Exploration and development practice of normal pressure shale gas in Dongsheng structural belt, Nanchuan area, southeast Chongqing
-
摘要: 渝东南南川地区东胜构造带位于四川盆地东南缘的盆缘过渡带，经历多期构造改造，具有构造复杂、保存条件复杂、地应力场复杂的典型地质特征，导致常压页岩气单井产量差异较大。为提高东胜复杂构造带常压页岩气单井产量、实现效益开发，通过开展地震资料目标处理、构造特征分析、成藏富集规律研究及生产动态分析等，以及加强基础研究和勘探开发实践，明确了东胜复杂构造带实现常压页岩气效益开发的四项关键技术对策：①提高浅层速度模型精度，提升构造解释准确度；②优化井网部署，提高井控储量；③地质工程一体化，钻定导协同导向提高甜点钻遇率；④建立分区差异化压裂方案，提高裂缝复杂度。东胜常压页岩气效益开发关键技术对策为复杂构造带常压页岩气的效益开发提供了技术支撑，同时也可为盆缘其他类似地区的勘探开发提供借鉴。Abstract: The Dongsheng structural belt in Nanchuan area, southeast Chongqing, is located in the transitional zone of the southeastern margin of Sichuan Basin. It has experienced multi-period tectonic reformation and has typical geological characteristics of complex structure, complex preservation conditions and complex in-situ stress field, which leads to a significant difference in single well production. In order to increase the single well production of normal pressure shale gas wells in Dongsheng complex structural belt and realize profitable development, through target processing of seismic data, analysis of structural characteristics, study of accumulation regularity and analysis of production dynamics, as well as the strengthening of basic research and exploration and development practice, four key technical countermeasures for realizing profitable development of normal pressure shale gas in Dongsheng complex structural belt are defined: (1) improve the accuracy of shallow velocity model and structure interpretation; (2) optimize well pattern deployment, increase well-controlled reserves; (3) integrate geology and engineering, and coordinate drilling, orientation and steering to improve the drilling rate of sweet spots; (4) establish a zonal differentiated fracturing scheme to improve fracture complexity. These four countermea-sures provide technical support for the profitable development of normal pressure shale gas in complex structural zones, and provide reference for the exploration and development of other similar areas along the basin margin.
-
图 1 渝东南南川地区构造特征及地质剖面示意
Figure 1. Structural characteristics and geological section of Nanchuan area in southeast Chongqing
图 2 渝东南东胜构造带五峰组底界构造(a)、地层压力系数(b)、最大水平主应力方位变化(c)及最大水平主应力分布(d)
平面位置见图 1。
Figure 2. Bottom boundary structure (a), formation pressure coefficient (b), maximum horizontal principal stress direction change (c) and maximum horizontal principal stress distribution (d) of Wufeng Formation in Dongsheng structural belt, southeast Chongqing
图 3 渝东南东胜与阳春沟构造带施工压力对比
Figure 3. Contrast map of construction pressure of Dongsheng and Yangchungou structural belts in southeast Chongqing
图 4 渝东南东胜构造带过SY23-2HF井轨迹剖面
Figure 4. Trajectory profile of Dongsheng structural belt crossing well SY23-2HF in southeast Chongqing
图 5 渝东南东胜构造带不同加砂强度下裂缝扩展示意
Figure 5. Fracture propagation under different sand strength in Dongsheng structural belt in southeast Chongqing
图 6 渝东南东胜构造带优化开发对策前、后单井EUR(a)与归一化生产曲线对比(b)
Figure 6. Comparison of single well EUR(a) and normalized production curves(b) before and after optimization of development countermeasures in Dongsheng structural belt in southeast Chongqing
图 7 渝东南东胜构造带背斜区与斜坡区气井归一化生产曲线
Figure 7. Normalized production curves of gas wells in the anticline area and slope area of Dongsheng structural belt in southeast Chongqing
表 1 渝东南东胜构造带斜坡区不同加砂强度下缝网模拟参数
