深部煤层气水平井定向射孔压裂水力裂缝扩展特征

黄树新; 李松; 陈博

doi:10.11781/sysydz2025010153

深部煤层气水平井定向射孔压裂水力裂缝扩展特征

doi: 10.11781/sysydz2025010153

黄树新^1,,
李松^2, ,,
陈博²

1.
中国石化华东油气分公司采油气工程服务中心，南京 210004
2.
中国地质大学(北京) 能源学院，北京 100083

基金项目:

国家自然科学基金面上项目 42272195

中国石化科技项目 P23205

中国石化科技项目 YT24007

详细信息

作者简介:
黄树新(1974—)，男，工程师，从事非常规油气资源研究与现场管理。E-mail: 406682782@qq.com

通讯作者:
李松(1985—)，男，博士，副教授，从事非常规油气开发地质研究。E-mail: lisong@cugb.edu.cn

中图分类号: TE243
计量
- 文章访问数: 188
- HTML全文浏览量: 72
- PDF下载量: 39
- 被引次数: 0
出版历程
- 收稿日期: 2024-09-29
- 修回日期: 2024-12-03
- 刊出日期: 2025-01-28

Hydraulic fracture propagation characteristics of directional perforation fracturing in horizontal wells for deep coalbed methane

HUANG Shuxin^1
,,
LI Song^{2
, ,},
CHEN Bo²

1.
Oil and Gas Engineering Service Center, East China Oil and Gas Company, SINOPEC, Nanjing, Jiangsu 210004, China
2.
School of Energy Resource, China University of Geosciences (Beijing), Beijing 100083, China

摘要

摘要: 深部煤层气资源禀赋特征好，勘探开发潜力大，是国家天然气“增储上产”发展战略的重要现实基础。水平井定向射孔压裂作为深部煤层气重要的增渗改造技术应用广泛，而地质—工程因素作用下的水力裂缝起裂—扩展机制认识尚不明确。为了探究深部煤岩定向射孔压裂特征，采用三维离散格子模拟算法，建立了深部煤层水平井定向射孔压裂数值模型，研究地质参数和射孔参数对压裂改造难度、裂缝形态和压裂改造面积的影响。结果表明：随着弹性模量的增大，煤岩破裂压力增加，改造面积和改造面积差异系数逐渐增大，且有利于长—窄缝的形成；水平应力差的增大导致不同水力裂缝间的交互作用减弱，改造面积减小，改造面积差异系数和裂缝开度增大。此外，射孔深度和射孔直径的增加将显著降低深部煤岩的破裂压力，射孔深度的增大将大幅提升改造面积，而射孔直径的增加造成改造面积减小，且改造面积差异系数也逐渐增大；射孔密度对破裂压力的影响不显著，而与改造面积成正相关关系。针对煤体结构完整的煤岩进行压裂改造，适当提升射孔深度和射孔密度，降低射孔直径，可以取得较好的效果。
- 三维离散格子模拟算法 /
- 地质参数 /
- 射孔参数 /
- 定向射孔压裂 /
- 水力裂缝 /
- 深部煤层气
Abstract: Deep coalbed methane resources exhibit favorable geological characteristics and significant exploration and development potential, offering a substantial foundation for China's strategy to enhance natural gas storage and production. Directional perforation fracturing of horizontal wells is widely used as an important permeability enhancement technology for deep coalbed methane exploration. However, the mechanisms of hydraulic fracture initiation and propagation under the influence of geological and engineering factors remain unclear. To explore directional perforation fracturing characteristics in deep coal seams, a three-dimensional discrete lattice simulation algorithm was used to establish a numerical model. The paper studied the effects of geological and perforation parameters on fracturing difficulty, fracture morphology, and stimulated reservoir area (SRA). The results showed that, with the increase in elastic modulus, coal seam fracture pressure rose, and SRA and its variation coefficient increased gradually, which is conducive to long and narrow fracture formation. An increase in horizontal stress differences weakened the interaction between hydraulic fractures, reducing SRA while increasing its variation coefficient and fracture aperture. In addition, increasing perforation depth and diameter significantly reduced the fracture pressure in deep coal seams. Higher perforation depths greatly increased SRA, whereas larger perforation diameters decreased SRA, and its variation coefficient increased gradually. Perforation density had no significant impact on fracture pressure, but was positively correlated with SRA. The study suggests that for fracturing of structurally intact coal seams, increasing perforation depth and density while reducing perforation diameter can achieve better results.
- three-dimensional discrete lattice simulation algorithm /
- geological parameters /
- perforation parameters /
- directional perforation fracturing /
- hydraulic fractures /
- deep coalbed methane
注释:

利益冲突声明/Conflict of Interests

所有作者声明不存在利益冲突。

All authors declare no relevant conflict of interests.

