Quantitative assessment of source rock maturity with multiple aromatic parameters: a case study of Mesozoic source rocks in Yingen-Ejinaqi Basin
-
摘要: 芳烃成熟度参数被广泛应用于评价烃源岩或原油成熟度,但实际上生源特征、沉积环境等因素对一些参数的影响可能大于成熟度的控制,导致一些参数在某些研究区的应用效果并不理想,且前人基于单一参数建立的计算视镜质体反射率(Rc)的关系式也并不适用于所有研究区,因此,探索出了一种芳烃参数定量评价烃源岩成熟度的方法。该方法基于研究区一定数量的烃源岩芳烃组分的色谱—质谱(GC-MS)分析数据,通过开展各芳烃成熟度参数与Ro的相关性分析,分别在烷基萘系列、烷基菲系列和烷基二苯并噻吩系列3大类芳烃成熟度参数中找出1个对成熟度最敏感(相关系数最大)的参数,利用数值分析软件对这几个参数和Ro进行多元线性回归,拟合出一个利用多参数定量计算Rc的关系式。该方法在银额盆地哈日凹陷中生界湖相混合型(有机质类型以Ⅱ1—Ⅱ2型为主)烃源岩研究中取得了很好的应用效果。用该方法拟合出的关系式计算的Rc与Ro的相关系数R2高达0.96,相对于单一芳烃参数,相关系数有了大幅度的提高,表明该方法具有可靠性。Abstract: Aromatic parameters have been widely applied to assess the maturity of organic matters. Some parameters may not only be affected by maturation, but also more affected by organic matter source, sedimentary environment, etc. Therefore, the application effect of some parameters in some study areas were not satisfying, and the previous relational expression to calculate the vitrinite reflectance (Rc) which only based on a single parameter is also not suitable for other areas. In this study, we proposed a method to improve the accuracy of using multiple aromatic parameters to quantitatively evaluate source rock maturity. This method was based on a certain number of GC-MS analysis data of aromatic fractions of source rocks in the study area, to find out a most sensitive parameter to maturity in three categories of aromatics (alkyl naphthalene series, alkyl phenanthrene series and alkyl dibenzothiophene series) respectively. Here the most sensitive parameter meant having the largest correlation coefficient to Ro in certain category. Then a multiple linear regression equation was established among these three parameters and Ro using a numerical analysis software, and with this equation Rc can then be calculated with multiple parameters. This method is applied to the study of Mesozoic lacustrine source rocks in the Hari Sag of Yingen-Ejinaqi Basin, the organic matter types of these source rock are mainly type Ⅱ1-Ⅱ2. The results indicated that the correlation coefficient (Rc) between Ro and Rc which was calculated by established formula was as high as 0.96, and compared with the single aromatics parameter, the correlation coefficient has been considerably improved.
-
表 1 芳烃成熟度参数
Table 1. Maturity parameters of aromatic hydrocarbons
参数类别 参数代号 表达式 资料来源 烷基萘类 MNR 2-MN/1-MN 文献[1] DNR-1 (2,6-DMN+2,7-DMN)/1,5-DMN 文献[1] DNR-2 2,7-DMN/1,8-DMN 文献[1] DNR-3 2,6-DMN/1,8-DMN 文献[1] DNR-4 1,7-DMN/1,8-DMN 文献[1] DNR-5 1,6-DMN/1,8-DMN 文献[1] TMNr 2,3,6-TMN/(1,4,6-TMN+1,2,5-TMN) 文献[1] TMNr1 2,3,6-TMN/(1,4,6-TMN+1,3,5-TMN) 文献[1] TMNr2 (2,3,6-TMN+1,3,7-TMN)/(1,4,6-TMN+1,3,5-TMN+1,3,6-TMN) 文献[1] TMNr3 1,3,7-TMN/(1,3,7-TMN+1,2,5-TMN) 文献[1] TeMNr 1,3,6,7-TeMN/(1,3,6,7-TeMN+1,2,5,7-TeMN) 文献[1] PMNr 1,2,4,6,7-PMN/(1,2,4,6,7-PMN +1,2,3,5,6-PMN) 文献[1] 烷基菲类 MPI1 1.5×(2-MP+3-MP)/(P+1-MP+9-MP) 文献[7] MPI2 3×(2-MP)/(P+1-MP+9-MP) 文献[7] MPI3 (2-MP+ 3-MP)/(1-MP+9-MP) 文献[5] MPR (2-MP)/ (1-MP) 文献[1] F1 (3-MP + 2-MP) /(1-MP + 2-MP + 3-MP + 9-MP) 文献[9] F2 2-MP /(1-MP + 2-MP + 3-MP + 9-MP) 文献[9] DPR (2,6-MP+2,7-MP)/(1,6-MP+2, 10-MP) 文献[2] DPR2 2,7-MP/1,8-MP 文献[5] 烷基二苯并噻吩类 MDR 4-MDBT/1-MDBT 文献[12-13] MDBI 4-MDBT/(DBT+1-MDBT+2-MDBT+3-MDBT+4-MDBT) 文献[14] DMDBT1 4,6-DMDBT/1,4-DMDBT 文献[10, 12] DMDBT2 2,4-DMDBT/1,4-DMDBT 文献[10, 12] DMDBT3 2,6-DMDBT/1,4-DMDBT 文献[10, 12] DMDBT4 4,6- DMDBT /(1,4- DMDBT +1,6- DMDBT) 文献[11] DMDBT5 (2,6 - DMDBT+3,6- DMDBT)/(1,4- DMDBT + 1,6 - DMDBT) 文献[11] 注:MN.甲基萘;DMN.二甲基萘;TMN.三甲基萘;TeMN.四甲基萘;PMN.五甲基萘;P.菲;MP.甲基菲;DBT.二苯并噻吩;MDBT.甲基二苯并噻吩;DMDBT.二甲基二苯并噻吩 -
