Evolution of prototype basin and change of tectonic-sedimentary pattern in Paleozoic, Ordos Basin
-
摘要: 鄂尔多斯古生代盆地是在前寒武系裂陷体系上发育起来的克拉通盆地，经历了早古生代克拉通边缘拗陷和晚古生代克拉通内拗陷两个阶段。其中早古生代克拉通边缘拗陷阶段可细分为早—中寒武世张夏期、晚寒武世三山子期—早奥陶世亮甲山期、中奥陶世马家沟期、晚奥陶世平凉期—背锅山期等4个阶段；晚古生代克拉通内拗陷可细分为晚石炭世—早二叠世、中—晚二叠世等2个阶段。古生代盆地从早寒武世—中奥陶世被动大陆边缘伸展转变为晚奥陶世—二叠纪主动大陆边缘，构造变革受周缘大地构造体制转变控制，内部构造沉积格局具有从寒武纪早期西南“L”型伸展裂陷、中—晚寒武世“坳—坡—隆—坪”、奥陶纪“坳—坡—隆—坳”、石炭—二叠纪“一隆两坳”逐步演化的特征。古生代原型盆地演化和构造—沉积格局变迁过程中，派生了多套烃源岩和储层，其中盆地西—南缘持续沉降区域发育寒武系苏峪口组—辛集组、徐庄组、奥陶系平凉组、石炭—二叠系煤系烃源岩，盆地内部沉降区发育奥陶系徐庄组、马家沟组、石炭—二叠系煤系烃源岩；下古生界中央古隆起两侧古斜坡区发育张夏组高能鲕粒滩、克里摩里组生物礁滩—颗粒滩、马家沟组颗粒滩等有效储层。Abstract: The Ordos Basin is a craton basin developed based on the Precambrian rift system during Permian. It has experienced two stages of evolution including the Early Paleozoic craton marginal depression and Late Paleozoic intra-craton depression. The former can be further divided into four periods, including the Zhangxia period of Early to Middle Cambrian, the Sanshanzi period of Late Cambrian to the Liangjiashan period of Early Ordovician, the Majiagou period of Middle Ordovician, and the Pingliang-Beiguoshan period of Late Ordovician. The latter can be further divided into two periods, including Late Carboniferous to Early Permian and Middle to Late Permian. Controlled by the transformation of surrounding tectonic system of North-China blocks, the Paleozoic Ordos Basin evolved from passive continental margin extension in the Early Cambrian and Middle Ordovician to active continental convergence in Late Ordovician and Permian. The internal tectonic sedimentary pattern gradually evolved from a "L-shaped" extensional rift in the southwest of the basin during Cambrian, to "depression-slope-uplift-plateau" druing the Middle-Late Cambrian, to "depression-slope-uplift-depression" during Ordovician, and to "one uplift and two depressions" during[JP] Carboniferous to Permian. During the evolution of Paleozoic prototype basin and the change of tectonic-sedimentary pattern, several sets of source rocks and reservoirs were derived. In the continuously subsiding region on the western and southern margin of the basin, coal-measure source rocks deposited in Cambrian Suyukou-Xinji formations, Xuzhuang Formation, [JP]Ordovician Pingliang Formation, Carboniferous and Permian. In the subsiding region inside the basin, coal-measure source rocks deposited in Ordovician Xuzhuang Formation, Majigou Formation, Carboniferous and Permian. Effective reservoirs, such as high-energy oolitic beach of Zhangxia Formation, bioreef-granule beach of Krimori Formation and granulate beach of Majiagou Formation, were developed in the western and eastern paleoslope areas of the central paleouplift of the Paleozoic Ordos Basin.
