深部煤岩地质特征及煤层气富集主控地质因素——以鄂尔多斯盆地东部M区为例

郭晓娇; 王雷; 姚仙洲; 李旭; 张林科; 王晓双

doi:10.11781/sysydz2025010017

深部煤岩地质特征及煤层气富集主控地质因素——以鄂尔多斯盆地东部M区为例

doi: 10.11781/sysydz2025010017

郭晓娇^1,2,
王雷^3, ,,
姚仙洲³,
李旭³,
张林科³,
王晓双³

1. 西安石油大学地球科学与工程学院, 西安 710065;
2. 西安石油大学陕西省油气成藏地质学重点实验室, 西安 710065;
3. 中国石油集团东方地球物理勘探有限责任公司研究院长庆分院, 西安 710021

基金项目:

中国石油“十四五”前瞻性基础性重大科技项目(2021DJ2101)和西安石油大学硕士研究生创新与实践能力培养计划(YCS23113044)联合资助。

详细信息

作者简介:
郭晓娇(1998—)，女，硕士，主要从事油气地质勘探工作。E-mail:1185307231@qq.com。

通讯作者:
王雷(1988—)，男，高级工程师，主要从事地震资料解释及地质综合研究工作。E-mail：wanglei2015@cnpc.com.cn。

中图分类号: TE122.3
计量
- 文章访问数: 5
- HTML全文浏览量: 0
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2024-01-20
- 修回日期: 2024-12-03
- 网络出版日期: 2025-01-24

Geological characteristics of deep coal rock and main geological factors controlling coalbed methane enrichment: a case study of the M area in the eastern Ordos Basin

1. School of Earth Sciences and Engineering, Xi'an Shiyou University, Xi'an, Shaanxi 710065, China;
2. Shaanxi Key Laboratory of Petroleum Accumulation Geology, Xi'an Shiyou University, Xi'an, Shaanxi 710065, China;
3. Changqing Branch, Geophysical Research Institute, BGP INC., CNPC, Xi'an, Shaanxi 710021, China

摘要

摘要: 鄂尔多斯盆地M区上石炭统本溪组顶部8^#厚煤层分布广泛，有机质热成熟度高。该区煤层埋深大、横向变化快、非均质性强，且煤岩基础地质特征及深部煤层气富集规律尚不明确、有利目标优选标准尚未建立，这严重制约了深部煤层气的高效勘探。为了促进深部煤层气的增储和高效产出，进一步发展鄂尔多斯盆地东部深部煤层气富集理论，基于研究区76口井的岩心观察、实验分析测试、扫描电镜、测—录井资料，结合三维地震资料，开展了深部煤层地质特征及煤层气富集主控因素两方面的研究工作，初步明确了该区深部煤层气的勘探潜力。鄂尔多斯盆地M区上石炭统本溪组顶部8^#煤以焦煤—瘦煤为主，为中高阶煤；亮煤和半亮煤厚度为2～6 m；有机组分以镜质组为主，占比79.8%；工业组分表现为中高挥发分及灰分、固定碳丰富、低水分；煤岩储层孔缝发育，以原生孔隙为主，其孔隙主要由微孔和大孔组成；含气量介于16～25 m³/t之间。鄂尔多斯盆地东缘深部煤层气富集情况主要受煤储层、构造2个因素控制。以6 m以上的厚煤层发育区、远离断裂带(断距小于5 m)的裂缝发育区、微构造高点作为深部煤层气有利勘探区优选原则，优选出8^#煤有利勘探面积共207 km²，其中Ⅰ类区97 km²，Ⅱ类区110 km²。
- 深部煤层气 /
- 富集高产 /
- 主控因素 /
- 本溪组 /
- 鄂尔多斯盆地
Abstract: The 8^# thick coal seam is widely distributed with high organic matter thermal maturity at the top of the Upper Carboniferous Benxi Formation in the M area of the Ordos Basin. However, the coal seams in this area are characterized by large burial depth, rapid lateral changes, strong heterogeneity, and unclear basic geological features and enrichment patterns of deep coalbed methane (CBM). The criteria for selecting favorable targets are yet to be established. These severely restrict the efficient exploration of deep CBM. To promote increased reserves and efficient production of deep CBM, and to further develop the enrichment theory of deep CBM in the eastern Ordos Basin, a comprehensive study was conducted based on core observations, experimental tests, scanning electron microscopy, well logging data from 76 wells in the study area, and 3D seismic data. The geological characteristics of deep coal seams and the main controlling factors of CBM enrichment were investigated, preliminary clarifying the exploration potential of this area. The results indicate that: The 8^# coal seam at the top of the Upper Carboni-ferous Benxi Formation in the M area of the Ordos Basin is mainly composed of coking coal and lean coal, which are medium to high-ranked coals. The thickness of bright coal and semi-bright coal ranges from 2 to 6 m. Organic components are mainly vitrinite, accounting for 79.8%. Industrial components exhibit medium to high levels of volatile matter and ash, abundant fixed carbon, and low moisture content. The coal rock reservoir has well-developed pores and fractures, primarily composed of micropores and macropores. Gas content ranges between 16-25 m³/t. The enrichment of deep CBM in the eastern margin of the Ordos Basin is mainly controlled by coal reservoir and structural factors. Favorable exploration areas for deep CBM include regions with coal seams thicker than 6 m, areas with developed fractures far from fault zones (fault displacement less than 5 m), and microstructure high points. Based on these criteria, a favorable exploration area of 207 km² for the 8^# coal seam was identified, with 97 km² classified as Type Ⅰ and 110 km² as Type Ⅱ.
- deep coalbed methane /
- enrichment and high yield /
- main controlling factors /
- Benxi Formation /
- Ordos Basin

