川东北地区侏罗系凉高山组页岩储层孔隙结构及分形特征

李琦 陈睿倩 商斐 李玲 白昕

李琦, 陈睿倩, 商斐, 李玲, 白昕. 川东北地区侏罗系凉高山组页岩储层孔隙结构及分形特征[J]. 石油实验地质, 2025, 47(2): 323-335. doi: 10.11781/sysydz2025020323
引用本文: 李琦, 陈睿倩, 商斐, 李玲, 白昕. 川东北地区侏罗系凉高山组页岩储层孔隙结构及分形特征[J]. 石油实验地质, 2025, 47(2): 323-335. doi: 10.11781/sysydz2025020323
LI Qi, CHEN Ruiqian, SHANG Fei, LI Ling, BAI Xin. Pore structure and fractal characteristics of shale reservoirs in Jurassic Lianggaoshan Formation, northeastern Sichuan Basin[J]. PETROLEUM GEOLOGY & EXPERIMENT, 2025, 47(2): 323-335. doi: 10.11781/sysydz2025020323
Citation: LI Qi, CHEN Ruiqian, SHANG Fei, LI Ling, BAI Xin. Pore structure and fractal characteristics of shale reservoirs in Jurassic Lianggaoshan Formation, northeastern Sichuan Basin[J]. PETROLEUM GEOLOGY & EXPERIMENT, 2025, 47(2): 323-335. doi: 10.11781/sysydz2025020323

川东北地区侏罗系凉高山组页岩储层孔隙结构及分形特征

doi: 10.11781/sysydz2025020323
基金项目:

中国石油西南油气田分公司科技计划项目“川东北地区侏罗系下统凉高山组页岩油气地质特征研究” JS2022-90

详细信息
    作者简介:

    李琦(2000—),女,硕士生,从事页岩储层评价相关研究。E-mail: 270331500@qq.com

    通讯作者:

    陈睿倩(1987—),女,博士,副教授,从事石油地质学和地球化学研究。E-mail: richen@cup.edu.cn

  • 中图分类号: TE122.2

Pore structure and fractal characteristics of shale reservoirs in Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

  • 摘要: 川东北地区侏罗系凉高山组作为四川盆地页岩油重点勘探层段,因勘探程度较低,目前页岩储层特征尚不明确。利用X射线衍射矿物分析、扫描电子显微镜分析、高压压汞、低温氮气吸附等实验,深入探究其储集空间类型与分形特征。研究区凉高山组页岩矿物组成主要为黏土矿物(平均含量51.57%),其次为长英质矿物(平均含量47.11%),碳酸盐矿物极少(平均含量2.69%)。储集空间类型主要包括黏土矿物层间孔、石英与长石粒间孔以及微裂缝,低温氮气吸附曲线形态接近国际理论与应用化学联合会页岩孔径划分方法中的Ⅳ类,指示狭缝型孔隙。按照压汞曲线形态及储层物性参数特征,将研究区页岩储层分为四类,从Ⅰ到Ⅳ类,排驱压力、中值压力增大,最大进汞饱和度减小,储层非均质性增强。“FHH”模型显示孔隙表面分形维数DN1大于孔隙结构分形维数DN2,表明孔隙表面的复杂程度高于内部;“含水饱和度法”计算结果显示大孔隙分形维数D1平均值为2.991 2,小孔隙分形维数D2平均值为2.679 2,大孔隙分形维数更接近于3且分布更集中,表明非均质性更强的大孔隙对储层的贡献更大。相关性分析显示,D1与矿物组分含量(石英、黏土矿物)、孔喉结构参数存在相关性,证明大孔隙是研究区页岩储集与空间的主要贡献者。通过定性与定量分析对川东北地区凉高山组页岩进行储层评价,为后续该地区有利勘探层段评价与优选提供了思路。



  • 图  1  四川盆地构造分区及研究区位置

    据参考文献[11]修改。

    Figure  1.  Tectonic divisions of Sichuan Basin and location of study area

    图  2  川东北侏罗系凉高山组地层柱状图

    据参考文献[11]修改。

    Figure  2.  Stratigraphic column of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  3  川东北侏罗系凉高山组矿物组成条形图

    Figure  3.  Bar chart of mineral composition in Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  4  川东北侏罗系凉高山组矿物组成三角图