[1] 王崇敬, 张鹤, 李世宇, 等. 基于分子标志物的有机质成熟度评价参数选择及其适用范围分析[J]. 地质科技情报, 2018, 37(4): 202-211. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201804028.htmWANG Chongjing, ZHANG He, LI Shiyu, et al. Maturity para-meters selection and applicable range analysis of organic matter based on molecular markers[J]. Geological Science and Technology Information, 2018, 37(4): 202-211. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201804028.htm [2] 赵文, 郭小文, 何生. 生物标志化合物成熟度参数有效性: 以伊通盆地烃源岩为例[J]. 西安石油大学学报(自然科学版), 2016, 31(6): 23-31.ZHAO Wen, GUO Xiaowen, HE Sheng. Analysis on validity of maturity parameters of biomarkers: a case study from source rocks in Yitong Basin[J]. Journal of Xi'an Shiyou University (Natural Science Edition), 2016, 31(6): 23-31. [3] 陈治军, 张佳琪, 牛凌燕, 等. 芳烃参数在湖相烃源岩成熟度评价中的适用性: 以银根—额济纳旗盆地中生界烃源岩为例[J]. 石油学报, 2020, 41(8): 928-939. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202008003.htmCHEN Zhijun, ZHANG Jiaqi, NIU Lingyan, et al. Applicability of aromatic parameters in maturity evaluation of lacustrine source rocks: a case study of Mesozoic source rocks in Yingen-Ejinaqi Basin[J]. Acta Petrolei Sinica, 2020, 41(8): 928-939. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202008003.htm [4] 刘亚洲, 刚文哲, 陈果, 等. 鄂尔多斯盆地盐池—定边地区长7段烃源岩芳烃地球化学特征[J]. 沉积学报, 2018, 36(4): 818-828. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201804017.htmLIU Yazhou, GANG Wenzhe, CHEN Guo, et al. Geochemical characteristics of aromatic hydrocarbons of Chang7 source rocks from the Yanchi-Dingbian area, Ordos Basin[J]. Acta Sedimentologica Sinica, 2018, 36(4): 818-828. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201804017.htm [5] 许婷, 侯读杰, 曹冰, 等. 东海盆地西湖凹陷轻质原油芳烃地球化学特征[J]. 沉积学报, 2017, 35(1): 182-192. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201701018.htmXU Ting, HOU Dujie, CAO Bing, et al. Characteristics of aromatic geochemistry in light oils from Xihu Sag in East China Sea Basin[J]. Acta Sedimentologica Sinica, 2017, 35(1): 182-192. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201701018.htm [6] 王辉. 辽河西部凹陷沙河街组泥岩中多环芳烃分布特征及其地球化学意义[J]. 西安石油大学学报(自然科学版), 2016, 31(6): 39-47. https://www.cnki.com.cn/Article/CJFDTOTAL-XASY201606006.htmWANG Hui. Distribution characteristic of polycyclic aromatic hydrocarbons in Shahejie Formation mudstone, the western Sag, Liaohe Basin and its geochemical significance[J]. Journal of Xi'an Shiyou University (Natural Science), 2016, 31(6): 39-47. https://www.cnki.com.cn/Article/CJFDTOTAL-XASY201606006.htm [7] RADKE M, WELTE D H, WILLSCH H. Geochemical study on a well in the Western Canada Basin: relation of the aromatic distribution pattern to maturity of organic matter[J]. Geochimica et Cosmochimica Acta, 1982, 46(1): 1-10. doi: 10.1016/0016-7037(82)90285-X [8] 武英利, 朱建辉, 倪春华, 等. 松辽盆地南部中小断陷白垩系烃源岩成熟度综合评价: 以彰武、昌图断陷为例[J]. 