PRELIMINARY EXPERIMENTAL STUDY ABOUT EFFECT OF DEFORMATION ON ORGANIC MATURITY
-
摘要: 对3种不同煤级的煤样进行了高温高压变形实验。实验样品的镜质体反射率的变化与应变量之间显示出正相关关系,表明了变形可以促进有机质成熟度的提高。但是与时间和温度因素相比变形只是一个辅助因素,仅是变形不能改变有机质的成熟度。在本项实验中围压对有机质成熟度起到阻碍作用。虽然目前从实验角度区分应力和变形两者分别的作用尚有困难,但变形看来是更为关键的因素。共轴变形促进煤化作用的机理可能是与变形有利于煤化反应平衡方程向正向发展有关。Abstract: Three kinds of coal samples were coaxially deformed with Griggs-type rock experiment apparatus under high temperature and confining pressure. The vitrinie reflectance of original samples is 4.90% (coal sample L), 3.41% (coal sample X) and 0.67% (coal sample J) respectively. Phyrophyllite was used as confining pressure medium. Strain rates were kept constant during each experiment. The temperature condition is 350～700℃ and the confining pressure range is 400～600MPa. The shape of samples is column with 19mm in diameter and 40mm in length. Samples were kept open to outside during experiment so that produced gas can be vented out continually. In this paper some questions about effects of structural deformation on organic maturity are discussed by analysis to the changes of vitrinite reflectance in the samples which are of different strain and stress but of same temperature and confining pressure and near deformation time. It is indicated that increase of vitrinite reflectance is of positive relationship to stain. This result is similar to that of Mastalerzs (1993) study (although there are some differences in sample and condition of apparatus between these two studies) and further proved that structural deformation can promote the level of organic maturity. Deformation, as compared with time and temperature, is a subsidiary factor to organic maturity. Deformation alone can not cause the increase of organic maturity. Although the effects of hydrostatic pressure are more complicated, it appears to impede the increase of organic maturity in this experimental study. Strain seems to be more important than stress although it is still hard to respectively distinguish their effects on organic maturity by experiment. Although mechanisms of coaxial deformation promoting coalification are not clear yet, flattening of existing pores and mechanical rotation of aromatic lamellae are not likely to be the principal mechanisms. The possible origin may be that coaxial deformation promotes balance reaction equation of coalification to its positive direction.
-
Key words:
- deformation experiment /
- organic maturity /
- coalification
-
[1] Levine J R, Davis A.Reflectance anisotropy of Upper Carboniferous coals in the Appalachian foreland basin, Pennsylvannia, U.S.A.[J].International Journal of Coal Geology, 1989, 13: 340～373. [2] 邓云山,孟自芳.构造动力在油气形成中的作用[J].地球科学进展, 1996, 11(4): 362～366. [3] Bustin R M, Ross J V, Mofffat I.Vitrinite anisotropy under differential stress and high confining pressure and temperature: preliminary observations[J].International Journal of Coal Geology, 1986, 6: 343～351. [4] Ross J V, Bustin R M, Rouzaud J N.Graphitization of high rank coals——the role of shear strain: experimental considerations[J].Org.Geochem., 1991, 17(5):585～596. [5] Ross J V, Bustin R M.Vitrinite anisotropy resulting from simple shear experiments at high temperature and high confining pressure[J].International Journal of Coal Geology, 1997, 33(2): 153-168. [6] Wilks K R, Mastalerz M, Bustin R M, Ross J V.The role of shear strain in the graphitization of a high-volatile bituminous and an anthracitic coal[J].International Journal of Coal Geology, 1993, 22: 247～277. [7] Wilks K R, Mastalerz M, Ross J V, Bustin R M.The effect of experimental deformation on the graphitization of Pennsylvania anthracite[J].International Journal of Coal Geology, 1993, 24: 347～369. [8] Mastalerz M, Wilks K R, Bustin R M, Ross J V.The effect of temperature, pressure and strain on carbonization in high-volatile bituminous and anthracitic coals[J].International Journal of Coal Geology, 1993, 20: 315～325. [9] 周建勋, 邵震杰, 王桂梁.煤光性组构的实验变形研究[J].科学通报, 1993, 38(2): 147～150. [10] 周建勋, 王桂梁, 邵震杰.煤的高温高压变形实验研究[J].煤炭学报, 1993, 19(3): 324～332. [11] Bustin R M, Ross J V, Rouzaud J N.Mechanisms of graphite formation from kerogen: experimental evidence[J].International Journal of Coal Geology, 1995, 28: 1～36. [12] Goodarzi F.Optical properties of vitrinite carbonized at different pressures[J].Fuel, 1985, 64: 156～161. -