    Figure  4.  Ternary diagram of mineral composition in Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  5  川东北侏罗系凉高山组页岩储集空间类型

    a.狭缝状黏土矿物层间孔,会浅1井,1 764.20 m;b.网状黏土矿物层间孔,五宝浅020-H1井,3 183.66 m;c.石英与长石粒间孔,可见缩颈型喉道,会浅1井,1 898.00 m;d.草莓状黄铁矿,会浅1井,1 765.28 m;e.长石内溶蚀孔,会浅1井,1 765.28 m;f.岩屑溶蚀孔,五宝浅020-H1井,3 177.36 m;g.块状有机质,可见有机质收缩缝,中兴1井,1 901.35 m;h.凹坑状有机质孔,会浅1井,1 902.01 m;i.条带状有机质,可见狭缝状有机质孔,五宝浅020-H1井,3 187.00 m;j.构造微裂缝,可见黄铁矿晶体,中兴1井,1 905.48 m;k.构造微裂缝,五宝浅020-H1井,3 180.24 m;l.有机质收缩缝,可见层状黏土矿物,中兴1井,1 897.65 m。

    Figure  5.  Types of reservoir space in shale from Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  6  川东北侏罗系凉高山组四类储层压汞曲线

    Figure  6.  High-pressure mercury intrusion curves of four types of reservoirs in Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  7  川东北侏罗系凉高山组页岩低温氮气吸附脱附曲线

    Figure  7.  Low-temperature nitrogen adsorption and desorption curves of Jurassic Lianggaoshan Formation shale, northeastern Sichuan Basin

    图  8  川东北侏罗系凉高山组四类储层氮气吸附分形结果

    Figure  8.  Fractal analysis results of nitrogen adsorption in four types of reservoirs of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  9  川东北侏罗系凉高山组四类储层高压压汞分形结果

    Figure  9.  Fractal results based on high-pressure mercury intrusion in four types of reservoirs of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  10  川东北侏罗系凉高山组矿物组分含量与分形维数关系

    Figure  10.  Correlation between mineral composition and fractal dimension of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  11  川东北侏罗系凉高山组储层物性与分形维数关系

    Figure  11.  Correlation between reservoir physical properties and fractal dimension of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  12  川东北侏罗系凉高山组孔喉结构参数与分形维数关系

    Figure  12.  Correlation between pore-throat structure parameters and fractal dimension of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    图  13  川东北侏罗系凉高山组TOC含量与分形维数关系

    Figure  13.  Correlation between TOC content and fractal dimension of Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    表  1  川东北侏罗系凉高山组页岩基本物性及孔喉结构参数

    Table  1.   Basic physical properties and pore-throat structure parameters of shale from Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    样品编号 分类 井深/m 孔隙度/% 渗透率/10-3 μm2 排驱压力/MPa 中值压力/MPa 最大进汞饱和度/% 分选系数
    WB-5 3 184.66 4.81 0.003 01 0.182 6 1.453 6 90.73 2.798 2
    HQ1-2 1 765.28 2.47 0.060 80 0.292 0 2.135 0 89.89 2.672 6
    HQ1-3 1 889.17 2.30 3.330 00 0.191 6 3.106 2 88.79 2.923 3
    WB-4 3 183.66 4.35 0.086 90 0.182 2 1.566 1 87.75 2.738 1
    WB-6 3 187.00 3.54 0.050 10 0.463 4 3.554 6 91.38 2.752 3
    WB-1 3 176.10 2.10 0.052 00 0.463 9 4.415 2 88.33 2.944 2
    HQ1-1 1 764.20 1.96 0.048 90 0.459 2 3.899 9 91.44 2.623 0
    WB-2 3 177.36 8.08 0.038 00 0.458 9 4.271 6 88.45 2.763 3
    WB-3 3 179.54 8.88 0.033 00 0.457 2 2.056 9 91.73 2.348 5
    HQ1-8 1 902.01 6.60 0.013 20 0.730 0 10.150 4 87.08 2.911 0
    HQ1-7 1 900.39 7.80 0.005 44 0.734 9 22.598 3 87.62 2.874 1
    ZX1-1 1 901.35 11.45 0.014 40 1.135 5 12.969 6 83.02 2.870 0
    HQ1-4 1 894.61 2.15 0.004 69 1.158 8 13.177 9 85.87 2.718 2
    HQ1-5 1 897.15 3.97 0.006 29 1.158 9 4.298 5 87.05 2.494 2
    HQ1-9 1 915.01 5.79 0.006 65 1.160 1 47.529 0 84.67 2.984 1
    HQ1-6 1 898.00 10.19 0.001 53 1.838 1 11.855 9 83.71 2.622 5
    下载: 导出CSV