作者贡献/Authors’Contributions

黄树新、李松、陈博参与实验设计、完成实验操作，并参与论文写作和修改。所有作者均阅读并同意最终稿件的提交。

HUANG Shuxin, LI Song, and CHEN Bo designed the experiment, completed the experimental operation, and drafted and revised the manuscript. All authors have read the final version of the paper and consented to its submission.

HTML全文

图 1 三维离散格子算法示意

Figure 1. Schematic diagram of three-dimensional discrete lattice algorithm

下载: 全尺寸图片幻灯片

图 2 定向射孔压裂模型示意

S_V.垂向应力；S_H.水平最大主应力；S_h.水平最小主应力。

Figure 2. Schematic diagram of directional perforation fracturing model

下载: 全尺寸图片幻灯片

图 3 不同弹性模量下裂缝形态

Figure 3. Fracture morphologies under different elastic moduli

下载: 全尺寸图片幻灯片

图 4 不同弹性模量下水力压裂效果

Figure 4. Hydraulic fracturing effects under different elastic moduli

下载: 全尺寸图片幻灯片

图 5 不同水平应力差下裂缝的形态

Figure 5. Fracture morphologies under different horizontal stress differences

下载: 全尺寸图片幻灯片

图 6 不同水平应力差下射孔压裂改造效果

Figure 6. Modification effects of perforation fracturing under different horizontal stress differences

下载: 全尺寸图片幻灯片

图 7 不同射孔深度下裂缝的形态

Figure 7. Fracture morphologies under different perforation depths

下载: 全尺寸图片幻灯片

图 8 不同射孔深度下压裂效果

Figure 8. Hydraulic fracturing effects under different perforation depths

下载: 全尺寸图片幻灯片

图 9 不同射孔直径下水力裂缝形态

Figure 9. Hydraulic fracture morphologies under different perforation diameters

下载: 全尺寸图片幻灯片

图 10 不同射孔直径下的压裂效果

Figure 10. Hydraulic fracturing effects under different perforation diameters

下载: 全尺寸图片幻灯片

图 11 不同射孔密度下水力裂缝形态

Figure 11. Hydraulic fracture morphologies under different perforation densities

下载: 全尺寸图片幻灯片

图 12 不同射孔密度下的压裂效果

Figure 12. Hydraulic fracturing effects under different perforation densities

下载: 全尺寸图片幻灯片

表 1 定向射孔模型基本参数

Table 1. Basic parameters of directional perforation model

类型	参数	数值
储层	弹性模量/GPa	4
	单轴抗压强度/MPa	15
	渗透率/10^-3μm²	0.1
	水平最小主应力/MPa	27
	垂向应力/MPa	43
	压裂液密度/(kg/m³)	1 010
	泊松比	0.26
	抗拉强度/MPa	1.5
	孔隙度/%	6
	水平最大主应力/MPa	35
	注入排量/(m³/min)	20
	黏度/(mPa·s)	2
射孔参数	射孔长度/m	0.4
	射孔直径/m	0.012
	射孔密度(孔/m)	12
	相位角/(°)	180

下载: 导出CSV

参考文献(46)