HTML全文

参考文献(26)

[1]	张懿, 朱光辉, 郑求根, 等.中国煤层气资源分布特征及勘探研究建议[J].非常规油气, 2022, 9(4):1-8. ZHANG Yi, ZHU Guanghui, ZHENG Qiugen, et al.Distribution characteristics of coalbed methane resources in China and recommendations for exploration research[J].Unconventional Oil & Gas, 2022, 9(4):1-8.
[2]	徐凤银, 王成旺, 熊先钺, 等.深部(层)煤层气成藏模式与关键技术对策：以鄂尔多斯盆地东缘为例[J].中国海上油气, 2022, 34(4):30-42. XU Fengyin, WANG Chengwang, XIONG Xianyue, et al.Deep (layer) coalbed methane reservoir forming modes and key technical countermeasures:taking the eastern margin of Ordos Basin as an example[J].China Offshore Oil and Gas, 2022, 34(4):30-42.
[3]	李国永, 姚艳斌, 王辉, 等.鄂尔多斯盆地神木—佳县区块深部煤层气地质特征及勘探开发潜力[J].煤田地质与勘探, 2024, 52(2):70-80. LI Guoyong, YAO Yanbin, WANG Hui, et al.Deep coalbed methane resources in the Shenmu-Jiaxian block, Ordos Basin, China:geological characteristics and potential for exploration and exploitation[J].Coal Geology & Exploration, 2024, 52(2):70-80.
[4]	顾娇杨, 张兵, 郭明强.临兴区块深部煤层气富集规律与勘探开发前景[J].煤炭学报, 2016, 41(1):72-79. GU Jiaoyang, ZHANG Bing, GUO Mingqiang.Deep coalbed methane enrichment rules and its exploration and development prospect in Linxing block[J].Journal of China Coal Society, 2016, 41(1):72-79.
[5]	闫霞, 徐凤银, 聂志宏, 等.深部微构造特征及其对煤层气高产“甜点区”的控制：以鄂尔多斯盆地东缘大吉地区为例[J].煤炭学报, 2021, 46(8):2426-2439. YAN Xia, XU Fengyin, NIE Zhihong, et al.Microstructure characteristics of Daji area in east Ordos Basin and its control over the high yield dessert of CBM[J].Journal of China Coal Society, 2021, 46(8):2426-2439.
[6]	施雷庭, 赵启明, 任镇宇, 等.煤岩裂隙形态对渗流能力影响数值模拟研究[J].油气藏评价与开发, 2023, 13(4): 424-432. SHI Leiting, ZHAO Qiming, REN Zhenyu, et al. Numerical simulation study on the influence of coal rock fracture morphology on seepage capacity[J].Petroleum Reservoir Evaluation and Development, 2023, 13(4): 424-432.
[7]	牛小兵, 赵伟波, 史云鹤, 等.鄂尔多斯盆地本溪组天然气成藏条件及勘探潜力[J].石油学报, 2023, 44(8):1240-1257. NIU Xiaobing, ZHAO Weibo, SHI Yunhe, et al.Natural gas accumulation conditions and exploration potential of Benxi Formation in Ordos Basin[J].Acta Petrolei Sinica, 2023, 44(8):1240-1257.
[8]	王恒.吴堡矿区上古生界煤层气成藏地质条件研究及甜点区预测[D].西安:西北大学, 2022. WANG Heng.Study on geological conditions of coalbed methane accumulation and prediction of the sweet zones in Upper Paleozoic coal of Wubu mining area[D].Xi’an:Northwest University, 2022.
