Main controlling factors for oil and gas enrichment in Jurassic laminated shale in Fuxing area of Sichuan Basin
-
摘要: 四川盆地复兴地区侏罗系发育多套富有机质页岩，多口井试获高产工业油气流。明确不同页岩岩相沉积储层特征及富集主控因素对勘探部署具有重要意义。基于岩心精细描述、实验分析及钻井勘探实践，开展了陆相地层细粒沉积岩岩相划分与对比、储层精细表征、油气藏类型及富集高产主控因素解剖，形成了以下几点认识：(1)复兴地区侏罗系发育自流井组东岳庙段一亚段、凉高山组二段下亚段两套半深湖相优质页岩，具有多层叠置、中等有机碳含量、纹层发育、源储一体及高气油比特征；两套目的层页岩岩性复杂，为此，建立了基于“颜色—有机碳含量—沉积结构—矿物成分”四元岩相划分方案，明确了灰黑色高碳粉砂纹层型黏土页岩为凉二段下亚段有利岩相，灰黑色高碳介屑纹层、粉砂介屑纹层型黏土页岩为东一亚段有利岩相，3种有利岩相在研究区横向分布稳定。(2)灰黑色高碳粉砂纹层、介屑纹层、粉砂介屑纹层型黏土页岩具有“多孔共生、大孔大喉、孔缝一体”的储集特征，储集物性好、渗透率高，利于页岩油气在孔—缝储集体系中高效储集流动。(3)东一亚段为凝析气藏，凉二段下亚段为挥发性油藏。(4)明确了陆相页岩油气富集主控因素：中高生烃潜力、强滞留率为纹层型页岩油气富集提供物质基础；良好的成烃—成岩—成储—成藏配置关系利于油气聚集成藏；微裂缝发育及合适的热演化程度利于烃类富集及流动；大型宽缓向斜及高压—超压条件利于烃类持续保存。Abstract: The Fuxing area of the Sichuan Basin is known for its multiple sets of organic-rich shale in the Jurassic period, with several wells yielding significant amounts of industrial oil and gas. Understanding the characteristics and factors influencing the enrichment of different shale facies sedimentary reservoirs is crucial for effective exploration. Through detailed rock core descriptions, experimental analysis, and drilling exploration, the author has classified and compared fine-grained sedimentary rock facies in terrestrial strata, characterized reservoirs, identified types of oil and gas reservoirs, and analyzed the main factors influencing enrichment and productivity. The study reveals that the Jurassic strata in the Fuxing area contain two sets of high-quality shale with semi-deep lacustrine facies: the first sub-section of the Dongyuemiao section of the Ziliujing Formation and the lower sub-section of the second section of the Lianggaoshan Formation. These shale layers exhibit multi-layer stacking, moderate TOC content, well-developed bedding, integrated source storage, and high gas/oil ratio characteristics. The lithology of these target shale layers is complex, leading to the establishment of a four-element lithofacies classification scheme based on "color-TOC-sedimentary structure-mineral composition". This scheme identifies the gray-black high carbon sand-laminated clay shale as the favorable lithofacies for the lower sub-section of the second section of the Lianggaoshan Formation, and the gray-black high carbon medium debris-laminated and fine sand medium debris-laminated clay shale as the favorable lithofacies for the eastern sub-section. The three lithofacies in the study area are horizontally distributed in a stable manner. The gray-black high carbon fine sand layer, medium debris layer, and fine sand-medium debris layer type clay shale exhibit reservoir characteristics of "porous coexistence, large pores and throats, and integrated pores and fractures". These reservoir properties, including good permeability, facilitate the efficient storage and flow of shale oil and gas in the pore-fracture storage system. The first sub-section of the Dongyuemiao section is a condensate gas reservoir, while the lower sub-section of the Lianggaoshan Formation's second section is a volatile oil reservoir. Key factors contributing to the enrichment of continental shale oil and gas have been identified, including medium to high hydrocarbon generation potential and strong retention rates supporting the accumulation of laminated shale oil and gas. A favorable hydrocarbon-diagenesis-reservoir formation configuration promotes oil and gas accumulation. Additionally, the development of micro cracks and suitable thermal evolution aids in hydrocarbon enrichment and flow, while large, wide, gentle synclines and high-pressure overpressure conditions support the sustained preservation of hydrocarbons.