[1]	JIA Li, PENG Shoujian, XU Jiang, et al. Investigation on gas drainage effect under different borehole layout via 3D monitoring of gas pressure[J]. Journal of Natural Gas Science and Engineering, 2022, 101: 104522. doi: 10.1016/j.jngse.2022.104522
[2]	ZHANG Zetian, XIE Heping, ZHANG Ru, et al. Size and spatial fractal distributions of coal fracture networks under different mining-induced stress conditions[J]. International Journal of Rock Mechanics and Mining Sciences, 2020, 132: 104364. doi: 10.1016/j.ijrmms.2020.104364
[3]	LI Song, TANG Dazhen, PAN Zhejun, et al. Geological conditions of deep coalbed methane in the eastern margin of the Ordos Basin, China: implications for coalbed methane development[J]. Journal of Natural Gas Science and Engineering, 2018, 53: 394-402. doi: 10.1016/j.jngse.2018.03.016
[4]	康永尚, 皇甫玉慧, 张兵, 等. 含煤盆地深层"超饱和"煤层气形成条件[J]. 石油学报, 2019, 40(12): 1426-1438. doi: 10.7623/syxb201912002 KANG Yongshang, HUANGFU Yuhui, ZHANG Bing, et al. Formation conditions for deep oversaturated coalbed methane in coal-bearing basins[J]. Acta Petrolei Sinica, 2019, 40(12): 1426-1438. doi: 10.7623/syxb201912002
[5]	LI Song, QIN Yong, TANG Dazhen, et al. A comprehensive review of deep coalbed methane and recent developments in China[J]. International Journal of Coal Geology, 2023, 279: 104369. doi: 10.1016/j.coal.2023.104369
[6]	桑树勋, 韩思杰, 周效志, 等. 华东地区深部煤层气资源与勘探开发前景初探[J]. 油气藏评价与开发, 2023, 13(4): 403-415. SANG Shuxun, HAN Sijie, ZHOU Xiaozhi, et al. Deep coalbed methane resource and its exploration and development prospect in East China[J]. Petroleum Reservoir Evaluation and Development, 2023, 13(4): 403-415.
[7]	聂志宏, 时小松, 孙伟, 等. 大宁—吉县区块深层煤层气生产特征与开发技术对策[J]. 煤田地质与勘探, 2022, 50(3): 193-200. NIE Zhihong, SHI Xiaosong, SUN Wei, et al. Production characteristics of deep coalbed methane gas reservoirs in Daning-Jixian block and its development technology countermeasures[J]. Coal Geology & Exploration, 2022, 50(3): 193-200.
[8]	张鹏豹, 肖宇航, 朱庆忠, 等. 深层倾斜风化煤层特征及其对煤层气开发的影响: 以河北大城区块南部为例[J]. 天然气工业, 2021, 41(11): 86-96. doi: 10.3787/j.issn.1000-0976.2021.11.009 ZHANG Pengbao, XIAO Yuhang, ZHU Qingzhong, et al. Characteristics of deep inclined weathered coalbed reservoir and its influence on coalbed methane development: a case study of the southern Dacheng block of Hebei Province[J]. Natural Gas Industry, 2021, 41(11): 86-96. doi: 10.3787/j.issn.1000-0976.2021.11.009
[9]	桑树勋, 郑司建, 王建国, 等. 岩石力学地层新方法在深部煤层气勘探开发"甜点"预测中的应用[J]. 石油学报, 2023, 44(11): 1840-1853. doi: 10.7623/syxb202311007 SANG Shuxun, ZHENG Sijian, WANG Jianguo, et al. Application of new rock mechanical stratigraphy in sweet spot prediction for deep coalbed methane exploration and development[J]. Acta Petrolei Sinica, 2023, 44(11): 1840-1853. doi: 10.7623/syxb202311007
[10]	杨兆彪, 李存磊, 郭巧珍, 等. 新疆准噶尔盆地白家海凸起深部煤层气不同赋存态分配规律[J/OL]. 中国矿业大学学报, 1-11(2024-09-29). https://www.cnki.com.cn/Article/CJFDTotal-ZGKD20240927001.htm. YANG Zhaobiao, LI Cunlei, GUO Qiaozhen, et al. Distribution patterns of various occurrence states of deep coalbed methane in the Baijiahai Uplift, Junggar Basin, Xinjiang[J/OL]. Journal of China University of Mining & Technology, 1-11(2024-09-29). https://www.cnki.com.cn/Article/CJFDTotal-ZGKD20240927001.htm.
