Prediction of fracture distribution in the Lower Jurassic Da'anzhai Member on the eastern slope of the Western Sichuan Depression, Sichuan Basin
-
摘要: 四川盆地川西坳陷东坡地区下侏罗统大安寨段是致密油气的主要开发目的层，裂缝是大安寨段储层能否获得高产的关键因素。由于大安寨段地层岩性复杂，传统裂缝预测评价方法适用范围窄、预测结果精度低。基于岩心裂缝调查及薄片鉴定资料，运用地质统计学及数值模拟方法，明确了不同岩性储层的岩石学特征，揭示了大安寨段裂缝发育特征；结合岩石破裂基础和破裂外力二大因素，在区分岩性及亚段的条件下，提出并构建了3项裂缝评价因子，对各亚段裂缝平面分布进行预测评价。研究表明：(1)大安寨段储层为(介壳)灰岩、砂岩及泥页岩相互叠置的复杂岩性；(2)主要发育全充填裂缝，(介壳)灰岩主要发育构造裂缝，砂岩和泥页岩主要发育层间缝，缝面存在溶蚀现象，对油气流动具有积极意义；(3)提出并构建了岩性厚度评价因子、构造变形强度因子和断裂破裂强度因子3项裂缝评价因子，并建立裂缝综合预测评价定量模型，对各亚段裂缝平面分布进行综合预测评价，预测的裂缝密度与单井识别的裂缝发育指数吻合性较好，预测结果可靠。该裂缝平面分布预测评价方法对于同类型油气藏的评价具有借鉴意义。Abstract: The Da'anzhai Member of the Lower Jurassic on the eastern slope of the Western Sichuan Depression in the Sichuan Basin is a main target for the development of tight oil and gas. Fractures are essential for achieving high production in the Da'anzhai Member reservoirs. Due to their complex lithology, traditional methods for fracture prediction and evaluation have limited applicability and low prediction accuracy. Based on core fracture investigations and thin-section identification data, combined with geological statistics and numerical simulations, the lithological characteristics of various reservoirs were clarified, and the fracture development characteristics in the Da'anzhai Member were revealed. Considering both the fracture foundation and external fracturing forces, three fracture evaluation factors were proposed and constructed to predict and evaluate the planar distribution of fractures in each sub-member by distinguishing lithology and sub-members. The results showed that: (1) The Da'anzhai Member reservoirs had complex lithologies with interbedded (shell) limestone, sandstone, and shale. (2) Fully filled fractures were mainly developed, and (shell) limestone exhibited mainly structural fractures, while sandstone and shale mainly showed interlayer fractures with dissolution features on the fracture surfaces, which was beneficial for enhancing oil and gas flow. (3) Three fracture evaluation factors were proposed and constructed, which included lithologic thickness, tectonic deformation intensity, and fracture rupture intensity. A quantitative model for comprehensive prediction and evaluation of fractures was established to predict and evaluate the planar distribution of fractures in each sub-member comprehensively. The predicted fracture density aligned well with the fracture development index identified in individual wells, indicating the reliability of the prediction results. This method for fracture planar distribution prediction and evaluation offers a reference for similar oil and gas reservoirs.
