Characteristics and formation stages of natural fractures in Lower Silurian Longmaxi Formation in Tiangongtang area of Sichuan Basin
-
摘要: 四川盆地西南缘下志留统龙马溪组页岩气储量巨大，裂缝发育特征与形成期次对页岩气富集及产能具有重要影响。以天宫堂地区龙马溪组为研究对象，采用岩心分析、FMI成像测井、岩石声发射实验、裂缝充填物碳氧同位素测试、包裹体均一温度测试和埋藏—热演化史分析等分析技术和综合地质方法，研究页岩中天然裂缝的发育特征和形成时期。结果显示，研究区龙马溪组天然裂缝以构造成因的直立缝与低角度缝共同发育为特征，岩心裂缝具有发育程度高、延伸短、充填程度高等特征。成像测井裂缝倾角比对、岩心裂缝交切关系、裂缝充填物流体包裹体测试及岩石声发射实验等结果表明，天宫堂地区龙马溪组裂缝形成与3期构造运动有关。结合埋藏—热演化史分析可证实：第一期为NW向、NNE向平面剪切缝和NEE向剖面剪切缝，形成于燕山中期—晚期(130~62 Ma)，构造应力方位为近SN向(345°±5°)，包裹体均一温度为185~206 ℃；第二期为NE向、NWW向平面剪切缝和NNW向剖面剪切缝，形成于燕山晚期—喜马拉雅中期(62~34 Ma)，构造应力方位为EW向(80°±5°)，包裹体均一温度为165~184 ℃；第三期为近SN向、NEE向平面剪切缝和NE向剖面剪切缝，形成于喜马拉雅中期—现今(34 Ma至今), 构造应力方位为近NW向(315°±5°)，包裹体均一温度为125~162 ℃。结合地质力学背景，建立了天宫堂地区龙马溪组3期构造裂缝演化模式。Abstract: The Lower Silurian Longmaxi Formation on the southwestern margin of the Sichuan Basin holds significant shale gas reserves. The characteristics and formation stages of fractures play a crucial role in shale gas accumulation and productivity. Focusing on the Longmaxi Formation in the Tiangongtang area, this study employed core analysis, FMI (Formation Micro-Imager) logging, rock acoustic emission experiments, carbon-oxygen isotope analysis of fracture fillings, fluid inclusion homogenization temperature testing, and burial-thermal evolution history analysis to investigate the development characteristics and formation periods of natural fractures in the shale. The results indicate that the natural fractures in the Longmaxi Formation in the study area are characterized by the coexistence of tectonic vertical and low-angle fractures. The core fractures exhibit high development density, short extension, and high filling degree. Comparison of imaging log fracture dip angles, core fracture cross-cutting relationships, fracture filling fluid inclusion tests, and rock acoustic emission experiments suggested that the fractures in the Longmaxi Formation in the Tiangongtang area were associated with three tectonic events. Combined with burial-thermal evolution history analysis, the formation periods were confirmed as follows: the first stage involved NW-oriented and NNE-oriented planar shear fractures, and NEE-oriented cross-sectional shear fractures formed during the mid-late Yanshanian period (130-62 Ma) with tectonic stress orientation near SN (345°±5°) and inclusion homogenization temperatures of 185-206 ℃; the second stage involved NE-oriented and NW-oriented planar shear fractures, and NNW-trending cross-sectional shear fractures formed during the late Yanshanian to mid-Himalayan period (62-34 Ma) with tectonic stress orientation near EW (80°±5°) and inclusion homogenization temperatures of 165-184 ℃; the third stage involved near SN-oriented and NEE-oriented planar shear fractures, and NE-oriented cross-sectional shear fractures formed from the mid-Himalayan period to present (34 Ma to present) with tectonic stress orientation near NW (315°±5°) and inclusion homogenization temperatures of 125-162 ℃. Based on the geomechanical background, a three-stage tectonic fracture evolution model for the Longmaxi Formation in the Tiangongtang area was established.