Table 1. Simulation parameters of seam mesh under different sand strength in the slope area of Dongsheng structural belt in southeast Chongqing
加砂强度/(m3/m) 平均缝长/m 平均缝宽/m 平均缝高/m 裂缝导流能力/(10-3 μm2·m) EUR预测/108m3 2.0 225 11 31 224 0.65 3.0 286 16 34 427 0.74 4.0 339 19 38 596 0.80 5.0 368 20 40 643 0.82
下载: 导出CSV
-
[1] 马永生, 蔡勋育, 赵培荣. 中国页岩气勘探开发理论认识与实践[J]. 石油勘探与开发, 2018, 45(4): 561-574. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201804004.htmMA Yongsheng, CAI Xunyu, ZHAO Peirong. China's shale gas exploration and development: understanding and practice[J]. Petroleum Exploration and Development, 2018, 45(4): 561-574. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201804004.htm [2] 马永生, 黎茂稳, 蔡勋育, 等. 海相深层油气富集机理与关键工程技术基础研究进展[J]. 石油实验地质, 2021, 43(5): 737-748. doi: 10.11781/sysydz202105737MA Yongsheng, LI Maowen, CAI Xunyu, et al. Advances in basic research on the mechanism of deep marine hydrocarbon enrichment and key exploitation technologies[J]. Petroleum Geology & Experiment, 2021, 43(5): 737-748. doi: 10.11781/sysydz202105737 [3] 孙焕泉, 周德华, 蔡勋育, 等. 中国石化页岩气发展现状与趋势[J]. 中国石油勘探, 2020, 25(2): 14-26. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202002002.htmSUN Huanquan, ZHOU Dehua, CAI Xunyu, et al. Progress and prospect of shale gas development of SINOPEC[J]. China Petroleum Exploration, 2020, 25(2): 14-26. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202002002.htm [4] 方志雄. 中国南方常压页岩气勘探开发面临的挑战及对策[J]. 油气藏评价与开发, 2019, 9(5): 1-13. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ201905001.htmFANG Zhixiong. Challenges and countermeasures for exploration and development of normal pressure shale gas in southern China[J]. Reservoir Evaluation and Development, 2019, 9(5): 1-13. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ201905001.htm [5] 何希鹏. 四川盆地东部页岩气甜点评价体系与富集高产影响因素[J]. 天然气工业, 2021, 41(1): 59-71. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202101007.htmHE Xipeng. Sweet spot evaluation system and enrichment and high yield influential factors of shale gas in Nanchuan area of eastern Sichuan Basin[J]. Natural Gas Industry, 2021, 41(1): 59-71. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202101007.htm [6] 何贵松, 何希鹏, 高玉巧, 等. 渝东南盆缘转换带金佛斜坡常压页岩气富集模式[J]. 天然气工业, 2020, 40(6): 50-60. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202006007.htmHE Guisong, HE Xipeng, GAO Yuqiao, et al. Enrichment model of normal-pressure shale gas in the Jinfo slope of the basin-margin transition zone in southeast Chongqing[J]. Natural Gas Industry, 2020, 40(6): 50-60. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202006007.htm [7] 何希鹏, 何贵松, 高玉巧, 等. 常压页岩气勘探开发关键技术进展及攻关方向[J]. 天然气工业, 2023, 43(6): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202306001.htmHE Xipeng, HE Guisong, GAO Yuqiao, et al. Progress in and research direction of key technologies for normal-pressure shale gas exploration and development[J]. Natural Gas Industry, 2023, 43(6): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202306001.htm [8] 方志雄, 何希鹏. 渝东南武隆向斜常压页岩气形成与演化[J]. 石油与天然气地质, 2016, 37(6): 819-827. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201606005.htmFANG Zhixiong, HE Xipeng. Formation and evolution of normal pressure shale gas reservoir in Wulong Syncline, southeast Chongqing, China[J]. Oil & Gas Geology, 2016, 37(6): 819-827. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201606005.htm [9] 何治亮, 聂海宽, 张钰莹. 