Research on nitrogen injection for enhancing oil recovery in deep carbonate reservoirs
-
摘要:
塔里木盆地富满油田深层碳酸盐岩油藏开展了注氮气提高采收率现场试验。在注氮气驱过程中，是否混相会影响驱油效率，同时掌握地层在非平衡状态下注氮气过程中流体相态变化也具有重要意义。为明确该类油藏在注氮气辅助重力驱开采过程中的流体相态变化及混相压力，以满深X油藏为例，开展了注氮气相态实验，获取了注氮气后非平衡与平衡状态下的相态特征，建立地层流体类型随注气量变化判别图以及地层流体饱和压力随注气量变化图，确定了注氮气混相压力。结果表明：非平衡条件下，注入少量氮气时，与地层流体混为一相；随着注气量增加，会呈现顶部“氮气”相、中部气相、底部油相“三相”共存的状态；注氮气量达到0.8 PV，“氮气”相逐渐消失。平衡条件下，在注入氮气后，流体在饱和压力时出现“乳光现象”，饱和压力随注气量增加升高；注入体积达到0.2 PV后，在注气压力55 MPa条件下流体呈现两相；注入体积达到0.8 PV后，在地层压力81 MPa条件下流体仍为两相。根据地层流体类型随注气量变化判别图与地层流体饱和压力随注气量变化图，确定满深X油藏注氮气最小混相压力为 48 MPa。在注气压力55 MPa条件下，注氮气辅助重力驱能够实现混相；非平衡状态下，从上到下产生明显重力分异特征，导致满深X油藏注气后从顶部到底部氮气含量逐渐降低，烃类组分含量逐渐升高。
Abstract:A field test of nitrogen injection for enhanced oil recovery was conducted in the deep carbonate oil reservoir of Fuman Oilfield, Tarim Basin. In the nitrogen injection process, whether phase miscibility occurs can affect oil recovery efficiency, and understanding the variations in fluid phase states during nitrogen injection under non-equilibrium conditions in the formation is of significant importance. To clarify the changes in fluid phase state and the miscibility pressure during nitrogen injection-assisted gravity flooding in deep carbonate reservoirs, Manshen X reservoir was taken as an example. By conducting nitrogen injection phase experiments, the phase characteristics under non-equilibrium and equilibrium conditions after nitrogen injection were obtained. The discrimination diagram of variation of formation fluid type with injection volume and the diagram of variation of formation fluid saturation pressure with injection volume were established, thereby determining the miscibility pressure during nitrogen injection. The results showed that under non-equilibrium conditions, when a small amount of nitrogen was injected, it mixed with formation fluids to form a single phase. As the injection volume increased, a three-phase coexistence state appeared with a nitrogen phase at the top, a gas phase in the middle, and an oil phase at the bottom. When the nitrogen injection volume reached 0.8 PV, the nitrogen phase gradually disappeared. Under equilibrium conditions, after nitrogen injection, the fluids showed an "opalescence phenomenon" at the saturation pressure, and the saturation pressure increased with increasing injection volume. After the injection volume reached 0.2 PV, the fluids exhibited two phases under an injection pressure of 55 MPa. After the injection volume reached 0.8 PV, the fluids presented two phases under a formation pressure of 81 MPa. Based on the discrimination diagram of variation of formation fluid type with injection volume and the diagram of variation of formation fluid saturation pressure with injection volume, the minimum miscibility pressure for nitrogen injection in the Manshen X reservoir was determined to be 48 MPa. Under an injection pressure of 55 MPa, nitrogen injection-assisted gravity flooding could achieve miscibility. Under non-equilibrium conditions, a significant gravity segregation characteristic developed from top to bottom, resulting in a gradual decrease in nitrogen content and a gradual increase in hydrocarbon component content from the top to the bottom of the Manshen X reservoir after gas injection.