-
图 1 四川盆地川西坳陷东坡地区构造地理位置(a)及研究区构造和采样井分布(b)
Figure 1. Geographical location of eastern slope of Western Sichuan Depression in Sichuan Basin (a), structure and distribution of sampling wells (b) in study area
图 2 四川盆地川西坳陷东坡地区HL3井大安寨段取心段复杂岩性结构及典型沉积相剖面
Figure 2. Complex lithological structure and typical sedimentary facies profile of core section of Da'anzhai Member in well HL3 on eastern slope of Western Sichuan Depression, Sichuan Basin
图 3 四川盆地川西坳陷东坡地区大安寨段不同岩性地层岩石学特征
a.细晶介壳灰岩，大一亚段，2 736.84 m，HL3井，×25(+)；b.细—粗晶介壳灰岩，大一亚段，2 740.41 m，HL3井，×25(-)；c基质为黏土杂基，大一亚段，2 724.49 m，HL3井，×25(-)；d.基质为黏土杂基，大一亚段，2 734.55 m，HL3井，×25(-)；e.微晶—细晶灰岩，大一亚段，2 745.31 m，HL3井，×25(+)；f.泥晶灰岩，大一亚段，2 750.66 m，HL3井，×50(-)；g.长石岩屑砂岩，大三亚段，2 777.16 m，HL3井，×50(-)；h.长石岩屑砂岩，大三亚段，2 783.93 m，HL3井，×50(-)；i.FX3井，大二亚段，2 733.85~2 733.95 m，灰黑色泥页岩；j.FX3井，大二亚段，2 736.07~2 736.33 m，灰色钙质泥页岩；k.FX3井，大二亚段，2 732.86 m, 灰黑色泥页岩，岩性致密，见白云石、石英、菱铁矿、有机质等相间分布；l.FX3井，大二亚段，2 733.95 m，深灰色泥页岩，有机质多呈碎块状、填隙状，见微粒状石英发育串珠状孔隙。
Figure 3. Petrological characteristics of different lithological strata of Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 4 四川盆地川西坳陷东坡地区大安寨段不同成因裂缝在不同岩性中的分布
Figure 4. Distribution of different genesis fractures in different lithologies in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 5 四川盆地川西坳陷东坡地区大安寨段裂缝发育特征
Figure 5. Development characteristics of fractures in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 6 四川盆地川西坳陷东坡地区大安寨段泥页岩储层裂缝缝面特征
a.HL3井，2-46/57，擦痕面，无充填物，擦痕顺缝面方向(箭头标示)；b.FG101井，1-18/43，35°擦痕面，方解石半充填，擦痕顺缝面方向(箭头标示)；c.JS5井，21/58，25°擦痕面(箭头标示)，方解石半充填，缝面有溶蚀；d.YT2井，5-57/105，方解石半充填，沿缝面溶蚀孔洞发育，见擦痕(箭头标示)。
Figure 6. Characteristics of fracture surfaces in shale reservoirs in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 7 四川盆地川西坳陷东坡地区大安寨段岩层厚度反向指数与裂缝发育指数的关系
Figure 7. Relationship between rock layer thickness inverse index and fracture development index in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 8 四川盆地川西坳陷东坡地区大安寨段构造变形主曲率与构造变形强度因子的关系
Figure 8. Relationship between main curvature of tectonic deformation and tectonic deformation intensity factor in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 9 四川盆地川西坳陷东坡地区大安寨段断裂破裂强度因子平面分布
平面位置见图 1b。
Figure 9. Planar distribution of fracture rupture strength factor in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 10 四川盆地川西坳陷东坡地区大安寨段岩层厚度反向指数与页地比关系
Figure 10. Relationship between rock layer thickness inverse index and clay-to-ground ratio in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
图 11 四川盆地川西坳陷东坡地区大安寨段裂缝综合预测
平面位置见图 1b。
Figure 11. Comprehensive prediction of fractures in Da'anzhai Member on eastern slope of Western Sichuan Depression, Sichuan Basin
-
[1] 邓康龄, 余福林. 川西坳陷的复合构造与油气关系[J]. 石油与天然气地质, 2005, 26(2): 214-219. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200502014.htmDENG Kangling, YU Fulin. Compound structures and hydrocarbons in Western Sichuan Depression[J]. Oil & Gas Geology, 2005, 26(2): 214-219. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT200502014.htm [2] 李智武, 刘树根, 林杰, 等. 川西坳陷构造格局及其成因机制[J]. 