    表  2  川东北侏罗系凉高山组页岩氮气吸附分形维数计算结果

    Table  2.   Fractal dimension calculation of nitrogen adsorption in shale from Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    样品编号 分类 DN1 R12 DN2 R22
    WB-5 2.640 7 0.997 1 2.599 9 0.999 7
    HQ1-2 2.649 3 0.997 9 2.601 9 0.999 0
    HQ1-3 2.652 7 0.986 7 2.584 0 0.996 0
    WB-4 2.485 8 0.991 3 2.578 1 0.992 0
    WB-6 2.607 6 0.994 6 2.599 9 0.952 4
    WB-1 2.665 6 0.994 4 2.650 3 0.996 6
    HQ1-1 2.667 9 0.994 7 2.658 3 0.988 0
    WB-2 2.610 1 0.994 8 2.789 5 0.961 5
    WB-3 2.694 1 0.993 2 2.599 8 0.999 3
    HQ1-7 2.712 6 0.994 6 2.589 3 0.998 5
    HQ1-8 2.684 5 0.990 7 2.603 9 0.999 4
    HQ1-6 2.703 2 0.990 8 2.613 6 0.999 3
    HQ1-5 2.693 0 0.992 2 2.614 4 0.999 0
    HQ1-4 2.665 4 0.998 5 2.620 6 0.999 5
    ZX1-1 2.682 4 0.992 4 2.552 9 0.993 8
    HQ1-9 2.662 1 0.996 4 2.592 8 0.999 4
    下载: 导出CSV

    表  3  川东北侏罗系凉高山组页岩高压压汞分形维数计算结果

    Table  3.   Fractal dimension calculation based on high-pressure mercury intrusion in shale from Jurassic Lianggaoshan Formation, northeastern Sichuan Basin

    样品编号 分类 D1 R12 D2 R22
    WB-5 2.995 6 0.327 9 2.694 3 0.972 6
    HQ1-2 2.971 0 0.292 5 2.660 8 0.971 8
    HQ1-3 2.976 8 0.454 9 2.677 0 0.966 5
    WB-4 2.983 7 0.380 8 2.719 1 0.992 0
    WB-6 2.996 7 0.407 4 2.685 8 0.981 8
    WB-1 2.984 2 0.265 5 2.700 3 0.918 3
    HQ1-1 2.996 9 0.392 4 2.619 8 0.972 9
    WB-2 2.987 9 0.270 7 2.675 3 0.971 4
    WB-3 2.993 2 0.298 2 2.617 3 0.992 2
    HQ1-7 2.989 9 0.642 9 2.722 1 0.976 3
    HQ1-8 2.999 8 0.230 4 2.746 1 0.965 2
    HQ1-6 2.996 3 0.188 7 2.631 2 0.983 7
    HQ1-5 2.998 7 0.284 2 2.665 9 0.985 9
    HQ1-4 2.999 8 0.231 9 2.664 9 0.955 1
    ZX1-1 2.988 0 0.279 9 2.687 5 0.926 5
    HQ1-9 2.998 3 0.351 2 2.699 1 0.826 3
    下载: 导出CSV
  • [1] 王世谦, 陈更生, 黄先平. 四川盆地油气资源潜力及重点勘探领域[J]. 石油学报, 2005, 26(S1): 97-101.

    WANG Shiqian, CHEN Gengsheng, HUANG Xianping. Petroleum resource potential and major exploration areas in Sichuan Basin[J]. Acta Petrolei Sinica, 2005, 26(S1): 97-101.
    [2] 王世谦, 胡素云, 董大忠. 川东侏罗系: 四川盆地亟待重视的一个致密油气新领域[J]. 天然气工业, 2012, 32(12): 22-29.

    WANG Shiqian, HU Suyun, DONG Dazhong. Jurassic tight oil & gas resources in East Sichuan Basin: a new exploration target[J]. Natural Gas Industry, 2012, 32(12): 22-29.
    [3] 何文渊, 何海清, 王玉华, 等. 川东北地区平安1井侏罗系凉高山组页岩油重大突破及意义[J]. 中国石油勘探, 2022, 27(1): 40-49.

    HE Wenyuan, HE Haiqing, WANG Yuhua, et al. Major breakthrough and significance of shale oil of the Jurassic Lianggaoshan Formation in well Ping'an 1 in northeastern Sichuan Basin[J]. China Petroleum Exploration, 2022, 27(1): 40-49.
    [4] 胡东风, 李真祥, 魏志红, 等. 四川盆地北部地区巴中1HF井侏罗系河道砂岩油气勘探突破及意义[J]. 天然气工业, 2023, 43(3): 1-11.