-
[1] 李中超,齐桂雪,罗波波,等.深层低渗凝析气藏气驱适应性研究[J].油气藏评价与开发,2024,14(3):324-332.LI Zhongchao,QI Guixue,LUO Bobo,et al.Gas flooding adaptability of deep low permeability condensate gas reservoir[J].Petroleum Reservoir Evaluation and Development,2024,14(3):324-332. [2] 张传宝,李宗阳,张东,等.CO2驱油藏工程研究进展及展望[J].油气地质与采收率,2024,31(5):142-152.ZHANG Chuanbao,LI Zongyang,ZHANG Dong,et al.Research progress and prospects of reservoir engineering by CO2 flooding[J].Petroleum Geology and Recovery Efficiency,2024,31(5):142-152. [3] 关富佳,苏向光,何万军.天然气水合物CO2+N2驱替置换动力学研究[J].特种油气藏,2024,31(3):150-157.GUAN Fujia,SU Xiangguang,HE Wanjun.Study on dynamics of gas hydrate CO2+N2 displacement[J].Special Oil & Gas Reservoirs,2024,31(3):150-157. [4] 王牧原,李勇,吴克柳,等.孔隙型碳酸盐岩油藏储层微观孔隙结构定量表征及驱油效果评价[J].油气地质与采收率,2024,31(2):96-107.WANG Muyuan,LI Yong,WU Keliu,et al.Quantitative characterization of microscopic pore structure and oil recovery evaluation in porous carbonate reservoirs[J].Petroleum Geology and Recovery Efficiency,2024,31(2):96-107. [5] 胡书勇,郑冰洋,阴艳芳.基于模糊评判决策的天然气驱油藏开发效果评价[J].西南石油大学学报(自然科学版),2024,46(01):105-114. HU Shuyong,ZHENG Bingyang,YIN Yanfang.Evaluation method of development effect of natural gas drive reservoir based on fuzzy evaluation strategy[J].Journal of Southwest Petroleum University (Science & Technology Edition),2024,46(1):105-114. [6] 肖志朋,刘诗琪,李艳明,等.丘陵油田水驱后注气混相驱可行性实验[J].油气地质与采收率,2023,30(2):68-76.XIAO Zhipeng,LIU Shiqi,LI Yanming,et al.Experimental study on feasibility of gas-injection miscible flooding after water flooding of Qiuling Oilfield[J].Petroleum Geology and Recovery Efficiency,2023,30(2):68-76. [7] 李福堂,王博,辛春彦,等.注氮气对挥发性油藏流体相态特征影响实验研究[J].石油化工应用,2022,41(2):39-43.LI Futang,WANG Bo,XIN Chunyan,et al.Experimental study on the influence of nitrogen injection on the phase behavior of volatile oil reservoir[J].Petrochemical Industry Application,2022,41(2):39-43. [8] ZHANG R.Experimental investigation of non-equilibrium phase behavior in nitrogen-assisted gravity drainage for volatile oil reservoirs[J].Fuel,2021,285:119214. [9] WANG Y.Microscopic mechanisms of interfacial instability during nitrogen flooding in volatile oil reservoirs[J].Journal of Petroleum Science and Engineering,2022,208:109678. [10] LI H.Non-equilibrium phase separation dynamics of nitrogen-crude oil systems under low-temperature reservoir conditions[J].Energy & Fuels,2023,37(2):987-1001. [11] YANG L.Dynamic miscibility characterization in nitrogen gravity drainage:experimental and modeling study[J].Journal of Natural Gas Science and Engineering,2022,98:104378. [12] HOU B.Time-dependent recovery factors in nitrogen gravity drainage:the role of non-equilibrium phase transitions[J].Energy Reports,2023,9:312-325. [13] 程洪.不同成因岩溶储集体氮气辅助重力驱实验[J].新疆石油地质,2023,44(5):613-617.CHENG Hong.Experimental study on nitrogen-assisted gravity drainage in karst reservoirs of different genesis[J].Xinjiang Petroleum Geology,2023,44(5):613-617. [14] 张慧,鞠斌山,刘中春,等.缝洞型油藏氮气辅助重力驱可行性分析[J].断块油气田,2022,29(3):399-403.ZHANG Hui,JU Binshan,LIU Zhongchun,et al.Feasibility study on nitrogen-assisted gravity drainage in fractured-vuggy reservoirs[J].Fault-Block Oil & Gas Field,2022,29(3):399-403. [15] 李梦.缝洞型油藏氮气辅助重力驱机理实验研究[D].北京:中国石油大学(北京),2019. LI Meng.Experimental study on mechanism of nitrogen-assisted gravity flooding in fractured-vuggy carbonate reservoirs[D].Beijing:China University of Petroleum (Beijing),2019. [16] 王敬,姬泽敏,刘慧卿,等.