[11]	明盈, 孙豪飞, 汤达祯, 等. 四川盆地上二叠统龙潭组深—超深部煤层气资源开发潜力[J]. 煤田地质与勘探, 2024, 52(2): 102-112. MING Ying, SUN Haofei, TANG Dazhen, et al. Potential for the production of deep to ultradeep coalbed methane resources in the Upper Permian Longtan Formation, Sichuan Basin[J]. Coal Geology and Exploration, 2024, 52(2): 102-112.
[12]	冯义, 任凯, 刘俊田, 等. 深层煤层气水平井安全钻井技术[J]. 钻采工艺, 2024, 47(3): 33-41. doi: 10.3969/J.ISSN.1006-768X.2024.03.05 FENG Yi, REN Kai, LIU Juntian, et al. Safe drilling technology for deep CBM horizontal wells[J]. Drilling and Production Technology, 2024, 47(3): 33-41. doi: 10.3969/J.ISSN.1006-768X.2024.03.05
[13]	梁龙军, 陈捷, 颜智华, 等. 六盘水煤田大倾角地层煤层气L型水平井钻完井技术[J]. 断块油气田, 2023, 30(4): 616-623. LIANG Longjun, CHEN Jie, YAN Zhihua, et al. Drilling and completion technology of L-shaped horizontal wells for coalbed methane in high-dip formation in Liupanshui coalfield[J]. Fault- Block Oil & Gas Field, 2023, 30(4): 616-623.
[14]	姚红生, 陈贞龙, 何希鹏, 等. 深部煤层气"有效支撑"理念及创新实践: 以鄂尔多斯盆地延川南煤层气田为例[J]. 天然气工业, 2022, 42(6): 97-106. doi: 10.3787/j.issn.1000-0976.2022.06.009 YAO Hongsheng, CHEN Zhenlong, HE Xipeng, et al. "Effective support"concept and innovative practice of deep CBM in South Yanchuan Gas Field of the Ordos Basin[J]. Natural Gas Industry, 2022, 42(6): 97-106. doi: 10.3787/j.issn.1000-0976.2022.06.009
[15]	PU Yifan, LI Song, TANG Dazhen, et al. Numerical simulation study on the effectiveness of temporary plugging and fracturing in deep coal seam to construct complex fracture network[J]. Geoenergy Science and Engineering, 2023, 227: 211939. doi: 10.1016/j.geoen.2023.211939
[16]	陈贞龙. 延川南深部煤层气田地质单元划分及开发对策[J]. 煤田地质与勘探, 2021, 49(2): 13-20. doi: 10.3969/j.issn.1001-1986.2021.02.002 CHEN Zhenlong. Geological unit division and development countermeasures of deep coalbed methane in southern Yanchuan block[J]. Coal Geology & Exploration, 2021, 49(2): 13-20. doi: 10.3969/j.issn.1001-1986.2021.02.002
[17]	陈贞龙, 郭涛, 李鑫, 等. 延川南煤层气田深部煤层气成藏规律与开发技术[J]. 煤炭科学技术, 2019, 47(9): 112-118. CHEN Zhenlong, GUO Tao, LI Xin, et al. Enrichment law and development technology of deep coalbed methane in South Yanchuan Coalbed Methane Field[J]. Coal Science and Technology, 2019, 47(9): 112-118.
[18]	薛洋. WC-X1井空心斜向器与定向射孔技术研究及应用[J]. 复杂油气藏, 2023, 16(1): 114-117. XUE Yang. Research and application of hollow whipstock and directional perforation technology in well WC-X1[J]. Complex Hydrocarbon Reservoirs, 2023, 16(1): 114-117.
[19]	李可心, 张聪, 李俊, 等. 沁水盆地南部煤层气水平井射孔优化[J]. 新疆石油地质, 2024, 45(5): 581-589. LI Kexin, ZHANG Cong, LI Jun, et al. Optimization of perforation in CBM horizontal wells in southern Qinshui Basin[J]. Xinjiang Petroleum Geology, 2024, 45(5): 581-589.
[20]	刘合, 王峰, 王毓才, 等. 现代油气井射孔技术发展现状与展望[J]. 石油勘探与开发, 2014, 41(6): 731-737. LIU He, WANG Feng, WANG Yucai, et al. Oil well perforation technology: status and prospects[J]. Petroleum Exploration and Development, 2014, 41(6): 731-737.
[21]	赵成龙, 王俊石, 卢启敬. 现代油气井射孔技术发展现状与展望[J]. 石化技术, 2022, 29(8): 216-218. doi: 10.3969/j.issn.1006-0235.2022.08.075 ZHAO Chenglong, WANG Junshi, LU Qijing. Oil well perforation technology: status and prospects[J]. Petrochemical Industry Technology, 2022, 29(8): 216-218. doi: 10.3969/j.issn.1006-0235.2022.08.075