成都理工大学学报(自然科学版), 2009, 36(6): 645-653. https://www.cnki.com.cn/Article/CJFDTOTAL-CDLG200906011.htmLI Zhiwu, LIU Shugen, LIN Jie, et al. Structural configuration and its genetic mechanism of the West Sichuan Depression in China[J]. Journal of Chengdu University of Technology (Science & Technology Edition), 2009, 36(6): 645-653. https://www.cnki.com.cn/Article/CJFDTOTAL-CDLG200906011.htm [3] 朱宏权. 川西坳陷中段沙溪庙组沉积相与储层评价研究[D]. 成都: 成都理工大学, 2009: 9-19.ZHU Hongquan. Depositional facies and reservoir characteristics research and evaluation of Shaximiao Formation, Middle area of Western Sichuan Depression[D]. Chengdu: Chengdu University of Technology, 2009: 9-19. [4] 谢刚平, 叶素娟, 田苗. 川西坳陷致密砂岩气藏勘探开发实践新认识[J]. 天然气工业, 2014, 34(1): 44-53. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201401008.htmXIE Gangping, YE Sujuan, TIAN Miao. New understandings of exploration and development practices in tight sandstone gas reservoirs in Western Sichuan Depression[J]. Natural Gas Industry, 2014, 34(1): 44-53. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201401008.htm [5] 王帅成, 王多义, 陈敏, 等. 川西坳陷中段沙溪庙组天然气成藏条件分析[J]. 海洋石油, 2010, 30(3): 42-46. https://www.cnki.com.cn/Article/CJFDTOTAL-HYSY201003011.htmWANG Shuaicheng, WANG Duoyi, CHEN Min, et al. Natural gas reservoir-formation condition of Shaximiao Formation in mid-band of Western Sichuan Depression[J]. Offshore Oil, 2010, 30(3): 42-46. https://www.cnki.com.cn/Article/CJFDTOTAL-HYSY201003011.htm [6] 杨跃明, 黄东. 四川盆地侏罗系湖相页岩油气地质特征及勘探开发新认识[J]. 天然气工业, 2019, 39(6): 22-33. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201906004.htmYANG Yueming, HUANG Dong. Geological characteristics and new understandings of exploration and development of Jurassic lacustrine shale oil and gas in the Sichuan Basin[J]. Natural Gas Industry, 2019, 39(6): 22-33. https://www.cnki.com.cn/Article/CJFDTOTAL-TRQG201906004.htm [7] 邹才能, 杨智, 王红岩, 等. "进源找油": 论四川盆地非常规陆相大型页岩油气田[J]. 地质学报, 2019, 93(7): 1551-1562. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201907001.htmZOU Caineng, YANG Zhi, WANG Hongyan, et al. "Exploring petroleum inside source kitchen": Jurassic unconventional continental giant shale oil & gas field in Sichuan Basin, China[J]. Acta Geologica Sinica, 2019, 93(7): 1551-1562. https://www.cnki.com.cn/Article/CJFDTOTAL-DZXE201907001.htm [8] 杨跃明, 杨家静, 杨光, 等. 四川盆地中部地区侏罗系致密油研究新进展[J]. 石油勘探与开发, 2016, 43(6): 873-882. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201606005.htmYANG Yueming, YANG Jiajing, YANG Guang, et al. New research progress of Jurassic tight oil in central Sichuan Basin[J]. Petroleum Exploration and Development, 2016, 43(6): 873-882. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201606005.htm [9] 孙莎莎, 董大忠, 李育聪, 等. 四川盆地侏罗系自流井组大安寨段陆相页岩油气地质特征及成藏控制因素[J]. 石油与天然气地质, 2021, 42(1): 124-135. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101012.htmSUN Shasha, DONG Dazhong, LI Yucong, et al. Geological characte-ristics and controlling factors of hydrocarbon accumulation in terrestrial shale in the Da'anzhai Member of the Jurassic Ziliujing Formation, Sichuan Basin[J]. Oil & Gas Geology, 2021, 42(1): 124-135. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202101012.htm [10] XIE Runcheng, LUO Ziwei, ZHANG Mengyuan, et al. Factors controlling tight oil and gas reservoir development in the Jurassic siliciclastic-carbonate rocks in Sichuan Basin, China[J]. Energy Geoscience, 2022, 3(4): 453-464. doi: 10.1016/j.engeos.2021.08.001 [11] 王濡岳, 胡宗全, 赖富强, 等. 