, 赵路子, 等. 四川盆地西南边缘地区天然气保存条件研究[J]. 石油实验地质, 2005, 27(3): 218-221. doi: 10.11781/sysydz200503218CHENG Yan, LU Zhengyuan, ZHAO Luzi, et al. Study on the preservation condition of gas reservoir in southwestern edge of Sichuan Basin[J]. Petroleum Geology & Experiment, 2005, 27(3): 218-221. doi: 10.11781/sysydz200503218 [7] 安作相. 沪州古隆起与川南油气[J]. 石油实验地质, 1996, 18(3): 267-273. doi: 10.11781/sysydz199603267AN Zuoxiang. The Luzhou Paleohigh and oil/gas accumulation in southern Sichuan[J]. Experimental Petroleum Geology, 1996, 18(3): 267-273. doi: 10.11781/sysydz199603267 [8] 李其荣, 王廷栋, 李延钧, 等. 泸州古隆起嘉陵江组油气成藏期的确定[J]. 天然气工业, 2005, 25(7): 8-10. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200507005.htmLI Qirong, WANG Tingdong, LI Yanjun, et al. Determination of the reservoir formation stages of Jialingjiang Formation in Luzhou Palaeohigh[J]. Natural Gas Industry, 2005, 25(7): 8-10. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200507005.htm [9] 李延钧, 李其荣, 王廷栋, 等. 泸州古隆起下三叠统嘉陵江组成藏地球化学特征[J]. 石油与天然气地质, 2006, 27(3): 363-369. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200603010.htmLI Yanjun, LI Qirong, WANG Tingdong, et al. Geochemical research of hydrocarbon reservoiring in Lower Triassic Jialingjiang Formation in Luzhou Palaeohigh[J]. Oil & Gas Geology, 2006, 27(3): 363-369. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200603010.htm [10] 李延钧, 梁艳, 雷卞军, 等. 川中-川南过渡带西部嘉二段天然气成因与来源[J]. 天然气地球科学, 2006, 17(6): 820-823. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX200606016.htmLI Yanjun, LIANG Yan, LEI Bianjun, et al. Natural gas genesis for the section Ⅱ of West Jialingjiang Formation in middle Sichuan-south Sichuan transitional belt[J]. Natural Gas Geoscience, 2006, 17(6): 820-823. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX200606016.htm [11] 徐国盛, 何玉, 袁海锋, 等. 四川盆地嘉陵江组天然气藏的形成与演化研究[J]. 西南石油大学学报(自然科学版), 2011, 33(2): 171-178. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201102030.htmXU Guosheng, HE Yu, YUAN Haifeng, et al. Study on the formation and evolution of gas accumulation in Lower Triassic Jialingjiang Formation of Sichuan Basin[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 2011, 33(2): 171-178. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY201102030.htm [12] 黄士鹏, 吴小奇, 陶小晚, 等. 蜀南纳溪-合江地区嘉陵江组天然气地球化学特征及其气源[J]. 地球化学, 2011, 40(6): 525-535. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX201106002.htmHUANG Shipeng, WU Xiaoqi, TAO Xiaowan, et al. Geochemical characteristics and sources of natural gas reservoired in Lower Triassic Jialingjiang Formation in Naxi-Hejiang area, southern Sichuan Basin[J]. Geochimica, 2011, 40(6): 525-535. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX201106002.htm [13] 王维斌, 苟洪才, 邱彬, 等. 四川盆地东部下三叠统嘉陵江组储层特征[J]. 天然气工业, 2005, 25(10): 30-32. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200510009.htmWANG Weibin, GOU Hongcai, QIU Bin, et al. Reservoir characteristics of T1j in the east part of Sichuan Basin[J]. Natural Gas Industry, 2005, 25(10): 30-32. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG200510009.htm [14] 周彦, 谭秀成, 刘宏, 等. 磨溪气田嘉二段鲕粒灰岩储层特征及成因机制[J]. 西南石油大学学报, 2007, 29(4): 30-33. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY200704011.htmZHOU Yan, TAN Xiucheng, LIU Hong, et al. Oolitic limestone reservoir characteristics and its genetic mechanism of Jia2 member in Moxi gas field[J]. Journal of Southwest Petroleum University, 2007, 29(4): 30-33. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY200704011.htm [15] 曹剑, 谭秀成, 陈景山. 川西南犍为地区下三叠统嘉陵江组沉积相及其演化特征[J]. 高校地质学报, 2004, 10(3): 429-439. https://www.cnki.com.cn/Article/CJFDTOTAL-GXDX200403012.htmCAO Jian, TAN Xiucheng, CHEN Jingshan. Sedimentary facies and their evolution characteristics in Jialingjiang Formation of Qianwei area, southwest Sichuan Basin[J]. Geological Journal of China Universities, 2004, 10(3): 429-439. https://www.cnki.com.cn/Article/CJFDTOTAL-GXDX200403012.htm [16] 张长俊, 林雄, 黄文明. 四川盆地嘉陵江组储层形成与演化的成岩作用研究[R]. 成都: 成都理工大学, 2006.ZHANG Changjun, LIN Xiong, HUANG Wenming. Study on diage-nesis of formation and evolution of Jialingjiang Formation reservoir in Sichuan Basin[R]. Chengdu: Chengdu University of Technology, 2006. [17] 林雄, 侯中健, 田景春. 四川盆地下三叠统嘉陵江组储层成岩作用研究[J]. 西南石油大学学报(自然科学版), 2009, 31(2): 8-12. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY200902006.htmLIN Xiong, HOU Zhongjian, TIAN Jingchun. Research on diagenesis of Jialing River Formation, Lower Triassic in Sichuan Basin[J]. Journal of Southwest Petroleum University (Seience & Techno-logy Edition), 2009, 31(2): 8-12. https://www.cnki.com.cn/Article/CJFDTOTAL-XNSY200902006.htm [18] 陈莉琼, 沈昭国, 侯方浩, 等. 四川盆地三叠纪蒸发岩盆地形成环境及白云岩储层[J]. 石油实验地质, 2010, 32(4): 334-340. doi: 10.11781/sysydz201004334CHEN Liqiong, SHEN Zhaoguo, HOU Fanghao, et al. Formation environment of Triassic evaporate rock basin and dolostone reservoirs in the Sichuan Basin[J]. Petroleum Geology & Experiment, 2010, 32(4): 334-340. doi: 10.11781/sysydz201004334 [19] 宋晓波, 隆轲, 王琼仙, 等. 川西地区中三叠统雷口坡组四段上亚段沉积特征[J]. 石油实验地质, 2021, 43(6): 976-985. doi: 10.11781/sysydz202106976SONG Xiaobo, LONG Ke, WANG Qiongxian, et al. Sedimentary characteristics of the upper part of the fourth member of Leikoupo Formation of Middle Triassic in western Sichuan Basin[J]. Petroleum Geology & Experiment, 2021, 43(6): 976-985. doi: 10.11781/sysydz202106976 [20] 李勇, 邓美洲, 李国蓉, 等. 川西龙门山前带雷口坡组四段古表生期大气水溶蚀作用对储集层的影响[J]. 石油实验地质, 2021, 43(1): 56-63. doi: 10.11781/sysydz202101056LI Yong, DENG Meizhou, LI Guorong, et al. Palaeokarst characteristics and effects on reservoirs in the fourth member of Leikoupo Formation, Longmen Mountain front, western Sichuan Basin[J]. Petroleum Geology & Experiment, 2021, 43(1): 56-63. doi: 10.11781/sysydz202101056 -