石油实验地质, 2020, 42(2): 289-295. doi: 10.11781/sysydz202002289WU Yingli, ZHU Jianhui, NI Chunhua, et al. Comprehensive evaluation of Cretaceous source rock maturity in medium and small fault depressions in southern Songliao Basin: a case study of Zhangwu and Changtu fault depressions[J]. Petroleum Geology & Experiment, 2020, 42(2): 289-295. doi: 10.11781/sysydz202002289 [9] KVALHEIM O M, CHRISTY A A, TELNAES N, et al. Maturity determination of organic matter in coals using the methylphenanthrene distribution[J]. Geochimica et Cosmochimica Acta, 1987, 51(7): 1883-1888. doi: 10.1016/0016-7037(87)90179-7 [10] CHAKHMAKHCHEV A, SUZUKI M, TAKAYAMA K. Distribution of alkylated dibenzothiophenes in petroleum as a tool for maturity assessments[J]. Organic Geochemistry, 1997, 26(7/8): 483-489. [11] 周叶骏, 关平, 吴颜雄, 等. 柴达木盆地西部咸水湖相沉积有机质中二苯并噻吩类组成特征及环境意义[J]. 天然气地球科学, 2018, 29(6): 908-920. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201806018.htmZHOU Yejun, GUAN Ping, WU Yanxiong, et al. Characterization on the composition of dibenzothiophene series in saline lacustrine sediments in western Qaidam basin and its environmental implications[J]. Natural Gas Geoscience, 2018, 29(6): 908-920. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201806018.htm [12] LI Meijun, WANG T G, SHI Shengbao, et al. Oil maturity assessment using maturity indicators based on methylated dibenzothiophenes[J]. Petroleum Science, 2014, 11(2): 234-246. doi: 10.1007/s12182-014-0336-3 [13] HUGHES W B. Use of thiophenic organosulfur compounds in characterizing crude oils derived from carbonate versus siliciclastic sources[M]//PALACAS J G. Petroleum geochemistry and source rock potential of carbonate rocks. Tulsa: American Association of Petroleum Geologists, 1984: 181-196. [14] 魏志彬, 张大江, 张传禄, 等. 甲基二苯并噻吩分布指数(MDBI)作为烃源岩成熟度标尺的探讨[J]. 地球化学, 2001, 30(3): 242-247. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX200103006.htmWEI Zhibin, ZHANG Dajiang, ZHANG Chuanlu, et al. Methyl-dibenzothiophenes distribution index as a tool for maturity assessments of source rocks[J]. Geochimica, 2001, 30(3): 242-247. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX200103006.htm [15] 卢双航, 张敏. 油气地球化学[M]. 北京: 石油工业出版社, 2008.LU Shuanghang, ZHANG Min. Oil and gas geochemical[M]. Beijing: Petroleum Industry Press, 2008. [16] 李美俊, 王铁冠. 原油中烷基萘的形成机理及其成熟度参数应用[J]. 石油实验地质, 2005, 27(6): 606-611. doi: 10.11781/sysydz200506606LI Meijun, WANG Tieguan. The generating mechanism of methylated naphthalene series in crude oils and the application of their maturity parameters[J]. Petroleum Geology & Experiment, 2005, 27(6): 606-611. doi: 10.11781/sysydz200506606 [17] 周佩瑜. 石油烃中烷基萘的形成机理及其地球化学意义[J]. 地质科技情报, 2008, 27(5): 92-96. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200805017.htmZHOU Peiyu. Formation mechanism of alkylated naphthalene in petroleum hydrocarbon and its geochemistry significance[J]. Geological Science and Technology Information, 2008, 27(5): 92-96. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200805017.htm [18] 黄海平, 周树青, 初振淼, 等. 生物降解作用对原油中烷基菲分布的影响[J]. 现代地质, 2005, 19(3): 416-424. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ200503013.htmHUANG Haiping, ZHOU Shuqing, CHU Zhenmiao, et al. The effect of biodegradation on alkylated phenanthrene distributions in reservoired oils[J]. Geoscience, 2005, 19(3): 416-424. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ200503013.htm [19] 陈琰, 包建平, 刘昭茜, 等. 甲基菲指数及甲基菲比值与有机质热演化关系: 以柴达木盆地北缘地区为例[J]. 石油勘探与开发, 2010, 37(4): 508-512. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201004019.htmCHEN Yan, BAO Jianping, LIU Zhaoqian, et al. Relationship between methylphenanthrene index, methylphenanthrene ratio and organic thermal evolution: take the northern margin of Qaidam Basin as an example[J]. Petroleum Exploration and Development, 2010, 37(4): 508-512. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201004019.htm [20] 周士科, 杨志承, 张敏. 柴达木盆地绿参1井烃源岩芳烃组成及地球化学意义[J]. 石油天然气学报, 2013, 35(4): 31-35. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX201304008.htmZHOU Shike, YANG Zhicheng, ZHANG Min. Composition features and geochemical significance of aromatic hydrocarbons in oil source rock from well Lucan 1 in Qaidam Basin[J]. Journal of Oil and Gas Technology, 2013, 35(4): 31-35. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX201304008.htm [21] 赵兴齐, 陈践发, 郭望, 等. 开鲁盆地奈曼凹陷奈1区块原油及烃源岩芳烃地球化学特征[J]. 地球化学, 2013, 42(3): 262-273. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX201303007.htmZHAO Xingqi, CHEN Jianfa, GUO Wang, et al. Geochemical characteristics of aromatic hydrocarbon in crude oil and source rocks from Nai 1 block of Naiman Depression, Kailu Basin[J]. Geochimica, 2013, 42(3): 262-273. https://www.cnki.com.cn/Article/CJFDTOTAL-DQHX201303007.htm [22] 刘春, 郭庆新, 张惠良. 川西北地区飞仙关组原油的发现及地质意义[J]. 天然气地球科学, 2011, 22(4): 692-699. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201104019.htmLIU Chun, GUO Qingxin, ZHANG Huiliang. The discovery and geological significance of petroleum of Triassic Feixianguan Formation in northwest Sichuan Basin[J]. Natural Gas Geoscience, 2011, 22(4): 692-699. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201104019.htm [23] 包建平, 王铁冠, 周玉琦, 等. 甲基菲比值与有机质热演化的关系[J]. 江汉石油学院学报, 1992, 14(4): 8-13. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX199204001.htmBAO Jianping, WANG Tieguan, ZHOU Yuqi, et al. The relationship between methyl phenanthrene ratios and the evolution of organic matter[J]. Journal of Jianghan Petroleum Institute, 1992, 14(4): 8-13. https://www.cnki.com.cn/Article/CJFDTOTAL-JHSX199204001.htm [24] 陈治军, 刘舵, 刘护创, 等. 银额盆地厚层粗碎屑岩沉积特征与地层沉积年代的厘定[J]. 沉积学报, 2018, 36(3): 468-482. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201803004.htmCHEN Zhijun, LIU Duo, LIU Huchuang, et al. Sedimentary characte-ristics and stratigraphic age of the thick-bedded coarse clastic rocks in the Yingen-Ejin Banner Basin, Northern China[J]. Acta Sedi-mentologica Sinica, 2018, 36(3): 468-482. https://www.cnki.com.cn/Article/CJFDTOTAL-CJXB201803004.htm [25] 陈志鹏, 任战利, 崔军平, 等. 银额盆地哈日凹陷YHC1井高产油气层时代归属及油气地质意义[J]. 石油与天然气地质, 2019, 40(2): 354-368. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201902015.htmCHEN Zhipeng, REN Zhanli, CUI Junping, et al. Age and petroleum geological implications of prolific formations in Ha'ri Depression well YHC1, Yin'e Basin[J]. Oil & Gas Geology, 2019, 40(2): 354-368. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201902015.htm [26] 耿师江, 周勇水, 王亚明, 等. 银额盆地查干凹陷稠油油藏特征及成因[J]. 断块油气田, 2021, (4): 463-469. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202104007.htmGENG Shijiang, ZHOU Yongshui, WANG Yaming, et al. The characteristics and genesis of heavy oil reservoir in Chagan Sag, Yingen-Ejinaqi Basin[J]. Fault-Block Oil and Gas Field, 2021, (4): 463-469. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202104007.htm [27] 陈治军, 高怡文, 刘护创, 等. 