四川盆地及其周缘奥陶系五峰组—志留系龙马溪组页岩气富集主控因素分析[J]. 地学前缘, 2016, 23(2): 8-17. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201602004.htmHE Zhiliang, NIE Haikuan, ZHANG Yuying. The main factors of shale gas enrichment of Ordovician Wufeng Formation-Silurian Longmaxi Formation in the Sichuan Basin and its adjacent areas[J]. Earth Science Frontiers, 2016, 23(2): 8-17. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201602004.htm [10] 何希鹏, 张培先, 房大志, 等. 渝东南彭水—武隆地区常压页岩气生产特征[J]. 油气地质与采收率, 2018, 25(5): 72-79. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201805011.htmHE Xipeng, ZHANG Peixian, FANG Dazhi, et al. Production characteristics of normal pressure shale gas in Pengshui-Wulong area, southeast Chongqing[J]. Petroleum Geology and Recovery Efficiency, 2018, 25(5): 72-79. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201805011.htm [11] 张培先, 聂海宽, 何希鹏, 等. 渝东南地区古生界天然气成藏体系及立体勘探[J]. 地球科学, 2023, 48(1): 206-222. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202301014.htmZHANG Peixian, NIE Haikuan, HE Xipeng, et al. Paleozoic gas accumulation system and stereoscopic exploration in southeastern Chongqing[J]. Earth Science, 2023, 48(1): 206-222. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202301014.htm [12] 张培先, 高全芳, 何希鹏, 等. 南川地区龙马溪组页岩气地应力场特征及对产量影响分析[J]. 油气地质与采收率, 2023, 30(4): 55-65. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS202304004.htmZHANG Peixian, GAO Quanfang, HE Xipeng, et al. Characteristics of in-situ stress field and its influence on shale gas production from Longmaxi Formation in Nanchuan area[J]. Petroleum Geology and Recovery Efficiency, 2023, 30(4): 55-65. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS202304004.htm [13] 倪楷, 王明筏, 李响. 四川盆地东南缘页岩气富集模式: 以丁山地区上奥陶统五峰组—下志留统龙马溪组页岩为例[J]. 石油实验地质, 2021, 43(4): 580-588. doi: 10.11781/sysydz202104580NI Kai, WANG Mingfa, LI Xiang. Enrichment model of shale gas in southeastern Sichuan Basin: a case study of Upper Ordovician Wufeng and Lower Silurian Longmaxi formations in Dingshan area[J]. Petroleum Geology & Experiment, 2021, 43(4): 580-588. doi: 10.11781/sysydz202104580 [14] 胡文瑞. 地质工程一体化是实现复杂油气藏效益勘探开发的必由之路[J]. 中国石油勘探, 2017, 22(1): 1-5. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201701001.htmHU Wenrui. Geology-engineering integration: a necessary way to realize profitable exploration and development of complex reservoirs[J]. China Petroleum Exploration, 2017, 22(1): 1-5. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201701001.htm [15] 谢军, 张浩淼, 佘朝毅, 等. 地质工程一体化在长宁国家级页岩气示范区中的实践[J]. 中国石油勘探, 2017, 22(1): 21-28. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201701004.htmXIE Jun, ZHANG Haomiao, SHE Chaoyi, et al. Practice of geology-engineering integration in Changning State Shale Gas Demonstration Area[J]. China Petroleum Exploration, 2017, 22(1): 21-28. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201701004.htm [16] 鲜成钢, 张介辉, 陈欣, 等. 地质力学在地质工程一体化中的应用[J]. 中国石油勘探, 2017, 22(1): 75-88. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201701010.htmXIAN Chenggang, ZHANG Jiehui, CHEN Xin, et al. Application of geomechanics in geology-engineering integration[J]. China Petroleum Exploration, 2017, 22(1): 75-88. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201701010.htm [17] 包汉勇, 梁榜, 郑爱维, 等. 地质工程一体化在涪陵页岩气示范区立体勘探开发中的应用[J]. 中国石油勘探, 2022, 27(1): 88-98. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202201008.htmBAO Hanyong, LIANG Bang, ZHENG Aiwei, et al. Application of geology and engineering integration in stereoscopic exploration and development of Fuling shale gas demonstration area[J]. China Petroleum Exploration, 2022, 27(1): 88-98. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202201008.htm [18] 姚红生, 何希鹏, 王运海, 等. 复杂构造区常压页岩气地球物理勘探技术与实践[M]. 北京: 地质出版社, 2021.YAO Hongsheng, HE Xipeng, WANG Yunhai, et al. Geophysical exploration technology and practice of atmospheric shale gas in complex structure area[M]. Beijing: Geology Press, 2021. [19] 王运海, 任建华, 陈祖华, 等. 常压页岩气田一体化效益开发及智能化评价[J]. 油气藏评价与开发, 2021, 11(4): 487-496. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ202104003.htmWANG Yunhai, REN Jianhua, CHEN Zuhua, et al. Integrated benefit development and intelligent evaluation of normal pres-sure shale gas[J]. Petroleum Reservoir Evaluation and Deve-lopment, 2021, 11(4): 487-496. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ202104003.htm [20] 王伟, 李阳, 陈祖华, 等. 基于复杂渗流机理的页岩气藏压后数值模拟研究[J]. 油气藏评价与开发, 2020, 10(1): 22-29. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ202001005.htmWANG Wei, LI Yang, CHEN Zuhua, et al. Post-fracturing numerical simulation of shale gas reservoir based on complex flow mechanisms[J]. Reservoir Evaluation and Development, 2020, 10(1): 22-29. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ202001005.htm [21] 戴城, 胡小虎, 方思冬, 等. 基于微地震数据和嵌入式离散裂缝的页岩气开发渗流数值模拟[J]. 油气藏评价与开发, 2019, 9(5): 70-77. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ201905009.htmDAI Cheng, HU Xiaohu, FANG Sidong, et al. Numerical simulation for seepage of shale gas reservoir development based on microseismic data and embedded fracture modeling[J]. Reservoir Evaluation and Development, 2019, 9(5): 70-77. https://www.cnki.com.cn/Article/CJFDTOTAL-KTDQ201905009.htm [22] 李东海, 姚红生, 何希鹏, 等. 复杂构造区常压页岩气地质理论与资源潜力[M]. 北京: 地质出版社, 2022.LI Donghai, YAO Hongsheng, HE Xipeng, et al. Geological theory and resource potential of atmospheric shale gas in complex structure area[M]. Beijing: Geology Press, 2022. [23] 姚红生, 郭彤楼, 何希鹏, 等. 页岩气地质实验测试技术与应用[M]. 北京: 地质出版社, 2021.YAO Hongsheng, GUO Tonglou, HE Xipeng, et al. Geological test technology and application of shale gas[M]. Beijing: Geology Press, 2021. [24] 姚红生, 蔡勋育, 郭彤楼, 等. 渝东南常压页岩气勘探开发关键技术[M]. 北京: 石油工业出版社, 2023.YAO Hongsheng, CAI Xunyu, GUO Tonglou, et al. Exploration and development key technologies of atmospheric shale gas in southeastern Chongqing[M]. Beijing: Petroleum Industry Press, 2023. [25] 何希鹏, 卢比, 何贵松, 等. 渝东南构造复杂区常压页岩气生产特征及开发技术政策[J]. 石油与天然气地质, 2021, 42(1): 224-240. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101020.htmHE Xipeng, LU Bi, HE Guisong, et al. Production characteristics and optimized development technologies for normal-pressure shale gas in the structurally complex areas of southeastern Chongqing[J]. Oil & Gas Geology, 2021, 42(1): 224-240. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101020.htm [26] 杨振恒, 陶国亮, 鲍云杰, 等. 南方海相深层页岩气储集空间差异化发育及保持机理探讨[J]. 石油实验地质, 2022, 44(5): 845-853. doi: 10.11781/sysydz202205845YANG Zhenheng, TAO Guoliang, BAO Yunjie, et al. Differential development and maintenance mechanism of reservoir space for marine shale gas in South China's deep strata[J]. Petroleum Geology & Experiment, 2022, 44(5): 845-853. doi: 10.11781/sysydz202205845 -
