渤海湾盆地东营凹陷古近系富碳酸盐矿物页岩储集特征及其控制因素

徐效平

doi:10.11781/sysydz202303413

渤海湾盆地东营凹陷古近系富碳酸盐矿物页岩储集特征及其控制因素

doi: 10.11781/sysydz202303413

徐效平

中国石化胜利油田东胜精攻石油开发集团股份有限公司, 山东东营 257000

详细信息

作者简介:
徐效平(1974—)，男，硕士，高级工程师，从事石油地质综合研究工作。E-mail: xuxiaoping015.slyt@sinopec.com

中图分类号: TE122.2
计量
- 文章访问数: 926
- HTML全文浏览量: 392
- PDF下载量: 101
- 被引次数: 0
出版历程
- 收稿日期: 2023-03-27
- 修回日期: 2023-05-12
- 刊出日期: 2023-05-28

Reservoir characteristics and controlling factors of Paleogene carbonate-rich shale in Dongying Sag, Bohai Bay Basin

XU Xiaoping

Dongsheng Jinggong Petroleum Development Stock Co., Ltd., Shengli Oilfield, SINOPEC, Dongying, Shandong 257000, China

摘要

摘要: 综合运用岩心观察、薄片观察、氮气吸附和X衍射等分析方法，对渤海湾盆地济阳坳陷东营凹陷牛页1井、樊页平1井古近系沙河街组四段上亚段的湖相页岩的矿物组成、沉积构造、纹层类型、孔径分布、孔体积、比表面积、纹层数量及溶蚀孔形态等特征进行了精细刻画。在此基础上总结了该地区主要岩相类型及纹层特征，不同岩相的孔径、孔体积及比表面积，富碳酸盐矿物页岩的孔隙及纹层特征。东营凹陷主要发育富有机质纹层状泥质灰岩、富有机质纹层状砂质灰岩、含有机质纹层状砂质灰岩、含有机质块状灰岩4种岩相类型。纹层镜下特征主要有平直状、透镜状、夹层状、波状等特征。实测氮气吸附数据显示东营凹陷富碳酸盐矿物页岩具有更大的孔体积及比表面积。同时，溶蚀孔和纹层的发育使得富碳酸盐矿物页岩具有更高的储集能力和水平渗透率。因此，富碳酸盐矿物页岩是东营凹陷优质储集单位。