    HU Dongfeng, LI Zhenxiang, WEI Zhihong, et al. Breakthrough in oil and gas exploration of Jurassic channel sandstone in well Bazhong 1HF in northern Sichuan Basin and its significance[J]. Natural Gas Industry, 2023, 43(3): 1-11.
    [5] 邹娟, 乐园, 金涛, 等. 川中地区侏罗系致密砂岩储集层成因及"甜点"预测[J]. 新疆石油地质, 2018, 39(5): 555-560.

    ZOU Juan, LE Yuan, JIN Tao, et al. Genesis and sweet spot prediction of Jurassic tight sandstone reservoir in central Sichuan Basin[J]. Xinjiang Petroleum Geology, 2018, 39(5): 555-560.
    [6] MANDELBROT B B. Fractals: form, chance and dimension[M]. New York: Freeman W H and Co., 1977.
    [7] 李小明, 王亚蓉, 吝文, 等. 湖北荆门探区五峰组—龙马溪组深层页岩微观孔隙结构与分形特征[J]. 天然气地球科学, 2022, 33(4): 629-641.

    LI Xiaoming, WANG Yarong, LIN Wen, et al. Micro-pore structure and fractal characteristics of deep shale from Wufeng Formation to Longmaxi Formation in Jingmen exploration area, Hubei Province[J]. Natural Gas Geoscience, 2022, 33(4): 629-641.
    [8] 王斌, 过敏, 施泽进, 等. 川东南地区志留系石牛栏组海相页岩储层孔隙结构特征及油气地质意义[J/OL]. 成都理工大学学报(自然科学版), (2024-08-21)[2024-10-27]. http://kns.cnki.net/kcms/detail/51.1634.N.20240821.1330.002.html.

    WANG Bin, GUO Min, SHI Zejin, et al. Characteristics of shale pore structure and its oil and gas geological significance of the Shiniulan Formation, southeast Sichuan Basin[J/OL]. Journal of Chengdu University of Technology (Science & Technology Edition), (2024-08-21)[2024-10-27]. http://kns.cnki.net/kcms/detail/51.1634.N.20240821.1330.002.html.
    [9] 杨鑫翊, 王民, 白雪峰, 等. 川东北地区侏罗系凉高山组页岩储集空间特征及页岩油可动性探索[J]. 石油科学通报, 2024, 9(2): 196-212.

    YANG Xinyi, WANG Min, BAI Xuefeng, et al. Reservoir space characteristics and exploration of shale oil mobility of the Jurassic Lianggaoshan Formation shale in the northeastern Sichuan Basin[J]. Petroleum Science Bulletin, 2024, 9(2): 196-212.
    [10] 王道军, 陈超, 刘珠江, 等. 四川盆地复兴地区侏罗系纹层型页岩油气富集主控因素[J]. 石油实验地质, 2024, 46(2): 319-332. doi: 10.11781/sysydz202402319

    WANG Daojun, CHEN Chao, LlU Zhujiang, et al. Main controlling factors for oil and gas enrichment in Jurassic laminated shale in Fuxing area of Sichuan Basin[J]. Petroleum Geology & Experiment, 2024, 46(2): 319-332. doi: 10.11781/sysydz202402319
    [11] 李楠, 洪海涛, 李国辉, 等. 四川盆地高陡构造区凉高山组页岩油气地质特征[J]. 天然气勘探与开发, 2022, 45(4): 86-95.

    LI Nan, HONG Haitao, LI Guohui, et al. Geological characteristics of shale oil and gas of Lianggaoshan Formation in high-steep structural zone, Sichuan Basin[J]. Natural Gas Exploration and Development, 2022, 45(4): 86-95.
    [12] 郭彤楼. 多旋回盆地叠合—复合控藏在常规非常规天然气勘探中的实践[J]. 地学前缘, 2022, 29(6): 109-119.

    GU0 Tonglou. Superimposition and composition control on hydrocarbon reservoirs in multi-cycle basins: concept and practice in conventional and unconventional natural gas explorations[J]. Earth Science Frontiers, 2022, 29(6): 109-119.
    [13] 成大伟, 张志杰, 洪海涛, 等. 四川盆地东部侏罗系凉高山组沉积、物源及盆山关系[J]. 石油勘探与开发, 2023, 50(2): 1-11.