-
图 1 四川盆地侏罗系半深湖相边界叠合地层埋深(a)、侏罗系综合柱状图(b)及典型地震剖面(c)
Figure 1. Burial depth of Jurassic semi-deep lacustrine boundary superimposed strata in Sichuan Basin (a), Jurassic comprehensive bar chart (b), and typical seismic profile (c)
图 2 四川盆地侏罗系东一亚段(a)与凉二下亚段(b)沉积相平面分布
Figure 2. Plane map of sedimentary facies of first sub-section of Dongyuemiao section of Ziliujing Formation (a) and lower sub-section of second section of Lianggaoshan Formation (b) of Jurassic in Sichuan Basin
图 3 四川盆地侏罗系陆相富有机质页岩发育模式
Figure 3. Development pattern of organic-rich terrestrial shale in Jurassic, Sichuan Basin
图 4 四川盆地复兴地区侏罗系陆相页岩储集空间类型
Figure 4. Reservoir space types of Jurassic terrestrial shale in Fuxing area of Sichuan Basin
图 5 四川盆地复兴地区侏罗系陆相页岩储集空间孔径分布
Figure 5. Pore size distribution of Jurassic terrestrial shale reservoirs in Fuxing area of Sichuan Basin
图 6 四川盆地复兴地区侏罗系不同岩相孔渗特征
Figure 6. Pore and permeability characteristics of different lithofacies in Jurassic of Fuxing area of Sichuan Basin
图 7 四川盆地复兴地区凉二下亚段(a)与东一亚段(b)页岩地质—工程双甜点评价
Figure 7. Double sweet spot evaluation of geology and engineering of shale in lower sub-section of second member of Lianggaoshan Formation (a) and first sub-section of Dongyuemiao section of Ziliujing Formation (b) of Fuxing area in Sichuan Basin
图 8 四川盆地复兴地区侏罗系凉二下亚段(a)、自流井组东一亚段(b)不同岩相地质参数对比
Figure 8. Comparison of geological parameters of different lithofacies in lower sub-section of second section of Lianggaoshan Formation (a) and first sub-section of Dongyuemiao section of Ziliujing Formation (b) of Fuxing area in Sichuan Basin
图 9 四川盆地复兴地区侏罗系自流井组东一亚段岩相展布
Figure 9. Lithological distribution of first sub-section of Dongyuemiao section of Ziliujing Formation of Fuxing area of Sichuan Basin
图 10 四川盆地复兴地区侏罗系凉二下亚段岩相展布
Figure 10. Lithological distribution of lower sub-section of second section of Lianggaoshan Formation in Fuxing area of Sichuan Basin
图 11 四川盆地复兴地区侏罗系陆相页岩成烃—成岩—成储—成藏配置关系
Figure 11. Configuration of hydrocarbon generation, diagenesis, reservoir formation and accumulation of terrestrial shale in Jurassic, Fuxing area, Sichuan Basin
图 12 四川盆地复兴地区侏罗系压力系统与典型油气藏剖面
Figure 12. Jurassic pressure system and typical oil and gas reservoir profiles in Fuxing area of Sichuan Basin
表 1 四川盆地复兴地区侏罗系陆相地层岩相特征
Table 1. Lithological characteristics of Jurassic terrestrial strata in Fuxing area of Sichuan Basin
-
[1] 贾承造, 郑民, 张永峰. 中国非常规油气资源与勘探开发前景[J]. 石油勘探与开发, 2012, 39(2): 129-136. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201202002.htmJIA Chengzao, ZHENG Min, ZHANG Yongfeng. Unconventional hydrocarbon resources in China and the prospect of exploration and development[J]. Petroleum Exploration and Development, 2012, 39(2): 129-136. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201202002.htm [2] 杜金虎, 何海清, 杨涛, 等. 中国致密油勘探进展及面临的挑战[J]. 中国石油勘探, 2014, 19(1): 1-9. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201401001.htmDU Jinhu, HE Haiqing, YANG Tao, et al. Progress in China's tight oil exploration and challenges[J]. China Petroleum Exploration, 2014, 19(1): 1-9. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201401001.htm [3] 郭旭升, 胡东风, 魏志红, 等. 涪陵页岩气田的发现与勘探认识[J]. 中国石油勘探, 2016, 21(3): 24-37. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201603003.htmGUO Xusheng, HU Dongfeng, WEI Zhihong, et al. Discovery and exploration of Fuling Shale Gas Field[J]. China Petroleum Exploration, 2016, 21(3): 24-37. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY201603003.htm [4] 付锁堂, 金之钧, 付金华, 等. 鄂尔多斯盆地延长组7段从致密油到页岩油认识的转变及勘探开发意义[J]. 石油学报, 2021, 42(5): 561-569. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202105001.htmFU Suotang, JIN Zhijun, FU Jinhua, et al. Transformation of understanding from tight oil to shale oil in the member 7 of Yanchang Formation in Ordos Basin and its significance of exploration and development[J]. Acta Petrolei Sinica, 2021, 42(5): 561-569. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202105001.htm [5] 赵贤正, 蒲秀刚, 周立宏, 等. 深盆湖相区页岩油富集理论、勘探技术及前景: 以渤海湾盆地黄骅坳陷古近系为例[J]. 石油学报, 2021, 42(2): 143-162. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202102001.htmZHAO Xianzheng, PU Xiugang, ZHOU Lihong, et al. Enrichment theory, exploration technology and prospects of shale oil in lacustrine facies zone of deep basin: a case study of the Paleogene in Huanghua Depression, Bohai Bay Basin[J]. Acta Petrolei Sinica, 2021, 42(2): 143-162. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202102001.htm [6] 何文渊, 蒙启安, 冯子辉, 等. 松辽盆地古龙页岩油原位成藏理论认识及勘探开发实践[J]. 石油学报, 2022, 43(1): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202201001.htmHE Wenyuan, MENG Qi'an, FENG Zihui, et al. In-situ accumulation theory and exploration & development practice of Gulong shale oil in Songliao Basin[J]. Acta Petrolei Sinica, 2022, 43(1): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202201001.htm [7] 郭旭升, 魏志红, 魏祥峰, 等. 四川盆地侏罗系陆相页岩油气富集条件及勘探方向[J]. 石油学报, 2023, 44(1): 14-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202301002.htmGUO Xusheng, WEI Zhihong, WEI Xiangfeng, et al. Enrichment conditions and exploration direction of Jurassic continental shale oil and gas in Sichuan Basin[J]. Acta Petrolei Sinica, 2023, 44(1): 14-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202301002.htm [8] 匡立春, 侯连华, 杨智, 等. 陆相页岩油储层评价关键参数及方法[J]. 石油学报, 2021, 42(1): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202101001.htmKUANG Lichun, HOU Lianhua, YANG Zhi, et al. Key parameters and methods of lacustrine shale oil reservoir characterization[J]. Acta Petrolei Sinica, 2021, 42(1): 1-14. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202101001.htm [9] 胡东风, 魏志红, 刘若冰, 等. 四川盆地拔山寺向斜泰页1井页岩油气重大突破及意义[J]. 中国石油勘探, 2021, 26(2): 21-32. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202102003.htmHU Dongfeng, WEI Zhihong, LIU Ruobing, et al. Major breakthrough of shale oil and gas in well Taiye 1 in Bashansi Syncline in the Sichuan Basin and its significance[J]. China Petroleum Exploration, 2021, 26(2): 21-32. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202102003.htm [10] 魏志红, 刘若冰, 魏祥峰, 等. 四川盆地复兴地区陆相页岩油气勘探评价与认识[J]. 中国石油勘探, 2022, 27(1): 111-119. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202201010.htmWEI Zhihong, LIU Ruobing, WEI Xiangfeng, et al. Exploration evaluation and recognition of continental shale oil and gas in Fuxing area, Sichuan Basin[J]. China Petroleum Exploration, 2022, 27(1): 111-119. https://www.cnki.com.cn/Article/CJFDTOTAL-KTSY202201010.htm [11] 刘惠民, 孙善勇, 操应长, 等. 东营凹陷沙三段下亚段细粒沉积岩岩相特征及其分布模式[J]. 油气地质与采收率, 2017, 24(1): 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201701001.htmLIU Huimin, SUN Shanyong, CAO Yingchang, et al. Lithofacies characteristics and distribution model of fine-grained sedimentary rock in the lower Es3 member, Dongying Sag[J]. Petroleum Geology and Recovery Efficiency, 2017, 24(1): 1-10. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201701001.htm [12] 刘惠民, 于炳松, 谢忠怀, 等. 陆相湖盆富有机质页岩微相特征及对页岩油富集的指示意义: 以渤海湾盆地济阳坳陷为例[J]. 石油学报, 2018, 39(12): 1328-1343. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201812002.htmLIU Huimin, YU Bingsong, XIE Zhonghuai, et al. Characteristics and implications of micro-lithofacies in lacustrine-basin organic-rich shale: a case study of Jiyang Depression, Bohai Bay Basin[J]. Acta Petrolei Sinica, 2018, 39(12): 1328-1343. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201812002.htm [13] WANG Ximeng, LIU Luofu, WANG Yang, et al. Comparison of the pore structures of Lower Silurian Longmaxi Formation shales with different lithofacies in the southern Sichuan Basin, China[J]. Journal of Natural Gas Science and Engineering, 2020, 81: 103419. [14] WANG Yang, CHENG Hongfei, HU Qinhong, et al. Diagenesis and pore evolution for various lithofacies of the Wufeng-Longmaxi shale, southern Sichuan Basin, China[J]. Marine and Petroleum Geology, 2021, 133: 105251. [15] LOUCKS R G, REED R M, RUPPEL S C, et al. Spectrum of pore types and networks in mudrocks and a descriptive classification for matrix-related mudrock pores[J]. AAPG Bulletin, 2012, 96(6): 1071-1098. [16] 胡东风, 魏志红, 刘若冰, 等. 湖相页岩油气富集主控因素与勘探潜力: 以四川盆地涪陵地区侏罗系为例[J]. 天然气工业, 2021, 41(8): 113-120. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202108017.htmHU Dongfeng, WEI Zhihong, LIU Ruobing, et al. Enrichment control factors and exploration potential of lacustrine shale oil and gas: a case study of Jurassic in the Fuling area of the Sichuan Basin[J]. Natural Gas Industry, 2021, 41(8): 113-120. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202108017.htm [17] IBAD S M, PADMANABHAN E. Lithofacies, mineralogy, and pore types in Paleozoic gas shales from western Peninsular Malaysia[J]. Journal of Petroleum Science and Engineering, 2022, 212: 110239. [18] 吴蓝宇, 胡东风, 陆永潮, 等. 四川盆地涪陵气田五峰组—龙马溪组页岩优势岩相[J]. 石油勘探与开发, 2016, 43(2): 189-197. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201602005.htmWU Lanyu, HU Dongfeng, LU Yongchao, et al. Advantageous shale lithofacies of Wufeng Formation-Longmaxi Formation in Fuling Gas Field of Sichuan Basin, SW China[J]. Petroleum Exploration and Development, 2016, 43(2): 189-197. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201602005.htm [19] 朱国文, 王小军, 张金友, 等. 松辽盆地陆相页岩油富集条件及勘探开发有利区[J]. 石油学报, 2023, 44(1): 110-124. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202301010.htmZHU Guowen, WANG Xiaojun, ZHANG Jinyou, et al. Enrichment conditions and favorable zones for exploration and development of continental shale oil in Songliao Basin[J]. Acta Petrolei Sinica, 2023, 44(1): 110-124. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB202301010.htm [20] 郝芳, 邹华耀, 王敏芳, 等. 油气成藏机理研究进展和前沿研究领域[J]. 地质科技情报, 2002, 21(4): 7-14. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200204002.htmHAO Fang, ZOU Huayao, WANG Minfang, et al. Research advances and frontier areas of mechanisms of petroleum accumulation[J]. Geological Science and Technology Information, 2002, 21(4): 7-14. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ200204002.htm [21] 刘光祥, 沃玉进, 潘文蕾, 等. 中上扬子区海相层系流体特征与油气保存条件[J]. 石油实验地质, 2011, 33(1): 17-21. doi: 10.11781/sysydz201101017LIU Guangxiang, WO Yujin, PAN Wenlei, et al. Fluid characteristics and hydrocarbon preservation conditions in marine facies strata of Middle-Upper Yangtze region[J]. Petroleum Geology & Experiment, 2011, 33(1): 17-21. doi: 10.11781/sysydz201101017 [22] 张水昌, 张斌, 王晓梅, 等. 松辽盆地古龙页岩油富集机制与常规—非常规油有序分布[J]. 石油勘探与开发, 2023, 50(5): 911-923. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202305004.htmZHANG Shuichang, ZHANG Bin, WANG Xiaomei, et al. Gulong shale oil enrichment mechanism and orderly distribution of conventional-unconventional oils in the Cretaceous Qingshankou Formation, Songliao Basin, NE China[J]. Petroleum Exploration and Development, 2023, 50(5): 911-923. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202305004.htm -