-
Key words:
- prototype basin /
- tectonic setting /
- sedimentary pattern /
- Paleozoic /
- Ordos Basin
-
图 1 鄂尔多斯盆地中部东西向地震地质结构大剖面及构造—地层层序
Figure 1. E-W seismic geologic section and tectonic-stratigraphic sequences in central Ordos Basin
图 2 华北地区早古生代南北向区域构造—沉积演化模式
Figure 2. Regional tectonic-sedimentary evolution model of North China during Early Paleozoic
图 3 华北地区寒武纪—奥陶纪早期不同阶段原型盆地分布
Figure 3. Distribution of prototype basins in different stages from Cambrian to Early Ordovician in North China
图 4 华北地区奥陶纪中晚期不同阶段原型盆地分布
Figure 4. Distribution of prototype basins in different stages from middle to late Ordovician in North China
图 5 华北及邻区奥陶纪末—二叠纪南北向大地构造动力学背景
Figure 5. S-N tectonic dynamic background of North China and adjacent areas from Late Ordovician to Permian
图 6 华北地区晚石炭世—早中二叠世构造—沉积格局
Figure 6. Tectonic-sedimentary pattern in North China from Late Carboniferous to Early-Middle Permian
-
[1] 朱夏. 活动论构造历史观[J]. 石油实验地质, 1991, 13(3): 201-209. doi: 10.11781/sysydz199103201ZHU Xia. Tectonic history viewpoint of active theory[J]. Experiment Petroleum Geology, 1991, 13(3): 201-209. doi: 10.11781/sysydz199103201 [2] 张渝昌. 动态的盆地和石油: 从盆地原型系统的组合例解油气的形成和分布[M]. 北京: 石油工业出版社, 2010.ZHANG Yuchang. Dynamic basin and petroleum[M]. Beijing: Petroleum Industry Press, 2010. [3] 张渝昌. 中国含油气盆地原型分析[M]. 南京: 南京大学出版社, 1997.ZHANG Yuchang. Prototype analysis of oil-bearing basins in China[M]. Nanjing: Nanjing University Press, 1997. [4] 刘池洋, 王建强, 赵晓辰, 等. 盆地"原型"及其相关外延称谓与研究[J]. 石油实验地质, 2020, 42(5): 720-727. doi: 10.11781/sysydz202005720LIU Chiyang, WANG Jianqiang, ZHAO Xiaochen, et al. The prototype basin and its nomenclatures and research[J]. Petroleum Geology & Experiment, 2020, 42(5): 720-727. doi: 10.11781/sysydz202005720 [5] 朱伟林, 陈春峰, 张伯成, 等. 南黄海古生代盆地原型演变与烃源岩发育特征[J]. 石油实验地质, 2020, 42(5): 728-741. doi: 10.11781/sysydz202005728ZHU Weilin, CHEN Chunfeng, ZHANG Bocheng, et al. Paleozoic basin prototype evolution and source rock development in the South Yellow Sea[J]. Petroleum Geology & Experiment, 2020, 42(5): 728-741. doi: 10.11781/sysydz202005728 [6] 杨风丽, 周晓峰, 胡虞杨, 等. 新元古代扬子克拉通TSM盆地原型分析[J]. 石油实验地质, 2020, 42(5): 742-755. doi: 10.11781/sysydz202005742YANG Fengli, ZHOU Xiaofeng, HU Yuyang, et al. TSM prototype basins on the Neoproterozoic Yangtze Craton[J]. Petroleum Geology & Experiment, 2020, 42(5): 742-755. doi: 10.11781/sysydz202005742 [7] 王振涛, 周洪瑞, 王训练, 等. 鄂尔多斯盆地西缘北部奥陶纪盆地原型: 来自贺兰山和桌子山地区奥陶系的沉积响应[J]. 地质论评, 2016, 62(4): 1041-1061. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201604020.htmWANG Zhentao, ZHOU Hongrui, WANG Xunlian, et al. The Ordovician basin prototype in the northwest Ordos Basin: constraint from the Ordovician sedimentary respond in the Helan-Zhuozi mountains[J]. Geological Review, 2016, 62(4): 1041-1061. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201604020.htm [8] 方成名, 黄泽光. 中国中西部大型盆地差异演化与碎屑岩油气响应[J]. 石油实验地质, 2016, 38(6): 703-712. doi: 10.11781/sysydz201606703FANG Chengming, HUANG Zeguang. Differential characteristics of large-scale basin evolution and hydrocarbon response of clastic strata in central-western China[J]. Petroleum Geology & Experiment, 2016, 38(6): 703-712. doi: 10.11781/sysydz201606703 [9] 张进, 李锦轶, 刘建峰, 等. 早古生代阿拉善地块与华北地块之间的关系: 来自阿拉善东缘中奥陶统碎屑锆石的信息[J]. 岩石学报, 2012, 28(9): 2912-2934. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201209021.htmZHANG Jin, LI Jinyi, LIU Jianfeng, et al. The relationship between the Alxa block and the North China Plate during the Early Paleozoic: new information from the Middle Ordovician detrial zircon ages in the eastern Alxa block[J]. Acta Petrologica Sinica, 2012, 28(9): 2912-2934. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201209021.htm [10] 徐旭辉, 方成名, 陆建林, 等. 原型控源、迭加控藏: 油气盆地资源分级评价与有利勘探方向优选思维及技术[J]. 石油实验地质, 2020, 42(5): 824-836. doi: 10.11781/sysydz202005824XU Xuhui, FANG Chengming, LU Jianlin, et al. Hydrocarbon sources controlled by basin prototype and petroleum accumulation controlled by basin superposition: thoughts and technology of resource grading evaluation and exploration optimization in petroliferous basins[J]. Petroleum Geology & Experiment, 2020, 42(5): 824-836. doi: 10.11781/sysydz202005824 [11] 周小进, 倪春华, 杨帆. 华北古生界原型-变形构造演化及其控油气作用[J]. 石油与天然气地质, 2010, 31(6): 779-794. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201006014.htmZHOU Xiaojin, NI Chunhua, YANG Fan. The Paleozoic prototype basins and their tectonic deformation in North China and their controlling effects upon hydrocarbon accumulation[J]. Oil & Gas Geology, 2010, 31(6): 779-794. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201006014.htm [12] 余和中, 韩守华, 谢锦龙, 等. 华北板块东南缘原型沉积盆地类型与构造演化[J]. 石油与天然气地质, 2006, 27(2): 244-252. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200602016.htmYU Hezhong, HAN Shouhua, XIE Jinlong, et al. Types of original sedimentary basins and tectonic evolution on southeastern margin of North China plate[J]. Oil & Gas Geology, 2006, 27(2): 244-252. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200602016.htm [13] 袁卫国, 赵一鸣. 鄂尔多斯南部地区早古生代被动大陆边缘特征与演化[J]. 西北大学学报(自然科学版), 1996, 26(5): 84-87. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ605.018.htmYUAN Weiguo, ZHAO Yiming. Characteristics and evolution of passive continental margin during Early Palaeozoic Era in southern Ordos[J]. Journal of Northwest University (Natural Science Edition), 1996, 26(5): 84-87. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ605.018.htm [14] 王玉新. 鄂尔多斯地块早古生代构造格局及演化[J]. 地球科学(中国地质大学学报), 1994, 19(6): 778-786. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX199406008.htmWANG Yuxin. Tectonic framework and evolution of Ordos massif in Early Paleozoic[J]. Earth Science(Journal of China University of Geosciences), 1994, 19(6): 778-786. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX199406008.htm [15] 冯娟萍, 李文厚, 欧阳征健. 鄂尔多斯地区中新元古代构造沉积演化研究[J]. 西北大学学报(自然科学版), 2020, 50(4): 634-643. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ202004015.htmFENG Juanping, LI Wenhou, OUYANG Zhengjian. Tectonic and depositional evolution of Meso-Neo Proterozoic in Ordos area[J]. Journal of Northwest University (Natural Science Edition), 2020, 50(4): 634-643. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ202004015.htm [16] 周进高, 席胜利, 邓红婴, 等. 鄂尔多斯盆地寒武系-奥陶系深层海相碳酸盐岩构造-岩相古地理特征[J]. 天然气工业, 2020, 40(2): 41-53. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202002007.htmZHOU Jin'gao, XI Shengli, DENG Hongying, et al. Tectonic-lithofacies paleogeographic characteristics of Cambrian-Ordovician deep marine carbonate rocks in the Ordos Basin[J]. Natural Gas Industry, 2020, 40(2): 41-53. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202002007.htm [17] 杜金虎, 李相博, 包洪平, 等. 鄂尔多斯盆地中新元古界-下古生界天然气成藏地质条件及勘探新领域[J]. 石油勘探与开发, 2019, 46(5): 820-835. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201905004.htmDU Jinhu, LI Xiangbo, BAO Hongping, et al. Geological conditions of natural gas accumulation and new exploration areas in the Mesoproterozoic to Lower Paleozoic of Ordos Basin, NW China[J]. Petroleum Exploration and Development, 2019, 46(5): 820-835. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201905004.htm [18] 郝松立, 孙六一, 包洪平, 等. 鄂尔多斯盆地中-新元古界勘探方向及潜力[J]. 天然气地球科学, 2016, 27(12): 2127-2135. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201612004.htmHAO Songli, SUN Liuyi, BAO Hongping, et al. Exploration direction and potential of the Middle-Upper Proterozoic in Ordos Basin[J]. Natural Gas Geoscience, 2016, 27(12): 2127-2135. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201612004.htm [19] LI Z X, BOGDANOVA S V, COLLINS A S, et al. Assembly, configuration, and break-up history of Rodinia: a synthesis[J]. Precambrian Research, 2008, 60(1/2): 179-210. [20] DONG Yunpeng, SANTOSH M. Tectonic architecture and multiple orogeny of the Qinling Orogenic Belt, Central China[J]. Gondwana Research, 2016, 29(1): 1-40. [21] 张春林, 姚泾利, 李程善, 等. 鄂尔多斯盆地深层寒武系碳酸盐岩储层特征与主控因素[J]. 石油与天然气地质, 2021, 42(3): 604-614. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202103008.htmZHANG Chunlin, YAO Jingli, LI Chengshan, et al. Characteristics of deep Cambrian carbonate reservoirs in the Ordos Basin and main control factors[J]. Oil & Gas Geology, 2021, 42(3): 604-614. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202103008.htm [22] 张军涛, 金晓辉, 谷宁, 等. 鄂尔多斯盆地北部地区马家沟组岩溶储层的差异性和发育模式[J]. 石油与天然气地质, 2021, 42(5): 1159-1168. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202105014.htmZHANG Juntao, JIN Xiaohui, GU Ning, et al. Differences and development patterns of karst reservoirs in Majiagou Formation, northern Ordos Basin[J]. Oil & Gas Geology, 2021, 42(5): 1159-1168. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202105014.htm [23] 吴素娟, 张永生, 邢恩袁. 鄂尔多斯盆地西北缘奥陶纪凝灰岩锆石U-Pb年龄、Hf同位素特征及地质意义[J]. 地质论评, 2017, 63(5): 1309-1327. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201705015.htmWU Sujuan, ZHANG Yongsheng, XING Enyuan. Zircon U-Pb ages and Hf isotope characteristics and their geological significance of tuff in Wulalike Formation in the northwestern Ordos Basin[J]. Geological Review, 2017, 63(5): 1309-1327. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201705015.htm [24] 李振宏, 徐黎明, 刘新社, 等. 鄂尔多斯盆地南缘奥陶纪沉积充填记录的关键时限及其构造意义[J]. 地质科学, 2015, 50(2): 428-445. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX201502006.htmLI Zhenhong, XU Liming, LIU Xinshe, et al. Critical timing of sedimentary filling records of Ordovician and its tectonic significance on the southern Ordos Basin[J]. Chinese Journal of Geo-logy, 2015, 50(2): 428-445. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX201502006.htm [25] 金晓辉, 张军涛, 孙冬胜, 等. 鄂尔多斯盆地南缘上奥陶统平凉组浅钻中古岩溶洞穴的发现及其意义[J]. 石油与天然气地质, 2021, 42(3): 595-603. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202103007.htmJIN Xiaohui, ZHANG Juntao, SUN Dongsheng, et al. Discovery and significance of the Ordovician paleo-karst caves in shallow drilling in the southern Ordos Basin[J]. Oil & Gas Geology, 2021, 42(3): 595-603. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202103007.htm [26] 张克信. 中国沉积大地构造图说明书(1: 2500000)[M]. 北京: 地质出版社, 2015.ZHANG Kexin. Explanatory note to the sedimentary tectonic map of China[M]. Beijing: Geological Publishing House, 2015. [27] 张克信, 何卫红, 徐亚东, 等. 中国沉积岩建造与沉积大地构造[M]. 北京: 地质出版社, 2017.ZHANG Kexin, HE Weihong, XU Yadong, et al. Sedimentary rock formation and geotectonics of China[M]. Beijing: Geolo-gical Publishing House, 2017. [28] 徐亚军, 杜远生, 杨江海. 