-
Key words:
- shale fracture /
- fracture characteristic /
- tectonic stage /
- Longmaxi Formation /
- Lower Silurian /
- Sichuan Basin
-
图 1 川西南天宫堂地区构造样式(a)、过典型井剖面(b)及典型井下志留统龙马溪组柱状图(c)
Figure 1. Tectonic style of Tiangongtang area, southwestern Sichuan Basin (a), cross-section of typical well (b), and columnar map of typical well of Lower Silurian Longmaxi Formation (c)
图 2 川西南天宫堂地区下志留统龙马溪组构造裂缝
a.Y208井，3 830.61~3 831.05 m，高角度剪切缝，方解石、石膏混合充填；b.Y207井，3 072.8 m，高角度剪切缝，方解石半充填；c.Y208井，3 830.1~3 830.3 m，高角度剪切缝，方解石全充填；d.Y203井，3 786.00~3 786.44 m，张性缝，方解石半充填；e.Y202井，3 501.99~3 502.20 m，异常高压缝，方解石、沥青混合充填；f.Y207井，3 031.43~3 031.70 m，页理缝；g.Y205井，3 433.89~3 433.98 m，页理缝；h.Y207井，3 069.09 m，构造缝；i.Y207井，3 049.62 m，构造缝。
Figure 2. Structural fractures of Lower Silurian Longmaxi Formation in Tiangongtang area, southwestern Sichuan Basin
图 3 川西南天宫堂地区裂缝FMI成像测井显示及走向玫瑰花图
Figure 3. Fracture FMI imaging logging display and strike rosette diagram in Tiangongtang area, southwestern Sichuan Basin
图 4 川西南天宫堂地区下志留统龙马溪组岩心、薄片裂缝交切关系
Figure 4. Core and thin section fracture intersection relationship of Lower Silurian Longmaxi Formation in Tiangongtang area, southwestern Sichuan Basin
图 5 川西南天宫堂地区下志留统龙马溪组页岩天然裂缝发育参数统计
Figure 5. Statistics of natural fracture development parameters for Lower Silurian Longmaxi Formation shale in Tiangongtang area, southwestern Sichuan Basin
图 6 川西南天宫堂地区典型井裂缝纵向变化特征
Figure 6. Longitudinal variation characteristics of typical well fractures in Tiangongtang area, southwestern Sichuan Basin
图 7 川西南天宫堂地区下志留统龙马溪组裂缝充填物包裹体均一温度
Figure 7. Homogenization temperature distribution of fractures filling inclusions of Lower Silurian Longmaxi Formation in Tiangongtang area, southwestern Sichuan Basin
图 8 川西南天宫堂地区下志留统龙马溪组岩石声发射实验曲线
Figure 8. Experimental curves of rock acoustic emission of Lower Silurian Longmaxi Formation in Tiangongtang area, southwestern Sichuan Basin
图 9 川西南天宫堂地区裂缝充填物碳氧同位素交会分析
Figure 9. Cross plot analysis of carbon and oxygen isotope of fracture filling in Tiangongtang area, southwestern Sichuan Basin
图 10 川西南天宫堂地区Y203井下志留统龙马溪组埋藏史
Figure 10. Burial history of Lower Silurian Longmaxi Formation in well Y203, Tiangongtang area, southwestern Sichuan Basin
图 11 川西南天宫堂地区下志留统龙马溪组构造裂缝演化模式
Figure 11. Evolution model of structural fractures of Lower Silurian Longmaxi Formation in Tiangongtang area, southwestern Sichuan Basin
表 1 川西南天宫堂地区下志留统龙马溪组裂缝充填物包裹体样品测温数据
Table 1. Temperature measurement data of inclusions of fracture filling materials of Lower Silurian Longmaxi Formation in Tiangongtang area, southwestern Sichuan Basin
井号 井深/m 宿主矿物 类型 均一温度/℃ Y202 3 503.25~3 503.53 石膏 原生 180~205 Y205 3 431.58~3 431.82 方解石 原生 125~130 Y208 3 830.17~3 830.37 方解石 原生 140~188 Y208 3 831.05 石膏 原生 145~162 Y209 4 453.00~4 453.25 方解石 原生 140~158 Y209 4 459.93~4 460.13 方解石 原生 148~172
下载: 导出CSV
-