    CHENG Dawei, ZHANG Zhijie, HONG Haitao, et al. Sedimentary and provenance characteristics and the basin-mountain relationship of the Jurassic Lianggaoshan Formation in eastern Sichuan Basin, SW China[J]. Petroleum Exploration and Development, 2023, 50(2): 1-11.
    [14] 王羽, 金婵, 汪丽华, 等. 应用氩离子抛光—扫描电镜方法研究四川九老洞组页岩微观孔隙特征[J]. 岩矿测试, 2015, 34(3): 278-285.

    WANG Yu, JIN Chan, WANG Lihua, et al. Characterization of pore structures of Jiulaodong Formation shale in the Sichuan Basin by SEM with Ar-ion milling[J]. Rock And Mineral Analysis, 2015, 34(3): 278-285.
    [15] 赵毅楠. 川南地区龙马溪组海相富有机质页岩储层岩石学特征及评价[D]. 成都: 成都理工大学, 2017.

    ZHAO Yinan. Petrological characteristics and evaluation of marine organic shale reservoirs in Longmaxi Formation, southern Sichuan[D]. Chengdu: Chengdu University of Technology, 2017.
    [16] SCHIEBER J. Common themes in the formation and preservation of intrinsic porosity in shales and mudstones: illustrated with examples across the Phanerozoic[C]//SPE Unconventional Gas Conference. Pittsburgh: SPE, 2010.
    [17] THOMMES M, KANEKO K, NEIMARK A V, et al. Physisorption of gases, with special reference to the evaluation of surface area and pore size distribution(IUPAC Technical Report)[J]. Pure and Applied Chemistry, 2015, 87(9/10): 1051-1069.
    [18] PFEIFER P, AVNIR D. Chemistry in noninteger dimensions between two and three.I.Fractal theory of heterogeneous surfaces[J]. The Journal of Chemical Physics, 1983, 79(7): 3358-3565.
    [19] 贺承祖, 华明琪. 储层孔隙结构的分形几何描述[J]. 石油与天然气地质, 1998, 19(1): 17-25.

    HE Chengzu, HUA Mingqi. Fractal geometry description of reservoir pore structure[J]. Oil & Gas Geology, 1998, 19(1): 17-25.
    [20] 彭军, 韩浩东, 夏青松, 等. 深埋藏致密砂岩储层微观孔隙结构的分形表征及成因机理: 以塔里木盆地顺托果勒地区柯坪塔格组为例[J]. 石油学报, 2018, 39(7): 775-791.

    PENG Jun, HAN Haodong, XIA Qingsong, et al. Fractal characterization and genetic mechanism of micro-pore structure in deeply buried tight sandstone reservoirs: a case study of Kalpintag Formation in Shuntuoguole area, Tarim Basin[J]. Acta Petrolei Sinica, 2018, 39(7): 775-791.
    [21] 赵会涛, 郭英海, 杜小伟, 等. 鄂尔多斯盆地高桥地区本溪组砂岩储层微观孔隙多重分形特征[J]. 地质科技通报, 2020, 39(6): 175-184.

    ZHAO Huitao, GUO Yinghai, DU Xiaowei, et al. Micro-pore multifractal characteristics of Benxi Formation sandstone reservoir in Gaoqiao area, Ordos Basin[J]. Bulletin of Geological Science and Technology, 2020, 39(6): 175-184.
    [22] DANIEL J K, ROSS R, BUSTIN M. Shale gas potential of the Lower Jurassic Gordondale Member, northeastern British Columbia, Canada[J]. Bulletin of Canadian Petroleum Geology, 2007, 55(1): 51-75.
    [23] 赖锦, 王贵文, 郑懿琼, 等. 低渗透碎屑岩储层孔隙结构分形维数计算方法: 以川中地区须家河组储层41块岩样为例[J]. 东北石油大学学报, 2013, 37(1): 1-7.

    LAI Jin, WANG Guiwen, ZHENG Yiqiong, et al. Method For calculating the fractal dimension of the pore structure of low permeability reservoirs: a case study on the Xujiahe Formation reservoir in central Sichuan Basin[J]. Journal of Northeast Petroleum University, 2013, 37(1): 1-7.
    [24] 张婷, 徐守余, 杨珂. 储层微观孔隙结构分形维数应用[J]. 大庆石油学院学报, 2010, 34(3): 44-47.

    ZHANG Ting, XU Shouyu, YANG Ke. Application of fractal dimension of micro-pore structure[J]. Journal of Daqing Petroleum Institute, 2010, 34(3): 44-47.