川东北地区下侏罗统自流井组大安寨段陆相页岩脆性特征及其控制因素[J]. 石油与天然气地质, 2023, 44(2): 366-378. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202302009.htmWANG Ruyue, HU Zongquan, LAI Fuqiang, et al. Brittleness features and controlling factors of continental shale from Da'anzhai Member of the Lower Jurassic Ziliujing Formation, northeastern Sichuan Basin[J]. Oil & Gas Geology, 2023, 44(2): 366-378. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202302009.htm [12] 康家豪, 王兴志, 谢圣阳, 等. 川中地区侏罗系大安寨段页岩岩相类型及储层特征[J]. 岩性油气藏, 2022, 34(4): 53-65. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX202204006.htmKANG Jiahao, WANG Xingzhi, XIE Shengyang, et al. Lithofacies types and reservoir characteristics of shales of Jurassic Da'anzhai Member in central Sichuan Basin[J]. Lithologic Reservoirs, 2022, 34(4): 53-65. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX202204006.htm [13] 冯动军. 四川盆地侏罗系大安寨段陆相页岩油气地质特征及勘探方向[J]. 石油实验地质, 2022, 44(2): 219-230. doi: 10.11781/sysydz202202219FENG Dongjun. Geological characteristics and exploration direction of continental shale gas in Jurassic Daanzhai Member, Sichuan Basin[J]. Petroleum Geology & Experiment, 2022, 44(2): 219-230. doi: 10.11781/sysydz202202219 [14] 孔祥晔, 曾溅辉, 罗群, 等. 川中地区大安寨段陆相页岩岩相对孔隙结构的控制作用[J]. 新疆石油地质, 2023, 44(4): 392-403. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSD202304002.htmKONG Xiangye, ZENG Jianhui, LUO Qun, et al. Controls of continental shale lithofacies on pore structure of Jurassic Da'anzhai Member in central Sichuan Basin[J]. Xinjiang Petroleum Geology, 2023, 44(4): 392-403. https://www.cnki.com.cn/Article/CJFDTOTAL-XJSD202304002.htm [15] 黄董, 曾德铭, 王兴志, 等. 川中地区侏罗系大安寨段沉积相及有利岩石组合分析[J]. 特种油气藏, 2023, 30(1): 65-73. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202301009.htmHUANG Dong, ZENG Deming, WANG Xingzhi, et al. Sedimentary facies and favorable rock assemblages of Jurassic Da'anzhai Member, central Sichuan[J]. Special Oil & Gas Reservoirs, 2023, 30(1): 65-73. https://www.cnki.com.cn/Article/CJFDTOTAL-TZCZ202301009.htm [16] 罗莹莹, 吴丰. 四川盆地侏罗系大安寨段湖相介壳灰岩裂缝测井识别[C]//第十七届全国古地理学及沉积学学术会议摘要集: 专题6测井地质学在非常规油气沉积储层评价中的应用. 青岛: 中国矿物岩石地球化学学会岩相古地理专业委员会, 2023.LUO Yingying, WU Feng. Logging identification of lacustrine shell limestone fractures in the Jurassic Da'anzhai Member of the Sichuan Basin[C]//Lithofacies Paleogeography Committee of the Chinese Society of Mineral Petrogeochemistry, International Society of Palaeogeography. Qingdao: The Professional Committee of Lithology and Paleogeography of the Chinese Society of Mineral and Rock Geochemistry, 2023. [17] 蒋代琴, 李平平, 邹华耀. 川东北元坝地区侏罗系陆相页岩天然裂缝发育特征及其对页岩油气富集和保存的影响[J]. 现代地质, 2024, 38(2): 362-372. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ202402008.htmJIANG Daiqin, LI Pingping, ZOU Huayao. Characteristics of natural fractures and their influence on oil and gas enrichment and pre-servation of the Jurassic continental shale in the Yuanba area, northeastern Sichuan Basin[J]. Geoscience, 2024, 38(2): 362-372. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ202402008.htm [18] 李磊. 元坝地区大安寨段泥页岩孔缝表征与页岩气富集规律研究[D]. 