[22]	MILLER C K, WATERS G A, RYLANDER E I. Evaluation of production log data from horizontal wells drilled in organic shales[C]//North American Unconventional Gas Conference and Exhibition. The Woodlands, Texas, USA: OnePetro, 2011: SPE-144326-MS.
[23]	LI Yuwei, HUBUQIN, WU Jing, et al. Optimization method of oriented perforation parameters improving uneven fractures initiation for horizontal well fracturing[J]. Fuel, 2023, 349: 128754. doi: 10.1016/j.fuel.2023.128754
[24]	ZHANG Jun, LI Yuwei, PAN Yishan, et al. Experiments and analysis on the influence of multiple closed cemented natural fractures on hydraulic fracture propagation in a tight sandstone reservoir[J]. Engineering Geology, 2021, 281: 105981. doi: 10.1016/j.enggeo.2020.105981
[25]	张儒鑫, 侯冰, 单清林, 等. 致密砂岩储层水平井螺旋射孔参数优化研究[J]. 岩土工程学报, 2018, 40(11): 2143-2147. doi: 10.11779/CJGE201811022 ZHANG Ruxin, HOU Bing, SHAN Qinglin, et al. Parameter optimization of spiral perforations in horizontal well with tight sandstone reservoir[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(11): 2143-2147. doi: 10.11779/CJGE201811022
[26]	ZHANG Ruxin, HOU Bing, SHAN Qinglin, et al. Hydraulic fracturing initiation and near-wellbore nonplanar propagation from horizontal perforated boreholes in tight formation[J]. Journal of Natural Gas Science and Engineering, 2018, 55: 337-349. doi: 10.1016/j.jngse.2018.05.021
[27]	LI Minghui, ZHOU Fujian, DONG Enjia, et al. Experimental study on the multiple fracture simultaneous propagation during extremely limited-entry fracturing[J]. Journal of Petroleum Science and Engineering, 2022, 218: 110906. doi: 10.1016/j.petrol.2022.110906
[28]	GUO Peng, LI Xiao, LI Shouding, et al. Experimental investigation of simultaneous and asynchronous hydraulic fracture growth from multiple perforations in shale considering stress anisotropy[J]. Rock Mechanics and Rock Engineering, 2023, 56(11): 8209-8220. doi: 10.1007/s00603-023-03499-6
[29]	单清林, 金衍, 韩玲, 等. 水平井螺旋射孔参数对近井筒裂缝形态影响规律[J]. 石油科学通报, 2017, 2(1): 44-52. SHAN Qinglin, JIN Yan, HAN Ling, et al. Influence of spiral perforation parameters on fracture geometry near horizontal wellbores[J]. Petroleum Science Bulletin, 2017, 2(1): 44-52.
[30]	LI Jing, WANG Lixiang, FENG Chun, et al. Study on the influence of perforation parameters on hydraulic fracture initiation and propagation based on CDEM[J]. Computers and Geotechnics, 2024, 167: 106061. doi: 10.1016/j.compgeo.2023.106061
[31]	SHAN Qinglin, ZHANG Ruxin, JIANG Yujing. Complexity and tortuosity hydraulic fracture morphology due to near-wellbore nonplanar propagation from perforated horizontal wells[J]. Journal of Natural Gas Science and Engineering, 2021, 89: 103884. doi: 10.1016/j.jngse.2021.103884
[32]	LIAN Zhanghua, MENG Yingfeng, TONG Min. A new method of numerical simulation for perforation completion of fracture formation[C]//SPE Asia Pacific Oil and Gas Conference and Exhibition. Brisbane, Australia: SPE, 2000.
[33]	ZHANG Guangqing, CHEN Mian. Complex fracture shapes in hydraulic fracturing with orientated perforations[J]. Petroleum Exploration and Development, 2009, 36(1): 103-107. doi: 10.1016/S1876-3804(09)60113-0