银根—额济纳旗盆地哈日凹陷下白垩统烃源岩地球化学特征与油源对比[J]. 石油学报, 2018, 39(1): 69-81. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201801006.htmCHEN Zhijun, GAO Yiwen, LIU Huchuang, et al. Geochemical characteristics of Lower Cretaceous source rocks and oil-source correlation in Hari Sag, Yingen-Ejinaqi Basin[J]. Acta Petrolei Sinica, 2018, 39(1): 69-81. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201801006.htm [28] 陈治军, 马芳侠, 肖刚, 等. 银额盆地哈日凹陷巴音戈壁组精细油源对比[J]. 石油与天然气地质, 2019, 40(4): 900-916. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201904019.htmCHEN Zhijun, MA Fangxia, XIAO Gang, et al. Oil-sources rock correlation of Bayingebi Formation in Hari Sag, Yingen-Ejinaqi Basin[J]. Oil & Gas Geology, 2019, 40(4): 900-916. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201904019.htm [29] 蒋航, 曾德铭, 刘护创, 等. 银额盆地拐子湖凹陷北部烃源岩特征及控制因素[J]. 特种油气藏, 2020, 27(4): 33-40. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202004005.htmJIANG Hang, ZENG Deming, LIU Huchuang, et al. Source-rock characterization and main-controlling factors in the Northern Guaizihu Depression of Yin'e Basin[J]. Special Oil & Gas Reserviors, 2020, 27(4): 33-40. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202004005.htm [30] 万涛, 张洪安, 张宝君, 等. C29重排谷甾烷在油源对比研究中的应用: 以银额盆地查干凹陷为例[J]. 断块油气田, 2021, (2): 173-178. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202102007.htmWAN Tao, ZHANG Hongan, ZHANG Baojun, et al. The application of C29 rearranged sitostane in oil source correlation research: taking Chagan Depression of Yingen-Ejinaqi Basin for example[J]. Fault-Block Oil and Gas Field, 2021, (2): 173-178. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202102007.htm [31] 王小多, 任来义, 刘护创, 等. 银额盆地哈日凹陷下白垩统烃源岩特征及资源潜力[J]. 西安科技大学学报, 2019, 39(2): 286-293.WANG Xiaoduo, REN Laiyi, LIU Huchuang, et al. Characteristics and resource potential analysis of the Lower Cretaceous source rocks in the Hari Sag, Yin'gen-Ejinaqi Basin[J]. Journal of Xi'an University of Science and Technology, 2019, 39(2): 286-293. [32] 中国石油天然气总公司. SY/T 5735-1995, 陆相烃源岩地球化学评价方法[S]. 北京: 石油工业出版社, 1996.PetroChina Co Ltd. SY/T 5735-1995, Geochemical evaluation standard of terrestrial hydrocarbon source rock[S]. Beijing: Petroleum Industry Press, 1996. [33] 侯读杰, 张林晔. 实用油气地球化学图鉴[M]. 北京: 石油工业出版社, 2003.HOU Dujie, ZHANG Linye. Practical oil and gas geochemical map[M]. Beijing: Petroleum Industry Press, 2003. [34] 朱扬明, 张洪波, 傅家谟, 等. 塔里木不同成因原油芳烃组成和分布特征[J]. 石油学报, 1998, 19(3): 33-37. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB803.006.htmZHU Yangming, ZHANG Hongbo, FU Jiamo, et al. Distribution and composition of aromatic hydrocarbon in various oils from Tarim Basin[J]. Acta Petrolei Sinica, 1998, 19(3): 33-37. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB803.006.htm [35] ZHANG Min, PHILP P. Geochemical characterization of aromatic hydrocarbons in crude oils from the Tarim, Qaidam and Turpan basins, NW China[J]. Petroleum Science, 2010, 7(4): 448-457. [36] 贾存善, 王延斌, 顾忆, 等. 塔河油田奥陶系原油芳烃地球化学特征[J]. 石油实验地质, 2009, 31(4): 384-388. doi: 10.11781/sysydz200904384JIA Cunshan, WANG Yanbin, GU Yi, et al. Geochemical characterisrics of aromatic hydrocarbons of crude oils from Ordovician reservoir in the Tahe oilfield[J]. Petroleum Geology & Experiment, 2009, 31(4): 384-388. doi: 10.11781/sysydz200904384 -