北京: 中国石油大学(北京), 2020.LI Lei. Characterization of shale pore and fracture and shale gas enrichment in Da'anzhai Member in Yuanba area[D]. Beijing: China University of Petroleum (Beijing), 2020. [19] 何龙, 郑荣才, 梁西文, 等. 川东涪陵地区大安寨段裂缝控制因素及期次分析[J]. 岩性油气藏, 2014, 26(4): 88-96. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX201404017.htmHE Long, ZHENG Rongcai, LIANG Xiwen, et al. Controlling factors and development periods of fracture of Da'anzhai Member in Fuling area, eastern Sichuan Basin[J]. Lithologic Reservoirs, 2014, 26(4): 88-96. https://www.cnki.com.cn/Article/CJFDTOTAL-YANX201404017.htm [20] WANG Pengwei, LIU Zhongbao, FENG Dongjun, et al. Microfracture development at Ziliujing lacustrine shale reservoir and its significance for shale-gas enrichment at Fuling in eastern Sichuan Basin, China[J]. Journal of Natural Gas Geoscience, 2022, 7(1): 39-48. doi: 10.1016/j.jnggs.2022.03.002 [21] 赵辉, 司马立强, 颜其彬, 等. 川中大安寨段裂缝评价及储层产能预测方法[J]. 测井技术, 2008, 32(3): 277-280. https://www.cnki.com.cn/Article/CJFDTOTAL-CJJS200803025.htmZHAO Hui, SIMA Liqiang, YAN Qibin, et al. Assessment of fracture and method of production forecast of Daanzai reservoir[J]. Well Logging Technology, 2008, 32(3): 277-280. https://www.cnki.com.cn/Article/CJFDTOTAL-CJJS200803025.htm [22] 田杰. 川中侏罗系大安寨段裂缝评价[D]. 成都: 西南石油大学, 2018.TIAN Jie. Fracture evaluation of Jurassic Da'anzhai section in central Sichuan[D]. Chengdu: SouthWest Petroleum University, 2018. [23] LUO Ziwei, XIE Runcheng, CAI Wenli, et al. Comprehensive logging identification method of shell limestone fractures in the Lower Jurassic Da'anzhai Member in the Dongpo area of the western Sichuan Depression[J]. Unconventional Resources, 2022, 2: 97-107. doi: 10.1016/j.uncres.2022.08.002 [24] ZHANG Xiaoju, HE Jianhua, DENG Hucheng, et al. Controls of interlayers on the development and distribution of natural fractures in lacustrine shale reservoirs: a case study of the Da'anzhai Member in the Fuling area in the eastern Sichuan Basin[J]. Journal of Petro-leum Science and Engineering, 2022, 208: 109224. doi: 10.1016/j.petrol.2021.109224 [25] ZHANG Mengyuan, XIE Runcheng, YIN Shuai, et al. Logging identification of complex lithology of the Lower Jurassic Da'anzhai Member in the eastern slope of the Western Sichuan Depression[J]. Unconventional Resources, 2023, 3: 7-19. doi: 10.1016/j.uncres.2022.10.001 [26] 王濡岳, 胡宗全, 周彤, 等. 四川盆地及其周缘五峰组-龙马溪组页岩裂缝发育特征及其控储意义[J]. 石油与天然气地质, 2021, 42(6): 1295-1306. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202106005.htmWANG Ruyue, HU Zongquan, ZHOU Tong, et al. Characteristics of fractures and their significance for reservoirs in Wufeng-Longmaxi shale, Sichuan Basin and its periphery[J]. Oil & Gas Geology, 2021, 42(6): 1295-1306. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT202106005.htm [27] 汪虎, 何治亮, 张永贵, 等. 四川盆地海相页岩储层微裂缝类型及其对储层物性影响[J]. 石油与天然气地质, 2019, 40(1): 41-49. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201901006.htmWANG Hu, HE Zhiliang, ZHANG Yonggui, et al. Microfracture types of marine shale reservoir of Sichuan Basin and its influence on reservoir property[J]. Oil & Gas Geology, 2019, 40(1): 41-49. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201901006.htm [28] 王力, 夏连军, 陈栋, 等. 