FRACTURES OF THE ORDOVICIAN LIMESTONE AND THEIR RELATIONSHIP WITH HYDROCARBON ACCUMULATION IN THE SANGTAMU FAULT BELT OF THE TARIM BASIN
-
摘要: 塔里木盆地塔北隆起桑塔木断垒带奥陶系碳酸盐岩储层油气资源丰富,裂缝在油气藏的形成中起很重要的作用。通过大量的岩心观察和统计,发现取心段平均裂缝密度为3.3条/m,以小的半充填的斜交缝为主;裂缝主要发育2个带,第1条发育带位于不整合面之下,厚20～50m;第2条裂缝带与第1条相距约100m。通过分析化验资料的观察和分析,认为主要发育2期构造裂缝;综合分析测井、试油和构造等多方面的研究成果,认为裂缝的发育程度主要受断裂、不整合面和岩性等因素控制。裂缝发育程度与油气关系密切,裂缝发育区域油气高产的可能性大。裂缝发育于油气大规模运聚之前,为油气成藏提供通道。同时定量分析了裂缝对储层的贡献,认为其为储层提供一定的储集空间和绝大部分渗透率。Abstract: Sangtamu fault belt was located at Tabei uplift in Tarim basin. A lot of oil and gas resource was discovered in the Ordovician limestone of buried hill. Reservoirs are pore-fracture type. Many fractures were developed in the reservoirs. Average fractures density in cored inteval is 3.3 strap per meter. The fractures are characterized by small, oblique and half-filled ones. Two belt of fractures were vertically developed with the first one located under uncomformity surface. Its thickness is 20～50m. The second one is located below 100m of the first belt. Its thickness is 50～80m. In different position of fault belt, development level of fractures is different, and fracture is more developed inside the fault belt than the outside. Unconformity surface and lithology infleunced the vertical distribution of fractures. There is close relationship between hydrocarbon accumulation and fractures. The location with little fractures is poor for oil and gas production. Fractures are principal contributor of permeability and porosity of ressrvoirs. They supplied for 99.4% of total permeability and 12% of total porosity.
-
[1] Peter H Hennings, Jan E Olson, Lard B Thompson. Combine outcrop data and three dimensional structural model to characte-rize fractured reservoir: an example from Wyoming[J]. AAPG, 2000, 84(6):830～849 [2] 樊生利,童崇光.四川二叠系碳酸盐岩裂缝系统成因模式探讨[J].石油实验地质.1995,17(4):343～347 [3] 岳建华,康志宏,韩燕英.新疆塔里木盆地艾协克-桑塔木油气区圈闭类型及空间组合规律[J].石油实验地质,1999,21(4):16～19 [4] 魏国齐,贾承造,宋蕙珍等.塔里木盆地塔中地区奥陶系构造-沉积模式与碳酸盐岩裂缝储层预测[J].沉积学报,2000,18(3):408～413 [5] 杨威,王清华,赵仁德等.和田河气田奥陶系碳酸盐岩裂缝[J].石油与天然气地质,2000,21(3):252～255 [6] 杨威,王清华,刘效曾等.岩心裂缝分维数的计算及与储层物性的关系[J]. 石油勘探与开发,2001,20(3):46～48 [7] Wang Genjiu, Yu Gaoyi, Yang Rongjin, et al. Carbo-nate reservoir model of Tahe oilfield[J]. Petroleum Science,2001, 4(3):35～59 [8] 贾承造,魏国齐,姚慧群等.盆地构造演化与区域构造地质[M].北京:石油工业出版社,1995.105～128 [9] 单业华,葛维萍.储层天然裂缝形成机制的初步研究——以静北潜山油藏为例[J]. 石油实验地质,2001,23(4):457～466 [10] 张敬轩,金强.山东莱芜地区太古界露头裂缝特征及油气储层意义[J]. 石油实验地质,2003,25(4):371～374 [11] 谭廷栋.裂缝性油气藏测井解释模型与评价方法[M].北京:石油工业出版社,1987.1～22 -