北祁连造山带晚奥陶世-泥盆纪构造演化: 碎屑锆石年代学证据[J]. 地球科学(中国地质大学学报), 2013, 38(5): 934-946. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201305004.htmXU Yajun, DU Yuansheng, YANG Jianghai. Tectonic evolution of the North Qilian Orogenic belt from the Late Ordovician to Devonian: evidence from detrital zircon geochronology[J]. Earth Science(Journal of China University of Geosciences), 2013, 38(5): 934-946. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX201305004.htm [29] XU Yajun, DU Yuansheng, CAWOOD P A, et al. Detrital zircon record of continental collision: assembly of the Qilian orogen, China[J]. Sedimentary Geology, 2010, 230(1/2): 35-45. [30] 杜远生, 朱杰, 韩欣, 等. 从弧后盆地到前陆盆地: 北祁连造山带奥陶纪-泥盆纪的沉积盆地与构造演化[J]. 地质通报, 2004, 23(9/10): 911-917. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD2004Z2012.htmDU Yuansheng, ZHU Jie, HAN Xin, et al. From the back-arc basin to foreland basin: Ordovician-Devonian sedimentary basin and tectonic evolution in the North Qilian orogenic belt[J]. Geological Bulletin of China, 2004, 23(9/10): 911-917. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD2004Z2012.htm [31] 胡云亭, 刘灵童, 王文升, 等. 基于沉积相控的优质储层预测: 以鄂尔多斯盆地X区块下石盒子组致密砂岩气为例[J]. 断块油气田, 2020, 27(6): 705-709, 718. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202006007.htmHU Yunting, LIU Lingtong, WANG Wensheng, et al. High-quality reservoir prediction based on sedimentary facies control technique: taking tight sandstone gas of X block in Lower Shihezi Formation of Ordos Basin as an example[J]. Fault-Block Oil and Gas Field, 2020, 27(6): 705-709, 718. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202006007.htm [32] 罗开平, 杨帆, 陆永德, 等. 鄂尔多斯盆地杭锦旗地区关键构造期与二叠系致密气成藏响应[J]. 石油实验地质, 2021, 43(4): 557-568. doi: 10.11781/sysydz202104557LUO Kaiping, YANG Fan, LU Yongde, et al. Key structural periods and Permian tight gas accumulation response in Hangjinqi area, Ordos Basin[J]. Petroleum Geology & Experiment, 2021, 43(4): 557-568. doi: 10.11781/sysydz202104557 [33] 廖建波, 陈启林, 李智勇, 等. 鄂尔多斯南缘下寒武统烃源岩的发现与意义[J]. 中国矿业大学学报, 2016, 45(3): 527-534. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGKD201603015.htmLIAO Jianbo, CHEN Qilin, LI Zhiyong, et al. Discovery and significance of hydrocarbon source rocks in the Lower Cambrian at the southern margin of Ordos Basin[J]. Journal of China University of Mining & Technology, 2016, 45(3): 527-534. https://www.cnki.com.cn/Article/CJFDTOTAL-ZGKD201603015.htm [34] 侯林君, 陈洪德, 罗林军, 等. 鄂尔多斯盆地前寒武纪末期古地貌恢复及其对烃源岩的控制作用[J]. 地球科学与环境学报, 2019, 41(4): 475-490. https://www.cnki.com.cn/Article/CJFDTOTAL-XAGX201904009.htmHOU Linjun, CHEN Hongde, LUO Linjun, et al. Reconstruction of Late Precambrian palaeogeomorphology in Ordos Basin, China and its control on source rocks[J]. Journal of Earth Sciences and Environment, 2019, 41(4): 475-490. https://www.cnki.com.cn/Article/CJFDTOTAL-XAGX201904009.htm [35] 刘池洋, 王建强, 张东东, 等. 鄂尔多斯盆地油气资源丰富的成因与赋存-成藏特点[J. 石油与天然气地质, 2021, 42(5): 1011-1029. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202105002.htmLIU Chiyang, WANG Jianqiang, ZHANG Dongdong, et al. Genesis of rich hydrocarbon resources and their occurrence and accumulation characteristics in the Ordos Basin[J]. Oil & Gas Geology, 2021, 42(5): 1011-1029. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202105002.htm [36] 包洪平, 杨帆, 白海峰, 等. 细分小层岩相古地理编图的沉积学研究及油气勘探意义: 以鄂尔多斯地区中东部奥陶系马家沟组马五段为例[J]. 岩石学报, 2017, 33(4): 1094-1106. https://www.cnki.com.cn/Article/CJFDTOTAL-YSXB201704006.htm -