裂缝—孔洞型储集层注氮气辅助重力泄油实验[J].石油勘探与开发,2019,46(2):342-353.WANG Jing,JI Zemin,LIU Huiqing,et al.Experiments on nitrogen assisted gravity drainage in fractured-vuggy reservoirs[J].Petroleum Exploration and Development,2019,46(2):342-353. [17] 黄梦梅.裂缝性油藏氮气泡沫辅助重力驱油实验研究[D].青岛:中国石油大学(华东),2018. HUANG Mengmei.Experimental study on nitrogen foam assisted gravity flooding in fractured reservoirs[D].Qingdao:China University of Petroleum (East China),2018. [18] 王传飞,吴光焕,韦涛,等.薄层特超稠油油藏氮气与降粘剂联合蒸汽辅助重力泄油物理模拟实验[J].油气地质与采收率,2017,24(1):80-85.WANG Chuanfei,WU Guanghuan,WEI Tao,et al.Physical simulation experiment of nitrogen gas and dissolve solvent aided SAGD for thin formation and extra-super heavy oil reservoir[J].Petroleum Geology and Recovery Efficiency,2017,24(1):80-85. [19] 杨阳,张东晓,王昊,等.准噶尔盆地永进油田原油中沥青质固相析出影响机理研究[J].石油实验地质,2025,47(4):930-940.YANG Yang,ZHANG Dongxiao,WANG Hao,et al.Influencing mechanisms of solid-phase asphaltene precipitation in crude oil of Yongjin Oil Field,Junggar Basin[J].Petroleum Geology & Experiment,2025,47(4):930-940. [20] 杨兆中,郑南鑫,朱静怡,等.纳米颗粒强化泡沫压裂液的构建及其稳泡机理研究[J].油气藏评价与开发,2023,13(2):260-268.YANG Zhaozhong,ZHENG Nanxin,ZHU Jingyi,et al.Preparation of nanoparticle-stabilized foam fracturing fluid and its foam stabilization mechanism[J].Petroleum Reservoir Evaluation and Development,2023,13(2):260-268. [21] 樊晓伊,周继龙,周永强,等.高矿化度油藏“强化泡沫+凝胶”调驱实验研究[J].西南石油大学学报(自然科学版),2024,46(4):159-168. FAN Xiaoyi,ZHOU Jilong,ZHOU Yongqiang,et al.An Experimental of “Enhanced Foam+Gel” Flooding in High Salinity Reservoirs[J].Journal of Southwest Petroleum University (Science & Technology Edition),2024,46(4):159-168. [22] ALMOBARAK M,MYERS M B,WOOD C D,et al.Chemical-assisted MMP reduction on methane-oil systems:implications for natural gas injection to enhanced oil recovery[J]Petroleum,2024,10(1):101-108. [23] 刘小杰,黄帅帅,美合日阿依·穆泰力普,等.CO2与混合烷烃最小混相压力的界面张力法实验研究[J].石油与天然气化工,2020,49(3):87-92.LIU Xiaojie,HUANG Shuaishuai,MUTAILIPU M,et al.Experiments on the minimum mixing pressure of CO2 and mixed alkane by using the interfacial tension regression method[J].Chemical Engineering of Oil & Gas,2020,49(3):87-92. [24] ZHANG Kaiqiang,JIA Na,ZENG Fanhua,et al.A review of experimental methods for determining the oil gas minimum miscibility pressures[J].Journal of Petroleum Science and Engineering,2019,183:106366. [25] SAFAEI A,KAZEMZADEH Y,RIAZI M.Mini review of miscible condition evaluation and experimental methods of gas miscible injection in conventional and fractured reservoirs[J].Energy & Fuels,2021,35(9):7340-7363. [26] OYINLOYE O,DARMAKI N A,ZAROONI M A,et al.Estimation of minimum miscibility pressure for flue gas injection using soft experimentations[J].Natural Resources, 2021. [27] WANG Jing,JI Zemin,LIU Huiqing,et al.Experiments on nitrogen assisted gravity drainage in fractured-vuggy reservoirs[J].Petroleum Exploration and Development,2019,46(2):355-366. [28] 马勇新,张乔良,朱金起,等.考虑微观特征的低渗油藏注气能力研究[J].石油实验地质,2025,47(4):913-920.MA Yongxin,ZHANG Qiaoliang,ZHU Jinqi,et al.Gas injection capacity of low permeability reservoirs considering microscopic characteristics[J].Petroleum Geology & Experiment,2025,47(4):913-920. [29] HAMIDI H,MOGHADASI J,RAHIMI S.Experimental investigation of minimum miscibility pressure for CO2 injection in a heavy oil reservoir using the slim tube apparatus[J].Journal of Petroleum Exploration and Production Technology,2020,10(3):1419-1429. -