[1] 王濡岳, 胡宗全, 赖富强, 等. 川东北地区下侏罗统自流井组大安寨段陆相页岩脆性特征及其控制因素[J]. 石油与天然气地质, 2023, 44(2): 366-378. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202302009.htmWANG Ruyue, HU Zongquan, LAI Fuqiang, et al. Brittleness features and controlling factors of continental shale from Da'anzhai Member of the Lower Jurassic Ziliujing Formation, northeastern Sichuan Basin[J]. Oil & Gas Geology, 2023, 44(2): 366-378. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202302009.htm [2] 蔡勋育, 赵培荣, 高波, 等. 中国石化页岩气"十三五"发展成果与展望[J]. 石油与天然气地质, 2021, 42(1): 16-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101003.htmCAI Xunyu, ZHAO Peirong, GAO Bo, et al. SINOPEC's shale gas development achievements during the "Thirteenth Five-Year Plan" period and outlook for the future[J]. Oil & Gas Geology, 2021, 42(1): 16-27. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101003.htm [3] 王濡岳, 胡宗全, 董立, 等. 页岩气储层表征评价技术进展与思考[J]. 石油与天然气地质, 2021, 42(1): 54-65. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101006.htmWANG Ruyue, HU Zongquan, DONG Li, et al. Advancement and trends of shale gas reservoir characterization and evaluation[J]. Oil & Gas Geology, 2021, 42(1): 54-65. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101006.htm [4] 詹国卫, 杨建, 赵勇, 等. 川南深层页岩气开发实践与面临的挑战[J]. 石油实验地质, 2023, 45(6): 1067-1077. doi: 10.11781/sysydz2023061067ZHAN Guowei, YANG Jian, ZHAO Yong, et al. Development practice and challenges of deep shale gas in southern Sichuan Basin[J]. Petroleum Geology & Experiment, 2023, 45(6): 1067-1077. doi: 10.11781/sysydz2023061067 [5] 魏富彬, 刘珠江, 陈斐然, 等. 川东南五峰组—龙马溪组深层、超深层页岩储层特征及其页岩气勘探意义[J]. 石油实验地质, 2023, 45(4): 751-760. doi: 10.11781/sysydz202304751WEI Fubin, LIU Zhujiang, CHEN Feiran, et al. Characteristics of the deep and ultra-deep shale reservoirs of the Wufeng-Longmaxi formations in the southeastern Sichuan Basin and the significance of shale gas exploration[J]. Petroleum Geology & Experiment, 2023, 45(4): 751-760. doi: 10.11781/sysydz202304751 [6] 马新华, 谢军, 雍锐, 等. 四川盆地南部龙马溪组页岩气储集层地质特征及高产控制因素[J]. 石油勘探与开发, 2020, 47(5): 841-855. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202005003.htmMA Xinhua, XIE Jun, YONG Rui, et al. Geological characteristics and high production control factors of shale gas reservoirs in Silurian Longmaxi Formation, southern Sichuan Basin, SW China[J]. Petroleum Exploration and Development, 2020, 47(5): 841-855. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202005003.htm [7] 郭彤楼, 刘若冰. 复杂构造区高演化程度海相页岩气勘探突破的启示: 以四川盆地东部盆缘JY1井为例[J]. 天然气地球科学, 2013, 24(4): 643-651. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201304000.htmGUO Tonglou, LIU Ruobing. Implications from marine shale gas exploration breakthrough in complicated structural area at high thermal stage: taking Longmaxi Formation in well JY1 as an example[J]. Natural Gas Geoscience, 2013, 24(4): 643-651. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201304000.htm [8] 张静平, 唐书恒, 郭东鑫. 四川盆地下古生界筇竹寺组与龙马溪组页岩气勘探优选区预测[J]. 地质通报, 2011, 30(2/3): 357-363. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD2011Z1023.htmZHANG Jingping, TANG Shuheng, GUO Dongxin. Shale gas favorable area prediction of the Qiongzhusi Formation and Longmaxi Formation of Lower Palaeozoic in Sichuan Basin, China[J]. Geological Bulletin of China, 2011, 30(2/3): 357-363. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD2011Z1023.htm [9] 李彦录, 陆诗磊, 夏东领, 等. 鄂尔多斯盆地南部延长组长7油组页岩层系天然裂缝发育特征及主控因素[J]. 地质科学, 2022, 57(1): 73-87. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX202201004.htmLI Yanlu, LU Shilei, XIA Dongling, et al. Development characteristics and main controlling factors of natural fractures in shale series of the seventh member of the Yanchang Formation, southern Ordos Basin[J]. Chinese Journal of Geology, 2022, 57(1): 73-87. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKX202201004.htm [10] 魏祥峰, 黄静, 李宇平, 等. 元坝地区大安寨段陆相页岩气富集高产主控因素[J]. 中国地质, 2014, 41(3): 970-981. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201403022.htmWEI Xiangfeng, HUANG Jing, LI Yuping, et al. The main factors controlling the enrichment and high production of Da'anzhai Member continental shale gas in Yuanba area[J]. Geology in China, 2014, 41(3): 970-981. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201403022.htm [11] 冯子齐, 黄士鹏, 吴伟, 等. 北美页岩气和我国煤成气发展历程对我国页岩气发展的启示[J]. 天然气地球科学, 2016, 27(3): 449-460. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201603009.htmFENG Ziqi, HUANG Shipeng, WU Wei, et al. The development history of shale gas in United States and coal-derived gas in China and enlightenment to China[J]. Natural Gas Geoscience, 2016, 27(3): 449-460. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201603009.htm [12] 丁文龙, 李超, 李春燕, 等. 页岩裂缝发育主控因素及其对含气性的影响[J]. 地学前缘, 2012, 19(2): 212-220. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201202031.htmDING Wenlong, LI Chao, LI Chunyan, et al. Dominant factor of fracture development in shale and its relationship to gas accumulation[J]. Earth Science Frontiers, 2012, 19(2): 212-220. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201202031.htm [13] 聂海宽, 唐玄, 边瑞康. 页岩气成藏控制因素及中国南方页岩气发育有利区预测[J]. 石油学报, 2009, 30(4): 484-491. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200904003.htmNIE Haikuan, TANG Xuan, BIAN Ruikang. Controlling factors for shale gas accumulation and prediction of potential development area in shale gas reservoir of South China[J]. Acta Petrolei Sinica, 2009, 30(4): 484-491. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200904003.htm [14] 王濡岳, 胡宗全, 周彤, 等. 四川盆地及其周缘五峰组—龙马溪组页岩裂缝发育特征及其控储意义[J]. 石油与天然气地质, 2021, 42(6): 1295-1306. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202106005.htmWANG Ruyue, HU Zongquan, ZHOU Tong, et al. Characteristics of fractures and their significance for reservoirs in Wufeng-Longmaxi shale, Sichuan Basin and its periphery[J]. Oil & Gas Geology, 2021, 42(6): 1295-1306. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202106005.htm [15] 王濡岳, 胡宗全, 龙胜祥, 等. 四川盆地上奥陶统五峰组—下志留统龙马溪组页岩储层特征与演化机制[J]. 石油与天然气地质, 2022, 43(2): 353-364. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202202009.htmWANG Ruyue, HU Zongquan, LONG Shengxiang, et al. Reservoir characteristics and evolution mechanisms of the Upper Ordovician Wufeng-Lower Silurian Longmaxi shale, Sichuan Basin[J]. Oil & Gas Geology, 2022, 43(2): 353-364. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202202009.htm [16] REN Long, SU Yuliang, ZHAN Shiyuan, et al. Progress of the research on productivity prediction methods for stimulated reservoir volume (SRV)-fractured horizontal wells in unconventional hydrocarbon reservoirs[J]. Arabian Journal of Geosciences, 2019, 12(6): 184. doi: 10.1007/s12517-019-4376-2 [17] 郭旭升, 胡东风, 魏祥峰, 等. 四川盆地焦石坝地区页岩裂缝发育主控因素及对产能的影响[J]. 石油与天然气地质, 2016, 37(6): 799-808. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201606002.htmGUO Xusheng, HU Dongfeng, WEI Xiangfeng, et al. Main controlling factors on shale fractures and their influences on production capacity in Jiaoshiba area, the Sichuan Basin[J]. Oil & Gas Geo-logy, 2016, 37(6): 799-808. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201606002.htm [18] 王濡岳, 胡宗全, 刘敬寿, 等. 中国南方海相与陆相页岩裂缝发育特征及主控因素对比: 以黔北岑巩地区下寒武统为例[J]. 石油与天然气地质, 2018, 39(4): 631-640. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201804002.htmWANG Ruyue, HU Zongquan, LIU Jingshou, et al. Comparative analysis of characteristics and controlling factors of fractures inmarine and continental shales: a case study of the Lower Cambrian in Cengong area, northern Guizhou Province[J]. Oil & Gas Geology, 2018, 39(4): 631-640. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201804002.htm [19] 邓虎成, 周文, 姜文利, 等. 鄂尔多斯盆地麻黄山西区块延长、延安组裂缝成因及期次[J]. 吉林大学学报(地球科学版), 2009, 39(5): 811-817. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200905008.htmDENG Hucheng, ZHOU Wen, JIANG Wenli, et al. Genetic mechanism and development periods of fracture in Yanchang and Yan'an Formation of western Mahuangshan block in Ordos Basin[J]. Journal of Jilin University (Earth Science Edition), 2009, 39(5): 811-817. https://www.cnki.com.cn/Article/CJFDTOTAL-CCDZ200905008.htm [20] 尹帅, 李爱荣, 陈梦娜, 等. 强变形区走滑断裂带伸展—聚敛应力效应构造解析及控气作用[J]. 天然气地球科学, 2018, 29(11): 1568-1574. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201811003.htmYIN Shuai, LI Airong, CHEN Mengna, et al. Stretch-convergence stress effect tectonic analysis and gas controlling of strike-slip fault zone in strong deformed zone[J]. Natural Gas Geoscience, 2018, 29(11): 1568-1574. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX201811003.htm [21] 陈丽清, 伍秋姿, 范存辉, 等. 四川盆地南部双龙—罗场地区龙马溪组构造裂缝特征及形成期次[J]. 天然气地球科学, 2022, 33(5): 789-798. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX202205010.htmCHEN Liqing, WU Qiuzi, FAN Cunhui, et al. Tectonic fracture characteristics and formation stages of Longmaxi Formation in Shuanglong-Luochang areas, southern Sichuan Basin[J]. Natural Gas Geoscience, 2022, 33(5): 789-798. https://www.cnki.com.cn/Article/CJFDTOTAL-TDKX202205010.htm [22] 何顺, 秦启荣, 周吉羚, 等. 川东南DS地区龙马溪组页岩裂缝发育特征及期次解析[J]. 地质科技情报, 2019, 38(2): 101-109. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201902012.htmHE Shun, QIN Qirong, ZHOU Jiling, et al. Shale fracture characteristics and its application of the Longmaxi Formation in DS area, southeast Sichuan[J]. Geological Science and Technology Information, 2019, 38(2): 101-109. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201902012.htm [23] 尹帅, 孙晓光, 邬忠虎, 等. 鄂尔多斯盆地东北缘上古生界构造演化及裂缝耦合控气作用[J]. 