[9]	胡建波, 刘之的, 段玉顺, 等.小尺度断裂沿层曲率敏感性研究[J].地质与勘探, 2023, 59(4):891-900. HU Jianbo, LIU Zhidi, DUAN Yushun, et al.Sensitivity of small-scale faults curvature along the layer[J].Geology and Exploration, 2023, 59(4):891-900.
[10]	石婧, 何登发, 包洪平, 等.鄂尔多斯盆地东部边界的构造学分析:以石楼北地区为例[J].古地理学报, 2024, 26(1):150-164. SHI Jing, HE Dengfa, BAO Hongping, et al.Tectonic analysis of the eastern boundary of Ordos Basin:a case study of northern region of Shilou area[J].Journal of Palaeogeography (Chinese Edition), 2024, 26(1):150-164.
[11]	赵振宇, 郭彦如, 王艳, 等.鄂尔多斯盆地构造演化及古地理特征研究进展[J].特种油气藏, 2012, 19(5):15-20. ZHAO Zhenyu, GUO Yanru, WANG Yan, et al.Study progress in tectonic evolution and paleogeography of Ordos basin[J].Special Oil & Gas Reservoirs, 2012, 19(5):15-20.
[12]	田瀚, 冯周, 王金锋, 等.陕西省煤岩焦油产率测井评价方法研究[J/OL].地球物理学进展:1-13[2024-02-17 ].http://kns.cnki.net/kcms/detail/11.2982.P.20231109.1731.014.html. TIAN Han, FENG Zhou, WANG Jinfeng, et al.Study on logging evaluation method of coal tar yield in Shaanxi Province[J/OL].Progress in Geophysics:1-13[2024-02-17].http://kns.cnki.net/kcms/detail/11.2982.P.20231109.1731.014.html.
[13]	郭晓娇, 王雷.深部煤层演化过程中储层结构变化特征分析：以鄂尔多斯盆地东部为例[J].中国煤层气, 2023, 20(5):24-27. GUO Xiaojiao, WANG Lei.Analysis on characteristics of reservoir structure changes during evolution process of deep coal seams：taking the eastern Ordos Basin as an example[J].China Coalbed Methane, 2023, 20(5):24-27.
[14]	赵方钰, 邓泽, 王海超, 等.煤体结构与宏观煤岩类型对煤体吸附/解吸瓦斯的影响[J].煤炭科学技术, 2022, 50(12):170-184. ZHAO Fangyu, DENG Ze, WANG Haichao, et al.Influence of coal structure and macrolithotype of coal on coal adsorption and desorption of gas[J].Coal Science and Technology, 2022, 50(12):170-184.
[15]	郭广山, 徐凤银, 刘丽芳, 等.鄂尔多斯盆地府谷地区深部煤层气富集成藏规律及有利区评价[J].煤田地质与勘探, 2024, 52(2):81-91. GUO Guangshan, XU Fengyin, LIU Lifang, et al.Enrichment and accumulation patterns and favorable area evaluation of deep coalbed methane in the Fugu area, Ordos Basin[J].Coal Geology & Exploration, 2024, 52(2):81-91.
[16]	王勃.沁水盆地煤层气富集高产规律及有利区块预测评价[D].徐州:中国矿业大学, 2013. WANG Bo.Coalbed methane enrichment and high-production rule & prospective area prediction in Qinshui Basin[D].Xuzhou:China University of Mining and Technology, 2013.
[17]	李景明, 巢海燕, 李小军, 等.中国煤层气资源特点及开发对策[J].天然气工业, 2009, 29(4):9-13. LI Jingming, CAO Haiyan, LI Xiaojun, et al.Characteristics of coalbed methane resource and the development strategies[J].Natural Gas Industry, 2009, 29(4):9-13.