苏北盆地高邮凹陷泥页岩网状裂缝系统预测[C]//中国石油学会石油物探专业委员会, 中国地球物理学会勘探地球物理委员会. 中国石油学会2019年物探技术研讨会论文集. 成都: 《中国学术期刊(光盘版)》电子杂志社有限公司, 2019: 5.WANG Li, XIA Lianjun, CHEN Dong, et al. Prediction of shale reticular fracture system in Gaoyou Sag, Subei Basin[C]//Professional Committee of Petroleum Geophysics, Chinese Petro-leum Society, Exploration Geophysics Committee, Chinese Geophysical Society. 2019 Symposium on Geophysical Prospecting Technology of China Petroleum Institute. Chengdu: 《China Academic Journal (CD Edition)》Electronic Magazine Co., Ltd., 2019: 5. [29] 陈珂磷, 杨扬, 井翠, 等. 页岩裂缝型储层模型参数化及AVAZ反演预测方法研究[J]. 地球物理学进展, 2022, 37(6): 2364-2372. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWJ202206014.htmCHEN Kelin, YANG Yang, JING Cui, et al. Model parameterization and AVAZ inversion prediction method in shale fractured reservoir[J]. Progress in Geophysics, 2022, 37(6): 2364-2372. https://www.cnki.com.cn/Article/CJFDTOTAL-DQWJ202206014.htm [30] 程晓艳, 胡曦, 罗颖, 等. 基于相干约束的页岩裂缝OVT地震预测方法研究及应用[J]. 断块油气田, 2023, 30(6): 982-990. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202306013.htmCHENG Xiaoyan, HU Xi, LUO YING, et al. Research and application of OVT seismic prediction method for shale fractures based on coherence constraints[J]. Fault-Block Oil & Gas Field, 2023, 30(6): 982-990. https://www.cnki.com.cn/Article/CJFDTOTAL-DKYT202306013.htm [31] 吴林强, 刘成林, 张涛, 等. "二元法"在构造裂缝定量预测中的应用: 以松辽盆地青一段泥页岩为例[J]. 地质力学学报, 2018, 24(5): 598-606. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLX201805063.htmWU Linqiang, LIU Chenglin, ZHANG Tao, et al. The application of two factor method in quantitative prediction of tectonic fractures: a case study of shale in Qing-1 Member, Songliao Basin[J]. Journal of Geomechanics, 2018, 24(5): 598-606. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLX201805063.htm [32] 杨勇. 松辽盆地北部青山口组构造应力场与裂缝预测研究[D]. 西安: 西安石油大学, 2022.YANG Yong. Study on tectonic stress field and fracture prediction of Qingshankou Formation in northern Songliao Basin[D]. Xi'an: Xi'an Shiyou University, 2022. [33] 丁文龙, 王垚, 王生晖, 等. 页岩储层非构造裂缝研究进展与思考[J]. 地学前缘, 2024, 31(1): 297-314. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY202401021.htmDING Wenlong, WANG Yao, WANG Shenghui, et al. Research progress and insight on non-tectonic fractures in shale reservoirs[J]. Earth Science Frontiers, 2024, 31(1): 297-314. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY202401021.htm [34] 张晓鹏. 内陆湖泊非均质碳酸盐岩油藏勘探技术方法研究: 以四川盆地侏罗系大安寨段灰岩油藏为例[D]. 成都: 成都理工大学, 2005: 26-37.ZHANG Xiaopeng. Studies of the exploration technology of interio lake heterogeneous carbonate reservoirs: taking Jurassic limestone reservoir of Daanzai Member in Sichuan Basin as an example[D]. Chengdu: Chengdu University of Technology, 2005: 26-37. [35] 黄开伟, 王兴志, 张帆, 等. 川中小潼场地区大安寨段储层特征研究[J]. 重庆科技学院学报(自然科学版), 2010, 12(5): 14-18. https://www.cnki.com.cn/Article/CJFDTOTAL-CQSG201005006.htmHUANG Kaiwei, WANG Xingzhi, ZHANG Fan, et al. Reservoir characteristics of Da'anzhai Member in Xiaotongchang area of central Sichuan[J]. Journal of Chongqing University of Science and Technology (Natural Sciences Edition), 2010, 12(5): 14-18. https://www.cnki.com.cn/Article/CJFDTOTAL-CQSG201005006.htm -