中南大学学报(自然科学版), 2022, 53(9): 3724-3737. https://www.cnki.com.cn/Article/CJFDTOTAL-ZNGD202209033.htmYIN Shuai, SUN Xiaoguang, WU Zhonghu, et al. Coupling control of tectonic evolution and fractures on the Upper Paleozoic gas reservoirs in the northeastern margin of the Ordos Basin[J]. Journal of Central South University (Science and Technology), 2022, 53(9): 3724-3737. https://www.cnki.com.cn/Article/CJFDTOTAL-ZNGD202209033.htm [24] 尹帅, 丁文龙, 林利飞, 等. 鄂尔多斯盆地西部志丹—吴起地区延长组裂缝特征及其控藏作用[J]. 地球科学, 2023, 48(7): 2614-2629. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202307013.htmYIN Shuai, DING Wenlong, LIN Lifei, et al. Characteristics and controlling effect on hydrocarbon accumulation of fractures in Yanchang Formation in Zhidan-Wuqi area, western Ordos Basin[J]. Earth Science, 2023, 48(7): 2614-2629. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202307013.htm [25] 郭安林, 程顺有, 张朝锋, 等. 川西南多重褶皱构造及背景分析[J]. 西北大学学报(自然科学版), 2009, 39(3): 484-489. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ200903019.htmGUO Anlin, CHENG Shunyou, ZHANG Chaofeng, et al. Multi-phased fold structures and tectonic background analysis in southwest Sichuan Province[J]. Journal of Northwest University (Natural Science Edition), 2009, 39(3): 484-489. https://www.cnki.com.cn/Article/CJFDTOTAL-XBDZ200903019.htm [26] 赵瞻, 李嵘, 冯伟明, 等. 滇黔北地区五峰组—龙马溪组页岩气富集条件及有利区预测[J]. 天然气工业, 2017, 37(12): 26-34. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201712008.htmZHAO Zhan, LI Rong, FENG Weiming, et al. Enrichment conditions and favorable zone prediction of Wufeng-Longmaxi shale gas reservoirs in the northern Yunnan-Guizhou provinces, China[J]. Natural Gas Industry, 2017, 37(12): 26-34. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201712008.htm [27] 黄继新, 彭仕宓, 王小军, 等. 成像测井资料在裂缝和地应力研究中的应用[J]. 石油学报, 2006, 27(6): 65-69. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200606013.htmHUANG Jixin, PENG Shimi, WANG Xiaojun, et al. Applications of imaging logging data in the research of fracture and ground stress[J]. Acta Petrolei Sinica, 2006, 27(6): 65-69. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB200606013.htm [28] 苟启洋, 徐尚, 郝芳, 等. 基于成像测井的泥页岩裂缝研究: 以焦石坝区块为例[J]. 地质科技通报, 2020, 39(6): 193-200. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ202006021.htmGOU Qiyang, XU Shang, HAO Fang, et al. Research on mud shale fractures based on image logging: a case study of Jiaoshiba area[J]. Bulletin of Geological Science and Technology, 2020, 39(6): 193-200. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ202006021.htm [29] 赖锦, 王贵文, 郑新华, 等. 油基泥浆微电阻率扫描成像测井裂缝识别与评价方法[J]. 油气地质与采收率, 2015, 22(6): 47-54. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201506009.htmLAI Jin, WANG Guiwen, ZHENG Xinhua, et al. Recognition and evaluation method of fractures by micro-resistivity image logging in oil-based mud[J]. Petroleum Geology and Recovery Efficiency, 2015, 22(6): 47-54. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201506009.htm [30] 万远飞, 秦启荣, 范宇, 等. 长宁背斜龙马溪组页岩裂缝发育特征及期次解析[J]. 特种油气藏, 2021, 28(1): 59-66. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202101008.htmWAN Yuanfei, QIN Qirong, FAN Yu, et al. Development characteristics of shale fractures in Longmaxi Formation of Changning anticline and the stage analysis[J]. Special Oil & Gas Reservoirs, 2021, 28(1): 59-66. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202101008.htm [31] 何顺, 秦启荣, 范存辉, 等. 川东南丁山地区页岩气保存条件分析[J]. 油气地质与采收率, 2019, 26(2): 24-31. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201902004.htmHE Shun, QIN Qirong, FAN Cunhui, et al. Shale gas preservation conditions in Dingshan area, southeastern Sichuan[J]. Petroleum Geology and Recovery Efficiency, 2019, 26(2): 24-31. https://www.cnki.com.cn/Article/CJFDTOTAL-YQCS201902004.htm [32] 范存辉, 李虎, 钟城, 等. 川东南丁山构造龙马溪组页岩构造裂缝期次及演化模式[J]. 石油学报, 2018, 39(4): 379-390. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201804002.htmFAN Cunhui, LI Hu, ZHONG Cheng, et al. Tectonic fracture stages and evolution model of Longmaxi Formation shale, Dingshan structure, southeast Sichuan[J]. Acta Petrolei Sinica, 2018, 39(4): 379-390. https://www.cnki.com.cn/Article/CJFDTOTAL-SYXB201804002.htm [33] 赵奎, 项威斌, 曾鹏, 等. 岩石声发射Kaiser效应研究现状及展望[J]. 金属矿山, 2021(1): 94-105. https://www.cnki.com.cn/Article/CJFDTOTAL-JSKS202101008.htmZHAO Kui, XIANG Weibin, ZENG Peng, et al. Research status and prospect of Kaiser effect in rock acoustic emission[J]. Metal Mine, 2021(1): 94-105. https://www.cnki.com.cn/Article/CJFDTOTAL-JSKS202101008.htm [34] 谢佳彤. 丁山—东溪地区页岩裂缝发育特征及主控因素[J]. 断块油气田, 2023, 30(3): 389-395. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202303005.htmXIE Jiatong. Development characteristics of shale fracture and main controlling factors in Dingshan-Dongxi area[J]. Fault-Block Oil & Gas Field, 2023, 30(3): 389-395. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202303005.htm [35] 李小佳, 邓宾, 刘树根, 等. 川南宁西地区五峰组—龙马溪组多期流体活动[J]. 岩性油气藏, 2021, 33(6): 135-144. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX202106014.htmLI Xiaojia, DENG Bin, LIU Shugen, et al. Multi-stage fluid activity characteristics of Wufeng-Longmaxi formation in Ningxi area, southern Sichuan Basin[J]. Lithologic Reservoirs, 2021, 33(6): 135-144. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX202106014.htm [36] 刘安, 周鹏, 陈孝红, 等. 运用方解石脉包裹体和碳氧同位素评价页岩气保存条件: 以中扬子地区寒武系为例[J]. 天然气工业, 2021, 41(2): 47-55. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202102010.htmLIU An, ZHOU Peng, CHEN Xiaohong, et al. Evaluation of shale gas preservation conditions using calcite vein inclusions and C/O isotopes: a case study on the Cambrian strata of Middle Yangtze area[J]. Natural Gas Industry, 2021, 41(2): 47-55. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG202102010.htm [37] 唐永, 周立夫, 陈孔全, 等. 川东南构造应力场地质分析及构造变形成因机制讨论[J]. 地质论评, 2018, 64(1): 15-28. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201801004.htmTANG Yong, ZHOU Lifu, CHEN Kongquan, et al. Analysis of tectonic stress field of southeastern Sichuan and formation mechanism of tectonic deformation[J]. Geological Review, 2018, 64(1): 15-28. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP201801004.htm -