[18]	贾小宝.大宁—吉县地区深部煤储层物性特征研究[D].太原:太原理工大学, 2018. JIA Xiaobao.The physical characteristics of deep coal reservoir in Daning-Jixian area[D].Taiyuan:Taiyuan University of Technology, 2018.
[19]	IUPAC (International Union of Pure and Applied chemistry).Physical chemistry division commission on colloid and surface chemistry, subcommittee on characterization of porous solids:recommendations for the characterization of porous solids (technical report)[J].Pure and Applied Chemistry, 1994, 66(8):1739-1758.
[20]	朱正平, 雷克辉, 潘仁芳.沁水盆地和顺区块基于地震多属性分析的煤层含气量预测[J].石油物探, 2015, 54(2):226-233. ZHU Zhengping, LEI Kehui, PAN Renfang.Coal seam gas content prediction based on seismic multi-attributes analysis in Heshun block, Qinshui Basin[J].Geophysical Prospecting for Petroleum, 2015, 54(2):226-233.
[21]	陈刚, 秦勇, 胡宗全, 等.不同煤阶深煤层含气量差异及其变化规律[J].高校地质学报, 2015, 21(2):274-279. CHEN Gang, QIN Yong, HU Zongquan.Variations of gas content in deep coalbeds of different coal ranks[J].Geological Journal of China Universities, 2015, 21(2):274-279.
[22]	刘道理, 李坤, 杨登锋, 等.基于频变AVO反演的深层储层含气性识别方法[J].天然气工业, 2020, 40(1):48-54. LIU Daoli, LI Kun, YANG Dengfeng, et al.A gas-bearing property identification method for deep reservoirs based on frequency-dependent AVO inversion[J].Natural Gas Industry, 2020, 40(1):48-54.
[23]	李曙光, 王成旺, 王红娜, 等.大宁—吉县区块深层煤层气成藏特征及有利区评价[J].煤田地质与勘探, 2022, 50(9):59-67. LI Shuguang, WANG Chengwang, WANG Hongna, et al.Reservoir forming characteristics and favorable area evaluation of deep coalbed methane in Daning-Jixian block[J].Coal Geology & Exploration, 2022, 50(9):59-67.
[24]	高玉巧, 李鑫, 何希鹏, 等.延川南深部煤层气高产主控地质因素研究[J].煤田地质与勘探, 2021, 49(2):21-27. GAO Yuqiao, LI Xin, HE Xipeng, et al.Study on the main controlling geological factors of high yield deep CBM in southern Yanchuan block[J].Coal Geology & Exploration, 2021, 49(2):21-27.
[25]	闫霞, 徐凤银, 张雷, 等.微构造对煤层气的控藏机理与控产模式[J].煤炭学报, 2022, 47(2):893-905. YAN Xia, XU Fengyin, ZHANG Lei, et al.Reservoir-controlling mechanism and production-controlling patterns of microstructure to coalbed methane[J].Journal of China Coal Society, 2022, 47(2):893-905.
[26]	李勇.鄂尔多斯盆地东缘煤层气富集成藏规律研究[D].北京:中国地质大学(北京), 2015. LI Yong.Coalbed methane accumulation and reservoring in east margin of Ordos Basin, China[D].Beijing:China University of Geosciences (Beijing), 2015.