[34]	ZHANG F, MACK M. Modeling of hydraulic fracture initiation from perforation tunnels using the 3D lattice method[C]//50th U.S. Rock Mechanics/Geomechanics Symposium. Houston, Texas: OnePetro, 2016: ARMA-2016-534.
[35]	HUANG Liuke, LIU Jianjun, ZHANG Fengshou, et al. 3D lattice modeling of hydraulic fracture initiation and near-wellbore propagation for different perforation models[J]. Journal of Petroleum Science and Engineering, 2020, 191: 107169. doi: 10.1016/j.petrol.2020.107169
[36]	WANG Xiaohua, TANG Meirong, DU Xianfei, et al. Three-dimensional experimental and numerical investigations on fracture initiation and propagation for oriented limited-entry perforation and helical perforation[J]. Rock Mechanics and Rock Engineering, 2023, 56(1): 437-462. doi: 10.1007/s00603-022-03069-2
[37]	付海峰, 黄刘科, 张丰收, 等. 射孔模式对水力压裂裂缝起裂与扩展的影响机制研究[J]. 岩石力学与工程学报, 2021, 40(S2): 3163-3173. FU Haifeng, HUANG Liuke, ZHANG Fengshou, et al. Effect of perforation technologies on the initiation and propagation of hydraulic fracture[J]. Chinese Journal of Rock Mechanics and Engineering, 2021, 40(S2): 3163-3173.
[38]	赵凯凯, 张镇, 李文洲, 等. 基于XSite的钻孔起裂水力裂缝三维扩展研究[J]. 岩土工程学报, 2021, 43(8): 1483-1491. ZHAO Kaikai, ZHANG Zhen, LI Wenzhou, et al. Three-dimensional simulation of hydraulic fracture from a borehole using XSite[J]. Chinese Journal of Geotechnical Engineering, 2021, 43(8): 1483-1491.
[39]	柳贡慧, 庞飞, 陈治喜. 水力压裂模拟实验中的相似准则[J]. 石油大学学报(自然科学版), 2000, 24(5): 45-48. LIU Gonghui, PANG Fei, CHEN Zhixi. Development of scaling laws for hydraulic fracture simulation tests[J]. Journal of the University of Petroleum, China, 2000, 24(5): 45-48.
[40]	郭天魁, 刘晓强, 顾启林. 射孔井水力压裂模拟实验相似准则推导[J]. 中国海上油气, 2015, 27(3): 108-112. GUO Tiankui, LIU Xiaoqiang, GU Qilin. Deduction of similarity laws of hydraulic fracturing simulation experiments for perforated wells[J]. China Offshore Oil and Gas, 2015, 27(3): 108-112.
[41]	侯冰, 陈勉, 李志猛, 等. 页岩储集层水力裂缝网络扩展规模评价方法[J]. 石油勘探与开发, 2014, 41(6): 763-768. HOU Bing, CHEN Mian, LI Zhimeng, et al. Propagation area evaluation of hydraulic fracture networks in shale gas reservoirs[J]. Petroleum Exploration and Development, 2014, 41(6): 763-768.
[42]	LECAMPION B, BUNGER A, ZHANG Xi. Numerical methods for hydraulic fracture propagation: a review of recent trends[J]. Journal of Natural Gas Science and Engineering, 2018, 49: 66-83. doi: 10.1016/j.jngse.2017.10.012
[43]	CONG Ziyuan, LI Yuwei, TANG Jizhou, et al. Numerical simulation of hydraulic fracture height layer-through propagation based on three-dimensional lattice method[J]. Engineering Fracture Mechanics, 2022, 264: 108331. doi: 10.1016/j.engfracmech.2022.108331
[44]	GU Hongren, SIEBRITS E. Effect of formation modulus contrast on hydraulic fracture height containment[J]. SPE Production & Operations, 2008, 23(2): 170-176. http://www.onacademic.com/detail/journal_1000039080441010_9e52.html
[45]	BRUMLEY J L, ABASS H H. Hydraulic fracturing of deviated wells: interpretation of breakdown and initial fracture opening pressure[C]//SPE Eastern Regional Meeting. Columbus, Ohio: SPE, 1996: SPE-37363-MS.
[46]	余前港. 螺旋射孔裂缝扩展规律及不同储层压裂优化研究[D]. 大庆: 东北石油大学, 2023. YU Qiangang. Study on fracture propagation law of spiral perforation and optimization of fracturing for different reservoirs[D]. Daqing: Northeast Petroleum University, 2023.
